Vacon NX User manual

vacon nx
ac drives
optci
modbus/tcp option board
user manual

2 • vacon Introduction
Tel. [phone] • Fax [phone]
INDEX
Document code: DPD00900A
Last edited: 26.1.2012
1. Introduction ....................................................................................................................... 3
2. Ethernet board technical data............................................................................................ 4
2.1 Overview....................................................................................................................................4
2.2 LED indications .........................................................................................................................4
2.3 Ethernet ....................................................................................................................................5
2.4 Connections and Wiring............................................................................................................6
3. Installation......................................................................................................................... 7
3.1 Installing the Ethernet Option Board in a Vacon NX Unit .........................................................7
3.2 NCDrive .....................................................................................................................................9
3.3 IP Tool NCIPConfig....................................................................................................................9
4. Commissioning ................................................................................................................ 13
5. MODBUS/TCP................................................................................................................... 15
5.1 Overview..................................................................................................................................15
5.2 MODBUS/TCP vs. MODBUS RTU.............................................................................................16
5.3 Ethernet Option Board's Modbus Addresses..........................................................................16
5.4 Supported Modbus Functions .................................................................................................16
5.5 Coil Register............................................................................................................................16
5.6 Input Discrete..........................................................................................................................18
5.7 Holding Registers....................................................................................................................20
5.8 Input Registers........................................................................................................................24
6. Start-up Test.................................................................................................................... 27
6.1 Frequency Converter Settings ................................................................................................27
6.2 Master Unit Programming......................................................................................................27
7. Error Codes and Errors.................................................................................................... 28
7.1 Frequency Converter Error Codes..........................................................................................28
7.2 Modbus TCP ............................................................................................................................28
8. Appendix .......................................................................................................................... 29

Introduction vacon • 3
24-hour support [phone] • Email: [e-mail]
1
1. INTRODUCTION
Vacon NX frequency converters can be connected to Ethernet using an Ethernet fieldbus board
OPTCI.
The OPTCI can be installed in the card slots D or E.
Every appliance connected to an Ethernet network has two identifiers; a MAC address and an IP
address. The MAC address (Address format: xx:xx:xx:xx:xx:xx ) is unique to the appliance and cannot
be changed. The Ethernet board's MAC address can be found on the sticker attached to the board or
by using the Vacon IP tool software NCIPConfig. Please find the software installation at
www.vacon.com
In a local network, IP addresses can be defined by the user as long as all units connected to the
network are given the same network portion of the address. For more information about IP
addresses, contact your Network Administrator. Overlapping IP addresses cause conflicts between
appliances. For more information about setting IP addresses, see Section 3, Installation.
WARNING!
Internal components and circuit boards are at high potential when the frequency
converter is connected to the power source. This voltage is extremely dangerous
and may cause death or severe injury if you come into contact with it.
If you need further information related to EtherNet/IP, please contact [email protected].

4 • vacon installation
Tel. [phone] • Fax [phone]
3
2. ETHERNET BOARD TECHNICAL DATA
2.1 Overview
General
Card Name OPTCI
Ethernet
connections
Interface RJ-45 connector
Communications
Transfer cable Shielded Twisted Pair
Speed 10 / 100 Mb
Duplex half / full
Default IP-address 192.168.0.10
Protocols
EtherNet/IP
Environment
Ambient operating
temperature
–10°C…50°C
Storing
temperature
–40°C…70°C
Humidity <95%, no condensation allowed
Altitude Max. 1000 m
Vibration
0.5 G at 9…200 Hz
Safety
Fulfils EN50178 standard
Table 1. EtherNet/IP board technical data
2.2 LED indications
Figure 1-2, LED indications on the OPTCI board
LED: Meaning:
H4 LED in ON when board is powered
H1 Blinking 0,25s ON / 0,25s OFF when board firmware
is corrupted (chapter 3.2.1 NOTE).
OFF when board is operational.
H2 Blinking 2,5s ON / 2,5s OFF when board is ready for
external communication.
OFF when board is not operational.

Ethernet board technical data vacon • 5
24-hour support [phone] • Email: [e-mail]
3
2.3 Ethernet
EtherNet/IP™ was introduced in 2001 and today is the most developed, proven and complete
industrial Ethernet network solution available for manufacturing automation. EtherNet/IP is a
member of a family of networks that implements the Common Industrial Protocol (CIP™) at its
upper layers. CIP encompasses a comprehensive suite of messages and services for a variety of
manufacturing automation applications, including control, safety, synchronization, motion,
configuration and information. As a truly media-independent protocol that is supported by hundreds
of vendors around the world, CIP provides users with a unified communication architecture
throughout the manufacturing enterprise.
Common use-cases of Ethernet – devices are ‘human to machine’ and ‘machine to machine’.
Basic features of these two use-cases are presented in the pictures below.
1. Human to machine (Graphical User interface, relatively slow communication)
Note! NCDrive can be used in NXS and NXP drives via Ethernet. In NXL drives this is not
possible.
NCDrive / NCIPConfig
interface
-
Parameter
-
Slow rate actual
Values
-
Trends
-
Fault history
-
-
-
Ethernet switch

6 • vacon installation
Tel. [phone] • Fax [phone]
3
2. Machine to machine (Industrial environment, fast communication)
2.4 Connections and Wiring
The Ethernet board supports 10/100Mb speeds in both Full and Half-duplex modes. The
boards must be connected to the Ethernet network with a shielded CAT-5e cable. Use a so-
called crossover cable (at least CAT-5e cable with STP, Shielded Twisted Pair) if you want to
connect the Ethernet option board directly to the master appliance.
Use only industrial standard components in the network and avoid complex structures to
minimize the length of response time and the amount of incorrect dispatches.
More information on Ethernet can be found at www.odva.org.
PLC or Programmable Controller
Real
-
Time Control
-
Start/Stop, Direction,...
-
Reference
-
Feedback
PLC or Programmable Controller
PLC or Programmable Controller
-
Master
-
Start/Stop, Direction, ..
-
Reference
-
Feedback
Ethernet switch

Installation vacon • 7
24-hour support [phone] • Email: [e-mail]
3
3. INSTALLATION
3.1 Installing the Ethernet Option Board in a Vacon NX Unit
!
NOTE
MAKE SURE THAT THE FREQUENCY CONVERTER
IS SWITCHED OFF
BEFORE
AN OPTION OR FIELDBUS BOARD IS CHANGED OR ADDED!
A
Vacon NX frequency converter.
B
Remove the cable cover.
C
Open the cover of the control unit.

8 • vacon installation
Tel. [phone] • Fax [phone]
3
D
Install EtherNet/IP option board in slot
D or E on the control board of the
frequency converter. Make sure that the
grounding plate (see below) fits tightly in
the clamp.
E
Make a sufficiently wide opening for
your cable by cutting the grid as wide as
necessary.
F
Close the cover of the control unit and
the cable cover.

Installation vacon • 9
24-hour support [phone] • Email: [e-mail]
3
3.2 NCDrive
NCDrive software can be used with the Ethernet board in NXS and NXP drives.
NOTE! Does not work with NXL
NCDrive software is recommended to be used in LAN (Local Area Network) only.
NOTE! If OPTCI Ethernet Option board is used for NC Tools connection, like NCDrive, the OPTD3
board can not be used.
NOTE! NCLoad does not work via Ethernet. See NCDrive help for further information.
3.3 IP Tool NCIPConfig
To begin using the Vacon EtherNet/IP board, you need to set an IP address. The factory default IP
address is 192.168.0.10. Before connecting the board to the network, its IP addresses must be set
according to the network. For more information about IP addresses, contact your network
administrator.
You need a PC with an Ethernet connection and the NCIPConfig tool installed to set the EtherNet/IP
board's IP addresses. To install the NCIPConfig tool, start the installation program from CD or
download it from www.vacon.com website. After starting the installation program, follow the on-
screen instructions.
Once the program is installed successfully, you can launch it by selecting it in the Windows Start
menu. Follow these instructions to set the IP addresses. Select Help --> Manual if you want more
information about the software features.
Step 1. Connect your PC to the Ethernet network with an Ethernet cable. You can also connect
the PC directly to the device using a crossover cable. This option may be needed if your PC does not
support Automatic crossover function.
Step 2. Scan network nodes. Select Configuration --> Scan and wait until the devices connected to
the bus in the tree structure are displayed to the left of the screen.
NOTE!
Some switches block broadcast messages. In this case, each network node must be scanned
separately. Read the manual under Help menu!

10 • vacon installation
Tel. [phone] • Fax [phone]
3
Step 3. Set IP adresses. Change the node’s IP settings according to the network IP settings. The
program will report conflicts with a red color in a table cell. Read the manual under Help menu!
Step 4. Send configuration to boards. In the table view, check the boxes for boards whose
configuration you want to send and select Configuration, then Configure. Your changes are sent to
the network and will be valid immediately.
NOTE! Only A-Z, a-zand 0-9 symbols can be used in the drive name, no special characters, or
Scandinavian letters (ä, ö, etc.)! The drive name can be freely formed using the allowed characters.
3.3.1 Update OPTCI Option Board program with the NCIPConfig Tool
In some cases it may be necessary to update the option board's firmware. Differing from other Vacon
option boards, the EtherNet/IP option board's firmware is updated with the NCIPConfig tool.
NOTE! The IP addresses of the PC and the option board must be in the same area when the software
is loaded.
To start the firmware update, scan the nodes in the network according to the instructions in section
7. Once you can see all nodes in the view, you can update the new firmware by clicking the VCN
packet field in NCIPCONFIG 's table view on the right.
Click

Installation vacon • 11
24-hour support [phone] • Email: [e-mail]
3
After clicking the VCN packet field, a file open window where you can choose a new firmware packet
is displayed.
Send the new firmware packet to the option board by checking its box in the 'VCN Packet' field
at the right corner of the table view. After selecting all nodes to be updated by checking the
boxes, send the new firmware to the board by selecting 'Software' then 'Download'.
NOTE!
Do not do a power up cycle within 1 minute after downloading the option board software. This may
cause the option board to go to “Safe Mode”. This situation can only be solved by re-downloading the
software. The Safe Mode triggers a fault code (F54). The Board slot error F54 may also appear due to
a faulty board, a temporary malfunction of the board or disturbance in the environment.
1
2

12 • vacon installation
Tel. [phone] • Fax [phone]
3
3.4 Configure Option board parameters
These features are available from NCIPConfig tool version 1.6.
In the tree-view, expand the folders until you reach the board parameters. Slowly double-click the
parameter (
Comm. Time-out in figure below) and enter new value. New parameter values are
automatically sent to the option board after the modification is complete.
NOTE! If the fieldbus cable is broken at the Ethernet board end or removed, a fieldbus error is
immediately generated.

Modbus/tcp vacon • 13
24-hour support [phone] • Email: [e-mail]
4
4. COMMISSIONING
The Vacon EtherNet/IP board is commissioned with the control keypad by giving values to
appropriate parameters in menu M7 (or with NCIPConfig tool, read chapter
IP Tool
NCIPConfig
). Keypad commissioning is only possible with NXP- and NXS-type frequency
converters, not possible with NXL-type frequency converters.
Expander board menu (M7)
The
Expander board menu makes it possible for the user to see what expander boards are
connected to the control board and to reach and edit the parameters associated with the
expander board.
Enter the following menu level (G#) with the
Menu button right . At this level, you can browse
trough slots A to E with the
Browser buttons to see what expander boards are connected. On
the lowermost line of the display you see the number of parameter groups associated with the
board. If you still press the
Menu button right once you will reach the parameter group level
where there are one group in the Ethernet board case: Parameters. A further press on the
Menu button right takes you to Parameter group.
Ethernet/IP parameters
#
Name
Default
Range
Description
1 Comm. Timeout 10 0…255 s0 = Not used
2 IP Part 1 192 1…223 IP Address Part 1
3 IP Part 2 168 0…255 IP Address Part 2
4 IP Part 3 0 0…255 IP Address Part 3
5 IP Part 4 10 0…255 IP Address Part 4
6 SubNet Part 1 255 0…255 Subnet Mask Part 1
7 SubNet Part 2 255 0…255 Subnet Mask Part 2
8 SubNet Part 3 0 0…255 Subnet Mask Part 3
9 SubNet Part 4 0 0…255 Subnet Mask Part 4
10 DefGW Part 1 192 0…255 Default Gateway Part 1
11 DefGW Part 2 168 0…255 Default Gateway Part 2
12 DefGW Part 3 0 0…255 See Ch. 7
13 DefGW Part 4 1 0…255 See Ch. 7
14 InputAssembly - - NOT USED
15
OutputAssembly
-
-
NOT USED
Table 2. Ethernet parameters
IP Address
IP is divided to 4 parts. (Part = Octet) Default IP Address is 192.168.0.10.
Communication timeout
Defines how much time can pass from the last received message from the Client Device before
fieldbus fault is generated. Communication time out is disabled when given the value 0.
Communication timeout value can be changed from the keypad or with NCIPConfig tool (read
chapter
IP Tool NCIPConfig ).

14 • vacon Commissioning
Tel. [phone] • Fax [phone]
4
NOTE!
If fieldbus cable is broken from Ethernet board end, fieldbus error is generated immediately.
All Ethernet parameters are saved to the Ethernet board (not to the control board). If new
Ethernet board is changed to control board you must configure the new Ethernet board. Option
board parameters are possible to save to the keypad, with NCIPConfig tool or with NCDrive.
Unit Identifier
Modbus Unit Identifier is used to identify multiple endpoints at the Modbus server (i.e. gateway
to serial line devices). As there is only one endpoint the Unit Identifier default is set to it’s non-
significant value of 225 (0xFF). The IP address is used to identify the individual boards. It is
however possible to change it with the NCIPConfig tool. When 0xFF value is selected, also 0 is
accepted. If unit identifier parameter has different value than 0xFF, only this value is accepted.
-Default Unit Identifier changed from 0x01 to 0xFF in software version 10521V005.
-Added possibility to change Unit Identifier with NCIPConfig (V1.5) tool in software version
10521V006.

Modbus/tcp vacon • 15
24-hour support [phone] • Email: [e-mail]
4
5. MODBUS/TCP
5.1 Overview
Modbus/TCP is a variant of the MODBUS family. It is a manufacturer-independent protocol for
monitoring and controlling automatic devices.
Modbus/TCP is a client server protocol. The client makes queries to the server by sending
“request” messages to the server's TCP port 502. The server answers client queries with
“response” messages.
The term 'client' can refer to a master device that runs queries. Correspondingly, the term
'server' refers to a slave device that serves the master device by answering its queries.
Both the request and response messages are composed as follows:
Byte 0: Transaction ID
Byte 1: Transaction ID
Byte 2: Protocol ID
Byte 3: Protocol ID
Byte 4: Length field, upper byte
Byte 5: Length field, lower byte
Byte 6: Unit identifier
Byte 7: Modbus function code
Byte 8: Data (of variable length)
Figure 4-1. Modbus Transaction

16 • vacon Commissioning
Tel. [phone] • Fax [phone]
4
5.2 MODBUS/TCP vs. MODBUS RTU
Compared to the MODBUS RTU protocol, the MODBUS/TCP differs mostly in error checking
and slave addresses. As the TCP already includes an efficient error checking function, the
MODBUS/TCP protocol does not include a separate CRC field. In addition to the error checking
functionality, the TCP is responsible for resending packets and for splitting long messages so
that they fit the TCP frames.
The slave address field of the MODBUS/RTU is called unit identifier field in MODBUS/TCP.
5.3 Ethernet Option Board's Modbus Addresses
A Modbus/TCP class 1 functionality has been implemented in OPTCI board. The following table
lists supported MODBUS registers.
Name
Size
Modbus address
Type
Input Registers 16bit 30001-3FFFF Read
Holding
Register
16bit 40001-4FFFF Read / Write
Coils 1bit 00001-0FFFF Read / Write
Input discretes 1bit 10001-1FFFF Read
Table 3. Supported Registers
5.4 Supported Modbus Functions
Following table lists supporter MODBUS functions.
Function Code
Name
Access
Type
Address Range
1 (0x01) Read Coils Discrete 00000-0FFFF
2 (0x02) Read Input Discrete Discrete 10000-1FFFF
3 (0x03) Read Holding Registers 16 Bit 40000-4FFFF
4 (0x04) Read Input Registers 16 Bit 30000-3FFFF
5 (0x05) Force Single Coil Discrete 00000-0FFFF
6 (0x06)
Write Single Register
16 Bit
40000-4FFFF
15 (0x0F) Force Multiple Coils Discrete 00000-0FFFF
16 (0x10) Write Multiple
Registers
16 Bit 40000-4FFFF
23 (0x17) Read/Write Multiple
Registers
16 Bit 40000-4FFFF
Table 4. Supported Function Codes
5.5 Coil Register
The Coil register represents data in a binary form. Thus, each coil can only be in mode “1” or
mode ”0”. Coil registers can be written using the MODBUS function 'Write coil' (5) or the
MODBUS function 'Force multiple coils' (16). The following tables include examples of both
functions.

Modbus/tcp vacon • 17
24-hour support [phone] • Email: [e-mail]
4
5.5.1 Control Word (Read / Write)
See chapter 5.6.4.
Address
Function
Purpose
0001 RUN/STOP Control word, bit 1
0002 DIRECTION Control word, bit 2
0003 Fault reset Control word, bit 3
0004 FBDIN1 Control word, bit 4
0005 FBDIN2 Control word, bit 5
0006 FBDIN3 Control word, bit 6
0007 FBDIN4 Control word, bit 7
0008
FBDIN5
Control word, bit 8
0009 Not used Control word, bit 9
0010 Not used Control word, bit 10
0011 FBDIN6 Control word, bit 11
0012 FBDIN7 Control word, bit 12
0013 FBDIN8 Control word, bit 13
0014 FBDIN9 Control word, bit 14
0015 FBDIN10 Control word, bit 15
0016 Not used Control word, bit 16
Table 5. Control Word Structure
The following table shows a MODBUS query that changes the engine's rotation direction by
entering “1” for control-word bit 1 value. This example uses the 'Write Coil' MODBUS function.
Note that Control word is application specific and use of bits may vary depending on it.
Query:
0x00, 0x00, 0x00, 0x00, 0x00, 0x06, 0xFF, 0x05, 0x00, 0x01, 0xFF, 0x00
Data
Purpose
0x00 Transaction ID
0x00 Transaction ID
0x00 Protocol ID
0x00 Protocol ID
0x00 Length
0x06 Length
0xFF Unit identifier
0x05 Write coil
0x00 Reference number
0x01 Reference number
0xFF Data
0x00 Padding
Table 6. Writing a Single Control Word Bit

18 • vacon Commissioning
Tel. [phone] • Fax [phone]
4
5.5.2 Clearing trip counters
The frequency converter's operation day trip counter and energy trip counter can be reset by
entering “1” as the value of the coil in request. When the value “1” is entered, the device resets
the counter. However, the device does not change the Coil value after reset but maintains the
“0” mode.
Address
Function
Purpose
0017 ClearOpDay Clears OpDay counter
0018 ClearMWh Clears MWh counter
Table 7. Counters
The following table represents a MODBUS query that resets both counters simultaneously.
This example applies the 'Force Multiple Coils' function. The reference number indicates the
address after which the amount of data defined by the 'Bit Count' is written. This data is the
last block in the MODBUS/TCP message.
Data
Purpose
0x00 Transaction ID
0x00 Transaction ID
0x00 Protocol ID
0x00
Protocol ID
0x00 Length
0x08 Length
0xFF Unit identifier
0x0F Force multiple coils
0x00 Reference number
0x10 Reference number
0x00 Bit count
0x02 Bit count
0x01 ByteCount
0x03 Data
Table 8. Force Multiple Coils Query
5.6 Input Discrete
Both the 'Coil register' and the 'Input discrete register' contain binary data. However, the
difference between the two registers is that the Input register's data can only be read. The
Vacon Ethernet board's MODBUS/TCP implementation uses the following Input discrete
addresses.

Modbus/tcp vacon • 19
24-hour support [phone] • Email: [e-mail]
4
5.6.1 Status Word (Read Only)
See chapter 5.6.3.
Address
Name
Purpose
10001 Ready Status word, bit 0
10002 Run Status word, bit 1
10003 Direction Status word, bit 2
10004 Fault Status word, bit 3
10005 Alarm Status word, bit 4
10006 AtReference Status word, bit 5
10007 ZeroSpeed Status word, bit 6
10008 FluxReady Status word, bit 7
10009-
Manufacturer reserved
Table 9. Status Word Structure
The following tables show a MODBUS query that reads the entire status word (8 input
discretes) and the query response.
Query:
0x00, 0x00, 0x00, 0x00, 0x00, 0x06, 0xFF, 0x02, 0x00, 0x00, 0x00, 0x08
Data
Purpose
0x00 Transaction ID
0x00 Transaction ID
0x00 Protocol ID
0x00 Protocol ID
0x00 Length
0x06 Length
0xFF
Unit identifier
0x02 Read input discretes
0x00 Reference number
0x00 Reference number
0x00 Bit count
0x08 Bit count
Table 10. Status Word Read - Query
Response:
0x00, 0x00, 0x00, 0x00, 0x00, 0x04, 0xFF, 0x02, 0x01, 0x41
Data
Purpose
0x00 Transaction ID
0x00 Transaction ID
0x00
Protocol ID
0x00 Protocol ID
0x00 Length
0x04 Length
0xFF Unit identifier
0x02 Read input discretes
0x01 Byte count
0x41 Data
Table 11. Status Word Read - Response

20 • vacon Commissioning
Tel. [phone] • Fax [phone]
4
In the responses' data field, you can read the bit mask (0x41) that corresponds to the read
discrete status after shifting with the 'Reference number' field value (0x00, 0x00).
LSB 0x1 MSB 0x4
0
1
2
3
4
5
6
7
1 0 0 0 0 0 1 0
Table 12. Response's Data Block Broken into Bits
In this example, the frequency converter is in the 'ready' mode because the first 0 bit is set.
The motor does not run because the 6 bit is set.
5.7 Holding Registers
You can both read and write data from the MODBUS holding registers. The Ethernet board's
MODBUS/TCP implementation uses the following address map.
Address range
Purpose
0001 - 2000 Vacon Application ID’s
2001 - 2099 FBProcessDataIN
2101 - 2199
FBProcessDataOUT
2200 - 10000 Vacon Application ID’s
10301 – 10333 MeasureTable
10501 – 10530 IDMap
10601 - 10630 IDMap Read/Write
10634 - 65535 Not Used
Table 13. Holding Registers
5.7.1 Application ID
Application ID's are parameters that depend on the frequency converter's application. These
parameters can be read and written by pointing the corresponding memory range directly or
by using a so-called ID map (more information below). It is easiest to use a straight address if
you want to read a single parameter value or parameters with consecutive ID numbers. Read
restrictions, possible to read 12 consecutive ID address.
Address range
Purpose
ID
0001 - 2000 Application parameters 1 – 2000
2200 – 10000 Application parameters 2200 – 10000
Table 14. Parameter ID's
