Samba™ OPLC™ OPLC Installation Guide
SM43-J-R20/SM35-J-R20
12 Digital Inp
uts, include
1 HSC/Shaft
-
encoder Input
,
2 Analog inputs (only when the digital inputs are set to pnp),
8 Relay Outputs
SM43-J-T20/ SM35-J-T20 12 Digital Inputs, include 3 HSC/Shaft-encoder Input,
2 Analog inputs, 8 Transistor Outputs
General Description
The SAMBA SM43-J-R20/SM43-J-T20 OPLC is an All-in-One Programmable Logic Controller that
Comprises a built-in 4.3" Color Touchscreen.
The SAMBA SM35-J-R20/SM35-J-T20 OPLC is an All-in-One Programmable Logic Controller that
Comprises a built-in 3.5" Color Touchscreen.
Communications
For SM43: USB device programming port (Mini-B)
For SM35: 1 build-in serial port:RS232
Optional: the user may install -
RS232/RS485 port (V100-17-RS4/V100-17-RS4X) or Ethernet (V100-17-ET2)
& CANbus (V100-17-CAN)
Standard
K
it Contents
Samba controller Mounting brackets (x2)
I/O connectors (x2) Rubber seal
Battery (installed)
Alert Symbols and General Restrictions
When any of the following symbols appear, read the associated information carefully.
Symbol Meaning Description
Danger The identified danger causes physical and property damage.
Warning The identified danger could cause physical and property damage.
Caution Caution Use caution.
Before using this product, the user must read and understand this document.
All examples and diagrams are intended to aid understanding, and do not guarantee operation.
Unitronics accepts no responsibility for actual use of this product based on these examples.
Please dispose of this product according to local and national standards and regulations.
Only qualified service personnel should open this device or carry out repairs.
Failure to comply with appropriate safety guidelines can cause severe injury or property damage.
Do not attempt to use this device with parameters that exceed permissible levels.
To avoid damaging the system, do not connect/disconnect the device when power is on.
Environmental Considerations
Do not install in areas with: excessive or conductive dust, corrosive or flammable gas,
moisture or rain, excessive heat, regular impact shocks or excessive vibration, in
accordance with the standards given in the product’s technical specification sheet.
Do not place in water or let water leak onto the unit.
Do not allow debris to fall inside the unit during installation.
Ventilation: 10mm space required between controller’s top/bottom edges & enclosure walls.
Install at maximum distance from high-voltage cables and power equipment.
Чтобы подобрать подходящую модель, уточнить стоимость исрок поставки обращайтесь кнашим
специалистам по электронной почте [email protected] или по телефонам [phone] [phone],
8-800-511-65-88 (Бесплатно по России)

Samba™ OPLC™ Installation Guide
2 Unitronics
Mounting
Dimensions
SM43
-
J
-
R20/SM43
-
J
-
T20
SM35-J-R20/SM35-J-T20

Samba™ OPLC™
Unitronics 3
Panel Mounting SM43-J-R20/SM43-J-T20
Before you begin, note that the mounting panel cannot be more than 5 mm thick.
1. Make a panel cut-out measuring
122.5x91.5 mm (4.82”x3.6”).
2.Slide the controller into the cut-
out, ensuring that the rubber seal
is in place.
3.Push the mounting brackets into
their slots on the sides of the
panel as shown in the figure to the
right.
4.Tighten the bracket’s screws
against the panel. Hold the
bracket securely against the unit
while tightening the screw.
5.When properly mounted, the
controller is squarely situated in
the panel cut-out as shown in the
figure to the right.
Note: For UL listed module, in order to meet the UL508 standard,
panel-mount this device on the flat surface of a Type 1 enclosure.

Samba™ OPLC™ Installation Guide
4 Unitronics
Panel Mounting SM35-J-R20/SM35-J-T20
Before you begin, note that the mounting panel cannot be more than 5 mm thick.
1. Make a panel cut-out measuring
92x92 mm (3.622”x3.622”).
2. Slide the controller into the cut-
out, ensuring that the rubber seal
is in place.
3. Push the mounting brackets into
their slots on the sides of the
panel as shown in the figure to
the right.
4. Tighten the bracket’s screws
against the panel. Hold the
bracket securely against the unit
while tightening the screw.
5. When properly mounted, the
controller is squarely situated in
the panel cut-out as shown in the
figure to the right.
Note: For UL listed module, in order to meet the UL508 standard,
panel-mount this device on the flat surface of a Type 1 enclosure.
Wiring
Do not touch live wires.
Install an external circuit breaker. Guard against short-circuiting in external wiring.
Use appropriate circuit protection devices.
Unused pins should not be connected. Ignoring this directive may damage the device.
Double-check all wiring before turning on the power supply.
Caution
To avoid damaging the wire, do not exceed a maximum torque of 0.5 N·m (5 kgf·cm).
Do not use tin, solder, or any substance on stripped wire that might cause the wire
strand to break.
Install at maximum distance from high-voltage cables and power equipment.

Samba™ OPLC™
Unitronics 5
Wiring Procedure
Use crimp terminals for wiring; use 3.31 mm ² –0.13 mm² wire (12-16 AWG):
1.Strip the wire to a length of 7±0.5mm (0.270–0.300“).
2.Unscrew the terminal to its widest position before inserting a wire.
3.Insert the wire completely into the terminal to ensure a proper connection.
4.Tighten enough to keep the wire from pulling free.
Input or output cables should not be run through the same multi-core cable or share the same wire.
Allow for voltage drop and noise interference with I/O lines used over an extended distance.
Use wire that is properly sized for the load.
The controller and I/O signals must be connected to the same 0V signal.
I/Os
SM43-J-R20/SM35-J-R20 comprises a total of 12 inputs and 8 relays.
Input functionality can be adapted as follows:
1.12 inputs may be used as digital inputs. They may be wired in a group via a single jumper
as either npn or pnp.
According to jumper settings and appropriate wiring:
- Inputs 5 and 6 can function as either digital or analog inputs.
•If the digital inputs function as npn, analog option is not available.
- Input 0 can function as a high-speed counter, as part of a shaft-encoder, or as a normal
digital input.
- Input 1 can function as either a counter reset, normal digital input, or as part of a
shaft-encoder.
- If input 0 is set as a high-speed counter (without reset), input 1 can function
as a normal digital input.
SM43-J-T20/SM35-J-T20 comprises a total of 12 inputs and 8 transistor outputs.
Input functionality can be adapted as follows:
1.12 inputs may be used as digital inputs. They may be wired in a group via a single jumper
as either npn or pnp.
According to jumper settings and appropriate wiring:
- Inputs 10 and 11 can function as either digital or analog inputs.
- Inputs 0, 2, and 4 can function as high-speed counters, as part of a shaft-encoder,
or as normal digital inputs.
- Inputs 1, 3, and 5 can function as either counter reset, as part of a shaft-encoder,
or as normal digital inputs.
- If inputs 0, 2, 4 are set as high-speed counters (without reset), inputs 1, 3, 5 can function as
normal digital inputs.

Samba™ OPLC™ Installation Guide
6 Unitronics
Input and Output Jumper Settings
The tables below show how to set a specific jumper to change input functionality. To access the I/O
jumpers, you must open the controller according to the instructions below.
Incompatible jumper settings and wiring connections may seriously damage the controller.
SM43-J-R20/SM35-J-R20
Digital Inputs 0-11: Set Type
Set to JP12 (all Inputs)
npn (sink) A
pnp (source)* B
Input 5: Set Type - Digital or Analog #1
Set to JP4 JP10
Digital* A A
Voltage B A
Current B B
Input 6: Set Type - Digital or Analog #0
Set to JP8 JP9
Digital* A A
Voltage B A
Current B B
*Default settings
SM43
-
J
-
T
20
/SM35
-
J
-
T20
Do not move JP2.
Digital Inputs 0-11: Set Type
Set to JP1 (all Inputs)
npn (sink) A
pnp(source)* B
Inputs 10/11: Set as Digital or Analog
Set to JP5 (Input 10) JP6 (Input 11)
Digital* A A
Analog B B
Analog Inputs AN0/AN1: Set Type
Set to JP3 (AN0) JP4 (AN1)
Voltage* A A
Current B B
*Default settings

Samba™ OPLC™
Unitronics 7
Opening the Controller
Note: Photo is for illustration purposes only. (Using SM43)
Before performing these actions, touch a grounded object to discharge any electrostatic charge.
Avoid touching the PCB board directly. Hold the PCB board by its connectors.
1.Turn off the power supply, disconnects, and
dismounts the controller.
2.The back cover of the controller comprises
4 screws, located in the corners.
Remove the screws, and pull off the back cover.
Changing I/O Settings
1.The I/O board of the controller is now
exposed, enabling you to change
I/O settings according to the jumpers above.
Closing the Controller
1.Replace the back cover of the controller and fasten the corner screws.
Note that you must replace the back cover securely before powering up the controller.
I/O Wiring
npn Input Wiring
SM43-J-R20/SM35-J-R20 SM43-J-T20/SM35-J-T20
Input wiring, npn (sink)

Samba™ OPLC™ Installation Guide
8 Unitronics
HSC input wiring, npn (sink)
pnp Input Wiring
SM43-J-R20/SM35-J-R20 SM43-J-T20/SM35-J-T20
Input wiring, pnp (source)
HSC input wiring, pnp (source)

Samba™ OPLC™
Unitronics 9
Shaft-encoder
SM43-J-R20/SM35-J-R20 SM43-J-T20/SM35-J-T20
Analog Input W
iring
SM43-J-R20/SM35-J-R20 SM43-J-T20/SM35-J-T20
Analog input wiring, current (2/3 wire)
Analog input wiring, current/voltage (4-wire)
Shields should be connected at the signal’s source.
The 0V signal of the analog input must be connected to the controller’s 0V.

Samba™ OPLC™ Installation Guide
10 Unitronics
Relay Outputs Transistor Outputs
SM43-J-R20/SM35-J-R20 SM43-J-T20/SM35-J-T20
Increasing Contact Life Span
SM43-J-R20/SM35-J-R20- Only
To increase the life span of the
relay output contacts and protect
the device from potential damage
by reverse EMF, connect:
A clamping diode in parallel with
each inductive DC load
An RC snubber circuit in parallel with
each inductive AC load
Power Supply
The controller requires an external 24VDC power supply.
Note: Photo is for illustration purposes only.
1. The power supply must include double insulation. Outputs must be rated as
SELV/PELV/Class 2/Limited Power.
2. Use separate wires to connect the functional
earth line (pin 3) and the 0V line (pin 2) to the
system earth ground.
3. Install an external circuit breaker. Guard
against short-circuiting in external wiring.
4. Double-check all wiring before turning
on the power supply.
5. Do not connect either the ‘Neutral’ or ‘Line’
signal of the 110/220VAC to device’s 0V pin.
6. In the event of voltage fluctuations or non-
conformity to voltage power supply
specifications, connect the device to
a regulated power supply.

Samba™ OPLC™
Unitronics 11
Earthing the OPLC
To maximize system performance, avoid electromagnetic interference by:
Mounting the controller on a metal panel.
Connect each common and ground connection directly to the earth ground of your system.
For ground wiring use the shortest and thickest possible wire.
Communication Port
Turn off power before making communications connections.
Caution
Always use the appropriate port adapters.
SM43-J-R20/SM43-J-T20
This series comprises a USB port.
Caution
The USB port is not isolated. Make sure that the PC and the controller are grounded to
same potential.
The USB port may be used for programming, OS download, and PC access.
SM35-J-R20/SM35-J-T20
This series comprises a build-in RS232 port.
Caution
Signals are related to the controller’s 0V; the same 0V is used by the power supply.
The serial port is not isolated. If the controller is used with a non-isolated external device,
avoid potential voltage that exceeds ± 10V.
Use RS232 to download programs from a PC, and to communicate with serial devices and
applications, such as SCADA.
Pinouts
The pinouts below show the PLC port signals.
RS232
Pin # Description
1 Not connected
2 0V reference
3 TXD signal
4 RXD signal
5 0V reference
6 Not connected
Чтобы подобрать подходящую модель, уточнить
стоимость исрок поставки обращайтесь кнашим
специалистам по электронной почте [email protected] или
по телефонам [phone] [phone],
8-800-511-65-88 (Бесплатно по России)

Samba™ OPLC™ Installation Guide
Київ
тел. [phone]
[email protected]v.ua
Самара
тел. [phone]
[email protected]
Москва
тел. [phone]
mosco[email protected]
Екатеринбург
тел. [phone]
yekat[email protected]
Санкт-Петербург
тел. [phone]
[email protected]
Rīga
tel. [phone]
[email protected]
Helsinki
puh. [phone]
automation@klinkmann.
Tallinn
tel. [phone]
[email protected]
Vilnius
tel. [phone]
[email protected]
Минск
тел. [phone]
[email protected]
www.klinkmann.ru
sm35-j-r20_en_1215
