V-tech Vsmart vs001 User manual

Congratulations

on purchasing your new VTech product.

Before using this product, please read

Important safety instructions.

This manual has instructions on how to

set up and register your new sensor.

For instructions on sensor settings, see the

User guide that came with your VS150.

What’s in the box

Your product package contains the following

items. Save your sales receipt and original

packaging in the event warranty service is

necessary.

Sensor overview

1 – Magnet unit

2 – Sensor unit

Sensor unit overview

1 – Latch button

• Press to open the battery

compartment case.

2 – Back cover

3 – Pair button

• Press and hold to enter the

registration mode.

4 – LED light

• Red for a second when the sensor is

powered on.

• Flashes red when the sensor is in the

registration mode.

5 – Battery compartment case

VS001

Wire-Free

Contact Sensor

for use with compatible

VTech telephone systems

User Guide

Before use

Install batteries to the

open/closed sensor

1. Press the latch button on the sensor to

open the battery compartment case.

2. Insert two AAA batteries into the battery

compartment.

NOTE

• Do not mix old and new batteries. Do not

mix alkaline, standard (Carbon-Zinc) or

rechargeable (Ni-Cad, Ni-Mh, etc) batteries.

• While you insert the batteries, make sure the

polarities are correct.

• The batteries operate properly under the

temperature between -18°C (0°F) and 55°C (130°F).

Add and register a sensor

You need to register the Contact Sensor with

your VTech telephone system.

1. Place your telephone base into pairing

mode as per the instructions in your

telephone user guide.

2. Press and hold the pair button (P) on the

Contact sensor, until the LED light ﬂashes

red, to enter the registration mode.

The registration process takes about 90

seconds to complete.

Replacing a sensor

If you have purchased this new VS001

accessory sensor to replace an old sensor,

follow the instructions to deregister your old

sensor, and then register this new sensor to

the telephone base.

To deregister a sensor on VS150:

1. Press MENU when the phone is not in use.

2. Enter the code *33734# to access the

DEREGISTER menu.

3. Scroll to Single sensor, and then press

SELECT.

4. Scroll to the sensor you want to

deregister, and then press SELECT.

5. Press YES to conﬁrm the deregistration.

Check the sensor before use

1. Separate the sensor unit from the magnet

unit.

• You will hear an alert tone, followed by

an announcement - “Open/Closed X is

open”, from the handset.

• The handset will display Open/Closed

X is open.

Test the sensor signal strength

You can mount the Contact sensor on a door,

window, or medicine cabinet that opens or

closes.

1. Take the sensor unit and magnet unit

to the desired mounting location, and

hold them at the object and the frame

respectively.

2. Use your handset to enter the Settings

menu, and then the Sensor setup menu.

Follow the steps to test the sensor’s signal

strength, and then exit the sensor setup

mode.

3. Open the door, window, or medicine cabinet

again to make sure you receive alerts.

NOTE

• Move the base closer to the mounting location,

or move the sensor closer to the base, if the

sensor is out of range

• Use adhesive tape to hold the sensor

temporarily in place.

• Depending on surroundings and obstructing

factors, like walls or cabinets, the sensor may

not transmit to the base properly.

Mount the sensor

We recommend you to mount the magnet

unit on a door, window, or medicine cabinet,

and mount the sensor unit on its respective

frame.

NOTE

• Make sure the mounting surface is clean.

A textured surface or any imperfections to

a smooth surface can keep the sticker from

making a strong bond.

• Make sure you align the magnet unit with

sensor unit when mounting.

• The distance between the sensor unit and

magnet unit must be less than 1 cm (0.4 inch).

• The door images in this installation guide are

for conceptual reference only.

> 1 cm

(0.4 inch)

> 1 cm

(0.4 inch)

> 1 cm

(0.4 inch)

> 1 cm

(0.4 inch)

TIPS

• If there is a difference in level between the

door, window, or medicine cabinet and its

respective frame, or the frame is too narrow or

has some decorative molding, you can choose

to mount the open/closed sensor with spacer.

You can also mount the magnet unit on the

frame, and the sensor unit on the door, window,

or medicine cabinet instead.

• You can choose to mount the sensor unit with

sticker ﬁrst, and then use screws later if you

decide to mount it at that location for long term.

User guide

Sensor unit

AAA battery x 2

User guide

Magnet unit

Spacer of

sensor unit

Spacers of magnet unit

Double-sided adhesive

stickers

Screws

Small

screws
