4G ID Card
User Guide

2
UniGuard Technology Limited
1. Features
⚫Real-time tracking by APP/Platform
⚫History Playback and Historical location report
⚫Geo-fence alarm
⚫Call to 3 family numbers
⚫SOS alert number, call and location SMS report
⚫Current time check
⚫Current battery status check
⚫Voice monitoring
⚫Two way voice speaking
⚫1000mAh rechargeable battery
2. Specs.
Item
Details
Dimension
100*60*8 mm
Weight
58g
Material
Anti-fire ABS
Button
5 buttons (Call 1 Call2 Call 3, SOS, Switch)
Wearing
Rope
Network
4G + 2G
GSM Module
SIMCOM LTE A7680C
GPS Chip
AT6558R
OTA
YES
Positioning
GPS+Beidou+WIFI+LBS+AGPS
Battery
Rechargeable battery 1000mAh
Charge time
About 3hrs
Standby
5 days
Charging port
USB
Microphone
Built-in
Speaker
Built-in

3
UniGuard Technology Limited
3. Install SIM Card
Prepare a micro SIM card with Call, SMS and network activated. Insert 4G
SIM card with activated GPRS data; Make sure SIM card with full balance; If
SIM card with PIN code, must remove it advance.
4. Device light description
Light
Signal
Flashing
ON
OFF
Red
Power
Charging
Fully charged
Blue
GPS
GPS located
GPS unlocated
Yellow
GSM/GPRS
GPRS connected
GPRS failed
5. Device button description
Button
Description
Call1
Call: press 3 seconds to call the first number, and broadcast:
”Calling family number 1“
Message: when there is new message, single click to broadcast message
Time check: double click to broadcast the current time:
“Nine Forty, Wednesday”
Call2
Call: press 3 seconds to call the second number, and broadcast:
“Calling family number 2”
Network check: double click to broadcast the connection status:
“Connect platform successfully”
Call3
Call: press 3 seconds to call the third number, and broadcast:
“Calling family number 3”
Battery check: double click to broadcast battery status:
“Battery level 65%”
Switch
Press 3 seconds to switch on device
Press 6 seconds to switch off device
SOS
Call: press 6 seconds to call SOS number periodically 3 times. If not answered, call the family
number. (When SOS alert is triggered, device first send SMS link to report location first.)
If number is not set, broadcast: ”Number not setup”

4
UniGuard Technology Limited
6. Command List
Note: All Alarms only will be sent to admin Number Only
Command
Function
admin123456 15012404563
Set admin number
noadmin123456 15012404563
Remove admin number
password123456 888888
Change password
apn123456 APN APNname APNpassword
Set APN
adminip123456 www.gpspos.net 8800
Set IP Port
smslink123456
google link
fix020s060m***n123456
Set upload interval, moving at 20s, stopping at 60mins
monitor123456 15012404563
Device call back to start voice monitoring
lowbattery123456 on
Turn on low battery alert (below 20%)
lowbattery123456 off
Turn off low battery alert
IPAPN123456
IP APN Checking
IMEI123456
Check device IMEI and ICCD
check123456
Check device status
reset123456
Restart device.
ver123456
Check device version
LBS123456 1
Turn on LBS position mode (Default)
LBS123456 0
Turn off LBS position mode
mod123456 0
Power saving mode
mod123456 1
Smart working mode
mod123456 300
GPS Tracking mode, minimum interval is 300 seconds
Familynumber123456 Tel1 Tel2 Tel3
Setup call1 call2 call 3 phone number
whitenum123456 13512341234
Set white number list. After setting up, only white list and
family number can call device.
ckauthnum123456
Check admin and family number
almclock123456 08:00 1111111
Set alarm clock. (here alarms at 8 am)
7. Web platform GPS tracking software
Website: www.gpspos.net
Default IMEI as user name, password 123456.
Searching APP name: GPSPOS at Appstore, POSGPS at Googleplay
