V-tech VSP600A User manual

ErisTerminal®SIP DECT Base Station
and Cordless Headset
VSP600A
Administrator and Provisioning Manual
Rev. 1 09/15

2Back to Contents
VSP600A Administrator and Provisioning Manual
C ONTENTS
Preface ...................................................................................................... 6
Text Conventions................................................................................................................7
Audience.............................................................................................................................7
Related Documents............................................................................................................7
Introducing the VSP600A ........................................................................ 8
About the VSP600A base station .......................................................................................9
Quick Reference Guide ....................................................................................................10
Network Requirements.....................................................................................................12
VSP600A Configuration Methods.....................................................................................13
Configuration Using the Phone Menus................................................ 14
Viewing the Main Menu ....................................................................................................15
Using the Status menu.........................................................................................15
Viewing Line status..............................................................................................17
Using the Admin Settings Menu .......................................................................................18
Using the Network Setting menu.........................................................................19
Using the Secure browsing menu........................................................................21
Using the Provisioning menu...............................................................................22
Editing the handset PIN code..............................................................................23
Using the WebUI..................................................................................... 24
Using the Web User Interface (WebUI)............................................................................25
Status Page ......................................................................................................................27
System Status......................................................................................................27
Handset Status ....................................................................................................28
System Pages ..................................................................................................................29
SIP Account Management...................................................................................29
General Account Settings .............................................................................29
Dial Plan........................................................................................................31
SIP Server Settings.......................................................................................32
Registration Settings.....................................................................................32
Outbound Proxy Settings ..............................................................................32
Backup Outbound Proxy Settings .................................................................33

3Back to Contents
VSP600A Administrator and Provisioning Manual
Audio Settings...............................................................................................33
Quality of Service..........................................................................................34
Signaling Settings .........................................................................................34
Feature Access Codes Settings....................................................................35
Voicemail Settings.........................................................................................36
NAT Traversal ...............................................................................................36
Music on Hold Settings .................................................................................37
Network Conference Settings .......................................................................37
Session Timer ...............................................................................................37
Call Settings.........................................................................................................38
General Call Settings ....................................................................................38
Do Not Disturb...............................................................................................38
Call Forward..................................................................................................38
User Preferences.................................................................................................40
General User Settings...................................................................................40
Signaling Settings................................................................................................41
Voice .............................................................................................................41
NAT Traversal ...............................................................................................41
Handset Settings .................................................................................................42
Account Assignments....................................................................................42
Handset Name ..............................................................................................43
Network Pages .................................................................................................................44
Basic Network Settings........................................................................................44
Basic Network Settings .................................................................................44
Advanced Network Settings.................................................................................45
VLAN.............................................................................................................45
LLDP-MED....................................................................................................46
802.1x ...........................................................................................................46
Contacts Pages ................................................................................................................47
Base Directory.....................................................................................................47
Create Base Directory Entry .........................................................................49
Directory Import/Export .................................................................................49
Blacklist.........................................................................................................50
Create Blacklist Entry....................................................................................51
Blacklist Import/Export ..................................................................................52
LDAP ...................................................................................................................53
LDAP Settings...............................................................................................53
Servicing Pages................................................................................................................56
Reboot.................................................................................................................56
Time and Date .....................................................................................................56
Network Time Settings..................................................................................56
Time Zone and Daylight Savings Settings ....................................................57
Manual Time Settings....................................................................................58
Firmware Upgrade...............................................................................................59
Firmware Server Settings..............................................................................59
Manual Firmware Update and Upload ..........................................................60
Updating a Handset ......................................................................................60
Provisioning.........................................................................................................62
Provisioning Settings.....................................................................................63

4Back to Contents
VSP600A Administrator and Provisioning Manual
Plug-and-Play Settings..................................................................................63
DHCP Settings..............................................................................................64
Resynchronization.........................................................................................65
Import Configuration......................................................................................66
Export Configuration .....................................................................................67
Reset Configuration ......................................................................................67
Security................................................................................................................68
Administrator Password ................................................................................68
User Password..............................................................................................68
Web Server ...................................................................................................69
Certificates...........................................................................................................69
System Logs........................................................................................................70
Syslog Settings .............................................................................................70
Network Trace...............................................................................................71
Download Log...............................................................................................71
Provisioning Using Configuration Files............................................... 72
The Provisioning Process.................................................................................................73
Resynchronization: configuration file checking....................................................74
VSP600A restart..................................................................................................74
Configuration File Types...................................................................................................75
Data Files..........................................................................................................................76
Configuration File Tips and Security.................................................................................77
Guidelines for the MAC-Specific configuration file...............................................77
Securing configuration files with AES encryption ................................................78
Configuration File Parameter Guide..................................................... 80
"sip_account" Module: SIP Account Settings ...................................................................81
General configuration file settings .......................................................................81
MAC-specific configuration file settings...............................................................89
"hs_settings" Module: Handset Settings...........................................................................91
MAC-specific configuration file settings...............................................................91
"network" Module: Network Settings.................................................................................92
General configuration file settings .......................................................................92
MAC-specific configuration file settings...............................................................93
"provisioning" Module: Provisioning Settings....................................................................96
"time_date" Module: Time and Date Settings.................................................................101
"log" Module: Log Settings..............................................................................................105
"remoteDir" Module: Remote Directory Settings.............................................................106
"web" Module: Web Settings ..........................................................................................110
"user_pref" Module: User Preference Settings............................................................... 111
"call_settings" Module: Call Settings ..............................................................................112
"file" Module: Imported File Settings...............................................................................114
General configuration file settings .....................................................................114
MAC-specific configuration file settings.............................................................115
"tone" Module: Tone Definition Settings..........................................................................116
"profile" Module: Password Settings...............................................................................119
General configuration file settings .....................................................................119
MAC-specific configuration file settings.............................................................119

5Back to Contents
VSP600A Administrator and Provisioning Manual
Troubleshooting................................................................................... 120
Common Troubleshooting Procedures...........................................................................120
Appendixes........................................................................................... 122
Appendix A: Maintenance...............................................................................................122
Appendix B: GPL License Information............................................................................123

Preface 6 Back to Contents
VSP600A Administrator and Provisioning Manual
PREFACE
Congratulations on your purchase of this VTech product. Please thoroughly read this
manual for all the feature operations and troubleshooting information necessary to install
and operate your new VTech product.
This administrator and provisioning manual contains detailed instructions for installing and
configuring your VSP600A SIP DECT base station with software version 1.1.1 or newer.
See “Using the Status menu” on page 15 for instructions on checking the software version
on the VSP600A. Please read this manual before installing the product.
Please print this page and record the following information regarding your product:
Model number: VSP600A
Type: Small to medium business SIP-endpoint base station
Serial number: _______________________________
Purchase date: _______________________________
Place of purchase: ____________________________
Both the model and serial numbers of your VTech product can be found on the bottom of
the console.
Save your sales receipt and original packaging in case it is necessary to return your
telephone for warranty service.

Preface 7 Back to Contents
VSP600A Administrator and Provisioning Manual
Text Conventions
Table 1 lists text formats and describes how they are used in this guide.
Audience
This guide is written for installers and system administrators. It assumes that you are
familiar with networks and VoIP, both in theory and in practice. This guide also assumes
that you have ordered your IP PBX equipment or service and selected which PBX features
you want to implement. This guide references specific IP PBX equipment or services only
for features or settings that have been designed for a specific service. Please consult your
equipment supplier or service provider for recommended switches, routers, and firewall
and NAT traversal settings, and so on.
As the VSP600A SIP DECT base station becomes certified for IP PBX equipment or
services, VTech may publish interop guides for those specific services. The interop guides
will recommend second-party devices and settings, along with VSP600A-specific
configurations for optimal performance with those services.
Related Documents
The VSP600A Quick Start Guide contains a quick reference guide to the VSP600A
external features and brief instructions on connecting the VSP600A to a working IP PBX
system.
The VSP600A User Guide contains a quick reference guide, full installation instructions,
instructions for making and receiving calls, and a guide to all user-configurable settings.
Table 1. Description of Text Conventions
Text Format Description
Screen Identifies text that appears on a device screen or a
WebUI page in a title, menu, or prompt.
HARD KEY or DIAL-PAD KEY Identifies a hard key, including the dial-pad keys.
Identifies a soft key.
Example of a Note.
Example of a Caution.
CallFwd
Notes provide important information
about a feature or procedure.
A caution means that loss of data or
unintended circumstances may result.

Introducing the VSP600A 8 Back to Contents
VSP600A Administrator and Provisioning Manual
CHAPTER 1
INTRODUCING THE VSP600A
This administrator and provisioning guide contains detailed instructions for configuring the
VSP600A SIP DECT base station. Please read this guide before attempting to configure
the VSP600A.
Some of the configuration tasks described in this chapter are duplicated in the Web User
Interface (WebUI) described in the next chapter, but if you need to assign static IP
addresses, they must be set at each device.
This chapter covers:
“About the VSP600A base station” on page 9
“Quick Reference Guide” on page 10
“Network Requirements” on page 12
“VSP600A Configuration Methods” on page 13

Introducing the VSP600A 9 Back to Contents
VSP600A Administrator and Provisioning Manual
About the VSP600A base station
The VTech VSP600A SIP DECT base station with VSP601Acordless handset is a cordless
business phone system designed to work with popular SIP telephone (IP PBX) equipment
and services. Once you have ordered and configured your SIP equipment or service, the
VSP600A and cordless handsets enable you to make and receive calls as you would with
any other business phone.
The VSP600A base station features include:
Up to 6 SIP account registrations
Up to 4 active SIP sessions (per account)
Registration of up to 6 DECT cordless handsets
Power over Ethernet
Handset locator
The VSP601 cordless handset features include:
Orbitlink Wireless Technology™
Backlit Liquid Crystal Display
Speakerphone, hold, intercom and mute capability
Corded headset jack
3-way conferencing
200-entry call history
You can configure the VSP600A using the menus on the VSP601 handset, a
browser-based interface called the WebUI, or an automatic provisioning process (see
“Provisioning Using Configuration Files” on page 72). The WebUI enables you to configure
the VSP600A using a computer that is connected to the same Local Area Network. The
WebUI resides on the VSP600A, and may get updated with firmware updates.

Introducing the VSP600A 10 Back to Contents
VSP600A Administrator and Provisioning Manual
Quick Reference Guide
The external features of the VSP600A base station and handset are described below.
VSP600
Use only
Supplied
Adapter
RESET
Antenna
Wall mount slot
(on top)
HandsetLocator
and registration
button
Power LED
VoIP LED
Front Back
AC Adapter input
Reset button
Ethernet port
