Upright X27RT User manual

Operator Manual
This first section of the Operator manual is the English language version.
(EN) Manual part number 508401-003-EN for serial numbers 10131 to current.
June 08 ( Rev C )
VERSION II
X27RT / X33RT
X27BE / X33BE
Diesel
Bi-Energy 24V DC

X-27-33-RT
Serial Numbers 10131 - Current
ENGLISH
When contacting UpRight for service or parts information, be sure to include the MODEL and SERIAL
NUMBERS from the equipment nameplate.
UpRight Powered Access HQ
Vigo Centre
Birtley Road
Washington
Tyne & Wear
NE38 9DA
Tel: [phone]
Fax: [phone]
POWERED ACCESS
www.upright.com
Please note:
The Upright X-27-33-RT/BE is also sold as the Snorkel SR Series in some regions.
Therefore any reference to the Snorkel SR Series also applies to the UpRight X-27-33-RT/BE .
o
o
o
xxx
Tanfield Engineering Systems Ltd.
Vigo Centre, Washington, Tyne and Wear, UK.
Upright.
508764-001
UNLOADED

Operation ManualPage I
OPERATION MANUAL
WARNING
All personnel shall carefully read, understand and follow all safety rules and operating
instructions before operating or performing maintenance on any UpRight aerial work platform.
Safety Rules
Electrocution Hazard Tip Over Hazard Collision Hazard Fall Hazard
This machine is not
insulated NEVER elevate the platform or drive
the machine while elevated unless
the machine is on a firm, level surface
NEVER position the platform
without first checking for overhead
obstructions or other hazards
NEVER climb, stand or sit on
platform guardrails or midrail
USE OF THE AERIAL WORKPLATFORM:Thisaerialworkplatformisintendedtoliftpeopleandtheir tools aswellas the material
used for the job. It is designed for repair and assembly jobs and assignments at overhead workplaces (ceilings, cranes, roof struc-
tures, buildings etc.). All other uses of the aerial work platform are prohibited!
THIS AERIAL WORK PLATFORM IS NOT INSULATED! For this reason it is imperative to keep a safe distance from live parts of
electrical equipment!
Exceeding the specified permissible maximum load is prohibited! See "Special Limitations" on page 4 for details.
The use and operation of the aerial work platform as a lifting tool or a crane (lifting of loads from below upwards or from up high on
down) is prohibited!
NEVER exceed the manual force allowed for this machine. See "Special Limitations" on page 4 for details.
DISTRIBUTE all platform loads evenly on the platform.
NEVERoperatethe machinewithoutfirstsurveyingtheworkareaforsurfacehazardssuch asholes,drop-offs,bumps, curbs,orde-
bris; and avoiding them.
OPERATE machine only on surfaces capable of supporting wheel loads.
NEVER operate the machine when wind speeds exceed this machine's wind rating. See "Beaufort Scale" on page 4 for details.
IN CASE OF EMERGENCY push EMERGENCY STOP switch to deactivate all powered functions.
IF ALARM SOUNDS while the platform is elevated, STOP, carefully lower the platform. Move machine to a firm level surface.
Climbing up the railing of the platform, standing on or stepping from the platform onto buildings, steel or prefab concrete structures,
etc., is prohibited!
Dismantling the swing gate or other railing components is prohibited! Always make certain that the swing gate is closed and se-
curely locked!
It is prohibited to keep the swing gate in an open position (held open with tie straps) when the platform is raised!
To extend the height or range by placing ladders, scaffolds or similar devices on the platform is prohibited!
NEVER perform service on the machine while the platform is elevated without blocking the elevating assembly.
INSPECT the machine thoroughly forcracked welds, loose ormissing hardware, hydraulic leaks, loosewire connections, and dam-
aged cables or hoses before using.
VERIFY that all labels are in place and legible before using.
NEVER use a machine that is damaged, not functioning properly, or has damaged or missing labels.
To bypass any safety equipment is prohibited and presents a danger for the persons on the aerial work platform and in its working
range.
NEVER charge batteries near sparks or open flame. Charging batteries emit explosive hydrogen gas.
Modifications to the aerial work platformare prohibitedor permissible only at the approval by UpRight.
AFTER USE, secure the work platform from unauthorized use by turning the keyswitch off and removing the key.

Introduction
The most important chapter in this manual is the
safetychapter-Chapter1.Taketime,now,tostudy
it closely.
The information in Chapter 1, might save your life,
preventseriousinjury,ordamagetopropertyorthe
X33RT / X27RT.
This introduction also contains important informa-
tion concerning the responsibilities of the owner of
the machine.
■
Standard X33RT / X27RT Version 2
The standard X33RT / X27RT includes the fol-
lowing features:
●Fully proportional one handed joy stick
control
●Reliable diesel engine
●Large 1200mm multi position extension deck
●35% gradeability
●4 wheel drive
●Hour meter
●Temperature & ammeter gauges
●Easy access side trays for engine &
hydraulics
●Lockable hinged covers
●Independently operated hydraulic stabilisers
with auto level
●Swinging gate
●Independent articulating rear axles
●Forklift pockets
●Lifting lugs and tie down rings
●Flashing light
■Options
The following options are available for the X33RT
/X27RT:
●No stabilisers
●Non-marking tyres
●110/240V power to platform
●RCD/ELCB Outlet
●Alternative power options
❍Gasoline engine
❍LPG engine
❍Combination LPG/Gasoline engine
❍Bi-Energy 24V DC / Diesel engine
■Operation Manual
This manual provides information for safe and
proper operation of the aerial platform. Read and
understand the information in this Operator’s man-
ual before operating this machine on a job site.
Additional copies of this manual may be ordered
from Snorkel. Supply the model and manual part
number from the front cover to assure that the cor-
rect manual will be supplied.
All information in this manual is based on the latest
productinformationatthetimeofpublication.Snor-
kel reserves the right to make product changes at
any time without obligation.
■Photographs
Photographs are taken to represent the machine
and its component parts as clearly as possible.
However, there may be minor differences between
the photographs and your machine. This repre-
sents individual customer preferences and Snor-
kel's on-going committment to product
development.
■Safety Alerts
A safety alert symbol is used throughout this man-
ualtoindicatedanger,warningandcautioninstruc-
tions. Follow these instructions to reduce the
likelihood of personal injury, property damage or
damage to the machine.
The terms danger, warning, and caution indicate
varyingdegreesofpersonalinjuryorpropertydam-
agethatcanresultiftheinstructionisnotfollowed.
Denotes an imminently hazardous situation
which, if not avoided, will result in death or
serious injury.
Denotes a potentially hazardous situation
which,ifnotavoided,couldresultindeathor
serious injury.
Denotes a potentially hazardous situation
which, if not avoided, may result in minor or
moderate injury.
It may also be used to alert against unsafe
practices or action which may result in
damage to the RT.
Denotes important information pertaining to
settings, capacities, conditions, which
could, if ignored lead to machine damage or
future hazardous situations.
SR3370 & SR2770 – 13184A Rev A page - iii
DANGER
WARNING
CAUTION
IMPORTANT

It is also used to alert the reader to pay
careful attention to a particular passage of
text in the manual.
Notes
Notes are used to provide special information or
helpful hints to assist in aerial platform operation,
but do not indicate a hazardous situation.
■Operation
The RT aerial platform has built in safety features
and has been factory tested for compliance with
Snorkel specifications and industry standards.
However, any personnel lifting device can be po-
tentially dangerous in the hands of untrained or
careless operators.
Trainingisvitally important and mustbeperformed
under the direction of a QUALIFIED person. You
must display proficiency in knowledge and actual
operation of the RT before using it on a job site.
Before operation of the RT you must read and un-
derstand the operating instructions in this manual
aswellasthedecals,warnings,andinstructionson
the machine itself.
Before operating the RT you must be
AUTHORIZED by the person in charge to do so
and the operation of the RT must be within the
scope of the machine specifications.
Thepotentialforanaccidentincreaseswhen
the aerial platform is operated by personnel
whoare not trained and authorised.Deathor
serious injury can result from such
accidents.
Read and understand the information in this
manual and on the placards and decals on
the machine before operating the RT on the
job site.
■Maintenance
Everyperson whomaintains, inspects, tests, orre-
pairs these machines, and every person supervis-
inganyofthesefunctions,mustbeproperlytrained
and qualified to do so.
This Operators Manual provides a daily inspection
procedure that will help you keep your RT in good
operating condition.
Donotperformothermaintenanceunlessyouarea
trained mechanic, qualified to work on the RT. Call
qualified maintenance personnel if you find prob-
lems or malfunctions.
Do not modify this machine without written ap-
proval from the Engineering Department of Snor-
kel. Modification may void the warranty, adversely
affect stability, or affect the operational character-
istics of the RT.
■Responsibilities of parties
It is imperative that all owners and users of the RT
read, understand, and conform to all applicable
regulations. Ultimate compliance to OSHA
regulationsistheresponsibilityoftheuserandtheir
employer.
It is imperative that all owners and users of
the RT read, understand, and conform to all
applicable regulations.
Ultimate compliance to OSHA regulations is the
responsibility of the user and their employer.
ANSI Standard A92.6 clearly identifies
requirements of all parties who might be
involved with Self-Propelled Elevating Work
Platforms. EN280:2001(E)
AUSTRALIAN / NZ STANDARD 2550-10 also
identifiestherequirementsofallpartieswho
might be involved with Boom-Supported
Elevating Work Platforms.
Note - Standards
It is the responsibility of the owner to ensure that
the person operating the X33RT / X27RT is
provided with all the relevant information relating
to standards and codes of practice applicable in
their region.
❑In summary
●Only trained and authorised operators should
be permitted to operate the equipment.
●All manufacturers operating instructions and
safety rules and all employers safety rules
and all OSHA and other government safety
rules should be strictly adhered to.
●Repairs and adjustments should be made
only by qualified and trained maintenance
personnel.
●No modification should be made to the
equipment without prior written consent of
the UpRight Engineering Department.
●Make a pre-start inspection of the RT at the
beginning of each shift. A malfunctioning
machine must not be used.
page - iv Rev A SR3370 & SR2770 – 13184A
Introduction
WARNING
IMPORTANT
IMPORTANT

●Make an inspection of the work place to
locate possible hazards before operating the
RT.
■Additional information
For additional information, contact your local
dealer or UpRight at:
SR3370 & SR2770 – 13184A Rev A page - v
Introduction
UpRight Power Access HQ
Vigo Centre,
Birtley Road
Washington
Tyne & Wear,
NE38 9DA
Tel : [phone]
Fax : [phone]

Table of Contents
Electrical Hazard
Electrical Hazard Warning. . . . . . . . . . . . . . . . . . i
Introduction
Standard X33RT / X27RT Version 2 . . . . . . . iii
Options................................iii
OperationManual........................iii
Photographs............................iii
SafetyAlerts............................iii
Operation..............................iv
Maintenance ...........................iv
Responsibilities of parties . . . . . . . . . . . . . . . . . iv
Additional information . . . . . . . . . . . . . . . . . . . . . v
1. Safety
SafeOperation ........................1-1
Electrocution Hazards . . . . . . . . . . . . . . . . . . . 1-1
Minimum safe approach distance. . . . . . . . . 1-1
Pre-start Inspection . . . . . . . . . . . . . . . . . . . . . 1-1
Work Place Inspection and Practices . . . . . . . 1-1
Operation.............................1-2
Tipover and Falling Hazards . . . . . . . . . . . . . . 1-3
General Safety Precautions . . . . . . . . . . . . . . 1-3
Hydraulic System Precautions . . . . . . . . . . . . 1-3
FirePrevention........................1-3
Engine and Fuel Handling Precautions. . . . . . 1-3
Batteries .............................1-4
Safety Decals and Placards . . . . . . . . . . . . . . 1-4
Safety Placards and Decals Location . . . . . . . 1-5
2. Safety Devices
Safety Device Information. . . . . . . . . . . . . . . . 2-1
Emergency Stop Switches . . . . . . . . . . . . . . . 2-1
At platform control box . . . . . . . . . . . . . . . . . 2-1
At ground control box . . . . . . . . . . . . . . . . . . 2-1
Alarms...............................2-1
Levelsensor.........................2-2
Lowering............................2-2
High temperature . . . . . . . . . . . . . . . . . . . . . 2-2
Low oil pressure . . . . . . . . . . . . . . . . . . . . . . 2-2
Drive(reverse) .......................2-2
Drive(forward) .......................2-2
Guardrails............................2-2
SafetyProp...........................2-2
SwingingGate.........................2-2
SafetyControl.........................2-3
BubbleLevel..........................2-3
OperatorHorn ........................2-3
Stabilisers (Option) . . . . . . . . . . . . . . . . . . . . . 2-3
RCD/ELCB AC Outlet (option) . . . . . . . . . . . . 2-3
Flashing Light (option). . . . . . . . . . . . . . . . . . . 2-4
Lanyard Anchor Points (option) . . . . . . . . . . . 2-4
3. Specifications
Specifications .........................3-1
General Specifications, Standard Machine
X33RT. .............................3-1
Recommended Hydraulic Oil. . . . . . . . . . . . . . 3-1
General Specifications, Standard Machine
X27RT..............................3-2
Engine Oil Charts . . . . . . . . . . . . . . . . . . . . . . 3-3
EngineData...........................3-3
DF752..............................3-3
D902...............................3-3
Machine Component Identification . . . . . . . . . 3-4
4. Gauges
Water................................4-1
Amps................................4-1
EngineOil............................4-1
Hydraulic Oil Level . . . . . . . . . . . . . . . . . . . . . 4-1
Hours................................4-2
Fuel Level (option). . . . . . . . . . . . . . . . . . . . . . 4-2
BubbleLevel..........................4-2
5. Automatic Shut-offs and Circuit Breakers
Automatic Shut-offs . . . . . . . . . . . . . . . . . . . . 5-1
Levelsensor.........................5-1
Engine temperature . . . . . . . . . . . . . . . . . . . 5-1
Engine oil pressure . . . . . . . . . . . . . . . . . . . . 5-1
Platform height vs. drive speed. . . . . . . . . . . 5-1
Dynamicbrakes ......................5-1
Alternator not charging . . . . . . . . . . . . . . . . . 5-1
Stabilisers ..........................5-1
CircuitBreakers .......................5-2
Mainbreaker.........................5-2
RCD / ELCB outlet (option). . . . . . . . . . . . . . 5-2
6. Controls
Controls..............................6-1
Hydraulic Compartment. . . . . . . . . . . . . . . . . . 6-1
Ground Control Box. . . . . . . . . . . . . . . . . . . . . 6-1
Platform Control Box . . . . . . . . . . . . . . . . . . . . 6-2
7. Daily Inspection and Maintenance
Daily Inspection and Maintenance Table . . . . 7-1
FuelLevel............................7-2
(LPG-Option) .......................7-2
Fuel Filter (diesel engines only) . . . . . . . . . . . 7-2
FuelLeaks............................7-2
EngineOil............................7-3
EngineCoolant........................7-3
RadiatorCap..........................7-3
SR3370 & SR2770 – 13184A

Swinging Gate ........................7-3
Wiring Harnesses and Connectors .........7-3
Battery Terminals ......................7-4
Battery Fluid Level ....................7-4
Hydraulic Oil Tank......................7-4
Hydraulic tank cap ....................7-4
Hydraulic oil level .....................7-4
Hydraulic Oil Leaks ....................7-4
Tires and Wheels ......................7-5
Bolts and Fasteners ....................7-5
Structural Damage & Welds ..............7-6
Guardrails ............................7-6
Bubble Level ..........................7-6
Guides, rollers, and slides................7-6
Charging System.......................7-7
Ground Controls .......................7-7
Flashing Light .........................7-7
Platform Controls.......................7-7
Emergency Lowering....................7-8
RCD / ELCB (Option) ...................7-8
Safety prop ...........................7-8
Lanyard Anchorages (Option) ............7-8
Non-Slip Tread Grip ....................7-8
Wrist Support..........................7-9
Operator Manual .......................7-9
Placards and Decals ...................7-10
Standard placards and decals ..........7-10
Inspection drawing ...................7-11
8. Operation
Operating Procedures...................8-1
Control Stations........................8-1
Emergency Stopping....................8-1
Operation Considerations ................8-1
Fuel type .............................8-2
Operating From The Ground Control Box ...8-2
Raising the platform ...................8-3
Operating From The Platform Control Box ...8-4
Driving ..............................8-6
Raising the Platform ...................8-7
Stabilisers ............................8-7
Operating The Stabilisers Manually ........8-8
To set the stabilisers...................8-8
To raise the stabilisers: ................8-8
Operating The Auto Level System .........8-9
Setting the stabilisers automatically .......8-9
Raising the stabilisers automatically.......8-9
Extending The Multi-Position Platform ......8-9
9. Emergency Operation
Emergency Operation Procedures .........9-1
Emergency Stop .......................9-1
Emergency Bleed-Down .................9-1
Pushing / Towing.......................9-2
10. Stowing and Transporting
Stowing .............................10-1
Transporting .........................10-2
Trailering...........................10-2
Securing to a Transport Vehicle .........10-2
Towing ............................10-3
Lifting / Lashing Down.................10-3
Pushing ...........................10-3
Winching Procedure ..................10-3
11. Options
Bi-Energy Option......................11-1
DC motor...........................11-1
DC motor operation...................11-1
Master battery isolater switches .........11-1
Steering in DC motor mode ............11-2
Batteries ...........................11-2
Battery charger ......................11-2
Batteries - General maintenance ........11-3
Batteries - Charging ..................11-3
RCD / ELCB Outlet ....................11-3
Flashing Light ........................11-3
Lanyard Anchor Points .................11-4
Electrical Outlet.......................11-4
Non-Marking Tyres ....................11-4
Alternative Power Options...............11-4
Stabilisers ...........................11-4
12. Fire Fighting and Chemical Containment
Hazardous Components ................12-1
Antifreeze (UN 1993) .................12-1
Battery, Lead/Acid (UN 2794)...........12-1
Diesel Fuel (NA 1993).................12-1
Foam In Tires .......................12-2
Gasoline (UN 1203) ..................12-2
Hydraulic Oil (UN 1270) ...............12-3
Liquefied Petroleum Gas (UN 1075)......12-3
Motor Oil (UN 1270) ..................12-3
13. Operator's Troubleshooting
Troubleshooting.......................13-1
Operator Troubleshooting Chart.........13-1
Appendix A. Glossary
page - viii SR3370 & SR2770 – 13184A
Table of Contents

1. Safety
■Safe Operation
Knowledge of the information in this manual, and
propertraining,provideabasisforsafelyoperating
the X33RT / X27RT. Know the location of all the
controlsandhowtheyoperatetoactquicklyandre-
sponsibly in an emergency.
Safety devices reduce the likelihood of an acci-
dent. Never disable, modify, or ignore any safety
device. Safety alerts in this manual indicate situa-
tions where accidents may occur.
If any malfunction, hazard or potentially unsafe
conditionrelatingtocapacity,intendeduse,orsafe
operation is suspected, stop the operation of the
RT and seek assistance.
The operator bears ultimate responsibility for fol-
lowing all manufacturers instructions and warn-
ings, regulations and safety rules of their employer
and/or any country or regional law.
■Electrocution Hazards
The RT is an all metal aerial work platform and is
not electrically insulated. Do not operate it near
electricalconductors.Regardallconductorsasbe-
ing energized. Do not operate outside during a
thunderstorm.
❑Minimum safe approach distance
Minimum safe approach distances to energised
power lines and their associated parts must be ob-
served wile operating the RT.
Figure 1. - Minimum Safe Approach Distance
The RT is not electrically insulated. Death or
serious injury can result from contact with,
or inadequate clearance from, an energised
conductor. Do not go closer than the
minimum safe approach distance as defined
by ANSI.
ANSI publications define minimum distances that
mustbeobservedwhenworkingnearbusbarsand
energisedpowerlines.Figure1andTable1arere-
printed courtesy of the Scaffold industry Associa-
tion, ANSI/SIA A92.5.
Table 1. - Minimum Safe Approach Distance
Australian Standard AS 2550.10 defines minimum
distances that must be observed when working
near live aerial conductors up to and including
133kV (see Figure 2).
Figure 2 - Minimum Safe Approach Distance
AS 2550.10
SR3370 & SR2770 – 13184A Rev C page 1- 1
Denotes prohibited zone
Caution: - Diagrams shown are only for purposes of illustrating
M.S.A.D. Work positions, not all work positions.
Voltage Range
(Phase to Phase Minimum Safe Approach Distance
Feet Metres
0 to 300V Avoid Contact
Over 300V to 50kV 10 3.05
Over 50kV to 200kV 15 4.60
Over 200kV to 350kV 20 6.10
Over 350kV to 500kV 25 7.62
Over 500kV to 750kV 35 10.7
Over750kVto1000kV 45 13.72
DANGER
No go zone
6.4
6.4
3
3
Spotter
required
zone
Variations
in Sag
Personal
protection
barriers
Sag
FRONT VIEW SIDE VIEW
Distribution Lines Up to and Including 133kV
(Dimensions are in metres)
CLEARANCES FROM LIVE AERIAL CONDUCTORS

■Pre-start Inspection
At the start of each work shift, the X33RT /
X27RT shall be given a visual inspection and
function test. See the Daily Inspection and Mainte-
nance chapter , in this manual for a list of items to
inspect and test.
DONOToperatetheX33RT/X27RT unless
you are trained and authorized, understand
the operation characteristics of theX33RT /
X27RT, and have inspected and tested all
functions to be sure they are in proper
working order.
■Work Place Inspection and Practices
Do not use the X33RT / X27RT as a ground for
welding. Ground to the work piece.
Before the X33RT / X27RT is used, and during
use,checkthearea in which theX33RT/ X27RT
is to be used for possible hazards such as, but not
limited to:
●Drop-offs or holes.
●Side slopes.
●Bumps and floor obstructions.
●Debris.
●Overhead obstructions and electrical
conductors.
●Hazardous locations.
●Inadequate surface and support to withstand
all load forces imposed by the aerial platform
in all operating configurations.
●Wind and weather conditions.
●Presence of unauthorized persons.
●Other possible unsafe conditions.
Before the X33RT / X27RT is used, determine
the hazard classification of any particular atmo-
sphere or location according to ANSI/NFPA
505-1987.
AnyX33RT / X27RToperatedin a hazardous lo-
cation must be approved and of the type required
by ANSI/NFPA 505-1987.
While operating the RT a recommended safety
practice is to have trained and qualified personnel
in the immediate work area of the X33RT /
X27RT to:
●Help in case of an emergency.
●Operate emergency controls as required.
●Watch for loss of control by platform
operator.
●Warn the operator of any obstructions or
hazards that may not be obvious to them.
●Watch for soft terrain, sloping surfaces,
drop-offs, etc., where stability could be
jeopardized.
●Watch for bystanders and never allow
anyone to be under, or to reach through the
booms while operating the aerial platform.
Pinch points may exist between moving
components. Death or serious injury can
result from becoming trapped between
components, buildings, structures, or other
obstacles. Make sure there is sufficient
clearance around the machine before
moving the chassis, booms, or platform.
Allow sufficient room and time to stop
movement to avoid contact with structures
or other hazards.
Keep ground personnel from under the platform
when the platform is raised.
Secure all accessories, containers, tools, and
othermaterialsintheplatformtopreventthemfrom
accidentallyfallingorbeingkickedofftheplatform.
Always look in the direction of travel. Drive with
careandat speeds compatible withthework-place
conditions. Use caution when driving over rough
ground, on slopes, and when turning.
Do not engage in any form of horseplay or stunt
driving while operating the X33RT / X27RT.
Donotpermitridersonthemachineanyplaceother
than on the platform.
Remove all loose objects stored in or on the ma-
chine, particularly in the platform. Remove all ob-
jects which do not belong in or on the machine.
Never steady the platform by positioning it against
another platform.
Do not operate an X33RT / X27RT that is dam-
agedornotfunctioningproperly.DonotusetheRT
until the machine has been repaired by a qualified
maintenance person.
Do not operate a X33RT / X27RT that does not
have all its decals and placards attached and legi-
ble.
Watchforbystandersandneverallowanyonetobe
under, or to reach through, the machine and its
equipment while operating.
page 1- 2 Rev C SR3370 & SR2770 – 13184A
1. Safety
DANGER
WARNING

Use the recommended transport device when
loading the machine.
■Operation
If you encounter any suspected malfunction of the
aerial platform, or any hazard or potentially unsafe
conditionrelatingtocapacity,intendeduse,orsafe
operation, cease operation immediately and seek
assistance from management.
Use three points of support when getting on or off
theplatform(twohandsandonefootorasimilarset
of points). Keep the platform clean.
Maintain a firm footing on the platform floor. Oper-
ate the controls slowly and deliberately to avoid
jerky and erratic operation. Always stop the con-
trols in neutral before going in the opposite
direction.
Do not dismount while the platform is in motion or
jump off the machine.
Do not start until all personnel are clearly away
from the machine.
Never cover the floor grating or otherwise obstruct
your view below. Make sure the area below the
platform is free of personnel before lowering.
■Tipover and Falling Hazards
OperatetheRTonlyonafirm,flat,levelsurfaceca-
pable of withstanding all load forces imposed by
the X33RT / X27RT in all operating conditions.
The RT can tip over if it becomes unstable.
Death or serious injury can result from a
tip-over accident. Do not drive or position
the RT platform for elevated use near any
drop-off, hole, slope, soft or uneven ground,
or other tip-over hazard.
Do not operate the X33RT / X27RT from a posi-
tion on trucks, trailers, railway cars, floating ves-
sels, scaffolds, or similar equipment unless the
application is approved in writing by Snorkel.
Care shall be taken to prevent rope, electric cords,
and hoses, etc., from becoming entangled in the
aerial platform. If the platform or elevating assem-
bly becomes caught, snagged, or otherwise pre-
vented from normal motion by an adjacent
structure or other obstacle such that control rever-
saldoesnotfreetheplatform,removeallpersonnel
from the platform before attempts are made to free
the platform using ground controls.
Under normal working conditions it is best not to
transfer from the platform to another structure or
vice versa, unless that is the safest way to do the
job. Each situation must be judged separately
taking the work environment into account. The
following guidelines apply:
1. Where possible, place the work platform over
a roof or walking structure to do the transfer.
2. Transfer your anchorage from one structure
to another before you step across.
3. Remember, you might be departing the work
platform to a structure where fall arrest is
required.
4. Do not climb over or through the guardrails.
Use the platform entrance.
All platform occupants MUST wear and use fall re-
straint. Attach fall restraints to the platform lanyard
anchor points.
Do not exceed the unrestricted platform capacity
as indicated on the capacity placard at the en-
trance to the platform. Do not carry loads from any
point outside of the platform.
Makesurethatall protective guards, cowlings, and
doors are in place and secure. Be sure the guard-
rail system, including the gate, is in place and se-
cure.
Do not climb on the guardrails or use ladders,
planks, or other devices to extend or increase your
work position from the platform.
Do not use the RT as a crane, hoist, or jack,or for
anyotherpurposeotherthantopositionpersonnel,
their tools, and materials.
Do not operate the X33RT / X27RT in winds, or
wind gusts, of 28 mph, 45kph 12.5 m/s) or more
and do not add anything to the X33RT / X27RT
that will increase the wind loading (banners, flags,
etc.).
■General Safety Precautions
Do not modify the X33RT / X27RT in any way.
Whenpartsorcomponentsarereplaced,theyshall
be identical or equivalent to original Snorkel parts
or components.
Do not override any of the safety features of the
X33RT / X27RT.
■Hydraulic System Precautions
The hydraulic system contains hoses with hydrau-
lic fluid under pressure.
Hydraulicfluidescaping underpressurecan
have enough force to inject fluid into the
SR3370 & SR2770 – 13184A Rev C page 1- 3
1. Safety
DANGER
DANGER

flesh. Serious infection or reaction can
result if medical treatment is not given
immediately. In case of injury by escaping
hydraulic fluid, seek medical attention at
once.
DONOTplaceyourhandoranypartofyourbodyin
front of escaping hydraulic fluid. Use a piece of
cardboard or wood to search for hydraulic leaks.
Donot attemptrepairs to hydraulic systemsunless
you are trained. Refer to experienced repair per-
sonnel for help.
■Fire Prevention
Never operate your RT near a flame or spark. Hy-
draulic oil and gasoline are flammable and can ex-
plode.
■Engine and Fuel Handling Precautions
Engine exhaust contains carbon monoxide,
a poisonous gas that is invisible and
odorless. Breathing engine exhaust fumes
can cause death or serious illness. Do not
run the engine in an enclosed area or
indoors without adequate ventilation.
OnlyrefuelyourRToutdoorsinacleararea void of
gas fumes or spilled gas.
Never remove the fuel cap or refuel a gasoline en-
ginewhiletheengineisrunningorhot.ALWAYSal-
lowtheenginetocoolbeforerefueling.Neverallow
fuel to spill on hot machine components.
DO NOT smoke or permit open flames while
fueling or near fueling operations.
Maintain control of the fuel filler nozzle when filling
the tank.
ENSUREyouuseanapprovedfuelcontainer
with appropriate fuel filler nozzle
Do not fill the fuel tank to capacity. Allow room for
expansion.
If gasoline is spilled, clean up spilled fuel immedi-
ately, push/tow the RT away from the area of the
spill and avoid creating any source of ignition until
the spilled fuel has evaporated.
Tighten the fuel tank cap securely. If the fuel cap is
lost, replace it with an approved cap from Snorkel.
Use of a non-approved cap without proper venting
may result in pressurization of the tank.
Never use fuel for cleaning purposes.
For diesel engines, use the correct fuel grade for
the operating season.
■Batteries
Charge batteries in a well ventilated area free of
flame, sparks, or other hazards that might cause
fire or explosion.
Batteries give off hydrogen and oxygen that
can combine explosively. Death or serious
injury can result from a chemical explosion.
Do not smoke or permit open flames or
sparks when checking batteries.
Battery acid can damage the skin and eyes.
Serious infection or reaction can result if
medical treatment is not given immediately.
Wear face and eye protection when working
near batteries.
Batteries contain sulfuric acid that can damage
your eyes or skin on contact. Wear a face shield,
rubber gloves, and protective clothing when work-
ing around batteries. If acid contacts your eyes,
flush immediately with clear water and get medical
attention.Ifacidcontactsyourskin,washoffimme-
diately with clear water.
■Safety Decals and Placards
There are several safety decals and placards on
theX33RT/X27RT.Theirlocationsanddescrip-
tions are shown in this section. Take time to study
them.
Be sure that all the safety decals and
placards on the X33RT / X27RT are legible.
Clean or replace them if you cannot read the
words or see the pictures. Clean with soap &
water and a soft cloth. Do not use solvents.
You MUST replace a decal or placard if it is
damaged, missing, or cannot be read. If it is
on a part that is replaced, make sure a new
decal or placard is installed on the replaced
part. See your Snorkel dealer for new decals
and placards.
page 1- 4 Rev C SR3370 & SR2770 – 13184A
1. Safety
WARNING
CAUTION
WARNING
CAUTION
DANGER

■Safety Placards and Decals Location
SR3370 & SR2770 – 13184A Rev A page 1- 5
1. Safety
LEFTHANDSIDE OFTHE RT
On Fuel Tank Inside Cabinet &
Outside Of Cabinet Door
0372061
TORQUE
·
90-100 Ft. Lbs.122-135 N m
Lug Bolts/Nuts
Check Every 30 Days

page 1- 6 Rev C SR3370 & SR2770 – 13184A
1. Safety
RIGHT-HAND SIDE OF SR
STORAGE POSITION
PROPER POSITION FOR USE
SAFETY BAR 24”
YOU MUST NOT OPERATE THIS DEVICE UNLESS:
AN UNTRAINED OPERATOR SUBJECTS HIMSELF AND OTHERS TO
DEATH OR SERIOUS INJURY.
0323897
1.
2.
YOU HAVE BEEN TRAINED IN THE SAFE OPERATION OF THIS
DEVICE AND HHHH
YOU KNOW AND FOLLOW THE SAFETY AND OPERATING
RECOMMENDATIONS CONTAINED IN THE MANUFACTURER'S
MANUALS, YOUR EMPLOYER'S WORK RULES, AND APPLI-
CABLE GOVERNMENTAL REGULATIONS. HHHHHHHH
DANGER
DANGER
300700
SHEARING HAZARD/CRUSHING HAZARD
Death or serious injury might result from
having body parts sheared or crushed as the
platform descends. Keep away from closing
scissor arms and keep out from under the
platform as the platform comes down.
0372061
TORQUE
·
90-100 Ft. Lbs.122-135 N m
Lug Bolts/Nuts
Check Every 30 Days
0372061
TORQUE
·
90-100 Ft. Lbs.122-135 N m
Lug Bolts/Nuts
Check Every 30 Days
EMERGENCY OPERATION
1. EMERGENCY LOWERING
In the event of total power failure pull the emergency lowering handle
mounted at the front of the chassis until the platform starts to descend.
Once the platform is lowered the handle can be released.
In order to push or tow the SR the following steps MUST be taken.
A runaway SR can cause Death or serious injury. Do not proceed
unless the SR is on a level surface or is attached to an object that can
hold the SR on a slope.
The SR Drive motors will be ruined if the SR is pushed or towed faster
than 3.2 kph (2 mph).
2. TOWING OR PUSHING THE SR
Freewheel the Drive Motors
DANGER
CAUTION
Turn the FREEWHEEL knob [A] Counterclockwise fully.
Release the Brakes
Pump the hand pump [B] 5 to 10 times or until the Brakes are
released.
To re-set the Brakes pull knob [C] until it is fully open.
To re-set the Drive Motors turn the FREEWHEEL knob [A] clockwise
until it is fully closed.
After the SR has been pushed or towed the Brakes and the Drive
Motors MUST be re-set.
A
B
CPull To Reset
Brakes
12816
Freewheel
Valve
Hand Pump
13193

SR3370 & SR2770 – 13184A Rev A page 1- 7
1. Safety
FRONTENDOFRT
DEATH OR SERIOUS INJURY CAN RESULT FROM TIPPING OVER.
TO KEEP FROM TIPPING THIS MACHINE OVER FOLLOW THESE RULES.
OTHER ACTIONS CAN ALSO CAUSE THIS MACHINE TO TIP OVER
NOTE: STUDY THE OPERATOR'S MANUAL BEFORE OPERATING THIS MACHINE. 12574
DO NOT override safety devices.
DO NOT overload the machine.
DO NOT stand or sit on guardrails.
DO NOT attach ropes or chains to guardrails.
DO NOT carry loads outside the railing or use
as a crane.
DO NOT use this machine without the railings and the
entry gate in place. You could
fall out and hurt or kill yourself.
DO NOT use this machine if it is not operating correctly,
or if any part of it is damaged,
worn, or missing. An accident
could cause injury or death.
DO NOT let an untrained or unauthorized person use this machine.
When you leave the machine unattended,
remove the key, or turn off the battery
switch on the base of the machine and lock
the battery switch in the off position.
DO NOT replace components critical to machine stability, such as
batteries and wheel equipment, with lighter
DO NOT ride platform while machine is on a truck, fork
lift or other device.
DO NOT use ladder, scaffold, or other means to
increase size or platform height.
DO NOT use with improperly inflated or damaged tires
or wheels.
DO NOT RAISE OR DRIVE AN ELEVATED
PLATFORM ON
SOFT OR UNEVEN
SURFACES
DO NOT RAISE OR DRIVE AN ELEVATED
PLATFORM ON A
SLOPE
GO NO CLOSER THAN 4 feet (1.2m)
to ANY DROP OFF
OR HOLE
4 FT/1.2M
OK
1. 3.2.
TWO-TONE ALARM MEANS TIPOVER DANGER!
LOWER PLATFORM IMMEDIATELY TO AVOID
TIPOVER HAZARDS
USE ON
FLAT, LEVEL, AND
SOLID SURFACES
ONLY
OK
DO NOT RAISE A PLATFORM
IN WIND ABOVE 28 MPH (12.5 M/S)
4 FT/1.2M
DANGER
BEWARE OF ELECTRICAL HAZARDS
REGULATION 133A OF THE
CONSTRUCTION SAFETYACT 1912 REQUIRES
(a) Minimum approach of an appliance
(b) Inspection of the work site for
(c) Constant vigilance and an observer required
to live electrical apparatus.
electrical hazards before
commencing to use the appliance.
whilst working or travelling the appliance
in the vicinity of live electrical apparatus.
3m. for voltages up to 132,000
6m. for voltages above 132,000
and up to 330,000
8m. for voltages above 330,000
WARNING
KEEP LINESCLEAR POWEROF
Unless the Electrical Supply Authority has advised
in writing otherwise;
the clearance between any live overhead
power line and any part of this machine or
load carried is required by law to be
AT LEAST 4 METRES
This is a requirement of regulation 93 of the
Electrical Supply Regulations 1984
in the interests of safe working.
EMERGENCY BLEED
DOWN VALVE
12753
Australia Only
New Zealand Only
ALL DECALS ON
REVERSE SIDE
On Top Of Chassis Member

page 1- 8 Rev A SR3370 & SR2770 – 13184A
1. Safety
REARENDOFRT
X27RT PLATFORM RATINGS
UNIFORMLY DISTRIBUTED
RATED NUMBER OF OCCUPANTS: 2 PERSONS 12699
450kg
RATED WORK LOAD RATED WORK LOAD
MAIN
DECK EXTENSION
DECK
MAIN
DECK
990lb
120kg
264lb
330kg
726lb
EXTENSION DECK RETRACTED EXTENSION DECK EXTENDED
X27RT PLATFORM RATINGS
UNIFORMLY DISTRIBUTED
RATED NUMBER OF OCCUPANTS: 5 PERSONS 11346-1
580kg
RATED WORK LOAD RATED WORK LOAD
MAIN
DECK EXTENSION
DECK
MAIN
DECK
1280lb
120kg
264lb
460kg
1015lb
EXTENSION DECK RETRACTED EXTENSION DECK EXTENDED
X33RT
X27RT

2. Safety Devices
■Safety Device Information
For emergency operation controls and procedures
see the Emergency Operation chapter 9, in this
manual.
The devices listed in this chapter are safety de-
vices.
They are on an RT to increase safety in the work
place for both the operator and other people near
the machine.
Do not by-pass, disable, modify, or ignore
any of these devices. Check them carefully
atthestart of each workshiftto see that they
are in working order (see Daily Inspection &
Maintenance chapter 7). If any is found to be
defective, remove the RT from service
immediately until a qualified service
technician can make repairs.
■Emergency Stop Switches
❑At platform control box
Figure 2.1 - Platform Control Box Emergency
Stop Switch
Press the large red EMERGENCY STOP button in
and the entire machine stops, the engine turns off,
andnothingmoves.This switch must be out(on)to
control the RT from the platform (pull the switch
and it will pop out).
❑At ground control box
Figure 2.2 - Ground Control Box Emergency
Stop Switch
Press the red EMERGENCY STOP switch cover
down, at any time, under any conditions, and the
entire machine stops, the engine turns off, and
nothing moves. the EMERGENCY STOP switch
must be up for anything on the RT to work.
■Alarms
There are two alarms on an RT. One is located in
the platform control box, the other is located in the
ground control box.
The alarms are connected in parallel, they both
emit the same pattern of sound at the same time.
The different alarm sound patterns are shown in
the table immediately below and discussed below
the table.
Figure 2.3 - Alarm Sound Patterns
The high-temperature, low oil-pressure, and alter-
nator not-charging alarms are each a continuous
tone.
SR3370 & SR2770 – 13184A Rev A page 2- 1
WARNING
