VABCHES D8L222HS03 User manual

1-24
D8L222HS03
D8L222BS03
As this item contains many parts, please read the installation
instruction carefully before installation . Please use tools
properly and carefully. If you have any questions about the
product and installation, please contact us.
Our professional after-sales team will serve you online all
[e-mail]
day.
WhatsApp community↑

Before You Start
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing,
please be aware of to slow down and stop when screw is tight.
Failure to do so may result in stripping the screw. （Assembly
speed can be increased by using electric screwdriver）
Helpful Hints
- Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Identify, sort and count the parts before attempting assembly.
- Compression dowels are lightly tapped in with a hammer.
- Slides are labeled with an R (right) and L (left) for proper placement.
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge.
- If there is a back panel in the package, please install it to make sure your unit is
complete and sturdy.
-Please fix all the screws provided for the back panel which can enhance product
stability. If it is difficult to fix it when tightening, it can be fixed with the help of a
hammer and then tightened.
- Do NOT use harsh chemicals or abrasive cleaners on this item.
- Never push, pull, or drag your furniture.
PEOPLE NEEDED FOR ASSEMBLY: 1-2
2-24

Board Identification
Not actual size
TOP
Qty:1
RIGHT SIDE PANEL
Qty:1
LEFT SIDE PANEL
Qty:1
3-24
BACK BOARD
Qty:1
FRONT SLAT PANEL
Qty:1
BACK BOARD
Qty:1
DRESSING MIRROR
Qty:1
FRAME TOP BOARD
Qty:1
UPPER SIDE PANEL
Qty:2
DRAWER FRONT
Qty:1
DRAWER RIGHT PANEL
Qty:1
DRAWER LEFT PANEL
Qty:1
A B C
D E F
G H I
J K L

Board Identification
Not actual size
DRAWER BACK PANEL
Qty:1
DRAWER MIDDLE PARTITION
Qty:1
DRAWER BOTTOM
Qty:1
4-24
DRAWER SUPPORT RAIL
Qty:1
STOOL SIDE PANEL
Qty:2
STOOL BACK APRON
Qty:1
STOOL FRONT APRON
Qty:1
SPONGE CUSHION
Qty:1
STOOL BOTTOM BOARD
Qty:1
M N O
P Q R
S T U

Not actual size
Board Identification
5-24
A
B
C
D
E
F
G
H
H
I
J
K
L
M
N
O
U
R
R
S
T
Q
P

Part List
Ø15X11mm
1
CAM LOCK
spare:2
X13
6-24
2
CAM LOCK
spare:1
X5
Ø6.5X35mm
3
CAM BOLT
spare:2
X18
Ø8X40mm
4
WOOD DOWEL
spare:2
X28
Ø6X30mm
5
WOOD DOWEL
spare:1
X4 6
SCREW
spare:1
X7 7
SCREW
spare:3
X35 8
SCREW
spare:2
X20
9
SCREW
spare:1
X2 10
LIGHT BULB
X1 set
110*10*16mm
11
HANDLE
X1 12CL
LEFT CABINET MEMBER
X1
12CR
RIGHT CABINET MEMBER
X1 12DL
LEFT DRAWER RUNNER
X1 12DR
RIGHT DRAWER RUNNER
X1 13
PERFECT STICKERS
spare:2
X32
14" 14" 14"
Ø15X9.5mm
14"
Ø4X35mm Ø6.3X50mm Ø3.5X14mm
M4X18mm
Ø21mm

7-24
Part List
14
HINGE
X2 15
ANTI-TIPPING HARDWARE
X1set
Ø25mm
Cam Lock
Fastening
System
Insert the cam bolt into the
hole first, then insert the
cam lock and lock it.
1
3
2
4
The opening must point toward the
edge of the board
16
PLUG BOARD
17
HAIR DRYER RACK
X1 X1
18
SCREW
spare:1
X2 19
SCREW
spare:1
Ø3X12mm
X2
Ø4X12mm

STEP1
8-24
X6
8
B
C
X1
12CL X1 12CR
14" 14"
LEFT CABINET MEMBER
8
8
8
RLGHT CABINET MEMBER
8
12CL
12CR
X4
4
∅3.5X14mm ∅8X40mm
4
8
8
UP
UP

STEP2
9-24
X12
4
∅8X40mm
D E
IH
H x 2
4

STEP3
10-24
X12
7X12 13
∅21mm
7
13
B
C
E
F
D
These two holes are on the down side of the board.
∅6.3X50mm

STEP4
11-24
X13
3X2 5
Ø6X30mm
3
A
G
5
The foam in the packing box is placed under the mirror to
prevent scratches.

STEP5
12-24
X4
7X9 1
Ø15X11mm
H
HI
G
IH
H
7
1
Proper orientation of CAM LOCK
UNLOCK
LOCK
X4
13
∅21mm
13
∅6.3X50mm

STEP6
13-24
X7
7
7
G
A
H
∅6.3X50mm

STEP7
14-24
X4
1
A
G
B
C
1
Ø15X11mm
Proper orientation of CAM LOCK
UNLOCK
LOCK

STEP8
15-24
X2
18
Ø3X12mm
X2
19
Ø4X14mm
X1
16 X1 17
18
16
17
19
You can install the hair dryer rack(17) on
the left or right according to your needs
C
B

STEP9
16-24
X5
3
5
2
6
3
P
O
L
K
M
J
J
N
M
K
L
O
N
P
Proper orientation of CAM LOCK
UNLOCK
LOCK
X2
5X5 2
Ø6X30mm Ø15X9mm
X7
6
Ø4X35mm

STEP10
17-24
X1
12DL X1 12DR X6
14" 14"
8
Ø3.5X14mm
8
8
8
8
8
8
LEFT DRAWER RUNNER
RIGHT DRAWER RUNNER
26DL
26DL
K
L

STEP11
18-24
X2
9X1 11
9
9
11
M4X18mm
Cabinet Slide
Drawer Slide
13
X4
13
∅21mm

STEP12
19-24
X1 set
10
Pass the bulb wire through the pre punched plate, then gently press the
bulb and make it adhere to the plate.
Tear off a layer of 3M
polyethylene foam.

STEP13
20-24
Connect the lights according to the figure.
First connect the switch with the first bulb,
and then connect other bulbs in series.
1.Pass the bulb wire through the pre punched plate, then gently press the bulb and make it adhere
to the plate, and then connect the adjacent bulbs successively through the wire head slot on the
opposite side (corresponding to the line of the same color).
2.You can use the switch to turn on or off the light when you are putting on makeup, long press the
switch to adjust the brightness of the light.
ON / OFF
same color correspond
When connecting the interface, please note
that the colors of the wires at both ends
correspond one by one
