From the beginning the PT630D was designed to utilize a wide variety
of barcode scan engines. The PT630D works with many types of
Barcode readers currently available from the entire AIDC industry.
For more information, please address your enquiries to the appropriate
contact listed on the back of this brochure.
Main Features
Brutally Rugged Water splash resistant(IP54 rated)
Survives multiple 1.2M bounces off concrete
Operates from -5¡C to 50¡C (23¡F to 122¡F)
Ergonomic and Compact Weights only 230g (8.1oz)
User-friendly design
Flexible Supports a wide variety of barcode reader
Capable of multiple memory configurations
LCD display 128x64 pixel display supports up to 20x8(small font)
or 16x4(large font) characters
True one-hand operation Alphanumeric characters Built-in 27 key luminescent
Keypad
Powerful Li-ion battery capable of 12 hours of continuous operation.
PT630D
Rugged
Compact
The Unitech PT630D is a rugged and
compact Portable Data Terminal that is easily configured
with powerful built-in or off-the-shelf programming tools.
The PT630D is designed to meet and surpass business data collection
requirements in Supply Chain Management,
Field service,and many other application.
Its versatile design satisfies the most crucial business demands
for pick up and delivery, meter reading, retail inventory control,
and warehouse management, to name just a few.
The featherweight PT630D(only 230g/8.1oz)is both rugged
and exceptionally user-friendly.
Capable of withstanding 1.2 meter multiple bounces
off concrete, the PT630D also shrugs off water splashes
and is IEC 60529 compliant to IP54.
Programmable with built-in or readily available
programming tools, the PT630D can also utilize JobGen Plus-a powerful
Windows-based application generator available from Unitech.
Its intuitive drag-and-drop, point-and-click style of programming
requires little or no programming experience. JobGen Plus ensures that
any system can integrate quickly and easily with the PT630D.

Communication
Interface One RS232 communication port
Supports TX/RX, CTS /RTS , GND, 150K - 57.6K bps
Handshaking Xon/Xoff or CTS/RTS
Protocol None, or Multi-point for multi-drop installation
File Transfer Built-in Kermit server
Software Programming Tools
C Language MSC, Borland C, Turbo C
JobGen Plus A Windows-based program generator
FormCaching A built-in program generator
DLL Liberary Available for 16/32-bit C++, VB, VFP and Delphi
Docking Station Optional
Models ¥ PT063D-1 One RS232 port for point-to-point communication
¥ PT063D-3 Optional modem interface to telephone line
¥ PT063D-4 Ethernet Connectivity (TCP Client)
Battery Charging Quick charging typical 2~3 hours
Power Input AC/DC adapter @ 9VDC/2A
Physical And Environmental
IP Rating 54
DROP TEST 1.2 meters to floor
Dimensions 165 mm (L) x60 mm (W) x 35mm (H)
Weight approx. 230g with battery pack
Temperature Operation: -5ûC to 50ûC
Storage: -20ûC to 70ûC
Humidity 5% to 95% RH non-condensing
Regulatory CE, FCC
Specifications
PT630D
Memory / Operating System
CPU 16-bit 80188 compatible microprocessor
RAM 512K / 2.5MB / 4.5MB
FlashROM 256K with DOS-based system
Keyboard 26 alphanumeric keys + one scan trigger
with phosphorescent material
Display 128 x 64 pixel; 20 x 8 small font
or 16 x 4 lagre font (characters)
Buzzer Volume adjustable by software
Real Time Clock System date and time
Power Management
Main battery One rechargeable Lithium-ion battery pack
@3.6V, 880 mAH
Backup battery One lithium battery CR2032 for
SRAM memory backup
Li-ion recharging 2.5 hours in Docking Station or
through charging Cable.
Operating time Over 12 hours
Scanner And Barcode
Scanner Supports Laser scanner, CCD Scan Engine
Symbology UPC-A/E , EAN-8/13, Codabar, Code 39,
Code 39 full ASCII, Code 128, ITF,
China Postal Code, Interleave 2 of 5,EAN 128
01 / 08 REV. C
Specifications subject to change without notice. Copyright 2008 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
All product and company names are trademarks, service marks, or registered trademarks of their respective owners.
