Vaporesso BARR User manual

User Manual
VAPORESSO BARR

1
English
Thank you for choosing Vaporesso product. Please read this
instruction carefully before use to ensure a perfect experience.
If there is any additional requirement about this product, please
consult the local agent or contact us through our website:
www.vaporesso.com
ENGLISH
EXPLODED VIEW
SPECIFICATIONS
Dimensions 110 x 13 x 13mm
POD Capacity 1.2ml
POD Resistance 1.2Ω MESH
Battery Capacity 350mAh
Output Power 13W
Charging Current DC 5V/0.5A, Type-C
Drip Tip Silicone Plug
/Filling Hole Air-inlet Holes (on the back)
LED Indicator
Type-C USB Port
Replaceable POD

2English
USE INSTRUCTIONS
1. Replace the POD
- Pull out the used POD from the device;
2. Fill E-liquid
- Uncover the silicone plug at the side of the POD;
- Press down and squeeze the e-liquid through the hole;
- Please wait 5 minutes for the e-liquid to soak into the coil
completely.
PACKING LIST
1x VAPORESSO BARR Device
2x VAPORESSO BARR 1.2Ω POD (1.2ml)
1x Type-C USB Cable
1x User Manual
1x Warranty Card
1x ReminderCard

3
English
PROTECTIONS
3. Airow Adjustment (AIR CTRL)
Circle marks on the POD represent 4 rates airflow volume.
Insert the POD into the device from different sides for
achieving different airow effects.
Level 1 Level 2 Level 3 Level 4
4. Start Vaping
Inhale directly to enjoy extraordinary vaping experience.
5. Charge the Baery
After connecting the Type-C cable to the device, the LED
indicator will be always on. When the battery is fully charged,
the indicator will blink 20 times for reminding.
Protections Situation Indicator
Low Resistance
Protection
The device detects an
ultra-low resistance.
x 3 Stop Output
Short Circuit
Protection
The device detects a short
circuit.
x 2S Stop Output
Low Battery
Protection
The battery level drops too
low.
x 5 Stop Output
Over Charge
Protection
The device is fully charged. x 20 Stop Charging
Overtime
Protection
Constantly vape for more
than 10 seconds.
x 2

4English
CAUTIONS
WARNINGS
1. Please turn off the device when it is not in use.
2. Do not leave the charging device unattended.
3. Do not drop, throw or abuse your device, which may cause
damage.
4. Please use a standard USB output charger with proper
charging current and voltage range.
5. Keep away from the water or any ammable gas, liquid.
6. Do not expose the device to direct sunlight, dust, moisture
or mechanical shock.
7. Do not expose the device to extreme temperature.
(Recommended temperature range: -10~60℃ /14~140 ℉while
using and -10~45℃ /14~113 ℉ while storing).
8. EEE Recycling: The product should not be treated as
household waste, instead, it should be handed over to the
applicable collection point for the recycling of electrical and
electronic equipment.
9. Battery Recycling: The product battery should not be treated
as household waste, instead, it should be handed over to the
applicable used battery collection point for recycling.
10. Only have your device repaired by Vaporesso. Do not
attempt to repair it by yourself as damage or personal injury
may occur.
This product is intended for use with compatible e-liquid,
which may contain nicotine. Nicotine is an addictive substance
and it is not suitable or recommended to use in following
cases:
1. This device is not suitable for:
- Persons under the legal smoking age.
- Persons experiencing heart disease, stomach or duodenal
ulcers, liver or kidney problems, long-term throat disease or
difcult breathing due to bronchitis, emphysema or asthma.
- Persons with an overactive thyroid gland or experiencing
phaeochromocytoma (a tumour of the adrenal gland that can
affect blood pressure).
- Persons taking certain medications like Theophylline,
Ropinirole or Clozapine and etc..
2. This device is not recommended for:
- Non-smokers
- Pregnant or breastfeeding women

5
English
3. You may experience the following results if you use nicotine
containing e-liquid with this product. If it happens, please
consult a healthcare professional and show them this leaet if
possible:
- Feeling faint - Nausea - Dizziness - Headache
- Coughing - Irritation of the mouth or throat
- Stomach discomfort - Hiccups
- Nasal congestion - Vomition
- Chest palpitations/pain or an irregular heart rate
This device should not be used by
persons under the legal smoking
age.
