UWELL TRIPOD PCC Kit User manual

www.myuwell.com
Manufactured by SHENZHEN UWELL TECHNOLOGY CO., LTD.
©2020 By SHENZHEN UWELL TECHNOLOGY CO., LTD., All Rights Reserved.
Designed by UWELL Made in china

TRIPOD PCC Kit
User Manual

- 1 -
Specification
Charging Case
● Material: Aluminum, PC + ABS
● Size: 34.5 mm × 94 mm
● Net Weight: 67.4 g
● Standby Current: < 80 uA
● Battery Capacity: 1000 mAh
Pod System
● Material: PCTG, Aluminum, PC + ABS
● Size: 21.5 mm × 10.4 mm × 78 mm
● Net Weight: 20 g
● E-liquid Capacity: 2 ml
● Standby Current: < 30 uA
● Maximum Wattage: 11 W
● Coil Resistance: 1.2 Ω
● Battery Capacity: 370 mAh
The Packaging Includes
● 1 × Tripod PCC Kit ● 1 × Type-C Cable ● 1 × User’s manual
Features
1. The draw-activated mechanism, easy to use.
2. The charging box is easy to carry, and it keeps the pod system clean.
3. 370 mAh (pod system) + 1000 mAh(charging case) offers continuous battery life.
4. Carry 3 pods at the same time, and change them anytime and anywhere.
5. The Pro-FOCS flavor testing technology from UWELL gives you an unparalleled
vape experience.

- 2 -
6. The chip has multiple circuit protection functions to supply stable, safe, and reliable
performance.
Illustration
1
2
34
5
6
1. Charging case
3. Smart pad
5. Pod system
7. Pod
9. Pod system charging port
2. Type-C charging port
4. LED indicator on the Charging case
6. Pods
8. LED indicator on the Pod system
8
9
7

- 3 -
1. Open the charging box and take out the pod system.
2. Remove the pod from the body.
3. Fill e-liquid, and then insert the pod into the body and let it stand for 10 minutes
before using.
4. Just take a draw directly, and the LED will come on.
5. Insert the pod system together with a pod into the charging case to charge the pod
system. The LED will starts flashing and turn off when fully charged.
6. Insert the charging cable into the charging case to charge the case. The LED lights
start flashing. All LED lights will stay on when fully charged.
Instructions
1. How to fill the pod
a. Remove the pod from the pod system.
b. Unplug the filler plug on the pod to fill the e-liquid.
c. Press in the filler plug after filling, ensure it is in place.
d. Insert the pod back on the body.
Please Read the Following Information Before Use:

- 4 -
Attention:
a. Do not leave the filler plug off for an extended period. Press in the filler plug securely
after refilling to prevent leaking.
b. When using a new pod and then filling the pod, please let the pod sit for 10 minutes
to avoid coil burning.
c. Please add e-liquid when the e-liquid level is at the “MIN” line.
2. Vaping
Take a draw to vape, the LED will stay on. The device will automatically stop firing
when the device has been firing for longer than 8 seconds, then the LED will flash
green 5 times.
3. Changing the pod
a. Remove the used pod from the device.
b. After filling the new pod, place the pod into the device.
c. Please let the pod sit for 10 minutes to avoid coil burning.

- 5 -
4. Pod system power indicator function
During vaping, a green light means battery life is more than 60%, blue light means
battery life is between 20% and 60%, and a red light means battery life is less than
20%. When the red light flashes 10 times in a row, the power is too low, the pod
system will automatically shut down.
5. Charging the pod system
Insert the pod system into the charging box to charge, the LED will start to flash.
The red light flashes indicating power is less than 20%, the blue light flashing indicating
power is 20%~60%, and the green light flashing indicating power is more than 60%.
When the pod system is fully charged, the LED will turn off.
6. Protection Features of the Pod system
a. Short-circuit protection
When a short-circuit occurs, the LED will flash red 3 times to indicate a short-circuit
and stop output.
b. Low power indication
When the device has low battery, the LED will flash red 10 times to indicate low
battery and stop output.
c. Over-time protection
After 8 seconds of vaping, the green light flashes 5 times to indicate the timeout,
and automatically stops the output.
7. Charging the charging case
a. Insert the charging cable into the type-c port of the charging box to charge, six
LED indicators will flash as a group and rotate clockwise 3 times.
b. During charging: the LED indicators representing the current power stay on.

- 6 -
8. Charging box power indicator function
a. When LED indicators on charging box are not displayed, gently touch the central
position of the indicator plate with your finger several times to wake up the plate
and indicate the current power level.
b. The LED lights will flash and rotate clockwise while charging. As the battery capacity
increases, the LED lights indicating the current battery capacity of the charging
box will become solid, the remaining LED lights will flash gradually. When all the
LED lights stay on, the charging case is fully charged.
c. When the LED indicators on the charging box rotate counterclockwise three times,
it indicates that the charging box detects pod system being inserted.
9. Protection Features of the Charging box
a. Short-circuit protection
When a short-circuit occurs, all LEDs will flash 5 times to indicate a short-circuit
and stop output.
b. Low power indication
When the device is in low battery, the first LED will flash 10 times to indicate low
battery and stop output.
c. Overvoltage protection
When the charging voltage is greater than 6.8V, it will stop charging.
Attention
1. Please charge with certified high-quality adaptor from a reputable company and
a Type-C cable with the charging current of 5V/2A.
2. The device and adaptor may warm up when charging, keep away from flammable
and explosive goods.

- 7 -
3. Please use a dry and soft cloth to clean the device. Keep away from water or any
liquids.
4. Please remove the pod cartridge and store it separately when you are on a plane
to avoid leakage due to pressure changes.
5. Please do not put the device in your pocket with other hard objects to avoid
damages.
6. Please charge the device at least once a month.
7. Don’t disassemble the device.
8. Avoid high temperature, low temperature and humidity during use or storage to
avoid damage to the equipment.
9. The product parameters or pictures in this manual are for illustration purpose
only, please refer to the actual product.
Safety Instruction
Please read the following safety instructions carefully before using the product.
1. This product is only available to people who have reached the legal age of smoking.
It is strictly forbidden for young children, pregnant women and women during
breastfeeding or for patients with heart disease, high blood pressure, diabetes,
depression and asthma.
2. Please put the product out of reach of children and pets to avoid injury.
3. When using this product, please keep away from inflammable and explosive
materials to avoid injury.
4. The company does not assume any responsibility for any equipment damage or
personal injury caused by user misuse.

- 8 -
Warranty Details
Please keep the anti-counterfeit code and proof of purchase after purchasing the
product. The warranty period is 180 days from the date of purchase. Our company
provides warranty service (Device and atomizer only, exclude coil head and pod
cartridge).
Please note that any of the following conditions are not covered by the warranty:
1. Exceeding the warranty period.
2. Damage caused by the use, maintenance, and storage that is not in accordance
with the requirements as instructed.
3. Damage caused by unauthorized repair.
4. Damage caused by the usage of non-UWELL components.
5. Damage caused by force majeure.
Verification
1. Visit the UWELL official website www.myuwell.com through a smartphone or PC.
2. Please enter the 16 digits authentic code, and the result will be displayed in a few
seconds.
3. Please feel free to contact UWELL via e-mail, phone or website for more help.
Customer Service
We pride ourselves on manufacturing quality products and providing excellent
customer service. For any issues, please contact us at [email protected].
* UWELL reserves the right of final interpretation in the user manual.
* It is hereby stated that the markable area on the product is not enough to mark
the CE and WEEE as the standard dimensions.
