Vaporesso GEN X User manual

User Manual
VAPORESSO GEN X KIT

1
English
Thank you for choosing Vaporesso product.
Please read this instruction carefully before
use to ensure a perfect experience.
If there is any additional requirement about
this product, please consult the local agent or
contact us through our website:
www.vaporesso.com
ENGLISH
EXPLODED VIEW
SPECIFICATIONS
Mouthpiece
Top Cap
Glass Tube
Power Button
OLED Screen
Mode / Conrm Button
Down(-) Button
USB Port
Up(+) Button
Dimension: 27.6x49.4x144.8mm
Tank Capacity: 8ml (Standard) /2ml (TPD)
Coils: GT Meshed Coil (0.18Ω, 50-85W)
GT4 Meshed Coil (0.15Ω, 50-75W)
Battery Capacity: 2x18650 (Not included)
Display: 0.91”OLED Screen
Output Wattage: 5-220W
Bottom Base

2English
Step 1: Fill the e-liquid and install the tank.
Twist the top cap and ll the e-juice through
the slot.
Install the tank onto the mod by screwing the
510 thread connector.
HOW TO START
1 2
Step 2: Power on the device.
1) Press the power button 5 times in 2
seconds to power on or power off the
device.
2) Press the power button 3 times
continuously to lock or unlock the +, - and
mode buttons.
3) After installing the tank, the device will
automatically identify the coil material and
resistance, press + button for reset or –
button to maintain existing setting.
Step 3: Choose the mode.
1)PUL: PULSE mode (default). Boost flavor
with large cloud.
Resistance Range: 0.03-5Ω
Charging Current: 5V/2.5A

3
English
2)ECO: POWER ECO mode. When the battery
level is less than 40%, the device will
automatically recommend you enter the
ECO(Power ECO) mode.
3)STC: Smart Temperature Control mode.
When detecting the temperature control
heating wire(SS/Ti/Ni), the device will
automatically recommend you enter the
STC(Smart Temperature Control) mode.
4) DIY: DIY mode. You can choose traditional
VW(H,N,S), VV, VT,CCW, BP(Bypass mode) ,
SP(Super Player mode) in this section.
5)SET: System setting. Including puff
counter, brightness, ip screen, default and
version.
OPTIONS IN DIY MODE
• VW-H /VW-N /VW-S (Variable Wattage mode
- high/normal/soft): Automatically select the
adequate average wattage according to the
different resistances.
• VT-SS/VT-NI/VT-TI : Variable temperature
control mode for Stainless Steel /Nickel/
Titanium materials.
• VV(Variable Voltage mode): Manually
adjust the voltage level according to the coil
resistance.
• CCW (Custom Curve of Wattage mode):
Customize your own curve of wattage output
line by adjusting +/- buttons. Quick Press the
power button to move to next bar and save
the setting by pressing the mode button.

4English
CAUTIONS
1. Please turn off the device when it is not in
use.
2. Do not leave the charging device
unattended.
3. Do not drop, throw or abuse your device,
which may cause damage.
4. Please use a standard USB output charger
with proper charging current and voltage
range.
5. Keep away from the water or any ammable
gas, liquid.
6. Do not expose the device to direct sunlight,
dust, moisture or mechanical shock.
7. Do not expose the device to extreme
temperature. (Recommended temperature
range: -10~60℃/14~140 ℉while
using and -10~45℃/14~113 ℉while storing).
8. EEE Recycling: The product should not be
treated as household waste, instead, it should
be handed over to the applicable collection
point for the recycling of electrical and
electronic equipment.
9. Battery Recycling: The product battery
should not be treated as household waste,
instead, it should be handed over to the
applicable used
battery collection point for recycling.
10. Only have your device repaired by
Vaporesso. Do not attempt to repair it by
yourself as damage or personal injury may
occur.
• BP (Bypass mode): Direct output voltage
mode depends on battery level(Supported
resistance range: 0.05-5Ω)
• SP (Super Player mode): If the device
detects an extremely low resistance, it will
automatically recommend you to enter
SP(Super Player) Mode. (Supported resistance
range: 0.03-5Ω)

5
English
WARNINGS
This rellable electronic cigaree is
intended for use with compatible e-liquid,
which may contain nicotine. Nicotine is an
addictive substance and it is not suitable or
recommended to use in following cases:
1. This device is not suitable for:
- Persons under the legal smoking age.
- Persons experiencing heart disease,
stomach or duodenal ulcers, liver or
kidney problems, long-term throat disease
or difcult breathing due to bronchitis,
emphysema or asthma.
- Persons with an overactive thyroid gland or
experiencing
phaeochromocytoma (a tumour of the
adrenal gland that can affect blood
pressure).
- Persons taking certain medications like
Theophylline, Ropinirole or Clozapine and
etc..
2. This device is not recommended for:
- Non-smokers
- Pregnant or breastfeeding women
3. You may experience the following results
if you use nicotine containing e-liquid with
this product. If it happens, please consult a
healthcare professional and show them this
leaet if possible:
- Feeling faint - Nausea - Dizziness -
Headache
- Coughing - Irritation of the mouth or throat
- Stomach discomfort - Hiccups
- Nasal congestion - Vomition
- Chest palpitations/pain or an irregular
heart rate
This device should not be
used by persons under the
legal smoking age.

1Deutsch
DEUTSCH
Vielen Dank, dass Sie sich für ein Produkt
von Vaporesso entschieden haben. Bitte
lesen Sie diese Anleitung vor der Nutzung
sorgfältig durch, um ein perfektes Erlebnis
zu gewährleisten. Wenn es zusätzliche
Anforderungen an dieses Produkt gibt, wenden
Sie sich bitte an den Vertreter vor Ort oder
kontaktieren Sie uns über unsere Website:
www.vaporesso.com
ÜBERSICHT
SPEZIFIKATIONEN
Mundstück
Obere Kappe
Glasrohr
Einschalttaste
OLED-Bildschir
Modus/Bestätigen-Taste
Down(-)-Taste
USB-Anschluss
Up(+)-Taste
Abmessungen: 27,6 x 49,4 x 144,8 mm
Tankvolumen: 8ml (Standard)/2ml (TPD)
Coils: GT Meshed Coil (0,18Ω, 50-85W)
GT4 Meshed Coil (0,15Ω, 50-75W)
Akkukapazität: 2x18650 (Nicht inbegriffen)
Untere Basis

2
Deutsch
Schri 1: Füllen Sie das E-Liquid ein und
installieren Sie den Tank.
Drehen Sie die obere Kappe und füllen Sie
den E-Saft durch den Schlitz ein.
Installieren Sie den Tank am Mod, indem Sie
den Gewindeanschluss 510 einschrauben.
VERWENDUNG
1 2
Schri 2: Einschalten des Geräts.
1) Drücken Sie die Einschalttaste 5 Mal
in 2 Sekunden, um das Gerät ein- oder
auszuschalten.
2) Drücken Sie zum Sperren oder Entsperren
der „+“-Taste, „-“-Taste sowie Modus-Taste
die Einschalttaste 3 Mal kontinuierlich.
3) Nach der Installation des Tanks
identiziert das Gerät automatisch coil-
Material und -Widerstand. Drücken Sie
zum Zurücksetzen die „+“-Taste oder zum
Beibehalten der bestehenden Einstellung die
„-“-Taste.
Display: 0,91” OLED-Bildschirm
Ausgangsleistung: 5-220W
Widerstandsbereich: 0,03-5Ω
Ladestrom: 5V/2,5A

3Deutsch
Schri 3: Wählen Sie den Modus.
1)PUL: PULSE-Modus (Voreinstellung).
Geschmack mit großer Wolke erhöhen.
2)ECO: POWER ECO-Modus. Wenn der
Akkustand unter 40% beträgt, empehlt das
Gerät Ihnen automatisch den ECO(Power
ECO)-Modus.
3)STC: Smart Temperature Control-modus.
Wenn das Gerät den Temperatursteuerungs-
Heizdraht (SS/Ti/Ni) erkennt, empehlt
es Ihnen automatisch den STC(Smart
Temperature Control)-Modus.
4) DIY: DIY-Modus. In diesem Abschnitt
können Sie traditionell VW (H, N, S), VV, VT,
CCW, BP (Bypass-Modus), SP (Super Player-
Modus) auswählen.
5)SET: Systemeinstellung. Einschließlich
Zug-Zähler, Helligkeit, Bildschirm spiegeln,
Standard und Version.
OPTIONEN IM DIY-MODUS
• VW-H /VW-N /VW-S (Variabler
Leistungsmodus - hoch/normal/sanft):
Automatisches Auswählen der angemessenen
Durchschnittsleistung entsprechend der
verschiedenen Widerstände.
• VT-SS/VT-NI/VT-TI: Variabler
Temperatursteuerungsmodus für Edelstahl-/
Nickel-/Titan-Materialien.
