VADO eli Installation and operating instructions

eli
Sink mixer
Installation & maintenance instructions
Please leave these instructions with the customer
Vado
Wedmore Road, Cheddar, Somerset, England BS27 3EB
tel [phone]. fax [phone]
[email protected]
www.vado-uk.com
Guarantee
Customer/technical services
For any technical or installation queries please contact Vado on 01934 745163.
GUARANTEE REGISTRATION
NAME
ADDRESS
RETAILER
ADDRESS
PURCHASE DATE
PRODUCT DESCRIPTION
WHO INSTALLED THE PRODUCT?
FOR VADO USE
POSTCODE
POSTCODE
ARTICLE NUMBER (SEE BOX)
RETAILER PLUMBER BUILDER SELF
This product is guaranteed against manufacturing defects from the date of purchase until the expiry of the relevant
guarantee period shown below.
The guarantee is only valid if:-
1. The product has been installed, used and maintained in accordance with Vado’s instructions and subjected to
normal use only.
2. The defect is not due to use of an unsuitable or inadequate water or power supply.
3. The defect is not due to accident, misuse, neglect or repair other than by Vado or Vado authorised agents or
damage caused by foreign objects or substances.
4. We have received from you the completed Guarantee Registration Form. Vado accepts no responsibility for any
forms lost in the post and returns by registered means is therefore recommended.
Under this guarantee (which is non-transferable) Vado will, at its option, repair or replace free of charge any product
(or replacement part) found to be defective. The guarantee does not extend to any consequential loss or damage.
After repair or replacement the relevant guarantee period will be calculated from the original date of purchase.
The relevant guarantee periods are:-
1. Twelve years on chrome nish products.
2. Six years on Vado Identity products.
3. Three years on all other products with the exception of Stuart Turner Pumps which carry a 2 year Guarantee on
Monsoon Range and 1 Year Guarantee on Showermate Range.
All claims under the guarantee must be submitted in writing to the person who supplied the product to you and
must be received no later than the last day of the relevant guarantee period. All claims must be accompanied by
proof of purchase (sales receipt or delivery note).
Vado operates a policy of continuous product development and therefore reserves the right to change the product,
packaging and documentation specications without notice.
This guarantee is in addition to and does not aect your statutory rights as a consumer.

Important - please read
General installation
27
Installers/users notes
Please read these instructions carefully before starting installation and keep for future
reference.
Remove all packaging and check the product for missing parts or damage before
starting installation.
Any alterations made to this product and ttings may infringe water regulations and
will invalidate the guarantee.
The installation must comply with all Local/National Water Supply Authority
Regulations/Byelaws and Building and Plumbing (UK:BS6700) Regulations.
We strongly recommend that you use a qualied and registered plumber.
These ttings are mixing devices and therefore water supplies must be reasonably
balanced.
This product must be installed in accordance with, and meet the requirements of the
Water Supply (Water Fittings) Regulations 1999 and Scottish Byelaws 2004.
Before making any inlet pipe connections, all supply pipes MUST be thoroughly
ushed to remove debris. Failure to do so could result in damage or low ow from the
mixer unit. Water Supply (Water Fittings) Regulations 1999 Schedule 2 Section 13.
The tting of isolating valves to the inlet feeds is advised for ease of maintenance.
Please take great care when installing this mixer not to damage its surface.
Please note if installing in an enclosed environment, access should be left for servicing
and maintenance. No costs relating to inadequate access can be accepted.
Care of the mixer
Our products are nished to the highest standard and due care needs to be taken to
ensure their looks are retained.
We recommend cleaning all products with a soft damp cloth ONLY and advise strongly
against the use of ALL cleaning products i.e. powders and liquids.
If the above instructions are not followed this will invalidate your guarantee in the
event of a problem occurring.

6
Dimensions
3
Operating Specications
Installers/users notes
370mm
Maximum operating pressure 5 bar
Minimum operating pressure 0.5 bar
158mm
240mm
360mm
210mm
40mm max

Installation
45
Operation
Turn o the water supply.
Remove all the ttings.
Position the mixer onto the sink
ensuring that the chrome base ring is
correctly tted between the mixer base
and the sink top.
From the underside of the sink slide the
rubber seal and nylon spacer over the
hoses. Slide the rubber washer over the
threaded stud followed by the washer
and nut. Tighten the nut to clamp the
mixer to the sink.
CAUTION: Do not over tighten the nut
as this may damage the basin.
Slide on the hose retainer, followed by
the small nut.
Screw the adaptor onto the exible hose
and then onto the end of the threaded
stud.
Fix the hose weight in position at the
bottom of the exible hose.
NOTE: The hose weight is adjustable to
ensure the smooth ow of the hose.
Before connecting to the water supply
ush though the supply pipes in order
to remove any debris.
Finally connect the red braided hose
to the hot water supply and the blue
braided hose to the cold supply.
Base ring
Rubber washer
Washer
Nut
Hose retainer
Flexible hose
Control
handle
Rubber seal
Move the mixer lever to the right to increase the ow of water.
Pull the mixer lever forward to increase the ow of cold water.
Push the mixer lever backwards to increase the ow of hot water.
Hand spray.
Pull out to use
by hand.
Hand spray
Nut
Nylon spacer
Adaptor
Flexible inlet hoses
Hose weight
Threaded stud
