Unitech PA768 User manual

PA768 Single Slot Cradle
Quick Start Guide
V1.1
Package
How to Remove the Detachable Cover
How to Use PA768 Single Slot Cradle
Please make sure the following contents are in the
PA768 single slot cradle gift box.
If something is missing or damaged, please contact
your Unitech representative.
The Package Contents
Optional Accessories
•PA768 Single Slot Cradle
•Detachable cover for PA768 without bumper
•5V/6A <3-pin> power supply
There are two options to charge PA768 terminal:
1. Charge PA768 with bumper, hand strap or
gun grip.
2. Charge PA768 without bumper after installing
the detachable cover.
Grab the two edges on top of the detachable
cover and bent inward, then hold and pull up
the cover to remove it.
How to Install the Detachable Part
Insert the detachable cover into the cradle until you
hear a click sound.
•3-Pin Power Cord (UK) (PN#1550-602689G)
•Power Cord (EU) (PN#1550-602333G)
•Power Cord(US) (PN#1010-601551G)
To ensure the unit working properly, please keep all connectors away
from the contaminants such as dust, grease, mud, and water.
Negligence may cause the unit to lose communication, short circuit, or
overheated. If the connector is damaged, please ensure the connector
is fully repaired before using the unit to avoid short circuiting.
WARNING!
There is a risk of fire and burns if the battery is handled improperly.
DO NOT disassemble, crush, puncture, short external contacts,
or dispose the battery pack in fire or water.
DO NOT attempt to open or service the battery.
Dispose used batteries according to local recycling guidelines in your area.
CAUTION!

LED Indicator Status
PA768 single slot Charging/USB cradle Comparison
Product View
PA768 Single Slot Cradle
PA768 Single Slot
Charging Cradle
(5000-900105G)
PA768 Single Slot
USB/Ethernet Cradle
(5000-900106G)
(5000-900107G)
LED
LED Status Description
Blue LED Power On/Battery fully charged
Red LED Battery charging
Cradle LED
PA768 LED
LED Status Description
Blue LED Power On/Battery fully charged
Red LED Battery charging
Note: When PA768 is inserted in the cradle, the LED
indicator on the cradle will not be changed.
The charging status is indicated by the LED on PA768.
Remove the BatteryInstall the Battery
1. Press and hold the two buckles on both side of
the battery, align the battery with the battery
compartment and insert from around 45 degree
angle.
2. Press down the battery while holding the buckles,
then release after the battery is completely insert
into the battery compartment.
Make sure the battery stays flat, and there is no gap
between the battery and the battery compartment.
1. Press and hold the two buckles on both side
of the battery and push against the front.
2. Lift the battery while holding the buckles
to remove.

PA768 single slot Charging/USB cradle Comparison
P/N Models Description Rear View
5000-900105G PA768 1-Slot Charging Cradle with
spare battery slot
with power supply (5V/6A)
Charging terminal via DC jack
5000-900106G PA768 1-Slot USB Cradle
with spare battery slot
with power supply (5V/6A)
Charging terminal via DC jack
Data transfer by USB Type-C
between terminal and PC
5000-900107G PA768 1-Slot Ethernet Cradle
with spare battery slot
with power supply (5V/6A)
Charging terminal via DC jack
Data transfer by Ethernet
(RJ45) or USB host (2.0)
Display Port via USB type C
(DP only)
Copyright 2022 unitech Electronics Co., Ltd. All rights reserved.
Unitech is a registered trademark of Unitech Electronics Co., Ltd.
http://www.ute.com/
