Thank you for choosing Valley Acrylic Bath Ltd Products. This installation manual provides
general information on the installation of our products.
• Read all instructions before beginning installation.
• Consult local building codes to make sure the installation complies with standards.
• Remove the unit from its packaging. Before disposing of packaging , inspect the unit to make
sure it is in good condition.
• Should inspection reveal any damage or defect in the nish, Contact Valley Acrylic Bath Ltd. at
1-877-398-8827 . The warranty does not cover damages or defects in the nish once the unit has
been installed. The manufacturers responsibility for shipping damages ceases upon delivery of
the product in good order to the carrier. All complaints regarding damage due to transport must
be made directly to the carrier.
RISK OF PERSONAL INJURY OR PRODUCT DAMAGE. HANDLE WITH CARE. PRODUCT CAN BREAK,
CHIP OR CAUSE INJURY IF HANDLED CARELESSLY.
WE RECOMMEND THE INSTALLATION OF THIS PRODUCT BE DONE BY A LICENSED PROFESSIONAL
PLUMBER.
BEFORE YOU BEGIN
CAUTION
INSTALLATION GUIDE

website: www.valleyacrylic.com • E-mail: [email protected] • customer service call Toll Free: 1.877.398.8827 • Fax: [phone]
3
EASY DRAIN (A10135)
FREESTANDING BATHTUB DRAIN
SPECS
INSTALLATION GUIDE
Ø 7” / 178mm
3.5” / 89mm
Ø 2.5” / 64mm Measurements may vary ¼”
(Diagram Not to scale)
+
-
DISCLAIMER:
1 1/2” male and female adaptors
Threaded brass tailpiece
Easy Drain
ABS or PVC pipe
Gasket
Nut
A
B
C
D
E
F
A
A
B
B
C
C
D
D
E
E
F
F

website: www.valleyacrylic.com • E-mail: [email protected] • customer service call Toll Free: 1.877.398.8827 • Fax: [phone]
4
EASY DRAIN (A10135)
FREESTANDING BATHTUB DRAIN
01
02
03
Mark on the wood sub-oor the cutting location for the drain ange.
Cut 6-1/2” (16.5mm) hole into the wood sub-oor for the drain ange.
Assamble the drain (EasyDrain) • Insert assembly into oor opening.
EASY DRAIN INSTALLATION GUIDE
CUTTING
TEMPLATE
CUTTING
TEMPLATE

website: www.valleyacrylic.com • E-mail: [email protected] • customer service call Toll Free: 1.877.398.8827 • Fax: [phone]
5
EASY DRAIN (A10135)
FREESTANDING BATHTUB DRAIN
04
05
06
Screw the drain (EasyDrain) into place. • Install the Ceramic Tiles.
Turn the tub upside down for an easy installation. • Ensure you have the correct Waste & Overow.
FREESTANDING TUB INSTALLATION - TWO PEOPLE REQUIRED
Ax the appropiate brass tailpiece to the waste & overow.
DO NOT CUT THE SUPPLIED BRASS TAILPIECE, DOING SO MAY CAUSE A LEAK.
EASY DRAIN INSTALLATION GUIDE

website: www.valleyacrylic.com • E-mail: [email protected] • customer service call Toll Free: 1.877.398.8827 • Fax: [phone]
6
EASY DRAIN (A10135)
FREESTANDING BATHTUB DRAIN
07
08
09
Ensure the measurements between the base of the drain and the P-Trap will accomodate the tailpiece.
APPLY LUBRICANT TO THE TAILPIECE
Once the tailpiece is been installed on the waste & overlow, position the Tub and tailpiece in-line with the drain.
Carefully lower the tub with the installed brass tailpiece as vertical as possible into the red collar in drain
assembly.
EASY DRAIN INSTALLATION GUIDE
