UWELL CALIBURN A2S Pod System User manual

www.myuwell.com
Manufactured by SHENZHEN UWELL TECHNOLOGY CO., LTD.
©2022 By SHENZHEN UWELL TECHNOLOGY CO., LTD., All Rights Reserved.
Designed by UWELL Made in China
Uwell
Uwelltech Uwelltech Uwelltech Uwelltech

CALIBURN A2S Pod System
User Manual

- 1 -
Illustration
Quick Guide
1. Remove the pod, open the filler plug, fill the e-liquid through
the filling port and put the filler plug back.
2. Let the pod to sit for 10 minutes after closing the filler plug.
3. Insert the pod into the device and draw to vape.
Refillable pod
Filler plug
E-liquid window
LED indicator
Device
Type-C port

- 2 -
Meshed-H CoilPro-FOCS Flavor
Adjustment Technology
Type-C port
Refillable Pod
Large E-liquid Window
Light Matrix

- 3 -
Specifications
● Materials: Aluminium Alloy, PCTG
● Dimensions: 110.1 mm × 21.3 mm × 11.7 mm
● Net Weight: 30 g
● E-liquid Capacity: 2 ml
● Output Power: Maximum 15 W
● Pod Specification:
FeCrAl UN2 Meshed-H 1.2Ω CALIBURN A2 Side Refilling Pod
● Battery Capacity: 520 mAh
The Packaging Includes
● 1 × CALIBURN A2S Device
● 1 × UN2 Meshed-H 1.2Ω CALIBURN A2 Side Refilling Pod
(Pre-installed)
● 1 × UN2 Meshed-H 1.2Ω CALIBURN A2 Side Refilling Pod
(Spare)
● 1 × User Manual
Features
1. Draw to vape, it’s easy to operate.
2. Refillable pods are cost-effective.
3. Upgraded UWELL Pro-FOCS technology restores the flavor
excellently.
4. Stable, safe, and reliable performance is ensured by a built-in
safety mechanism.
5. A continuation of CALIBURN A series’ recognizable style.
6. Smooth surface decorated with cut lines, making the device
distinctive.
7. Animated light matrix flashes during vaping.
8. The device is compatible for the CALIBURN A2 Refillable Pod.

- 4 -
Instructions
1. How to fill the pod
a. Take out the pod.
b. Open the filler plug, fill it with e-liquid and put the filler plug back.
c. Insert the pod into the device.
Attention:
a. Insert the nozzle of the e-liquid bottle into the filling port.
b. Do not leave the filling port open for too long. Please put the
filler plug back in time to prevent e-liquid leakage.
c. Please let it sit for 10 minutes after the first e-liquid filling to
avoid coil burning.
d. Please refill the e-liquid when the e-liquid reaches the MIN level.

- 5 -
2. Vaping
When power is on, vape by drawing and the LED lights flash like
a wave while vaping. When stop vaping, the LED lights are fading
out from the bottom to the top. The green light flashes 5 times to
indicate an over 8-second vaping, and the device will stop output.
3. Pod replacement
a. Take out the used pod from the device, and install a new pod.
b. Please let it sit for 10 minutes after the first e-liquid filling to
avoid coil burning.
4. Battery level indication
During vaping, a green light indicates the battery level is over 60%,
a blue light indicates the battery level is 30%-60%, and a red light
indicates the battery level is under 30%. A red light flashes 10
times to indicate the battery level is too low and the device will
stop output.
5. Short-circuit protection
When a short-circuit occurs, the LED indicator will flash 3 times
in red, and the device will stop output.
6. Low voltage protection
When the device is at low power, the LED indicator will flash 10
times in red, and the device will stop output.
7. Overtime protection
The light will flash 5 times in green to indicate an over 8 second
vape, and the device will stop output.

- 6 -
8. Open circuit prompt
When the pod is disconnected from the device, the blue light will
flash 3 times.
9. Charging
The LED lights come on in turn when connecting the Type-C cable.
The red light flashes to indicate a low battery level, the blue light
flashes to indicate a medium battery level, and the green light
flashes to indicate an almost full battery level. The green light will
stay on when the charging is done.
Attention
1. Please charge with certified high-quality adaptor from a reputable
company and a Type-C cable with the charging current of 5V/1A.
2. The device and adaptor may warm up when charging, keep
away from flammable and explosive goods.
3. Please use a dry and soft cloth to clean the device. Keep away
from water or any liquids.
4. Please remove the pod cartridge and store it separately when
you are on a plane to avoid leakage due to pressure changes.
5. Please do not put the device in your pocket with other hard
objects to avoid damages.
6. Please charge the device at least once a month.
7. Don’t disassemble the device.
8. Avoid high temperature, low temperature and humidity during
use or storage to avoid damage to the equipment.

- 7 -
9. The product parameters or pictures in this manual are for
illustration purpose only, please refer to the actual product.
Safety Instruction
Please read the following safety instructions carefully before using
the product.
1. This product is only available to people who have reached the
legal age of smoking. It is strictly forbidden for young children,
pregnant women and women during breastfeeding or for patients
with heart disease, high blood pressure, diabetes, depression
and asthma.
2. Please put the product out of reach of children and pets to
avoid injury.
3. When using this product, please keep away from inflammable
and explosive materials to avoid injury.
4. The company does not assume any responsibility for any
equipment damage or personal injury caused by user misuse.
Warranty Details
Please keep the anti-counterfeit code and proof of purchase after
purchasing the product. The warranty period is 180 days from the
date of purchase. Our company provides warranty service (Device
and atomizer only, exclude coil head and pod cartridge).
Please note that any of the following conditions are not covered
by the warranty:
1. Exceeding the warranty period.

- 8 -
2. Damage caused by the use, maintenance, and storage that is
not in accordance with the requirements as instructed.
3. Damage caused by unauthorized repair.
4. Damage caused by the usage of non-UWELL components.
5. Damage caused by force majeure.
Verification
1. Visit the UWELL official website www.myuwell.com through
a smartphone or PC.
2. Please enter the 16 digits authentic code, and the result will be
displayed in a few seconds.
3. Please feel free to contact UWELL via e-mail, phone or website
for more help.
Customer Service
We pride ourselves on manufacturing quality products and providing
excellent customer service. For any issues, please contact us at
[email protected].
* UWELL reserves the right of final interpretation in the user manual.
* It is hereby stated that the markable area on the product is not
enough to mark the CE and WEEE as the standard dimensions.
