VADO synergie SYN132 Installation and operating instructions

3 and 4 hole single lever bath shower mixer
please leave these instructions with the customer
synergie
Vado
Wedmore Road, Cheddar, Somerset, England BS27 3EB
tel [phone]. fax [phone]
[e-mail]
www.vado-uk.com
guarantee
customer/technical services
For any technical or installation queries please contact Vado on 01934 745163.
GUARANTEE REGISTRATION
NAME
ADDRESS
RETAILER
ADDRESS
PURCHASE DATE
PRODUCT DESCRIPTION
WHO INSTALLED THE PRODUCT?
FOR VADO USE
POSTCODE
POSTCODE
ARTICLE NUMBER (SEE BOX)
RETAILER PLUMBER BUILDER SELF
This product is guaranteed against manufacturing defects from the date of purchase until the expiry of the relevant
guarantee period shown below.
The guarantee is only valid if:-
1. The product has been installed, used and maintained in accordance with Vado’s instructions and subjected to
normal use only.
2. The defect is not due to use of an unsuitable or inadequate water or power supply.
3. The defect is not due to accident, misuse, neglect or repair other than by Vado or Vado authorised agents or
damage caused by foreign objects or substances.
4. We have received from you the completed Guarantee Registration Form. Vado accepts no responsibility for any
forms lost in the post and returns by registered means is therefore recommended.
Under this guarantee (which is non-transferable) Vado will, at its option, repair or replace free of charge any product
(or replacement part) found to be defective. The guarantee does not extend to any consequential loss or damage.
After repair or replacement the relevant guarantee period will be calculated from the original date of purchase.
The relevant guarantee periods are:-
1. Twelve years on chrome nish products.
2. Three years on all other products with the exception of Stuart Turner Pumps which carry a 2 year Guarantee on
Monsoon Range and 1 Year Guarantee on Showermate Range.
All claims under the guarantee must be submitted in writing to the person who supplied the product to you and
must be received no later than the last day of the relevant guarantee period. All claims must be accompanied by
proof of purchase (sales receipt or delivery note).
Vado operates a policy of continuous product development and therefore reserves the right to change the product,
packaging and documentation specications without notice.
This guarantee is in addition to and does not aect your statutory rights as a consumer.
installation & maintenance instructions
Syn 132.indd 1 10/2/10 11:05:12

important - please read
general installation
27
operation
Please read these instructions carefully before starting installation and keep for future
reference.
Remove all packaging and check the product for missing parts or damage before
starting installation.
Any alterations made to this product and ttings may infringe water regulations and
will invalidate the guarantee.
The installation must comply with all Local/National Water Supply Authority
Regulations/Byelaws and Building and Plumbing (UK:BS6700) Regulations.
We strongly recommend that you use a qualied and registered plumber.
These ttings are mixing devices and therefore water supplies must be reasonably
balanced.
Where connections are made to the mains cold water supply, WRC approved single
check valves must be tted to both hot and cold inlets. This is a stated requirement of
Water Supply (Water Fittings) Regulations 1999 Schedule 2, Section 6 G15.13.2
Before making any inlet pipe connections, all supply pipes MUST be thoroughly
ushed to remove debris. Failure to do so could result in damage or low ow from the
mixer unit. Water Supply (Water Fittings) Regulations 1999 Schedule 2 Section 4 G13.1
The tting of isolating valves to the inlet feeds is advised for ease of maintenance.
Please take great care when installing this mixer not to damage its surface.
Please note if installing in an enclosed environment, access should be left for servicing
and maintenance. No costs relating to inadequate access can be accepted.
care of the taps
Our products are nished to the highest standard and due care needs to be taken to
ensure their looks are retained.
We recommend cleaning all products with a soft damp cloth ONLY and advise strongly
against the use of ALL cleaning products i.e. powders and liquids.
If the above instructions are not followed this will invalidate your guarantee in the
event of a problem occurring.
Shower/spout lever -
diverts the ow of water
to either the shower or
the spout.
Moving the mixer lever upwards/
downwards will increase/decrease the
ow of water.
Moving the mixer lever from right
to left will increase the water
temperature.
Syn 132.indd 2 10/2/10 11:05:12

6
dimensions
3
Operating Specications
Operating Pressure:
Minimum operating pressure 3 bar
Maximum operating pressure 5 bar
installation - spout (optional) and shower
Rubber
washer
Nut
Connecting
tube
Shower
hose
Cover
plate
Washer
Hand set
Position the spout in place , and from the
underside slide on the rubber washer and
nut. Tighten the nut to clamp on the spout.
CAUTION: Do not over tighten the nut.
Connect the spout to the diverter using
the large exible pipe.
If you are installing the Synergie 132ns
(without spout) please ignore this
section.
Rubber
washer
Nut
Position the Cover plate/connecting
tube in place and from the underside
slide on the rubber washer and nut.
Tighten the nut to clamp on the cover
plate.
CAUTION: Do not over tighten the nut.
Place the rubber washer into the cone
end of the hose and screw to the
handset, thread the other end of the
shower hose down through the cover
plate and screw onto the bottom of the
diverter.
200mm
81mm
140mm
99mm 75mm
42
G3/4
82mm
6mm
6mm
37mm
34.8
220mm
max 45mm
max 45mm
max 45mm
max 45mm
G1/2
42
56mm 56mm 56mm
Syn 132.indd 3 10/2/10 11:05:13

4
installation - diverter valve
5
installation - tap
Metal
washer
Rubber
washer
Control
handle
Outlet pipe
to diverter
valve
Cold inlet
Control
handle
Cover
plate
Rubber
washer
Valve
splines
Nut
Valve
Screw the nut onto the valve body
followed by a rubber washer, push the
valve up through the hole in the unit.
Carefully push the control handle onto
the splines of the valve and secure in
position by screwing the cover plate
onto the valve.
From the underside tighten the nut to
secure the valve in place.
CAUTION: Do not over tighten the nut
as this might damage the unit.
Connect the valve to the tap, shower
and spout using the exible connectors.
Flexible pipe
outlet to
spout
Flexible pipe
inlet from
tap
Locking
ring
Locking
bolts
Hot inlet
Shower to
handset
Before installing your new mixer, ush
through the pipework to ensure removal
of debris, turn o the water supply.
Remove one of the exible pipes by
unscrewing, slide o the locking ring
metal washer and rubber washer.
Push the valve down through the hole
in the unit, slide the rubber washer,
metal washer and locking ring back over
the exible pipe and outlet pipe, screw
onto the valve until the locking bolts
touch the metal washer.
Tighten the locking nut to clamp the
mixer to the unit using the 2 locking
bolts.
CAUTION: Do not over tighten the bolts
as this may damage the unit.
Replace the exible pipe, hand tighten
only.
Connect the water supply to the
inlet pipes. The hot water should be
connected to the left pipe and the cold
to the right.
Connect the back outlet pipe to the
diverter using a exible pipe.
Washer
Washer
