VADO AXCES AX-SIR-140/RO/DIV Operation manual

BATH SPOUT WITH DIVERTER
AX-SIR-140/RO/DIV
INSTALLATION / USER GUIDE
Installation
In the required position prepare
an ½” connection (not supplied).
Connect the water supply and
flush through.
Note: the threaded connection
on the spout can be cut to size,
remove any burrs.
Using PTFE screw the spout into
the wall connection.
Shower hose
Place the rubber washer into the
shower hose and screw onto the
outlet on the bottom of the spout.
Operation
Pull up the diverter handle
and turn clockwise to lock into
position. Turn clockwise again to
release the diverter and go back
to the primary outlet.
Dimensions
Shower outlet
Nozzle
½" connection
Diverter
Threaded
connection
Cutting points
234mm
½" 185mm
49mm
Ø32mm
Ø50mm
½"
Please read these instructions carefully before starting installation and keep for future reference.
Remove all packaging and check the product for missing parts or damage before starting installation.
Any alterations made to this product and fittings may infringe water regulations and will invalidate the
guarantee. The installation must comply with all Local/National Water Supply Authority Regulations/Byelaws
and Building and Plumbing Regulations. To be installed in accordance with BS EN806.
When installed, the fitting must comply with the requirements of the Water Supply (Water Fittings)
Regulations 1999 and Scottish Byelaws 2004. For further information, contact the Water Regulations
department of your local water supplier (see the WRAS website www.wras.co.uk for details) or the Water
Regulations Advisory Scheme by email ([e-mail]) or telephone: [phone].
We strongly recommend that you use a qualified and registered plumber.
Before making any inlet pipe connections, all supply pipes MUST be thoroughly flushed to remove debris.
Failure to do so could result in damage or low flow from the fitting.
Please take great care when installing this fitting not to damage its surface.
Please note if installing in an enclosed environment, access should be left for servicing and maintenance.
No costs relating to inadequate access can be accepted.

Guarantee
All AXCES by VADO products come with a 2 year guarantee as standard. Within this guarantee period VADO
will provide replacement parts and any labour [SEE NOTE 1, GUARANTEE CONDITIONS] needed to complete
the product repair.
This standard guarantee may be extended by registering your product to give a 10 year guarantee (2 years
parts and labour plus 8 years on parts supply only.).
Operational components such as, but not limited to; thermostatic cartridges, diverters, headworks and flow
control, waste mechanisms, shower hoses, O-rings and seals are guaranteed for 2 years parts and labour
plus 3 years on parts supply only.
Guarantee Conditions
Our products are guaranteed against manufacturing defects from the date of purchase until the expiry of the
relevant guarantee period shown above.
The guarantee is only valid if:
•The product has been installed, used and maintained in accordance with VADO's instructions and subjected
to normal use only.
•The defect is not due to use of an unsuitable or inadequate water or power supply.
•The defect is not due to accident, misuse, neglect or incorrect/inappropriate repair (other than by VADO or
VADO authorised agents) or damage caused by foreign objects or substances.
•The extended guarantee is only available if you have completed the Guarantee Registration Process. This can
be done via the VADO website or via phone to our aftersales team. Registration must be completed within 6
months from date of purchase.
Under the extended guarantee period VADO will, at its option, offer to supply any replacement product (or
component part) assessed to be defective [SEE NOTE 2].
The guarantee (whether standard or extended) is non-transferable to any subsequent owner.
All claims under the guarantee should be notified in the first instance to our Aftersales department, contact
details below, this must be done no later than the last day of the relevant guarantee period. All claims must be
accom panied by proof of purchase (sales receipt or delivery note) from an official AXCES by VADO dealer.
The guarantee does not extend to any consequential loss or damage.
After repair or replacement, the relevant guarantee period will be calculated from the original date of
purchase.
VADO operates a policy of continuous product development and therefore reserves the right to change the
product, packaging and documentation specifications without notice.
NOTES:
[1] Labour via our engineer network is only available in the UK. Attendance by a VADO engineer or sub-
contract engineer will be under our standard terms and conditions.
[2] VADO reserves the right to charge in advance for a product (or replacement part) pendin collection and
investigation (at VADO expense) to confirm a defect is due to a manufacturing issue. If a defect is found the
charge will be refunded or cancelled.
This guarantee is in addition to and does not affect your statutory rights as a consumer.
Tel: [phone]
Email: [e-mail]
Cleaning instructions
The electroplating on this product is finished to the highest standard. Due care needs to be taken to ensure
the appearance is retained.
We recommend cleaning all products with a soft damp cloth ONLY and advise strongly against the use of
all aggressive/corrosive cleaning products i.e. powders and liquids. If these instructions are not followed,
this may invalidate your guarantee in the event of a problem occurring.
