Vapor Clean Pro6 Duo User manual

Owner's Manual
Steam Cleaner
Duo
Pro6
For Home and Business

Notes

Please read instructions carefully before operating your machine.
Index
Pro6 Duo Features Page 1
Accessory Overview
Accessory Overview
Page 3
Accessory Overview
Page 4
Accessory Overview
Page 5
Important Safety Instructions
Page 6
Page 7
Page 8
Page 9
Page 10
Page 11
Modify for Grout Line
Grounding
Start Up
Maintenance
Troubleshooting
Page 2
Technical Specifications Page 12

Pro6 Duo Features
1
Pop off Reservoir Cap to add water to reservoir.1.
2. Cord Winder to wrap 14ft power cord securely for storage.
3. Fully adjustable Steam Output Regulator.
4. Pressure Gauge
5. The Low Water Light illuminates
and the audible signal will also alert you
when to add water to the reservoir.
6. The Steam Ready Light turns solid
upon ready and flashes as boiler is
heating during use.
7. Boiler Power Switch - Main Power
8. Steam Power Switch - Steam Power
9. Heavy-duty Hose Port with locking
mechanism allows you to pull by the hose
with no worry of damaging the connection.
10. Durable Wheels maneuver and
glide where you need to go with ease.
11. Accessible Boiler Drain Plug
12. The Extended Rubber Bumper
protects against damage done to
your vehicles, furniture and shins
during use. No Sharp Edges!
1

Carefully read the instructions contained in this handbook as they provide
important information concerning use and maintenance.
Do not add detergents or other additives. Use only filtered water.
Safely store or dispose of the large plastic bag and any other packaging that
is a suffocation hazard.
Do not operate the machine if there seems to be an issue. Contact qualified
personnel.
Make sure the machine is plugged directly into a standard US electrical
outlet.
Never remove the ground plug from the electrical cord.
Do not use extensions and/or adapters; whenever their use is
indispensable, only use single adapters or multiple adapters and extensions
complying with safety standards. Cords must be 12 gauge or heavier.
Do not use the product if the cord or plug are damaged. For possible cable
replacement or repair, see Authorized Technical Assistance Center.
If the machine is dropped or tips over, immediately switch it off and
disconnect the power plug. Do not use the product after any anomalous
functioning.
This machine must only be used for the purpose for which it is expressly
designed e.g., the cleaning and maintenance of surfaces. Any other use may
be deemed improper and dangerous. The manufacturer cannot be held
responsible for any damages due to improper, incorrect, or unreasonable
use.
Do not operate the machine in the presence of explosives, highly flammable
substances, gas or flames.
Never leave the machine unattended in the presence of children.
Do not allow children or anyone unfamiliar to operate the machine without
adequate supervision.
Disconnect the plug from the socket before emptying the boiler and/or
before any cleaning or maintenance operation.
When deciding to dispose of/discard the machine, make sure to render it
unusable by cutting off the power cord! Also make sure to render harmless
all those parts that could constitute a potential danger, especially for
children.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
Important Safety Instructions
WARNING! Danger - Never direct the steam jet at
persons, animals, power outlets, electrical
appliances or cleaning appliances.
WARNING
Hot Steam
2

2 x Extension Wands
3
1 x Window Squeegee
Accessory Overview
1 x Triangle Brush w/ Clips
This brush can be used the same way as the Rectangle
Floor Brush w/ Clips. You can also add a towel or pad
and sanitize mattresses, couches, chairs and more.
This accessory is suitable for windows, mirrors, doors,
shower tiles etc.
This heavy duty extended nozzle is perfect for hard to
reach areas around toilets, sinks and drains! It is used
independently as a crevice tool.
1 x Extended Silicone Covered Jet Nozzle
1 x Single Hole Jet Nozzle
This nozzle is best used with small detail brushes and
medium nylon brushes or independently for a more
precise application.
1 x 3 Hole Jet Nozzle
This three hole jet nozzle offers broader coverage.
Designed with 3 ports that provide an equal steam flow.
Connecting the nozzle to the medium triangle brush
attachment enables the user to clean sinks, stove tops,
ovens and more.
Best with Detail Brushes
Two rapid-assembly tubes are provided to obtain the
length desired. Used together with the flexible hose,
enables floor cleaning. Thermal insulation within the
aluminum exterior.
Maximum Length: 95 inches.
Best with Medium Triangle Brush
1 x 9.5 Ft. Standard Hose
Durable 9.5 ft Flexible Hose with heavy duty brass port
fittings.

2 x Stainless Steel Scrubbies
4
1 x Medium Nylon Round Brush
Accessory Overview
1 x Medium Nylon Triangle Brush
Our medium nylon triangle brush has three pressure points
for optimum cleaning when combined with the three hole jet
nozzle. This brush can be used on stove tops, counters, sinks,
dishwasher interior, fridge interior, glass shower doors etc.
This accessory can be used on the same surfaces as the
medium triangle brush. Insert a metal scrubby and attach
your 3 hole nozzle to increase the temperature.
These 16 x 16 microfiber towels are an essential when steam
cleaning. The fibers act as a trap, collecting all of the dirt and
grime that was loosened from steaming and they are
machine washable.
Enhance your cleaning by inserting these scrubbies in the
medium nylon brushes with the provided three hole jet nozzle.
When combined with the super heated steam, they will
conduct heat increasing the "tip" temperature.
2 x Microfiber Towels
1 x Filler Bottle w/ Cap
1.2 liter Capacity Fill Bottle with Cap

Check the O-rings on the extension wands for
damage.
Check the O-rings on the connector for damage.
5
Accessory Overview
All the accessories are fitted the same way. Fit the required accessory on the gun of
the flexible hose.
Caution! Make sure to work initially with a weak steam flow and increase the
steam setting accordingly by operating your steam regulator knob (3).
8 Nylon, 1 Stainless and 1 Brass Detail Brush. These brushes
are very versatile and best used with your single hole jet
nozzle.
10 x Detail Brushes
(See page 7 for modifying detail brushes to fit your grout line.)
1 x Large O-Ring is for the water level sensor (only replaced
by qualified technician).
2 x Medium O-Rings are for the Extension Wands and
Nozzle.
2 x Small O-Rings are for the boiler drain plug and mono-
block nipple.
A little Vaseline or dielectric grease applied on your O-Rings will increase their lifespan.
1 x Replacement O-Ring Kit
Check the O-rings on the safety handle for damage.

6
1 x Rectangle Floor Brush w/ Clips & Carpet Glider
Accessory Overview
The Carpet Glider covers the bristles on the floor brush, allowing the user
to sanitize rugs and carpets without damaging the fibers. Can be used with
or without a towel clipped on. The glider can be removed when you are
ready to clean hard surface floors.
Carpet Glider Disassembly
To remove glider, use the open side (fig.1). Release the locking fixtures by
tapping gently (fig.2 and fig. 3) to remove the glider cover completely (fig.4).
Carpet Glider Re-assembly
Cleaning Hard Surface Floors
Cleaning Carpets & Rugs
To assemble glider, position accessory on the floor brush (fig. 5). Press so
that the glider slides neatly in the grooves (fig. 6) until it reaches the locking
fixtures (fig. 7). To lock in - tap lightly (fig. 8) until the bristles are aligned
evenly with the glider.
Set steam setting to medium to low. Then disassemble the glider and clean
with the brush wrapped in a microfiber towel or pad.
For stubborn dirt or residuals of previously used chemicals, several
treatments may be necessary in order to obtain a satisfactory and even
result. For subsequent treatment, repeat the procedure using a dry rag
wrapped on the brush.
Carpet Glider
This brush is for all hard surface floors such as tile,
wood, linoleum, concrete etc.
Typically used with a microfiber towel clipped around. For more delicate
hard surface floors such as wood, always use with a microfiber towel or
pad.

7
Modify Detail Brushes for Grout Line
(Optional)
Nylon
The nylon brush is the least aggressive brush, yet sometimes the most
productive. Safe for nearly all surfaces; it's great for tile, minimally dirty
grout, sinks, microwaves, aluminum tracks, anywhere you need to clean.
Nylon brushes help to remove particles from crevices. Metal brushes will
conduct heat and provide a more aggressive cleaning when necessary.
Stainless
Brass
Best for Grout
Combined with steam it is the most powerful of the brushes by utilizing the
steel to conduct heat and the aggressive contact made for cleaning any
surface that can be cleaned with stainless. Form the brush to fit in the
appropriate grout lines by following the instructions below.
Brass is a relatively soft metal. It is good on surfaces that need a little more
scrubbing power than the nylon brush can offer. The brass is less likely to
harm surfaces than the hard steel. Brass can often be used on shower
grout but is not recommended for floor grout as it wears down quickly and
can leave a residue that will need to be cleaned later. Grills and Jen Air's are
good examples for using the brass brush.
Tools Needed:
Needle Nose Pliers
To prepare the brush for cleaning, grasp the detail brush in one hand, with
the other hand use a pair of needle nose pliers. Grab the steel at the base
where the tuft is attached. Use a circular twisting motion to pull the steel
out of the plastic base.
The width of the brush will depend on the style of grout you are cleaning.
For example, Mexican tile, 3 tufts top and bottom. Standard 12 or 18 inch
tiles will normally need a brush with 2 tufts at the top and 2 at the bottom.
Always test an inconspicuous area before you start cleaning. Do not use on
any type of plastic or painted surfaces. Only use this on ceramic tile grout,
cement, rusty metal or your outdoor grill or other surfaces you are
confident about using it on. Be sure to test first.

This machine must be grounded. If it should malfunction or
breakdown, grounding provides a path of least resistance for
electric current to reduce the risk of electrical shock. This machine
is equipped with a cord having an equipment-grounding conductor
and grounding plug. The plug must be inserted into an appropriate
outlet that is properly installed and grounded in accordance with all
local codes and ordinances.
WARNING - Improper connection of the equipment-grounding
conductor can result in a risk of electric shock. Check with a
qualified electrician or service person if you are in doubt as to
whether the outlet is properly grounded. Do not modify the plug
provided with the machine - if it will not fit the outlet, have the
proper outlet installed by a qualified electrician.
The machine is for use on a normal 120-Volt circuit and has a
grounding attachment plug that looks like the plug illustrated in
(Figure). Make sure that the appliance is connected to an outlet
having the same configuration as the plug. No adapter should be
used with this machine.
Grounded Outlet
Grounding Instructions
SAVE THESE INSTRUCTIONS
8
Grounded Pin

Remove the tank cap (1), and fill the tank with approx. 2 liters of filtered
tap water. Distilled water can also be used only if combined with
approximately 1 cup of filtered tap water per liter of distilled. Replace the
cap and connect the power cable to the electrical socket. The cap is
designed to loosely fit the machine. It does not screw on or lock in place.
Turn the machine on by pressing both switches (7) and (8). When the
steam ready light (6) is flashing, the machine is heating. Once the steam-
ready light turns solid the machine is ready for use. Once the machine is in
use, the light will begin flashing again and this is normal.
Open the flap to the mono-block socket (9) and connect the grip unit plug.
Make sure to correctly fit the plug.
When devise is heated and ready for operation, press steam trigger on
hose while adjusting the steam regulator knob (3) according to the
application. A medium to low setting is recommended for most surfaces. A
high setting is recommended for heavily soiled surfaces.
Attention! In the event of sudden power failure or accidental disconnection
of the plug from the main outlet, the unit switches to safety mode. To
restore the normal conditions of use disable and re-enable switch (7).
Start Up
9
This machine is designed for continuous refill. If the water finishes, the
boiler can be filled without switching the machine off and waiting for cool
down. When the low water light illuminates (5) and you hear the audible
signal to refill, simply remove the tank cap (1) and add water, close the cap
and resume cleaning.
Continuous Filling
IMPORTANT! We recommend filtered tap water in this machine. Distilled
water is not suitable for this type of machine unless mixed with filtered tap
at minimum ratio of 20% tap / 80% distilled . Do not use well, softened
water or water that is high in mineral content. Do not use a reverse
osmosis home system unless mixed with filtered tap.

Regular anti-scale treatment is necessary to ensure your machines long life and
efficient operation. The frequency of descaling depends on the type of water used
and length of time water has remained in your boiler. With water of low to
average hardness and normal domestic use, descaling is recommended at least
every three months.
Unscrew and remove the drain plug from the bottom of the machine.
Drain the machine completely.
Put the drain plug back in the machine.
Pour 2 cups of white distilled vinegar in the reservoir and fill the rest with
filtered tap water.
Turn on the machine and let the pump start pumping through the machine
into the boiler.
When the audible signal to add water starts, turn off the machine and let sit
for at least 15 minutes up to overnight if you choose.
Fill your reservoir with water, allow the pump to complete filling the boiler. As
soon as the pumping stops and the boiler is full, turn off the machine, cool
down and drain the boiler.
Refill with clean water and proceed normal operation.
1.
2.
3.
4.
5.
6.
7.
8.
Maintenance
Descaling
IMPORTANT! Before all maintenance operations, make sure the machine is
turned off and the power cord is not connected to the main power supply.
After use of the brushes, to prevent undue deformation, allow the bristles to cool in
their normal position.
Occasionally check O-Rings for cracks and apply Vaseline if needed.
Maintain your boiler by draining the water and descaling if the machine was stored
for an extended period of time (3+ Months). Follow the instructions below to descale
your machine.
1.
2.
3.
Get the most out of your machine by
visiting our product page when you
scan the barcode. You will find FAQs,
maintenance and more!
10
Descaling with White Distilled Vinegar
To scan, open camera app on
mobile device and hover over
barcode.

Technical Specifications
Power Supply 120V-60Hz
Boiler Power 1750W
Tank Capacity 2 Liter
Steam Pressure 6 Bar / 600 kPa
Steam Temperature 155° C
Max Power 1800W
Boiler Internal Capacity 1.8 Liters
Voltage 110 - 120V
Dimensions 12 x 12 x 11.5
Weight 16 lbs
Power Cord 14 Ft.
Hose Length 9.7 ft w/ Safety Handle
Boiler Stainless Steel AISI 304
Automatic Safety Shutoff Yes
Pressure Regulator Knob Yes - Full Range
Audible Low Water Signal Yes
11
Composition
Casing in stainless steel
Boiler in stainless steel
Pressure switch set to 6 Bar
Steam outlet control solenoid valve
Silicone electrical wires
Temperature safety thermostat
Safety valve
Extra low voltage on the handle
Safety

According to Directives 2011/65/EU and 2012/19/EU on the reduced use of
hazardous substances in electrical and electronic equipment, and their disposal, the
barred bin symbol means that after the end of its useful life the product must be
disposed of separately from ordinary waste.
The user must therefore take such equipment to proper collection centers for
electrical and electronic waste, or take it back to the dealer when he or she buys
some equivalent equipment, in the ratio of 1;1.
A suitably differentiated waste collection, followed by recycling, treatment and
environmental
friendly disposal helps prevent negative effects on health and the environment and
favors the recycling of materials.
Any unauthorized equipment disposal by the user will be subject to sanctions as
provided for by current local regulations.
Troubleshooting
Problem Cause Solution
Boiler fails to heat Plug into outlet
Press button (7) & (8)
Fill tank water
Machine Safety LED off mode Switch off and on switch (7)
Yellow LED (5) is on Low water level Fill tank water
No steam or only
water coming out
Boiler not ready yet
Amber LED is blinking
Boiler is overfilled, too
much distilled water
Wait for steady amber LED
Drain the boiler and refill
Steam ready LED comes
on but no steam comes out
The mono-block socket (hose) is
not completely fitted
The steam regulator (3) is
completely closed
Check mono-block socket
(hose) is correctly fitted to
machine
Open the steam regulator (3)
Disposal
12
Device not plugged in
Button (7) or (8) not pressed
Boiler is empty
