Vaporesso LUXE NANO User manual

User Manual
WITH

1English
Drip Tip
Top Lid
Glass Tube
Bottom Base
Power Button
Micro USB Port
Function button( up,mode,down)
Coil
Thank you for choosing Vaporesso product. Please
read this manual carefully before use to ensure
your perfect usage experiance.
If you require additional information or have any
question about this product, please consult the
local agent or contact us through website www.
vaporesso.com
SPECIFICATIONS
Tank Capacity: 3.5ml/2ml
Display: 1.3” TFT Color Screen
Built-in Battery: 2500mAh
Power Range: 5-80W
Resistance Range: 0.03~5Ω
English

2English
2) Suggested mode for different coil: VW-N mode for tank with QF MESHED and QF
STRIPS coil , SS(VT) mode for SK CCELL coil.
STEP3: POWER ON THE DEVICE
1)Turn device on by pressing the power button 5 times in 2 seconds, repeat to power
off.
2)For your safety, If you vape continuously for more than 10 seconds, it will display
"10s time over"and device will stop working temporarily.
3)3 press of MODE button is request when you enter MENU after unit waken up from
sleep.
HOW TO USE
STEP1 : FILLING THE E- JUICE
Uncrew the drip tip directly,then you
can ll your favorite E-juice through the
opening.
STEP2: INSTALL THE TANK
1) When in SS/NI/TI (VT)mode,atomizer's
type need to be reganized when a new
one is installed.

3English
UI interface
battery level time
voltage/
wattage instant
value during
vaping.
Screen lock
indicator
duration of
last puff
current mode
setting value
coil resistance
value
puff counter

4English
STEP4: CHOOSE YOUR FAVERITE MODE
1)VW-H /VW-N /VW-S (Variable Waage mode - high/normal/
so): it will automatically select the adequate average wattage
for your atomizer If you switch between different ohms
resistance.
2)SP (Super Player mode): In this mode, it will support broader
resistance range from 0.03Ω to 5Ω, which is adaptive to
mainstream RDA tanks.
3)VT-SS/VT-NI/VT-TI : Variable temperature control mode for
Stainless Steel/Nickel/Titanium material.
4)VV(Variable Voltage mode): You can manualy adjust the
voltage to match the resistances of the coil you use, the higher
resistance of the coil you use, the higher voltage it require
correspondingly.
5)CCW (Custom Curve of Waage mode): To use the up and
down buttons to customize you own curve of wattage output
line ,move to the next bar with a quick press of the fire
button,press the mode button to save and exit when setting is
done.

5English
6)BP (Bypass mode): Direct output voltage mode depends on
battery level, the higher the battery level the higher the output
voltage, supported coil resistance range: 0.05-5ohm.
7)CCV (Custom Curve of Voltage mode in DIY MENU): you
can use the up and down buttons to customize the curve of
voltage output line,move to the next bar with a quick press of
the re button , press the mode button to save and exit when
setting is done.
8)TCR-M1/M2 (Temperature Coefcient of Resistance mode ,in
DIY MENU) Note: when in VT and TCR mode, the Celsius and
Fahrenheit can be switched by adjust to its max value in the
main page.
9)SMART ON/OFF(in SET MENU):It is a advanced Variable
Wattage mode, when this function is enable, it can change
intensity according to the coils resistance levels within a safe
limit in VW-H/N/S mode.
10) AUTO ON/OFF(in SET MENU): The Auto function taking
away any operation difculties switching between VW-H and
VW-N or between VT-H and VT-N.

6English
CAUTIONS:
1. Please turn off the device when it is not in use.
2. Do not leave the charging device unattended.
3. Do not drop, throw or abuse your device, it may cause damage.
4. Please use a standard USB output charger in proper charging Current and Voltage
range.
5. Keep away from water or any ammable gas, liquid .
6. Do not exposure to direct sunlight, dust, moisture or mechanical shock.
7. Do not exposure the device to extreme temperature.
(Applicable temperature range:-10~60℃-/14~140 ℉while using, 0~+55℃/32-131 ℉
while charging, -10~45℃/14~113 ℉while storing).
8. EEE Recycling: the product should not be treated as household waste, instead it
should be handed over to the applicable collection point for the recycling of electrical
and electronic equipment.
9. Battery Recycling: the product battery should not be treated as household waste,
instead it should be handed over to the applicable used battery collection point for
recycling.
10. Only have your device repaired by Vaporesso. Do not attempt to repair it by
yourself as damage or personal injury may occur.

7English
This device should not be used by persons under the age
of 18 or non-smokers. Please keep this unit out of reach of
children or pets.
This refillable electronic cigarette is intended for use with compatible liquid,
which may contain nicotine. Nicotine is an addictive substance and its use is not
recommended for use by the following:
- Non smokers or persons under the legal smoking age
- Pregnant or breastfeeding women
- Persons experiencing heart disease, stomach or duodenal ulcers, liver or kidney
problems, long-term throat disease or difficulty breathing due to bronchitis,
emphysema or asthma.
- Persons with an overactive thyroid gland or experiencing phaeochromocytoma
(a tumour of the adrenal gland that can affect blood pressure)
- Those taking the medications Theophylline, Ropinirole or Clozapone
You may experience the following side effects if you use nicotine containing e-liquid
in combination with this product. If this happens, please consult a healthcare
professional and show them this leaet if possible:
- Feeling faint / - Nausea /- Dizziness /- Headache /- Coughing
- Chest palpitationspain or an irregular heart rate /- Irritation of the mouth or throat
- Stomach discomfort /- Hiccups /- Nasal congestion/- Vomition

1Français
Merci d'avoir choisi le produit Vaporesso. Veuillez lire attentivement ce manuel
avant de l'utiliser pour vous assurer d'une utilisation parfaite.Si vous avez besoin
d'informations supplémentaires ou si vous avez des questions sur ce produit, veuillez
consulter l'agent local ou nous contacter via le site web www.vaporesso.com.
ÉTAPE 2 : INSTALLER LE RÉSERVOIR:
1) En mode SS / NI / TI (VT), le type d'atomiseur doit être reconfiguré lorsqu'un
nouveau est installé.
2) Mode suggéré pour différentes bobines: mode VW-N pour le réservoir avec bobine
QF MESHED et QF STRIPS, mode SS (VT) pour la bobine SK CCELL.
ÉTAPE 3: ALIMENTATION DU DISPOSITIF
1) Allumez l'appareil en appuyant sur le bouton d'alimentation 5 fois en 2 secondes,
répétez l'opération pour l'éteindre.
2) Pour votre sécurité, si vous sautez continuellement pendant plus de 10 secondes, il
COMMENT UTILISER
ÉTAPE1 : REMPLISSAGE DU JUS ÉLECTRONIQUE
uncrew le goutte - à - goutte tuyau directement, alors vous pouvez combler ton
préféré e-juice par l'ouverture.
Français
