Unitech TB162 User manual

February 21, 2023
TB162
Accessory
US power cord in package (No EU power cord, no UK power cord).
TB162 included power cord with US plug only and EU customers need to pay for
additional power cord with EU or UK plug due to the vendor does not want to do it
unless we can commit to MOQ.
Does TB162 has a power adapter with a cigarette lighter plug?
1010-900056G TB162 Car charge power adapter.Data sheet link:
http://w3.tw.ute.com/pub/cs\product\TB162\OS9-NB31005_NLE-2003C20V72-TH02.pdf
Is there SDK for barcode scanner?
There is no SDK due to Honeywell N3680 is hardware decode.Data sheet link:
http://w3.tw.ute.com/pub/cs\product\TB162\N36XX-UG_Rev_D.zip
Document
Is there any user's manual for office docking and vehicle docking?
You can get user's manual from below URL
http://w3.tw.ute.com/pub/cs\product\TB162\NP03_v1.0_English_0522.pdf
Hardware
How many physical antenna ? Where are the antenna’s located ?
Five physical antenna inside there are GPS/LTE main & aux/wifi main &
aux,Please see below URL for antenna’s located
http://w3.tw.ute.com/pub/cs\product\TB162\TB162_antenna_location.PNG

February 21, 2023
What is behind all the covers at the back?
Please see below URL for details
http://w3.tw.ute.com/pub/cs\product\TB162\TB162_Back.PNG
There is no indication LED for battery charging.
Yes,there is no indication LED for battery charging.
Seems TB162 support some kind of hot swap,It is unclear how it
operarting and for how long.If you remove battery and put back in
certain time, the TB162 resume back to where it was.
Yes. When the backup battery is fully charged (Tablet power on >1.5H), it can
support to swap main battery within 60 seconds, this 60 seconds duration may be
different depends on system loading and the health of backup battery.
How long the batteries operating lifetime of using Prime95( 64 bits )
to test?
1. 200 minutes when contrast is at 75%
2. 235 minutes when contrast is at 25%
How long the batteries operating lifetime of using JEITA ver.2.0 to
test?
1. Media Operating time: 06:34:51(PQT team test)
2. Idle Operating time: 10:30:16(PQT team test)
3. Average Operating time: 08:32:33(PQT team test)

February 21, 2023
Does TB162 and cradle support wake up on LAN / Wi-Fi function?
TB162 cannot support wake up on LAN function.
TB162 does not support wake up on Wi-Fi function.
Cradle does not support wake up on LAN and wake up on Wi-Fi function both.
Does the TB162 support an active stylus?
TB162's Touch panel does not support an active stylus(Not support digitizer stylus)
and only supports a passive stylus.
Does the TB162's USB port adapt PD(Power Delivery) and Quick
Charge function?
The TB162's USB ports don't support Power Delivery & Quick Charge function.
How long does it take to charge the TB162 battery?
Power adaptor directly: 7H:46M:11S / Via cradle: 7H:46M:25S
How much the maximum capacity of both eMMC and Micro SDXC
Card Reader?
The maximum capacity of both eMMC and Micro SDXC Card Reader is 128GB.
How long does the 5100-900024G(TB162 - 4 Bay- Battery Charger)
take to charge the battery?
Full charge in 4.5 hours.

February 21, 2023
TB162 scanner setting question?
1. Do we need to scan the barcode from the manual to set the language?
→Yes
2. Will the setting remain when TB162 is suspended?
→Yes
3. Will the setting remain when the battery remove/insert?
→Yes
4. Will the setting be set to default when the factory resets the TB162?
→No. Please use the reset to default barcode in UG to reset the barcode to
default Reset the Custom Defaults.If you want the custom default settings
restored to your scan engine, scan the Activate Custom Defaults bar code below.
This is the recommended default bar code for most users. It resets the scan
engine to the custom default settings. If there are no custom defaults, it will reset
the scan engine to the factory default settings. Any settings that have not been
specified through the custom defaults will be defaulted to the factory default
settings.
Note: To remove custom defaults, see "Resetting the Factory Defaults" on page
8-162.
Can TB160 support glove ?
1. Can support gloves thickness of less than 1mm
2. Suggest to use 8mm capacitive stylus (384896G)

February 21, 2023
ME
Is it correct the IP grade is compromised when connector flaps are
open?
Yes. IP65 only can be guaranteed when all flaps and access doors are well
closed.
What is the purpose of the inserts?Is it Metric?What is the max.
length?
1.Right and left screw hole is for easel and V shape screw hole for VESA MOUNT
Screw holes distribution:
http://w3.tw.ute.com/pub/cs\product\TB162\TB162_Screw_holes_distribution.PNG
VESA mount guide:
https://www.ergotron.com/zh-hk/support/vesa-standard
2.Metric
3.The length of screw is depend on what accessory is installed. Different
accessory has different thickness therefore the length of screw will be different.
Please tell us the dimension of TB162 cradle(5000-900068G)?
Dimension: 200.1x142.6x77.5mm
Datasheet link:
http://w3.tw.ute.com/pub/cs\product\TB162\MS-NP03-Docking-SPEC_v1.1_200716.pdf
How does the TB162's vehicle cradle mount to the vehicle?
Please see the below link for details:
http://w3.tw.ute.com/pub/cs\product\TB162\TB162_vehicle_cradle_mount.pdf

February 21, 2023
OS
How to know the O.S version of TB162?
Settings→System→About→Windows specifications
How to reset TB162?
Press F3→Troubleshoot→Reset this PC→Remove everything→Just remove my
files→Reset
How to Turn Off Windows Update from other PCs?
Settings→Update & Security→Advanced options→Delivery Optimization→
allow downloads from other PCs→Turn Off.
Details:
http://w3.tw.ute.com/pub/cs\product\TB162\TB162_Turn_Off_Windows_Update_from_other_PCs.pdf
How to Turn Off Automatic Windows Updates on Windows 10
http://w3.tw.ute.com/pub/cs\product\TB162\TB162_Turn_Off_Windows_Update_Service.pdf
How to Avoid Screen Flickering?
Settings→Personalization→Colors→Transparency effects→Turn Off.
Details:
http://w3.tw.ute.com/pub/cs\product\TB162\TB162_Avoid_Screen_Flickering.pdf

February 21, 2023
Is there reason the Camera app is not embedded in the O.S ?
Due to TB162 is using window 10 LTSC version, so a Windows 10 LTSC does not
contain Microsoft Edge, Microsoft Store, such as Camera, Cortana, OneNote, and
other modern apps that continue to advance with innovative improvements.
Please check below link for LTSC VS SAC details:
https://techcommunity.microsoft.com/t5/windows-it-pro-blog/ltsc-what-is-it-and-when-should-it-be-used/ba-p/293181#
Face recognition / login does not operate.
TB162 doesn't support face recognition and face login.
There is green LED at the front next to Front Camera,It is unclear
what is the purpose When Tb162-screen is on the green LED is
also on but is sometimes also on when TB162-screen is off.
It is power on indicator. Power on / Sleep / Suspend : LED on; Power off (S5) :
LED off.
When TB162 is automatically powered off and power on, you need
to tap 2 times in login prompt before SIP appears.
It is the slow response of Win10.

February 21, 2023
It seems when the TB162 is automatically powered off and then
press the power key, the TB162 is rebooting rather then coming
from suspend. Is this correct?
Yes. Auto power off will act like manually power off.
How to Restore Hard Disk Image on TB162 G1 version?
Please follow the SOP to restore the O.S and download the O.S from the below
link:
Restore O.S instruction:
http://download1.tw.ute.com/cs/firmware/TB162/TB162_G1_HDI_SOP_20200422.pdf
Restore O.S file: ZS7-ND51RM4-WC2-8.0.E1.1.0.1.wim
http://download1.tw.ute.com/cs/firmware/TB162/ZS7-ND51RM4-WC2-8.0.E1.1.0.1.wim
Restore O.S tool: WINPE_X64_for Win10 RS5_20190723.rar
http://download1.tw.ute.com/cs/firmware/TB162/WINPE_X64_for Win10 RS5_20190723.rar
How to Restore Hard Disk Image on TB162 G2 version?
Please follow the SOP to restore the O.S and download the O.S from the below
link:
Restore O.S instruction:
http://download1.tw.ute.com/cs/firmware/TB162/TB162_G2_HDI_SOP_20210927.pdf
Restore O.S file: ZS7-ND54RM4-WC2-8.1.E1.1.0.1.wim
http://download1.tw.ute.com/cs\firmware\TB162\ZS7-ND54RM4-WC2-8.1.E1.1.0.1.wim
Restore O.S tool: WINPE_X64_for Win10 RS5_20190723.rar
http://download1.tw.ute.com/cs/firmware/TB162/WINPE_X64_for Win10 RS5_20190723.rar

February 21, 2023
So tware
Is there have any tools can testing for camera & NFC function?
For camera function link:
http://w3.tw.ute.com/pub/cs\product\TB162\CAMERARECORDER.RAR
For NFC function link:
http://w3.tw.ute.com/pub/cs\product\TB162\RFID_NFC.zip
How to set up the scanner to continuously read?
Please refer to the below link they are including:
https://a2401.s3.amazonaws.com/cs/firmware/TB162/TB162_scanner_continuously_read.zip
1. User's Manual N4680-EN-UG Rev C.
2. Instructions on how to set up the scanner to continuously read.
3. Demo video: TB162's Scanner in presentation mode
