VABCHES D8L241HS03 User manual

1/16
D8L241HS0 3
WhatsApp community↑
[email protected]

2/16

Parts Identification
Not actual size
ABC D
E F GH
IJK L
MNOP
QRS
3/16
x 1 x 1 x 2 x 4
x 2 x 2 x 2 x 2
x 1 x 2 x 12 x 1
x 1 x 1 x 1 x 1
x 1 x 1 x 1

4/16
Parts Identification
Not actual size
K
K
G
G
E
F
E
F
C
CD
D
P
J
J
I
B
A
S
M
N
D
Q
L
D
O

Hardware List
Plastic buckle
M8 x 13mm 1/4" x 13mm 1/4" x 35mm
1/4" x 50mm
1/4" x 25mm
Ø3.5 x 15mm
M4 M5
1 x 4 2 x 63 3 x 4 4 x 4
5 x 16 6 x 9 7 x 24 8 x 2
9x 7 10 x 1 11 x 1
5/16
13
D+
SPEED
-
SPEED
+
MODE
DEMO
-
MODE
RF Wireless
+
BRIGHT
-
BRIGHT
+
COLOR
-
COLOR
x 1 x 1 x 1
12 x 1
BOLT BOLT BOLT BOLT
BOLT SCREW WIRE CLIP
LEDSTRIP CLIPS ALLEN KEY ALLEN KEY SOCKET

STEP 1
STEP 2
1/4" x 50mm
5 x 4
Front
M
N
M
N
A
Front
B
Front
Please pay attention to the direction
of the metal bolt plate.
N
C
S
6/16
1/4" x 13mm
2 x 10
2
5
M
Pls do not tighten all bolts until the
bed is assembled completely

STEP 3
STEP 4
7/16
Front
L
1/4" x 50mm
5 x 2
Please pay attention to the direction
of the metal bolt plate.
L
5
L
12
R
Ø3.5 x 15mm
6 x 2
6

STEP 5
STEP 6
8/16
R
2
1/4" x 13mm
2 x 10
Front
D
1/4" x 50mm
5 x 4
D
D
D
5
D
D
Please pay attention to the direction
of the metal bolt plate.

STEP 7
STEP 8
9/16
13
Stick LED strip underneath .
Q
Q
13
9
Use the extra clips to reinforce the strip.
9
6
THE ENDS OF LAMP BELT SUGGESTED TO BE
REINFORCED BY THE EXTRA CLIPS 9 . Ø3.5 x 15mm
9 x 7 6 x7
2
1/4" x 13mm
2 x 10
Q
13
13 R
The LED switch is free to put onto the
board or hidden underneath the board.
13
D+
SPEED
-
SPEED
+
MODE
DEMO
-
MODE
RF Wireless
+
BRIGHT
-
BRIGHT
+
COLOR
-
COLOR

STEP 9
STEP 10
10/16
2
1/4" x 13mm
2 x 10
O
13
12
13
8
8
Connect LED strip usb, usb adapter
and socket . Then buckle the lines
using wire clip .
12
8
13
8 x 2
WIRE CLIP
13

STEP 11
STEP 12
11/16
2
2
F
B
E
A
1/4" x 13mm
2 x 4
5
D
D
D
D
D
Please pay attention to the direction
of the metal bolt plate.
D
C
C
1/4" x 50mm
5 x 4

STEP 13
STEP 14
1/4" x 13mm
2x 4
2
2
12/16
F
E
1/4" x 13mm
2 x 8
P
2

STEP 15
STEP 16
13/16
F
F
E
E
H
H
2
H
1/4" x 13mm
2x 4

STEP 17
Expand the folded portion
14/16
G
G
STEP 18
X 2
H
H
G
G
24
H
G
1/4" x 35mm
4 x 4
1/4" x 13mm
2x 4

STEP 19
15/16
J
I
3
3
3
3
J
1/4" x 25mm
3 x 4
STEP 20
1
I
I
5
5
1
5
I
G
1/4" x 50mm
5x 2
M8 x 13mm
1 x 4

Assemble the slats
1.Insert slats into the hole on sidebar
in the correct orientation.
2.Push the slats into the gaps.
3.Put the plastic clamp(L) into the
lower part of hole on 45 degree.
4.Press tight the upper part of
clamp to fix its position.
KK
7
7
Kx12
16/16
STEP 21
