PAGEPAC PLUS ZONE EXPANSION UNIT
V-5335100
by
PagePac®
INTRODUCTION
The Zone Expansion Unit (Z.E.U.) connects up to
16 zones of audio output (including talkback),
contact closure outputs or inputs.
SPECIFICATIONS (see Table 2)
FEATURES
• Provides same features as PP+ Controller
• Maximum of 3 Z.E.U.s per Controller
Power Requirements
• Power from the PP+ Controller through the
interconnect cable
Dimensions/Weight
• 16.00”W x 1.75”H x 6.875”D
(40.64cm x 4.45cm x 17.46cm)
• 3.0 lbs (1.35 kg)
Environment
• Temperature:0 to 40°C (32 to 104°F)
• Humidity: 5 to 95%
Locate in an area free of excess moisture, corro-
sive gases, dust and chemicals.
INSTALLATION
MOUNTING
NOTE: When installing the Zone Expansion Unit,
leave at least four inches of space above and
below for proper ventilation.
Installing the paging equipment in a ventilated
room where there is easy access to speaker
cabling (preferably in the telephone equipment
room). Disconnect all power before installing
equipment.
1. Mount the Zone Expansion Unit(s)(Z.E.U.) to
either a wall, cabinet or a rack (below the con-
troller).
2. Connect 8-pin Molex from Controller to first
Z.E.U., and next Z.E.U’s, if used.
NOTE: Up to 3 Z.E.U.s can be used, providing up
to 56 paging and/or control zones.
3. Set DIP switches on each Z.E.U.(s).
4. Set the Zone Option switches on the
Controller and Z.E.U.(s).
NOTE: For each zone used, no matter what its
function, this switch needs to be set to one of
three settings for proper zone operation before
applying power to the system.
The Controller has eight switches for zones 1-8.
Each subsequent Z.E.U. has switches for zones
9-24, 25-40, 41-56.
Refer to the Zone Map and Zone Configuration
Tables filled out during facility paging system
design. You can find these in the PagePac® Sys-
tem Installation and Configuration Guide.
5. Locate and mount all speakers in accordance
with the floor plan drawing for this installation.
6. Connect each speaker to the appropriate
Home Run or Speaker-to-Speaker wiring
scheme as shown on the floor plan.
NOTE: Adjust all speakers per volume and power
requirements as noted on floor plan, during or
after installation. Figures 7 and 8 show wiring
methods using local and zone connector blocks,
and contact closure zone applications.
Technical Manuals Online! - http://www.tech-man.comTechnical Manuals Online! - http://www.tech-man.com
firealarmresources.com

2947187
7. Test speaker wiring for short circuits.
Measure the resistance of each Home Run wiring
with an ohmmeter. Any pair indicating a value of
less than 15 Ohms must be rechecked for possi-
ble shorted wiring or speakers. Correct any prob-
lems and retest.
8. Make zone connections to Controller and
Z.E.U. (see Figures 5 thru 7).
The zone connectors on the Controller and Z.E.U.
can accommodate up to two 22 AWG wires or four
24 AWG wires per zone output. Check zone
option switch setting with Zone Map and Zone
Configuration tables as you connect each zone.
NOTE: DO NOT over tighten zone connector
screws.
Powering Up System
With all zones wired and connected to the Con-
troller and Z.E.U.(s), initial testing can begin.
Once initial testing is done, you can begin to pro-
gram the Controller with the features for each
zone.
1. Plug the power cord into the AC input connec-
tor on the AmpliCenter®. the following should
happen:
a. The green Power LED on the AmpliCenter
will turn on and stay on.
b. The green Page Access LED on the
AmpliCenter also turns on, but will go out
after a few seconds.
c. On the Controller, verify that the green
Phone System Enabled LED is off.
d. On the Controller, verify that the yellow
Attendant Access Enabled LED is off.
e. The green Power LED on the Z.E.U.(s) will
turn on and stay on.
NOTE: If during power up, the system does not
respond as described, refer to the Troubleshoot-
ing section of this guide, and/or the PagePac®
Plus System Installation and Configuration guide
for detailed troubleshooting.
2. Begin programming the Controller.
A quick reference card for telephone program-
ming, along with detailed programming instruc-
tions, can be found in the PagePac Plus System
Installation and Configuration Guide,
Programming.
TROUBLESHOOTING
Some common problems encountered when the
paging system is not operating are described
below. Check each item in the order listed.
1. No AC power to AmpliCenter or Controller
(they supply power to the Z.E.U.(s)).
2. Host telephone system failure.
3. Host system page port failure.
4. A hardwire disconnect between host system
and Controller.
5. AmpliCenter, Controller, or Z.E.U. zone
switches or DIP switch settings tampered with.
If the problem has not been resolved by checking
the preceding items, refer to the troubleshooting
tables in the PagePac Plus Installation and Con-
figuration Guide.
Controls and Indicators, Terminals and
Connectors
Figure 9 shows the controls and indicators, termi-
nals and connectors on the rear panel of the
Z.E.U.(s). Table 1 identifies them by function.
Table 1: Controls and Indicators, Terminals
and Connectors
1. Zone option 3-position slide switch: 70V
audio out, contact closure input, contact
closure output.
2. Zone connector for expansion zones: plus,
minus, and ground screw terminals.
3. 8-pin Molex connector from controller:
power, control, and audio or previous
Z.E.U.
4. 8-pin Molex connector to additional
Z.E.U.: power, control and audio.
5. DIP switch to be set when one, two, or
three Z.E.U.(s) are used.
Technical Manuals Online! - http://www.tech-man.comTechnical Manuals Online! - http://www.tech-man.com
firealarmresources.com

3947187
TECHNICAL ASSISTANCE
When calling, have a VOM and a telephone test
set available and call from the job site. Call (540)
427-3900 and ask for PagePac Technical Sup-
port, or call [phone] for Valcom 24-hour
Automated Support or visit our websites at
http://www.pagepac.com and www.valcom.com.
Should repairs be necessary, attach a tag to the
unit clearly stating company name, address,
phone number, contact person, and the nature of
the problem. Send the unit to:
PagePac®Repair Dept.
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019-5056
Capacities Each Z.E.U. connects up to 16 zones of audio output (including talkback), contact
closure outputs or inputs.
Dimensions and
Weights Height: 1.75” (4.4 cm)
Width: 16” (40.64 cm); 19” (48.3 cm) with brackets attached
Depth: 6.9” (17.53 cm)
Weight: 3.0 lbs (1.35 kg)
Electrical Relay
Contacts Control Contact Closure: Contacts are rated at 120VAC/50VDC at 1 Amp
Audio Zone: Contacts are rated at 2 Amps
Temperature Range: 0 to +40 deg. C (32 to 104 deg. F) operational
-40 to +66 deg. C (-40 to +150 deg. F) storage and shipment
Humidity Range: 5 to 95% (non-condensing) storage/shipment and operation
Altitude: Sea level to 10,000 ft. operational (1048 to 648 millibars) 40,000 ft. max. shipment
Environmental Locate in an area free of excess moisture, corrosive gases, dust, and chemicals
Interconnect Cable 8-position, 5 Amp contact rating, locking, keyed, 22 AWG wire, housing material
94V-2, providing 70.0 Vrms (4), common ground, +17VDC, Serial Data and Clock Data
Table 2. Z.E.U. Specifications
