Universal Tool UT8726 User manual

UT8726
CUT-OFF TOOL
PLEASE READ AND FOLLOW ALL WARNINGS
PL-2088
Universal Tool Air Tools
ADivision of Universal Tool Manufacturing Corporation
851 Jupiter Park Lane, Jupiter, Florida 33458
[phone] • Fax [phone] • Toll Free 1-800-327-9403
Read these instructions carefully before attempting to install,
operate or service this Universal Tool product. Failure to
comply with the instructions could result in personal injury and/
or property damage! Retain these instructions for future
reference.
Safety Instructions
The following instructions are furnished
as general guidelines for use of your
pneumatic tool. They cannot compre-
hensively cover all possible or conceiv-
able uses of the subject tool. For
additional information on the safe use
of air tools, we advise you to obtain a
copy of ANSI B186.1 Safety Code for
Portable Air Tools, available from the
following source:
American National Standards
Institute, Inc.
11 West 42nd Street
New York, NY 10036.
The use of the word “shall” in the
following instructions, indicates that
adherence to the particular require-
ment is necessary to conform to ANSI
B186.1.
Tool Application and Usage
Portable tools shall be used only for
the purposes intended in their design
and within the capacity for which they
were intended and rated. It shall be
the tool owner’s and/or employer’s
responsibility to instruct each operator
in the safe use of the tool. Tools shall
not be used without guards and safety
devices as furnished by the manufac-
turer. Where an air tool is modified or
altered, the modifier shall provide the
safeguards to enable it to be safely used
in the operations intended and to comply
with any applicable provisions as
contained in ANSI B186.1.
Tool Installation
Pressure regulators shall be used to limit
air pressure to the rated pressure where
the supply pressure exceeds the tool’s
rated pressure. Air hoses and lines shall
be relieved of compressed air before
being disconnected or disjointed, unless
there is automatic valve closing protec-
tion at the joint being separated. Syn-
thetic lubricants which can cause
deterioration of elastomer seals shall not
be used in air systems of air tools.
Tool Maintenance
It shall be the tool owner’s and/or
employer’s responsibility to assure that
tools are maintained in a safe operating
condition. Tool maintenance and repair
shall be performed by authorized,
trained, competent personnel. Tools shall
be disconnected from their compressed
air supply before repairs are attempted.
Repairs shall be consistent with the
manufacturer’s recommended proce-
dures. Tool, hoses and fittings shall be
replaced if unsuitable for safe operation.
It shall be the tool owner’s and/or
employer’s responsibility to keep required
rating markings and warnings on the tool
in legible condition.
FPMC
Rev. 04/02
Read Operating Instructions
Always become familiar with all the
instructions and warnings before
operating any power tool.
Always Wear Approved
Eye Protection
Impact resistant eye protection
should meet or exceed the
standards as set forth in the United
States ANSI Z87.1, Occupational
and Educational Eye and Face
Protection. Look for the marking
Z87.1 on your eye protection to
insure that it is an approved style.
For further information, ANSI Z87.1,
Occupational and Educational Eye
and Face Protection, is available
from the American National
Standards Institute, Inc., 11 West
42nd Street, New York, NY 10036.
Hearing Protection is
Recommended
Hearing protection should be used
when the noise level exposure
equals or exceeds an 8 hour time-
weighted average sound level of 85
dBA. Process noise, reflective
surfaces, other tools being
operated nearby, all add to the
noise level present in your work
area. If you are unable to determine
your noise level exposure, we
recommend the use of hearing
protection.
Avoid Prolonged Exposure to
Vibration
Tools can vibrate during use.
Prolonged exposure to vibration or
very repetitive hand and arm
movements, can cause injury.
Stop using any tool if discomfort,
tingling feeling or pain occurs. You
should consult your physician
before resuming use of the tool.
90 PSIG Maximum
This tool is designed to operate at
An air pressure of 90 pounds per
square inch gauge pressure (90
PSIG) maximum, at the tool. Use of
higher air pressure can, and may
cause injury. Also, the use of
higher air pressure places the
internal components under loads
and stresses they were not
designed for, causing premature
failure. The air supply should be
clean and dry, preferably
lubricated. For best results, drain
the moisture from your compressor
daily.
WARNING:
Some dust created by power sanding,
sawing, grinding, drilling, and other
construction activities contains chemicals
known to cause cancer, birth defects or
reproductive harm. Some examples of
these chemicals are:
•Lead from lead-based paints
•Crystalline silica from bricks, cement
and other masonry products
•Arsenic and chromium from chemi-
cally treated lumber
Your risk from these exposures varies,
depending on how often you do this type
of work. To reduce your exposure to
these chemicals, work in a well-ventilated
area and work with approved safety
equipment such as those dust masks that
are specially designed to filter out
microscopic particles.
Description
Universal Tool model UT8726 Cut-Off Tool is designed for use with 3" cut-off wheels
to cut through metal bolts, steel rod and other materials up to 3/4" thick. This model
features a lock-off lever to prevent accidental starts, a textured grip for comfortable
control, and rear exhaust to direct air away from the work surface. Clear Lexan®
guard provides operator with an unobstructed view of work surface. Includes 2 cut-
off wheels.

UT8726
CUT-OFF TOOL
Parts Breakdown for UT8726
UT8726
CUT-OFF TOOL
Ref. Description Part # Ref. Description Part #
Universal Tool’s Limited Warranty
Universal Tool warrants their tools to be free from defects in material and workmanship
for one year from the date of purchase. This warranty does not apply to tools which
have been abused, misused, modified or repaired by someone other than Universal
Tool or their authorized service centers. If a Universal Tool tool proves defective in
material or workmanship within one year after purchase, return it to any authorized
service center or Universal Tool freight prepaid. Please enclose your name, address
and adequate proof of purchase and a short description of the defect. Universal Tool
will, at their option, repair or replace defective tools, free of charge. Repairs or
replacements are warranted as described above for the remainder of the original
warranty period. Universal Tool’s sole liability and your exclusive remedy under this
warranty is limited to repair or replacement of the defective tool. There are no other
warranties expressed or implied and Universal Tool shall not be liable for incidental,
consequential or special damages, or any other damages, costs or expense of repair
or replacement as described above.
Specifications Replacement Parts for UT8726
- Never use tool without proper eye protection.
Wheel size ............................................................................................... 2-7/8" x 1/16" x 3/8"
Free speed ............................................................................................................ 20,000 RPM
Weight ........................................................................................................................ 1-5/8 lbs.
Length .............................................................................................................................. 6-3/4”
Average air consumption ........................................................................................... 4 CFM
Recommended hose size ........................................................................................ 3/8" I.D.
Air inlet size ............................................................................................................... 1/4" NPT
Maximum operating pressure ...................................................................................90 PSI
1 Hose adaptor 106120
2 Muffler disk 106280
3 Valve spring 118010
4 Tip valve 120480
5 O-Ring 115170
6 Lever spring pin 111230
7 Handle assembly
(incls. bushing & grip) 260340
∆Comfort grip (only) 266040
8 Valve pin 120490
9 Lever assembly 120510
10 Rear bearing 81010183
11 Rear end plate 113190
12 Cage 103090
13 Rotor 116160
14 Rotor vanes (4) 116260
15 Front end plate 113200
16 Front bearing 8729113
17 Lock nut 108110
18 Wave washer 117255
19 Safety shield 122110
20 Retaining clip 115040
21 Arbor 107250
22 Arbor flange 117040
23 Arbor screw 117065
∆Cut-off wheels (included) (2) 122065
∆Set of cut-off wheels (6) 122060
5906
∆3/4" Open end wrench
119116
∆7/32" Hex wrench
Items Below Available - not included
(∆) Not shown
