Vallox A3712-1 User manual

Manual
Model
Vallox 096 MV
Vallox 110 MV
Vallox 145 MV
Type
A3722
A3702
A3712-1
Document
D5326
Valid from
15.10.2021
Updated
15.05.2023
Ventilation units
MANUAL

2
INTRODUCTION............................. . . . . . 2
Safety ................................................. . . . . . . . 3
Installation ............................................. . . . . . 3
Guarantee ............................................. . . . . . . . 3
Intended use ........................................... . . . . . . . 3
Disposal of the ventilation unit ........................... . . . . . . . 3
Safety signs used in the instructions ..................... . . . . . . . 4
Dierences between the models ......................... . . . . . . . 4
Installation options...................................... . . . . . . . 4
System description ..................................... . . . . . . . 4
Ventilation unit control .................................. . . . . . . . 5
Ventilation unit control options........................... . . . . . 5
Filter reminder ......................................... . . . . . 5
Ventilation unit setup without a MyVallox control panel ..... . . . . . 5
Connecting the ventilation unit to the cloud service ........ . . . . . 5
Main parts ............................................. . . . . . . . 6
Vallox 096 MV, Vallox 110 MV, and Vallox 145 MV .......... . . . . . 6
INSTALLATION................................ . . . . . .7
Vallox 096 MV, Vallox 110 MV, and Vallox 145 MV............... . . 7
Mounting on the wall .................................... . . . . . . . 7
Mounting on the ceiling ................................. . . . . . . . 7
Mounting the ceiling mounting plate...................... . . . . . 7
Installing the ventilation unit to the ceiling mounting plate . . . . . . . 8
Attic floor penetration plate.............................. . . . . . 8
Vallox 145 MV ............................................... . . 9
Mounting on a base ..................................... . . . . . . . 9
Measuring and adjusting the air flows of the ventilation unit . . . . . . . 9
Removal of condensing water ............................ . . . . . . 10
Dimensioning figure and space required for installation of the
Vallox Silent Klick siphon ................................ . . . . 10
Space required by the alternative Vallox Silent Klick siphon
installation method (elbow) .............................. . . . . 10
Vallox 096 MV, Vallox 110 MV, and Vallox 145 MV............... . 10
Dimensions and duct outlets............................. . . . . . . . 11
Vallox 096 MV ......................................... . . . . . 11
Vallox 110 MV .......................................... . . . . .12
Vallox 145 MV .......................................... . . . . .13
NOTE
You can register your
Vallox MV ventilation
unit with the MyVallox
Cloud service and sign
in into your MyVallox
Cloud account at
www.myvallox.com.
CONTENTS
INTRODUCTION
MAINTENANCE .............................. 14
Before beginning maintenance work...................... . . . 14
Changing the filters ..................................... . . . 14
Cleaning the heat recovery cell .......................... . . . 15
Condensing water ...................................... . . . 15
Cleaning the fans ....................................... . . . 16
Cleaning the supply air fan .............................. . 16
Cleaning the extract air fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
TECHNICAL SPECIFICATIONS . . 19
Internal electrical connection ............................ . . .22
Vallox 096 MV ......................................... .22
Vallox 110 MV, and Vallox 145 MV ......................... .23
External electrical connection............................ . . . 24
External electrical connection for controlling the
MLV duct radiator ....................................... . . .25
Duct radiator operation.................................. . . .26
Duct radiator operation chart ............................ . . . 27
In the outdoor air duct .................................. . 27
In the supply air duct.................................... . 27
Exploded view and parts list ............................. . . . 28
Vallox 096 MV ......................................... . 28
Vallox 110 MV .......................................... .29
Vallox 145 MV .......................................... .30
Conformity certificates .................................. . . . 31

3© Vallox Oy - All rights reserved
SAFETY
Safe and appropriate handling requires knowledge of the basic
safety regulations, and of the intended use of the ventilation
system. Read this manual before operating the ventilation unit.
Retain the manual for later reference. If you lose the manual, it can
be downloaded from our website.
This user manual contains all the information necessary for safe
operation of the system. All persons who operate and maintain
the ventilation system must follow the instructions provided in this
manual. Furthermore, all local accident prevention regulations must
be observed.
Installation
Installation and setup should be carried out only by qualified
experts. Electrical installations and connections must be carried
out only by an electrician and in compliance with local regulations.
GUARANTEE
The guarantee and liability exclude damage resulting from:
• Inappropriate use of the ventilation system or the control unit
• Incorrect or inappropriate installation, setup or use
• Neglect of instructions concerning transportation, installation,
use, or maintenance
• Structural or electronic modifications or changes made to the
software
INTENDED USE
All Vallox ventilation units have been designed to provide
appropriate and continuous ventilation so as to present no threat to
health and to maintain structures in good condition.
IMPORTANT
In order to ensure that the indoor air presents no harm to
health and remains optimal also for the structures of the
building, ventilation must be kept on without disruptions. It is
recommended that ventilation be left turned on during long
holidays also. This keeps the indoor air fresh and prevents
humidity from condensing in the ventilation ducts and
structures. It also reduces the risk of moisture damage.
DISPOSAL OF THE VENTILATION UNIT
Do not dispose of electronic devices with household waste. Follow
local laws and regulations on safe and ecological disposal of the
product.
NOTE
For further information,
go to www.vallox.com
INTRODUCTION
WARNING
The unit is not intended
for use by children
under 8 or by persons
with reduced sensory,
physical or mental
capabilities, or whose
lack of knowledge
and experience do not
ensure safe operation
of the unit.
Such persons can
use the unit under
supervision, or
by following the
instructions of someone
who is responsible for
their safety.
Children must be
supervised and not be
allowed to play with the
device.

4
SAFETY SIGNS USED IN THE INSTRUCTIONS
DIFFERENCES BETWEEN THE MODELS
• Power
• Size and weight
• Vallox 096 MV does not have an additional heater. Vallox 110 MV and
Vallox 145 MV have an additional heater.
• In Vallox 096 MV, there is a sealing tape at the bottom of the heat
recovery cell. In other models, there is a separate sealing bar under the
heat recovery cell.
INSTALLATION OPTIONS
• Models Vallox 096 MV and Vallox 110 MV can be mounted either on the
wall, or on the ceiling by using a mounting plate (optional).
• Vallox 145 MV can be mounted either on the wall, or on the floor by using
a floor rack (optional).
• Vallox 245 MV must always be installed on the floor by using a floor rack.
NOTE
The standard
equipment and
available accessories
vary from country to
country.
DANGER
Indicates a hazard that
will result in death or
serious injury if not
avoided.
WARNING
Indicates a hazard that
can result in death or
serious injury if not
avoided.
IMPORTANT
Indicates a hazard that
can result in damage to
property or loss of data
if not avoided.
CAUTION
Indicates a hazard that
can result in minor or
moderate injury if not
avoided.
NOTE
Indicates essential
information about the
product.
TIP
Provides additional
information about the
use of the product and
its benefits.
INTRODUCTION
SYSTEM DESCRIPTION
MyVallox Cloud
MyVallox Home
Vallox MV
MyVallox control panel
Modbus KNX
KNX bus
module
1
23
4
5
6
1. Internet
2. WLAN
3. Router
4. WLAN/LAN
5. Additional switch
6. Sensors

5© Vallox Oy - All rights reserved
VENTILATION UNIT CONTROL
Ventilation unit control options
Operation of the Vallox ventilation unit can be controlled by the
following means:
• Through the MyVallox control panel installed in the building.
• Through the MyVallox Home local area network connection and
the MyVallox Home/Cloud user interface.
• Through the MyVallox Cloud service and the MyVallox Home/
Cloud user interface.
• Through a remote monitoring service or building automation
that uses voltage signals or Modbus messages.
In addition to the integrated humidity and carbon dioxide sensor,
ventilation can also be adjusted automatically by using the optional
carbon dioxide, humidity, or VOC (air quality) sensor. When these
are used, ventilation remains optimal even when the dwelling
is unoccupied. Each user can use the week clock to adjust the
ventilation to fit their individual lifestyle.
Filter reminder
The unit reminds the user of the need to change the filters through
the MyVallox control panel and the MyVallox Home/Cloud user
interface, as well as by changing the relay status, if a signal light
has been connected to the relay connectors of the unit.
The filter reminder can be acknowledged:
• From the MyVallox control panel
• From the MyVallox Home/Cloud user interface
• From the Vallox Delico PTD EC and Vallox Capto PTC EC
control hoods — Damper closed, then open-closed-open-
closed. Press at a less than 1 second interval.
Ventilation unit setup without a MyVallox
control panel
The ventilation unit setup can also be completed without a
MyVallox control panel. For instructions, please go to
https://vallox.techmanuals.info/ValloxMV/ENG/help/webhelp
See instructions provided in the section Connecting the ventilation
unit to the computer.
Connecting the ventilation unit to the cloud
service
The ventilation unit can be connected to the MyVallox Cloud
service. The cloud service allows for controlling ventilation
remotely also, using e.g. a smartphone or tablet. Also the unit
software is updated automatically through the cloud service.
To connect to the cloud service, the ventilation unit must be
connected to the Internet via LAN and registered with the cloud
service. At the same time you create a MyVallox Cloud account for
yourself. Read more about the service at www.myvallox.com.
INTRODUCTION
NOTE
For the MyVallox Cloud/
Home instructions,
please go to
vallox.techmanuals.info/
ValloxMV/ENG/help/
webhelp
IMPORTANT
Apartment-specific
ventilation units allows
residents to adjust the
ventilation eciency.
Ventilation is controlled
based on the need e.g.
through the cooker
hood, ventilation
control panel, or a
separate control centre.
In order to ensure that
the indoor air presents
no harm to health and
remains optimal also
for the structures of the
building, ventilation
must be kept on
without disruptions.
It is recommended
that ventilation be
left turned on during
long holidays also.
This keeps the
indoor air fresh and
prevents humidity
from condensing in
the ventilation ducts
and structures. It also
reduces the risk of
moisture damage.
IMPORTANT
Prolonged overpressure
can result in damage
to the structures of the
building.

6
Extract air fan (behind the protective cover)
1
Supply air fan (behind the protective cover)
2
Fine filter for supply air
3
Heat recovery cell
4
Bypass damper of the HR cell
5
Coarse filter for supply air
6
Coarse filter for extract air
7
Post-heating resistor (behind the extract air duct)
8
R model in the figure
MAIN PARTS
Vallox 096 MV, Vallox 110 MV, and Vallox 145 MV
Safety switch 9
Internal humidity sensor 10
Internal carbon dioxide sensor 10
Control panel
11
Humidity sensor (optional)
12
Carbon dioxide sensor (optional) 13
VOC sensor (Optional) 14
Ceiling bushing for electric wires 15
INTRODUCTION
A
N
N
U
A
L
E
F
F
I
C
I
E
N
C
Y
R
A
T
I
N
G
O
F
E
X
T
R
A
C
T
A
I
R
H
E
A
T
R
E
C
O
V
E
R
Y
A+
5
11 12
13
3
1
6
4
14
15
2
7
8
9
10

7© Vallox Oy - All rights reserved
MOUNTING ON THE WALL
NOTE
Avoid mounting the unit on a hollow, echoing partition wall or
on a bedroom wall, or prevent the conduction of sound.
The minimum distance between the top of the unit and the
finished ceiling surface is 30 mm. Note that during mounting
the unit rises 10 mm higher than the final height.
Mount the ventilation unit onto the wall with a mounting plate
(optional), as shown in the figures below. Make sure that the unit is
horizontally level after mounting.
MOUNTING ON THE CEILING
Vallox 096 MV and Vallox 110 MV can be equipped with an optional
ceiling mount plate. To attach the ceiling mounting plate:
• On rafter frames or other frame structure with M8 thread bars so
that they withstand the weight of the unit.
• Ensure that the installation plate is horizontally level, as this
determines the position of the unit.
• The top edge of the white covering strip of the ceiling mounting
plate can be installed against the ceiling. Alternatively, a
concealed mounting method can be used, in which case the
ceiling can be 20mm below the top of the white covering strip.
Insulate the ducts against condensation also between the unit and
the ceiling mounting plate.
Mounting the ceiling mounting plate
1. Fasten the thread bars on the rafter frames or other frame
structure, and screw the nuts onto the bars.
2. Lift the ceiling mounting plate in place.
3. Push a rubber damper and a washer onto each thread bar, and ensure
that they touch the bottom of the cups of the plate (Vallox 096 MV).
4. Turn the nuts to make sure that the unit is horizontally level.
5. Shorten the lower ends of the thread bars so that they will be at no
more than 10 mm from the lower surface of the ceiling mounting plate.
CAUTION
The ventilation unit is very heavy. Do not perform this
procedure alone.
INSTALLATION
INSTALLATION
NOTE
When installing the
unit, reserve a sucient
space in front of the unit
for servicing purposes.
Mount the ventilation
unit in a place where
the temperature does
not fall below +10°C.
Vallox 096 MV: The
service space in front of
the unit must be at least
400 mm.
Vallox 110 MV:
The service space in
front of the unit must be
at least 450 mm.
Vallox 145 MV:
The service space in
front of the unit must be
at least 550 mm.

8
TIP
You can detach the
unit from the ceiling
mounting plate by
pulling the spring-
loaded moulding to the
direction shown by the
arrow (more detailed
information provided
with the ceiling
mounting plate).
INSTALLATION
a
b
1
B
2
4
53
B
F
A
A
Installing the ventilation unit to the ceiling
mounting plate
1. Install the ceiling mounting plate with M8 thread bars so that it
is horizontally level.
NOTE
The end of the thread bars must be 5 mm or less below the
fastening nut. Do not fasten the ceiling mounting plate too
tight to the ceiling. Ensure that the sliding bars move and
restore to their original position by pulling from the operating
levers (A). The top edge of the white covering strip of the
ceiling mounting plate can be installed against the ceiling.
Alternatively, a concealed mounting method can be used, in
which case the ceiling can be 20 mm below the top of the
white covering strip.
2. 096 - Install the insulation washers into the outlet collars of the
ventilation unit.
110 - Ensure that the insulation washers are in place in the
outlet collars below the ceiling mounting plate.
3. Remove the door before installing the ventilation unit to the
ceiling mounting plate.
4. Lift the ventilation unit close to the ceiling mounting plate and
feed the cables and the connection box through the hole in the
ceiling mounting plate on top of the ceiling.
NOTE
Remember to make a service door in the ceiling so that
the cables and the connection box can be accessed. The
distance between the service door and the ceiling mounting
plate must be around 500 mm.
Alternatively, the cables can be fed between the ceiling
mounting plate and the ventilation unit to the rear wall. When
the ventilation unit is lifted against the ceiling mounting plate,
the unit locks in place. Where needed, guide the mounting
hooks on the ceiling mounting plate (B) to the grooves on the
side panels of the ventilation unit. There are operating levers
(A) on the front bottom corners of the ceiling mounting plate.
When the levers have been restored to the same level with the
white covering strip of the ceiling mounting plate, the unit has
been locked in place.
5. Where required, the unit can be detached from the ceiling
mounting plate. Remove the door of the unit. Lift the unit
slightly upwards and pull simultaneously from both operating
levers (A) of the ceiling mounting plate to detach the unit from
the ceiling mounting plate.
Attic floor penetration plate
The attic floor penetration plate (F) is optional. When an attic floor
penetration plate is used, the tightness of the vapour barrier has to
be ensured.
The minimum distance of the attic floor penetration plate from
the rear wall is 5mm. The minimum distance of the attic floor
penetration plate from the side walls is 15mm.
NOTE
Mount the ventilation
unit in a place where
the temperature does
not fall below +10°C.

9© Vallox Oy - All rights reserved
INSTALLATION
30
30
495
435
625
685
465
655
80
23 min.
30
133 min.
8
Ø 8
Ø 22
A
B
MOUNTING ON A BASE
NOTE
Vallox 145 MV must always be installed on a base on the
floor, or on the wall using a mounting plate.
The base is optional. Adjust the base with adjusting legs to
level it. Remove the (4 pcs) rubber plugs at the bottom of
the unit. Place the unit on top of the base so that the bars of
the base fit in the holes at the bottom of the unit. Mount the
ventilation unit on the wall with a mounting plate, as shown
in the adjacent figure. Make sure that the unit is horizontally
level after mounting.
A Thread bar M8 x 35, shorter thread upward
B The length of the adjusting screw is 37mm.
MEASURING AND ADJUSTING THE AIR
FLOWS OF THE VENTILATION UNIT
The accessories delivered with the unit include four (4) air flow
measuring tubes. These can be inserted in the ducts to allow for
easier ventilation adjustment.
92
1
Ø6
16
NOTE
Mount the ventilation
unit in a place where
the temperature does
not fall below +10°C.

10
REMOVAL OF CONDENSING WATER
NOTE
The Vallox Silent Klick siphon package is delivered with the
unit. Installation instructions for the siphon are enclosed with
the packaging, and can also be found online at www.vallox.
com. When the alternative siphon installation method is used,
the ring seal and the locking part must be moved to the pipe
connection part that is mounted on the wall.
INSTALLATION
Dimensioning figure and space required for installation of the Vallox
Silent Klick siphon
Space required by the alternative Vallox Silent Klick siphon installation
method (elbow)
Vallox 096 MV
R
L
55
R
L
121
143
143
121
L
140 140
R
141
43
43
180180
141
141
141
75
28
28
38
Vallox 110 MV Vallox 145 MV
Vallox 096 MV Vallox 110 MV Vallox 145 MV

11 © Vallox Oy - All rights reserved
INSTALLATION
DIMENSIONS AND DUCT OUTLETS
Vallox 096 MV
Main parts Dimensions and duct outlets
Dimensions
A
B
1
2
3
4
5
6
7
8
9
600
545
583
38
93
102
298
363
600
141
459
407
430
R
1
2
3
4
93
102
298
363
600
141
459
407
430
1
2
3
4
L
143
6
380
424
125
125
3
4
35
12
3
4
3
5
1 2
1. Extract air fan
(behind the protective cover)
2. Supply air fan
(behind the extract air duct)
3. Fine filter for supply air
4. Heat recovery cell
R model in the figure.
In the L model, the parts are mirrored
5. Bypass damper of the HR cell
6. Coarse filter for supply air
7. Coarse filter for extract air
8. Post-heating resistor
(behind the extract air duct
9. Safety switch
Air flow measurement points
A Supply air
B Extract air
Measurement points after the outlet
collar. The fan curves indicate the
total pressure accounted for by duct
losses.
1. Supply air
2. Extract air
3. Coarse filter
Locations of supports for HR cell
L modelR model
4. Fine filter
5. Upper support for HR cell
Duct outlets
Inner diameter of the outlet collar: 125mm
1. Supply air from the unit to the apartment
2. Extract air from the apartment to the unit
3. Exhaust air flowing outdoors from the unit
4. Outdoor air to the unit

12
Vallox 110 MV
INSTALLATION
28
678
706
638
455
472
638
111
325
112
390
160
478
L
1
2
3
4
455
472
638
111
325
112
390
160
478
R
1
2
3
4
142
4
429
473
160
160
1
2
3
4
5
6
7
8
9
10
A
B
3
4
3
12
5
6
3
4
3
1 2
5
6
1. Extract air fan
(behind the protective cover)
2. Supply air fan
(behind the extract air duct)
3. Fine filter for supply air
4. Heat recovery cell
5. Bypass damper of the HR cell
R model in the figure.
In the L model, the parts are mirrored
6. Coarse filter for supply air
7. Coarse filter for extract air
8. Post-heating resistor
(behind the extract air duct)
9. Safety switch
10. Additional heating resistor
(behind the extract air duct)
Air flow measurement points
A Supply air
B Extract air
Measurement points after the outlet
collar. The fan curves indicate the
total pressure accounted for by duct
losses.
Locations of supports for HR cell
L modelR model
Duct outlets
Inner diameter of the outlet collar: 160mm
1. Supply air from the unit to the apartment
2. Extract air from the apartment to the unit
3. Exhaust air flowing outdoors from the unit
4. Outdoor air to the unit
1. Supply air
2. Extract air
3. Coarse filter
4. Fine filter
5. Upper support for HR cell
6. Lower support for the HR cell
Main parts Dimensions and duct outlets
Dimensions

13 © Vallox Oy - All rights reserved
Vallox 145 MV
INSTALLATION
9
8
2
7
10
4
6
3
1
5
748
42
717
25
560
578
127
411
717
125
455
180
537
313
405
491
200
1
2
3
4
R
560
578
127
411
717
125
455
180
537
313
405
491
200
L
1
2
3
4
142
5
529
574
A
B
3
4
3
12
5
6
3
4
3
1 2
5
6
Main parts Dimensions and duct outlets
Dimensions
1. Extract air fan
(behind the protective cover)
2. Supply air fan
(behind the extract air duct)
3. Fine filter for supply air
4. Heat recovery cell
5. Bypass damper of the HR cell
R model in the figure.
In the L model, the parts are mirrored
6. Coarse filter for supply air
7. Coarse filter for extract air
8. Post-heating resistor
(behind the extract air duct)
9. Safety switch
10. Additional heating resistor
(behind the extract air duct)
Duct outlets
Inner diameter of the outlet collar: 200mm
1. Supply air from the unit to the apartment
2. Extract air from the apartment to the unit
3. Exhaust air flowing outdoors from the unit
4. Outdoor air to the unit
Air flow measurement points
A Supply air
B Extract air
Measurement points after the outlet
collar. The fan curves indicate the
total pressure accounted for by duct
losses.
1. Supply air
2. Extract air
3. Coarse filter
L model
4. Fine filter
5. Upper support for HR cell
6. Lower support for the HR cell
R model
Locations of supports for HR cell

14
BEFORE BEGINNING
MAINTENANCE WORK
The safety switch (S) automatically turns o the power
when the door of the unit is opened.
WARNING
Always disconnect the power plug before starting
the ventilation unit maintenance.
There are two unit models, left- (L) and right-handed (R).
The figure shows the right-handed model.
CHANGING THE FILTERS
When the maintenance reminder becomes activated,
check the cleanliness of the filters and replace them if
required.
The Vallox ventilation unit has three air filters:
• Coarse filter for supply air filters insects, heavy pollen
and other relatively large foreign objects out of the
outdoor air.
• Fine filter for supply air filters microscopic pollen and
dust particles out of the supply air.
• Coarse filter for extract air filters the extract air and
keeps the heat recovery cell clean.
The filter replacement interval depends on the ambient
particle concentration. It is recommended that the filters
be replaced every spring and autumn, or at the very least
once a year.
To replace the filters:
1. Disconnect the ventilation unit from the mains
electricity supply.
2. Lift the latch to open the door of the Vallox ventilation
unit.
3. Lift the door o.
CAUTION
The door is heavy.
4. Remove the old filters (A, B, C) and discard them.
5. Install the new filters (A, B, C).
6. Close the door of the unit. Ensure that the safety
switch catch of the door is touching the safety switch,
allowing the unit to be turned on.
7. Plug the ventilation unit back into the mains.
The filters have now been successfully replaced.
TIP
Using original Vallox
filters ensures that the
ventilation unit remains
in top condition, giving
the best results. To
select and order filter
packages, please go to:
filters.vallox.com
MAINTENANCE
MAINTENANCE
IMPORTANT
If the power cord
is damaged, the
manufacturer, its
service representative
or other person with
similar qualifications
must replace it to avoid
danger.
NOTE
Vallox 096 MV: The
service space in front of
the unit must be at least
400 mm.
Vallox 110 MV:
The service space in
front of the unit must be
at least 450 mm.
Vallox 145 MV: The
service space in front of
the unit must be at least
550 mm.

15 © Vallox Oy - All rights reserved
CLEANING THE HEAT RECOVERY CELL
Check that the heat recovery cell is clean roughly once a year,
or whenever the filters are being replaced. Clean by washing as
required.
To check and clean the heat recovery cell:
1. Disconnect the ventilation unit from the mains electricity
supply.
2. Open the Vallox ventilation unit door by first lifting the latch
fully up and then lowering it back a little way.
3. Lift the door o.
CAUTION
The door is heavy.
4. Remove the filters (A, B, C).
5. Remove the sealing strip (E) above the cell in the direction
of the arrow.
6. Lift and pull the cell (D) out of the unit.
IMPORTANT
Handle the cell carefully! For example, do not lift the
cell by the layers. The cell layers are very thin and easily
damaged.
7. If the cell is dirty, clean it by immersing it in warm water, to
which a small amount of a mild detergent has been added.
8. Rinse the cell clean with a water spray. Do not use a high-
pressure cleaner.
9. When all the water has drained from between the layers,
reassemble the ventilation unit in the reverse order.
10. When reassembling Vallox 096 MV, check that the sealing
strip below the cell is pressed against the bottom of the unit.
11. Close the door. Ensure that the safety switch catch of the
door is touching the safety switch.
12. Plug the ventilation unit back into the mains.
The heat recovery cell has now been checked and cleaned.
MAINTENANCE
CONDENSING WATER
In the heating season, the extract air humidity condenses to
water. In new buildings, condensation runo can form rapidly.
Condensed water must be able to freely leave the unit.
At some time before the heating season begins (e.g. during
autumn maintenance), check that the siphon or the condensing
water outlet in the bottom pool are not clogged. To check this,
pour some water into the pool. Clean as required.
NOTE
Some condensing water
may have accumulated
in the bottom pool
of the unit; this is
normal and requires no
corrective action.
WARNING
Water must at all times
be kept out of the
electrical system.

16
CLEANING THE FANS
Check the cleanliness of the fans when servicing the filters and
the heat recovery cell. Clean the fans as required.
You can clean the fan blades with compressed air (wear protective
goggles) or by brushing them gently. Do not remove or move the
fan blade balancing weights.
Cleaning the supply air fan
To clean the supply air fan:
1. Disconnect the ventilation unit from the mains electricity
supply.
2. Lift the latch to open the door of the Vallox ventilation unit.
3. Lift the door o.
CAUTION
The door is heavy.
4. Remove the extract air filter (C), the cell top bracket (E) and the
heat recovery cell (D). See chapters “Replacing the filters” and
“Cleaning the heat recovery cell”.
5. Pull out the temperature sensor (figure 1) located at the top
of the extract air duct (G). Remove the stopper screw (I) at the
bottom of the duct. The extract air duct now comes out by
turning and pushing it downwards simultaneously (figure 2).
6. Remove the temperature sensor from the resistor support
(figure 4).
7. Remove the additional and post-heating resistor support,
which is attached by two wing nuts (Vallox 110 MV and Vallox
145 MV) or screws (Vallox 096 MV) from below (figure 5).
MAINTENANCE
IMPORTANT
The fans are
extremely sensitive
to external shocks. It
is recommended that
the fans be cleaned
in place, i.e. without
attempting to remove
them.
Handle the fan blades
carefully. Do not
remove or move the
fan blade balancing
weights.
1 1 det 32
4 5 6 7

17 © Vallox Oy - All rights reserved
MAINTENANCE
8. Pull the radiator and the support out of the unit (figures
6 and 7) and remove the quick connector of the radiator
wires.
CAUTION
Before removing the resistor from the unit, make
sure it is not hot.
9. The fan can now be cleaned in place. It is
recommended that the fan be cleaned in place, i.e.
without attempting to remove it.
10. To remove the fan for cleaning:
a. If necessary, remove the arm pins. Use pliers to
press the pins straight, so that they are easier to
install back later.
b. Push the fan gently upward (figure 9).
c. Pry the plastic lock to the right of the fan with a
screwdriver, for example (figure 10).
d. The fan falls downwards.
e. Pull the fan out of the unit (figure 11).
f. Disconnect the fan wire quick connector (figure 12).
The fan has now been removed for cleaning.
11. To reassemble the ventilation unit, follow the above
steps in reverse order.
TIP
When you re-install the temperature sensor,
position it with the tip upward and pointing at the
wall in such a way that it does not get squeezed
between the HR cell bypass damper or lean against
the radiator frame.
12. Close the door. Ensure that the safety switch catch of
the door is touching the safety switch.
13. Plug the ventilation unit back into the mains.
The fan has now been checked and cleaned.
8
10
9
11
12

18
MAINTENANCE
Cleaning the extract air fan
To clean the extract air fan, proceed as follows:
1. Disconnect the ventilation unit from the mains electricity supply.
2. Lift the latch to open the door of the Vallox ventilation unit.
3. Lift the door o.
CAUTION
The door is heavy.
4. Remove the filters (C), the cell top support (E) and the heat recovery cell
(D). See chapters “Replacing the filters” and “Cleaning the heat recovery
cell”.
5. Open the four screws (figure 1) on the extract air fan cover and remove
the cover (figure 2). The fan can now be cleaned in place.
6. To remove the fan for cleaning:
a. Push the fan gently upward (figure 3).
b. Pry the plastic lock to the right of the fan with a screwdriver, for
example (figure 4).
c. The fan falls downwards (figure 5).
d. Pull the fan out of the unit.
e. Disconnect the fan wire quick connector (figure 6).
7. Clean the fan.
8. To reassemble the ventilation unit, follow the above steps in reverse
order.
9. Close the door and plug the unit back into the mains.
The extract air fan has now been checked and cleaned.
1 32
4 5 6

19 © Vallox Oy - All rights reserved
TECHNICAL SPECIFICATIONS
FAN INPUT POWER
Input power (total) (W)
Air flow (max) (dm/s)
SFP = SFP rate (Specific Fan Power)
recommended value <1.8 (kW m3/s)
Volume flow rate
Power (W)
SUPPLY/EXTRACT AIR VOLUMES
Volume flow rate (dm3/s)
Pressure loss in ducts. Total pressure (Pa)
extract air
supply air
0
50
100
150
200
250
300
0 10 20 30 40 50 60 70 80 90 100
80 %
70 %
60 %
50 %
40 %
30 %
20 %
10 %
100 %
L
SFP 1,0
SFP 1,5
SFP 1,2
036 72 108 144180 216 252 m³/h
(l/s)
dm³/s
288 324 360
30 %
50 %
10 % 20 %
40 %
60 %
70 %
80 %
100 % 90 %
0
20
40
60
80
100
120
140
160
180
200
0 10 20 30 40 50 60 70 80 90 100
0 36 72 108 144 180 216 252 288 324 360
m³/h
(l/s)
dm³/s
Sound power level in the supply air duct (one duct)
by octave band Lw, dB
Sound power level in the extract air duct (one duct)
by octave band Lw, dB
Adjustment position Adjustment position
Adjustment position (%) 10 20 30 40 50 60 70 80 90 100 10 20 30 40 50 60 70 80 90 100
Medium
frequency
of the
octave
band
Hz
63 54 64 69 74 76 80 84 87 87 86 51 56 63 66 70 73 76 78 79 79
125 50 56 62 66 70 73 77 80 82 81 43 46 52 55 60 63 66 68 71 71
250 46 54 59 63 66 69 72 75 77 77 33 38 44 47 51 55 58 61 63 63
500 40 48 54 57 61 63 66 68 70 71 29 38 44 47 51 54 57 59 61 61
1000 34 44 51 55 60 62 64 66 68 68 24 32 38 42 46 49 52 55 57 57
2000 21 35 44 49 54 57 61 63 66 66 13 17 24 29 33 36 39 42 44 44
4000 17 23 34 41 47 51 55 58 61 61 17 17 18 20 23 26 29 32 34 34
8000 21 21 26 34 42 47 52 56 59 59 21 21 21 21 21 22 23 25 27 27
LW,dB
LWA, dB(A)
56 65 70 75 78 81 85 88 89 88 52 56 64 66 71 74 76 79 80 80
42 50 57 61 64 67 70 73 75 75 33 39 45 48 52 55 58 61 63 63
Sound pressure level coming through the envelope of the unit in the room in which it is installed (10m sound absorption)
Adjustment position
Adjustment position (%) 10 20 30 40 50 60 70 80 90 100
LpA, dB (A) 24 28 34 33 37 41 44 46 48 48
SOUND VALUES
TECHNICAL SPECIFICATIONS
Product title
Vallox 096 MV R
Vallox 096 MV L
Product number
3474450
3474550
Air volumes
Supply air
Extract air
84 dm3/s, 100 Pa
88 dm3/s, 100 Pa
Fans
Supply air
Extract air
0.119 kW 0.9 A EC
0.119 kW 0.9 A EC
Post-heating Electrical resistor, 900 W Electrical connection 230 V, 50 Hz, 5.1 A power plug
Pre-heating –Enclosure protection class IP34
Additional heating –Heat recovery bypass Automatic
Filters
Supply air
Extract air
ISO Coarse > 75 % + ISO ePM
ISO Coarse > 75 %
Specific energy consumption (SEC)
in a cold climate
in a temperate climate
A+
A
Operating eciencies*
Annual eciency
Supply air eciency
Specific Fan Power (SFP)
77 %
86 %
1.33 kW/m/h (59 dm/s)
Dimensions (w x h x d) 600 x 545 x 428 mm Weight 53 kg
*Working point defined in the Ecodesign Directive (2009/125/EC), Southern Finland, Helsinki-Vantaa TRY year 2012.
You can calculate the sound values for each operating point with the Vallox MySelecta software.

20
TECHNICAL SPECIFICATIONS
FAN INPUT POWER SUPPLY/EXTRACT AIR VOLUMES
Volume flow rate
Power (W)
Volume flow rate (dm3/s)
Pressure loss in ducts. Total pressure (Pa)
Input power (total) (W)
Air flow (max) (dm/s)
SFP = SFP rate (Specific Fan Power)
recommended value <1.8 (kW m3/s)
extract air
supply air
Sound power level in the supply air duct (one duct)
by octave band Lw, dB
Sound power level in the extract air duct (one duct)
by octave band Lw, dB
Adjustment position Adjustment position
Adjustment position (%) 10 20 30 40 50 60 70 80 90 100 10 20 30 40 50 60 70 80 90 100
Medium
frequency
of the
octave
band
Hz
63 53 60 67 71 74 78 82 83 84 84 54 46 62 65 69 72 75 77 79 79
125 48 56 61 66 70 74 76 78 80 80 42 44 50 53 58 61 64 66 68 68
250 46 53 58 62 65 69 71 74 76 76 34 41 46 50 53 56 60 62 64 64
500 40 48 56 57 60 62 65 67 68 69 26 35 40 43 46 49 52 55 57 57
1000 31 42 50 55 58 61 64 65 67 67 18 28 34 38 41 45 47 50 52 51
2000 18 32 40 46 52 56 60 62 64 64 13 17 24 29 33 36 39 42 44 44
4000 17 20 30 38 44 49 53 56 59 59 17 17 18 19 21 24 27 31 33 33
8000 21 21 25 34 42 48 53 57 59 60 21 21 21 21 21 22 24 26 29 29
LW,dB
LWA, dB(A)
55 62 69 73 76 80 83 85 86 86 55 57 62 66 70 72 75 78 79 79
41 49 56 60 63 67 69 72 73 73 33 38 43 46 50 53 56 59 60 60
Sound pressure level coming through the envelope of the unit in the room in which it is installed (10m sound absorption)
Adjustment position
Adjustment position (%) 10 20 30 40 50 60 70 80 90 100
LpA, dB (A) 21 24 30 32 35 39 42 45 47 47
SOUND VALUES
TECHNICAL SPECIFICATIONS
Product title
Vallox 110 MV R
Vallox 110 MV L
Product number
3446650
3446750
Air volumes
Supply air
Extract air
96 dm3/s, 100 Pa
103 dm3/s, 100 Pa
Fans
Supply air
Extract air
0.119 kW 1.0 A EC
0.119 kW 1.0 A EC
Post-heating Electrical resistor, 900 W Electrical connection 230 V, 50 Hz, 8.5 A power plug
Pre-heating –Enclosure protection class IP 34
Additional heating Electrical resistor, 900 W Heat recovery bypass Automatic
Filters
Supply air
Extract air
ISO Coarse > 75 % + ISO ePM
ISO Coarse > 75 %
Specific energy consumption (SEC)
in a cold climate
in a temperate climate
A+
A
Operating eciencies*
Annual eciency
Supply air eciency
Specific Fan Power (SFP)
79 %
86 %
1.15 kW/m3/h (71 dm3/s)
Dimensions (w x h x d) 638 x 678 x 472 mm Weight 64 kg
*Working point defined in the Ecodesign Directive (2009/125/EC), Southern Finland, Helsinki-Vantaa TRY year 2012.
You can calculate the sound values for each operating point with the Vallox MySelecta software.
