Vatech EzScan-i User manual

User Manual
Version 3.6

Document
Software Version
Date
EzScan
User Manual
IOS-FPM-71-007_EN_AA
3.4
12.23.2021
3.5
02.07.2022
3.6
07.01.2022
Comeandjointhe growing
Vatech.co

Introducing the EzScan.................................................7
Introduction ................................................................................................................... 7
What’s new in this version................................................................................................ 7
Indications supported .................................................................................................. 7
Certification and compliance ....................................................................................... 7
Regulatory ................................................................................................................... 8
Intended Use ............................................................................................................... 8
Classifications .............................................................................................................. 8
Components Overview ..............................................9
Hardware Components................................................................................................ 9
Software Components ................................................................................................. 9
System Requirements and Specifications .................................................................. 10
Software .............................................. 11
Computer Requirements ........................................................................................... 11
Environment Conditions ............................................................................................ 12
Power Input ............................................................................................................... 13
Reusable ............................................................................................................. 13
Scanner Base andHandpiece ..................................................................................... 13
Calibration ........................................................................................................... 13
Installing and connecting the EzScan ......................14
Wall Mount Installation Instructions (Optional)........................................................ 14
Connecting the EzScan............................................................................................... 15
Getting Started With EzScan-i.................................18
Device Registration.................................................................................................... 18
Accessing the EzScan-i Homepage............................................................................. 20
Customizing the EzScan-i Admin User Account ......................................................... 21
Adding a New User Account ...................................................................................... 22
Accessing Your EzScan-i User Account...................................................................... 23
Linking a User Account to the EzScanCloud............................................................... 23
Configuring EzScan-i Settings ..................................24
Accessing the Settings Menu .................................................................................... 24
General Settings ........................................................................................................ 24
Data Settings.............................................................................................................. 26
Sound Settings ........................................................................................................... 29
User Settings.............................................................................................................. 29
Upload Settings ......................................................................................................... 30

Case Setup Settings ................................................................................................... 30
Lab Sheet Settings ..................................................................................................... 34
3D Settings................................................................................................................. 35
Managing Cases in EzScan-i ....................................37
Managing Patient Profiles ......................................................................................... 37
Managing Patient Cases ............................................................................................ 39
Setting Up a Case in EzScan-i ..................................................................................... 41
Scanning with EzScan..............................................45
Before You Scan......................................................................................................... 45
Using the Scan Tip ..................................................................................................... 46
An Example Scan Workflow Menu ............................................................................ 47
Useful Scanning Tips .................................................................................................. 48
Before You Scan: Important Notice ........................................................................... 48
Accessing the Scan Workflow .................................................................................... 49
Scanning the Maxillary Arch ...................................................................................... 49
Scanning the Mandibular Arch .................................................................................. 49
Recommended Scanpath Strategy ............................................................................ 50
Scan Memory Use................................................................................................ 52
Scan Live View ..................................................................................................... 53
2D Live Capture ................................................................................................... 53
Using Scan Tools .................................................................................................. 54
Carrying Out A Bite Alignment............................................................................. 58
Accessing Bite Alignment in the Scan Workflow............................................................. 58
Changing between automatic and manual mode ........................................................... 58
Using audio-guidance...................................................................................................... 58
Carrying out an Automatic Bite Alignment.......................................................... 59
Recommended Scanpath Strategy.................................................................................. 59
Bite-alignment using a single bite segment .................................................................... 60
Carrying out a Manual Bite Alignment ................................................................ 61
Auto-Realignment................................................................................................ 63
Using Bite Alignment Tools.................................................................................. 64
Finalizing A Patient Case .........................................65
Finalizing Your Order ................................................................................................. 65
Verify Patient & Restoration details................................................................................ 65
Case Review: Reviewing 2D images........................................................................... 65
Case Review: Reviewing 3D Models .......................................................................... 66
Using the Margin Line Tracing Tool ........................................................................... 66
Verify Export settings...................................................................................................... 67
Verify Lab Details ............................................................................................................ 68
Verify Order Form Details ............................................................................................... 68
Verify Case Status ........................................................................................................... 69

Page 5
Resending a Modified Order Form.................................................................................. 70
Communicating With Labs ......................................71
Linking an EzScan-i account to EzScanCloud.............................................................. 71
Creating An EzScanCloud User Account (Clinic)......................................................... 72
Overview of the EzScanCloud Dashboard.................................................................. 73
Configuring EzScanCloud User Settings ..................................................................... 74
Editing your EzScanCloud Profile ............................................................................... 74
Configuring View & Notification Settings .................................................................. 75
Configuring Connections with Labs ........................................................................... 76
Selecting Default Upload Settings in EzScan-i ................................................................. 76
Managing Cases in EzScanCloud ................................................................................ 77
Managing Case Status in EzScanCloud....................................................................... 78
Displaying Cases by Status .............................................................................................. 78
Filtering Cases ................................................................................................................. 78
Changing Case Status ...................................................................................................... 78
Case Status Descriptions ................................................................................................. 79
Displaying 3D Views in EzScanCloud.................................................................... 79
Downloading Case Files in EzScanCloud .............................................................. 80
Downloading specific case files....................................................................................... 80
Downloading all case files ............................................................................................... 80
Case File Details .............................................................................................................. 80
Displaying a Case Order Form in EzScanCloud..................................................... 81
Adding a Comment to a Case .............................................................................. 81
Contacting Support via EzScanCloud ................................................................... 82
Maintenance ......................................................83
Cleaning the Handpiece ....................................................................................... 83
Recommended and approved surface disinfectants:...................................................... 83
Cleaning and Sterilizing Tips ................................................................................ 83
Disposal ............................................................................................................... 85
Calibration ........................................................................................................... 85
Safety Guidelines and Warnings .........................86
Warnings and Symbols......................................................................................... 86
General Guidelines .............................................................................................. 86
General Warnings ................................................................................................ 87
System Modification ....................................................................................................... 87
Approved Software ......................................................................................................... 87
Equipment Failure........................................................................................................... 87
Mechanical Hazards............................................................................................. 87
Moving Parts ................................................................................................................... 87
Dropped Equipment........................................................................................................ 88
Base................................................................................................................................. 88

Electrical Safety ................................................................................................... 88
Electrical Shock ............................................................................................................... 88
Stress on Cables .............................................................................................................. 88
Eye Safety ............................................................................................................ 89
Hygiene................................................................................................................ 89
Precautions During Systems Operation ............................................................... 89
EzScan Performance ............................................................................................ 90
Accessories ..................................................................................................... 91
EMC Guidance and Declaration ...................................................................... 91
Symbols on the EzScan and TransportCase ..................................................... 95
Support, Warranty & RepairService....................97
Support ................................................................................................................ 97
Standard Warranty .............................................................................................. 97
Repair Service ...................................................................................................... 98
Out of Warranty RepairService............................................................................ 98

Page 7
Introducing the EzScan
1.1 Introduction
Thank you for purchasing the EzScan solution from Vatech.The EzScan
solution is designed and developed to produce high-quality digital
intraoral scans or models, for dental restoration or analysis.
The EzScan solution is designed with you as a dentist and your patient in
mind. The scanner is lightweight, small and easy to use, enabling fast,
accurate scanning and great patient experience. The Case management
application provides efficient and customizable order management, for
easy and intuitive use. Enjoy your new intraoral scanner solution!
1.2 What’s new in this version
This document update incorporates new features and improvements
added to the EzScan-i 3.6 software release.
For more information consult: EzScan-i 3.6 Release Notes.
1.3 Indications supported
The data sets from the EzScan can be used for the following indications.
· Conventional crowns
· Anatomic crowns
· Copings
· Provisional crowns
· Anatomical pontics
· Reduced pontics
· Provisional pontics
· Inlays/Onlays
· Implant abutments
· 3-unit implant bridges
· Up to 5-unit bridges
· Orthodontic aligners
· Nightguards
· Splints
· Retainers
· Bleach trays
· Sleep appliances
· …
* Verify with your dental lab or service provider about their capabilities
to produce particular indications.
1.4 Certification and compliance
The system has been tested and conforms to the following standards:
• IEC 60601-1, Medical electrical equipment - Part 1: General
requirements for basic safety and essential performance
• IEC 60601-1-2, Medical electrical equipment - Part 1-2: General

requirements for basic safety and essential performance - Collateral
Standard: Electromagnetic disturbances
- Requirements and tests:
• IEC 62471, Photobiological safety of lamps and lamp systems
1.5 Regulatory
The EzScan is manufactured and marketed in accordance with US FDA
Regulations and EU Medical Device Regulation 2017/745.
1.6 Intended Use
The EzScan is an optical impression system. It is used to record the
topographical characteristics of teeth, dental impressions, or stone models
for use in the computer-aided design (CAD) and computer-aided
manufacturing (CAM) of dental restorative prosthetic devices.
1.7 Classifications
The EzScan system has the following classifications
•Protection against electrical shock: Type B Applied Part
•Protection against harmful ingress of water: Ordinary equipment
(IPX0)
•Safety of application in the presence of a flammable anesthetic
material with air or with oxygen or nitrous oxide: Equipment not
suitable for use in the presence of a flammable anesthetic mixture
with air or with oxygen or nitrous oxide.
CAUTION: Rx only - Federal law restricts this device to be sold by or on the
order of aDentist.
WARNING: Unintended use of the system can result in physical injury to the
patient and operator, and damage to the system.

Page 9
2. Components Overview
The EzScan system is composed of hardware and software components:
2.1 Hardware Components
The EzScan system is composed of the
following hardware components*:
1. EzScan Scanner
2. EzScan base
3. Removable autoclavable tips
4. USB 3.0 cable
5. AC/DC power adapter
Hardware Component Part Number
EzScan System (Includes3 Tips) V2810110
USB 3.0 Cable IOS-CP-00-043
AC/DC Power Adapter IOS-CP-00-088
Save the Box: It is highly recommended that you store the box in a safe place and do
not dispose of it. The box is optimal for any necessary transportation or shipment of
the EzScan.
2.2 Software Components
The EzScan system comprises the following software components:
EzScan-i : 3D Scanning and Case Management software.
EzScanCloud : Dedicated cloud platform for ordering and communicating with
labs

Page 10
User Manual
2.3 System Requirements and Specifications
Scanner Specifications
Scanner Type
Hand-held (chairside) scanner that creates
optical impressions for dental restorations.
Design Compact, lightweight, ergonomic – designed
to be operated with little physical effort.
Dimensions Base Size: L 306mm, W 98mm, H 72mm
Dimensions Scanner Weight: 150 grams
Size: L 256mm, W 43mm, H 43mm
Cable length (scanner to base): 2m
Power Requirement DC 5.0V / 4A (Power supply included)
Scanner Tip Reusable up to 250 times, sterilize using
steam
autoclave
Heating Element Ventilated. Prevents formation of fog on optics
Acquisition Method/Imaging
technology
Hybrid technology: active stereo imaging and
structured light
Sensor technology CMOS
Color Scanning 24-bit (8-bit per channel)
Scanning frequency 25-30 FPS
Imaging field-of-view 12mm x 14mm
Light sources High-power LEDs
Scanning Process
Tooth Preparation No powder or spray required
Scanning Principle Continuously scanning and
accumulating (stitching) depth
and color data
Distance Scanner - Tooth -1mm – 19mm
Possible contact duration by operator <10 min. Note: May vary with
hardware configuration

Page 11
Operator accessible part Handpiece
Possible contact duration by patient t ≤ 10 min
Patient accessible part (Type B Applied Part)
Tip (autoclavable)
Computer – Scanner Interface USB 3.0
2.4 Software output and design software compatibility
Output File Format
STL, PLY, OBJ
Compatibility with CAD/CAM
Systems
Open Architecture Output format STL, PLY, OBJ
Compatible with most Dental CAD systems
2.5 Computer Requirements
Minimum Software Requirements
Operating System Windows 10 (Excluding Windows 10 S, now
defunct) Administrative rights required
Disk Space 100 GB or greater of free disk space
Ports At least 1 x USB 3.0 port (SuperSpeed)
Nvidia Driver Nvidia Studio driver version 471.68 is currently
required. Nvidia gamer-ready driver should not
be used with the EzScan-i software.
Screen resolution
Full HD (1920 x 1080) with DPI 100%
NOTE: The use of 4K (3840 x 2160 pixels) or Ultra-
Wide (3440 x 1440 pixels) resolutions is also possible,
however the impact on performance has not been
quantified at this stage.
Software Configuration Recommendations
Windows automatic updates We recommend deactivating all Windows
automatic updates (except for security
updates).
Nvidia driver automatic updates Nvidia driver automatic updates should be
disabled.

Page 12
User Manual
Windows Battery Settings On laptops, the battery setting in Windows
should be configured to high performance
mode only, with no battery saving option.
Minimum Hardware Requirements
CPU Type Intel 10, 11 and 12 generation. Intel i7 or i9 – 4 Cores
give best performance.
CPU Clock 2.8 GHz clock or greater
Memory 16 GB of RAM or greater (DDR4 or better)
Graphics Card Memory
6GB of RAM minimum on the graphics card are needed.
Below this, the software will not launch: an error message
will inform you that the minimum requirement is not
reached.
GPU
Quadro RTX3000, RTX4000 and above for laptop and
desktop
RTX2070 for laptop and desktop
RTX2080 for laptop and desktop
RTX2080TI for desktop
RTX3070 for laptop and desktop
RTX3080 for laptop and desktop
RTX3090 for desktop
2.6 Environment Conditions
Operating Temperature 10°C to 40°C
Operating Relative Humidity
10% to 80% (non-condensing)
Storage Temperature - 20°C to 60°C
Storage Relative Humidity 10% to 80% (non-
condensing) Indoor use
only
: AMD GPUs are NOT guaranteed compatible with
EzScan.
Not meeting minimum hardware requirements will affect the
performance of the scanner.

Page 13
Installation Category 1
Pollution Degree
2
Ingress of Liquids IPXO
Protective Class Class IIIb
Overvoltage category II per IEC 60664-1
Max. working condition Continuous cycles with image capture
and transmission from/to Notebook or
non-medical grade PC.
Other possible accessories (IEC60601-1
3rd, Cl. 16)
Notebook with AC/DC Adapter.
Equipment Maintenance No user maintenance is required, and no
user service is allowed. Please contact
technical support in case of problem.
Cleaning Do not try to clean the inside of the de-
vice Refer to section 9.1: Cleaning the
Handpiece for cleaning and sterilization.
2.7 Power Input
The power adapter input is 5V DC, 100-240V AC, 50-60Hz.
2.8 Reusable Tips
Scanner tip is autoclavable up to 250 times in a steam autoclave when used with
132°C/134°C 4 mins cycle or 121°C 45 min cycle.
See below: section 9.2 Cleaning and Sterilizing Tips.
2.9 Scanner Base and Handpiece
The scanner body consists of the Docking Base and Handpiece, which are
connected by a flexible, non-detachable cable.
2.10 Calibration
The EzScan™ intraoral scanner is factory calibrated. In the case of calibration issues
due to transport, please contact your reseller or Vatech support technician.

Page 14
User Manual
3. Installing and connecting the EzScan
3.1 Wall Mount Installation Instructions (Optional)
When wall mounting the scanner’s base, be careful to respect measurements
indicated to drill holes for the wall mount.
•It is recommended to use wall anchors and threaded screws with an 8mm
(5/16th inch) head diameter.
•A 4-5mm (3/16th in) distance between wall and bottom screw head is
recommended.
Caution: If the docking base is not properly installed there is a
possibility of the base falling and damaging the scanner.
IMPORTANT: Vatech is not responsible for accidents or damage
caused in the event the scanner falls.

Page 15
3.2 Connecting the EzScan
To install and connect the EzScan Scanner:
STEP 1. Place the docking base on a flat, stable surface and
place the EzScan handpiece securely on the base.
STEP 2. Connect the AC/DC power adapter cable to the docking
base (the connector socket is located underneath the
base of the scanner).
STEP 3. Connect the provided USB 3.0 cable to the docking
base (the connector socket is located underneath the
base of the scanner).
STEP 4. Connect the other end of the USB 3.0 cable to the
computer.
WARNING: Using a USB cable other than the one provided may
result in system malfunction or reduced performance.
WARNING: Make sure you use the 5.0V 4A power adapter
provided. Failure to do so may result in damage to the scanning
device.

Page 16
User Manual
STEP 5. Connect the adapter block provided to a power outlet.
IMPORTANT: Connect to Power Supply before Scanning!
If your laptop computer is not properly
connected to a power outlet, the following
message will appear:
In this case, please connect your laptop to the
power supply before proceeding to use to
scanner.
IMPORTANT: When using a desktop computer, it is strongly
recommended to plug the USB cable to a USB port located at the
back of the computer; not doing so may result in system
malfunction or reduced performance.
DO NOT plug the USB cable into an intermediate hub.
IMPORTANT: If using a laptop computer, make sure the power
supply is connected to a power outlet and not running on battery
power. Failure to do so will mean that the scanner will not have
sufficient power to produce images.
On laptop computers, battery settings in Windows should be
configured to high performance mode only, with no battery
saving option (Settings/System/Battery).
IMPORTANT: Make sure to use a USB port that is compatible
with USB 3.0 (SuperSpeed), usually indicated by this symbol:
not doing so may result system malfunction or reduced
performance.

Page 17
WARNING: Unsuitable installation sites:
•Locations with excessive humidity or dust
•Locations subject to high temperature
•Locations subject to shaking or vibration
•Locations exposed to considerable electrical or magnetic
noise, or other forms of electromagnetic energy

Page 18
User Manual
4. Getting Started With EzScan-i
Once you have connected the EzScan, you are ready to launch the EzScan-i
software installed on your computer. The EzScan-i software is launched by
selecting the IO Scanner option in EzDent-i.
4.1 Device Registration
When you launch the EzScan-i software for the first time, you will be invited to
register your EzScan device:
In the Device Registration dialog box:
STEP 1. Enter your personal contact details.
STEP 2. Copy/paste the scanner serial number from General
settings
STEP 3. Tick the consent box to agree to the storage and

Page 19
processing of your data.
STEP 4. Click to Submit device registration information.
When you submit the device registration form, the EzScan-i interface will open
directly in the Case Setup page.
Case Setup
The Case Setup icon is highlighted in the left-hand menu.
The Case Setup page enables you to select restorations, and to enter
restoration and order form details.
For more information see below: section 6.3 Setting Up a Case in EzScan-i
WARNING: It will not be possible to perform new scans or
export existing scans if the device has not been registered on
the PC.

Page 20
User Manual
4.2 Accessing the EzScan-i Homepage
To go to the EzScan-i homepage, click on the Home icon in the top left
corner of the Case Setup window.
Patients/Cases View
In the EzScan-i homepage, you can toggle
between Patients and Cases views, and Filter
or search desired Patients/Cases.
Filter/Search
You can search by term or Click on the Filter icon to open the Filters dialog
box.
Patients and cases can be filtered by Gender and/or Date.
An active filter is indicated as shown above.
Select A User Start Page Default View
To select a preferred Default View for the User Start Page:
STEP 1. Click Settings.
STEP 2. In the left-hand Settings menu select
