Parts Identification
Not actual size
ABC D
E F GH
IJK L
MNOP
QRS
3/16
x 1 x 1 x 2 x 4
x 2 x 2 x 1 x 2
x 1 x 2 x 12 x 1
x 1 x 1 x 1 x 1
x 1 x 1 x 1

4/16
Parts Identification
Not actual size
A
B
M
L
D
D
D
E
E
F
F
G
I
J
J
K
H
H
K
O
P
R
Q
N
S
C
C

Hardware List
Plastic buckle
M8 x 13mm 1/4" x 13mm 1/4" x 35mm
1/4" x 50mm
1/4" x 25mm
Ø3.5 x 15mm
M4 M5
5 x 15 6 x 9 7 x 20 8 x 2
9x 7 10 x 1 11 x 1
5/16
13
D+
SPEED
-
SPEED
+
MODE
DEMO
-
MODE
RF Wireless
+
BRIGHT
-
BRIGHT
+
COLOR
-
COLOR
x 1 x 1
12 x 1
BOLT BOLT BOLT BOLT
BOLT SCREW WIRE CLIP
LEDSTRIP CLIPS ALLEN KEY ALLEN KEY SOCKET
spare: 1 spare: 3 spare: 1 spare: 1
spare: 2 spare: 1 spare: 3
1 x 4 2 x 44 3 x 4 4 x 2
LEDSTRIP CABLE HOLE COVER

STEP 1
STEP 2
1/4" x 50mm
5 x 4
Front
M
N
M
N
A
Front
B
Front
Please pay attention to the direction
of the metal bolt plate.
N
6/16
1/4" x 13mm
2 x 6
5
M
Pls do not tighten all bolts until the
bed is assembled completely
side view
2
S

STEP 3
STEP 4
7/16
Front
L
1/4" x 50mm
5 x 2
Please pay attention to the direction
of the metal bolt plate.
L
5
L
12
R
Ø3.5 x 15mm
6 x 2
6
side view
12 x 1
SOCKET

STEP 5
STEP 6
8/16
1/4" x 13mm
2 x 6
Front
D
1/4" x 50mm
5 x 4
D
D
D
5
D
D
Please pay attention to the direction
of the metal bolt plate.
side view
2
R

STEP 7
STEP 8
9/16
13
Q
13
9
6
THE 2 ENDS OF LED STRIP MUST TO BE
REINFORCED BY LED STRIP CLIPS 9
13
D+
SPEED
-
SPEED
+
MODE
DEMO
-
MODE
RF Wireless
+
BRIGHT
-
BRIGHT
+
COLOR
-
COLOR
There are no screw holes on board(Q), you
can choose suitable positions to fix the
clips with screws.
Ø3.5 x 15mm
9 x 7 6 x7
Stick LED strip13 underneath board
Q
.then put the
clips 9
on LED strip and fasten it with screws 6 to
reinforce the LED strip.
2
U
V
R
Q
1/4" x 13mm
13
2 x 6
The switch is free to put onto the board
or hidden underneath the board.

STEP 9
STEP 10
10/16
1/4" x 13mm
2 x 6
8
13
12
8
Connect lamp strip usb, usb adapter and
socket . stick clip underneath board
Then buckle the lines.
12
8
R
8x 2
WIRE CLIP
R
2
O

STEP 11
STEP 12
11/16
5
D
D
D
D
D
Please pay attention to the direction
of the metal bolt plate.
D
C
C
1/4" x 50mm
5 x 4
side view
2
2
1/4" x 13mm
2 x 4
F
E
A
B

STEP 13
STEP 14
1/4" x 13mm
2x 4
12/16
1/4" x 13mm
2 x 6
2
P
2
2
F
E
P

STEP 15
STEP 16
13/16
F
F
E
E
1/4" x 13mm
2x 4
H
H
2
H

STEP 17
Expand the folded portion
G
G
X 1
14/16
STEP 18
2
G
4
H
1/4" x 35mm
4 x 2
1/4" x 13mm
2x 2
HG

STEP 19
15/16
J
I
3
3
3
3
J
1/4" x 25mm
3 x 4
1
I
5
5
11/4" x 50mm
5 x 1
M8 x 13mm
1 x 4
I
STEP 20

Assemble the slats
1.Insert slats into the hole on sidebar
in the correct orientation.
2.Push the slats into the gaps.
3.Put the plastic clamp(7) into the
lower part of hole on 45 degree.
4.Press tight the upper part of
clamp to fix its position.
KK
7
7
16/16
STEP 21
Plastic buckle
7 x 20
K x10
