V-tech IS7121 User manual

1
Installation guide
(Canada version)
IS7121/IS7121-2/IS7121-22
DECT 6.0 cordless telephone
with wireless doorbell
Before using this product, read this Installation guide for instructions for
installing the telephone base, handset and doorbell. For basic settings
and operation instructions, see the provided Abridged user’s manual.
Basic steps to install your phone and doorbell
5
Doorbell installation
Doorbell location testing
6Doorbell wall mount installation
Basic installation
Install telephone base & charger
Install handset battery
Install doorbell battery
3
2
1
4Install telephone base wall mount bracket

2
1Install telephone base & charger
Battery Pack
BT164392/BT264392
2.4V 550mAh Ni-MH
WARNING : DO NOT BURN OR
PUNCTURE BATTERIES
Made in China CR1222
2Install handset battery
123
4
Charge for at least 30 minutes
before initial settings.
Charge for 13 hours before
initial use.
Light on!
Battery Pack / Bloc-piles :
(2.4V Ni-MH)
WARNING / AVERTISSEMENT:
DO NOT BURN OR PUNCTURE BATTERIES.
NE PASINCINÉRER OU PERCER LES PILES.
Made in China / Fabriqué en chine
THISSIDE UP / CE CÔTÉ VERSLE HAUT
CR1232
If you subscribe to telephone service from a cable company or a
VoIP service provider, contact your cable/VoIP service provider
for more information.
Click!
Plug!
Plug!
DSL lter
Click!
Plug!
Battery Pack / Bloc-piles :
(2.4V Ni-MH)
WARNING / AVERTISSEMENT:
DO NOT BURN OR PUNCTURE BATTERIES.
NE PASINCINÉRER OU PERCER LES PILES.
Made in China / Fabriqué en chine
THISSIDE UP / CE CÔTÉ VERSLE HAUT
CR1232
Plug!

3
3Install telephone base wall mount bracket
(optional)
43
2
1
Unplug!
Unplug!
Plug!
Click!
Slide the
bracket down!

4
4Doorbell battery installation
BASIC INSTALLATION COMPLETED!
Keep reading for doorbell location testing.

5
5Doorbell location testing
Before mounting the doorbell on a wall, make sure you test if the
location you install the doorbell is in range, and adjust the camera
angle to best suit your needs.
To test the location for installation:
Hold the doorbell in the location where you want to install the doorbell,
then follow the steps below to test the reception range and video
capture angle.
Press MENU >> Press qor pto Settings >> Press SELECT.
Press qor pto Doorbell setup >> Press SELECT.
Press /DOORBELL to check the video streaming quality.
Press ISO, then press +or -to adjust the video streaming brightness.
If audio feedback occurs, press on the handset.
If the desired location is in good range, the handset displays .
Relocate your handset and/or telephone base according to the
instructions shown on the handset. When the reception is in
good range, the handset displays . Press OK to return to the
video steaming.
If the desired location is not in good range, the handset ashes .
Then press INFO for instructions.
Keep the video streaming on for camera lens adjustment.
When you check for the desirable location to install the doorbell,
make sure the visitor is standing in a reasonable distance away from
the doorbell.
1.
2.
3.
•
•
•
4.

6
DOORBELL LOCATION TESTING COMPLETED!
Keep reading for doorbell wall mount installation.
To adjust the shooting area, you may either relocate the doorbell in
different height level, or adjust the camera angle (see the section below).
To adjust the camera angle:
Tilt the lever to adjust the angle of the camera lens. The camera lens
can be adjusted to left, right or down, up to 10 degrees.
After you have tested the reception range and found the desirable
location to install the doorbell, press OK on the handset to end the video
streaming and proceed to Step 6.
•
CAUTION
View
Right
Angle
Adjustment
View
Left
CAUTION
FCC ID: xxxxx-xxxx-xx
IC: xxxxx-xxxxxxxx
Rotate
to Left
Angle
Adjustment
Rotate
to Right
CAUTION
View
Right
Angle
Adjustment
View
Left

7
6Doorbell wall mount installation
Make sure you have done Step 5 above before you mount the
doorbell on the wall.
If you drill the holes into a stud, go to Step 3.
-OR-
If you drill the holes into the wall, insert the wall anchors into the holes.
2.
Use the two holes on the doorbell wall mount to mark the desirable
installation location on the wall.
1.

8
Use a sharp object to open a hole on the soft plastic part on the
doorbell wall mount, then route the power adapter cord through
the hole.
4.
Align the wall mount and screws with the holes in the wall (or stud).3.
Align
Open a hole
Route through
the hole

9
Wire with
red end
Wire with
black end
Screws
Metallic
plate Metallic
plate
Loosen the screws and the metallic plates, then slide the metal part
of the wires underneath the metallic plate as shown. Twist the screws
to secure.
5.
If you already have a wired doorbell installed,
see Installing the doorbell with an existing
wired doorbell on pages 12 to 14 to install your
new IS7121 doorbell unit.

10
Push the doorbell gently onto the wall mount until they are
sealed tightly.
This doorbell meets the IPX4 waterproof standard. Make sure the
doorbell is tightly sealed with its wall mount in order to maintain its
waterproof ability.
6.
Tighten the
screw
Tighten the screw into the threaded socket at the bottom to secure.7.
Push
Push
Seal tightly

11
DOORBELL INSTALLATION COMPLETED!
Refer to the Abridged user’s manual for
common settings and operations.
Plug the adapter into the indoor domestic power supply.8.
Plug!

12
If you already have a wired doorbell installed, follow the instructions
below to install your new IS7121 doorbell unit.
Turn off the power supply to the existing wired doorbell.
Follow Step 1 through Step 5 in Doorbell wall mount installation
on pages 7 to 9.
Insert a cross-head screwdriver to the side of battery compartment
on the right, then twist and lift to loosen the screw and the metallic
plates. Using a wire, slide one end of the metal part of the wire
underneath the metallic plate, then twist the screws to secure.
Connect the other end to the transformer.
1.
2.
3.
Installing the doorbell with an existing wired
doorbell (optional)
Transformer
Transformer
Transformer

13
Option 1: Ring the front doorbell of the IS7121 and existing wired
doorbell simultaneously.
Using another wire, slide one end of the metal part underneath the
metallic plate on the doorbell, then connect the other end to the
Trans terminal of your chime/buzzer unit of the wired doorbell.
4.
Chime/buzzer of
wired doorbell
Transformer
Rear Trans Front

14
Option 2: Ring the rear doorbell of the IS7121 and existing wired
doorbell simultaneously.
Follow Step 6 to Step 8 in Doorbell wall mount installation on
pages 10 to 11 to complete the installation.
5.
If you do not connect domestic power supply nor install
AA batteries to the IS7121 doorbell, only the existing wired
doorbell will ring when being pressed.
VTECH TELECOMMUNICATIONS LTD.
A member of THE VTECH GROUP OF COMPANIES.
Distributed in the U.S.A. by VTech Communications, Inc., Beaverton, Oregon 97008.
Distributed in Canada by VTech Technologies Canada Ltd., Richmond, B.C. V6W 1L5.
VTech is the registered trademark of VTech Holdings Limited.
Copyright © 2013 for VTECH TELECOMMUNICATIONS LTD.
All rights reserved. Printed in China.
96-009372-010-100
Rear Trans Front
Transformer
Chime/buzzer of
wired doorbell
Transformer
