Vatech EzScan-i User manual

User Manual
Version 3.5

Document
Software Version
Date
EzScan
User Manual
IOS-FPM-71-007_EN_AA
3.4
12.23.2021
3.5
02.07.2022
Comeandjointhe growing
Vatech.co

Introducing the EzScan.................................................6
1.1 Introduction ................................................................................................................... 6
1.2 Indications supported .................................................................................................. 6
1.3 Certification and compliance ....................................................................................... 6
1.4 Regulatory ................................................................................................................... 7
1.5 Intended Use ............................................................................................................... 7
1.6 Classifications .............................................................................................................. 7
2. Components Overview ..............................................8
2.1 Hardware Components................................................................................................ 8
2.2 Software Components ................................................................................................. 8
2.3 System Requirements and Specifications .................................................................... 9
2.4 Software output and design software compatibility .............................................. 10
2.5 Computer Requirements ........................................................................................... 10
2.6 Environment Conditions ............................................................................................ 11
2.7 Power Input ............................................................................................................... 12
2.8 Reusable Tips ............................................................................................................. 12
2.9 Scanner Base andHandpiece ..................................................................................... 12
2.10 Calibration ............................................................................................................. 12
3. Installing and connecting the EzScan ......................13
3.1 Wall Mount Installation Instructions (Optional) ........................................................ 13
3.2 Connecting the EzScan............................................................................................... 14
4. Getting Started With EzScan-i.................................16
4.1 Device Registration.................................................................................................... 16
4.2 Accessing the EzScan-i Homepage............................................................................. 17
4.3 Customizing the EzScan-i Admin User Account ......................................................... 18
4.4 Adding a New User Account ...................................................................................... 19
4.5 Accessing Your EzScan-i User Account...................................................................... 20
4.6 Linking a User Account to the EzScanCloud............................................................... 20
5. Configuring EzScan-i Settings ..................................21
Accessing the Settings Menu .................................................................................... 21
5.1 General Settings ........................................................................................................ 21
5.2 Data Settings.............................................................................................................. 22
5.3 Sound Settings ........................................................................................................... 26
5.4 User Settings.............................................................................................................. 26
5.5 Upload Settings ......................................................................................................... 27
5.6 Case Setup Settings ................................................................................................... 27

5.7 Lab Sheet Settings ..................................................................................................... 30
5.8 3D Settings................................................................................................................. 31
6. Managing Cases in EzScan-i ....................................33
6.1 Managing Patient Profiles ......................................................................................... 33
6.2 Managing Patient Cases ............................................................................................ 35
6.3 Setting Up a Case in EzScan-i ..................................................................................... 37
7. Scanning with EzScan..............................................41
7.1 Before You Scan......................................................................................................... 41
7.1.1 Scan Tools Overview ............................................................................................ 41
7.2 An Example Scan Workflow Menu ............................................................................ 43
7.3 Useful Scanning Tips .................................................................................................. 44
7.4 Recommended EzScan Workflow.............................................................................. 44
7.5 Scan Live View ........................................................................................................... 47
7.6 2D Image Capture...................................................................................................... 48
7.7 Using Scan Tools ........................................................................................................ 48
7.8 Carrying Out A Bite Alignment................................................................................... 51
7.8.1 Automatic Bite Alignment.................................................................................... 51
7.8.2 Manual Bite Alignment ........................................................................................ 52
7.8.3 Auto-Realignment................................................................................................ 55
7.8.4 Using Bite Alignment Tools.................................................................................. 55
7.9 Finalizing A Patient Case............................................................................................ 56
8. Communicating With Labs ......................................60
8.1 Linking an EzScan-i account to EzScanCloud.............................................................. 60
8.2 Creating An EzScanCloud User Account (Clinic)......................................................... 61
8.3 Configuring EzScanCloud User Settings ..................................................................... 62
8.3.1 Editing your EzScanCloud Profile ......................................................................... 62
8.4 Configuring Connections with Labs ........................................................................... 63
8.5 Selecting Default Upload Settings in EzScan-i............................................................ 64
8.6 Using the EzScanCloud Dashboard ............................................................................ 64
8.6.1 Managing Cases in EzScanCloud .......................................................................... 64
9. Maintenance...........................................................66
9.1 Cleaning the Handpiece ............................................................................................. 66
9.2 Cleaning and Sterilizing Tips ...................................................................................... 66
9.3 Disposal ..................................................................................................................... 68
9.4 Calibration ................................................................................................................. 68
10. Safety Guidelines andWarnings..........................69
10.1 Warnings and Symbols......................................................................................... 69
10.2 General Guidelines .............................................................................................. 69
10.3 General Warnings ................................................................................................ 70

Page 5
10.3.1 System Modification ....................................................................................... 70
10.3.2 Approved Software ......................................................................................... 70
10.3.3 Equipment Failure........................................................................................... 70
10.4 Mechanical Hazards ................................................................................................ 70
10.4.1 Moving Parts ................................................................................................... 70
10.4.2 Dropped Equipment........................................................................................ 71
10.4.3 Base ................................................................................................................ 71
10.5 Electrical Safety.................................................................................................... 71
10.5.1 Electrical Shock .............................................................................................. 71
10.5.2 Stress on Cables .............................................................................................. 71
10.6 Eye Safety ............................................................................................................ 72
10.7 Hygiene................................................................................................................ 72
10.8 During Systems Operation ................................................................................... 73
10.9 EMC Guidance and Declaration ........................................................................... 73
11. Support, Warranty and RepairService ................80
11.1 Support ................................................................................................................ 80
11.2 Standard Warranty .............................................................................................. 80
11.3 Repair Service ...................................................................................................... 81
11.4 Out of Warranty RepairService............................................................................ 81

Introducing the EzScan
1.1 Introduction
Thank you for purchasing the EzScan solution from Vatech.The EzScan
solution is designed and developed to produce high-quality digital
intraoral scans or models, for dental restoration or analysis.
The EzScan solution is designed with you as a dentist and your patient in
mind. The scanner is lightweight, small and easy to use, enabling fast,
accurate scanning and great patient experience. The Case management
application provides efficient and customizable order management, for
easy and intuitive use. Enjoy your new intraoral scanner solution!
1.2 Indications supported
The data sets from the EzScan can be used for the following indications.
· Conventional crowns
· Anatomic crowns
· Copings
· Provisional crowns
· Anatomical pontics
· Reduced pontics
· Provisional pontics
· Inlays/Onlays
· Implant abutments
· 3-unit implant bridges
· Up to 5-unit bridges
· Orthodontic aligners
· Nightguards
· Splints
· Retainers
· Bleach trays
· Sleep appliances
· …
* Verify with your dental lab or service provider about their capabilities
to produce particular indications.
1.3 Certification and compliance
The system has been tested and conforms to the following standards:
• IEC 60601-1, Medical electrical equipment - Part 1: General
requirements for basic safety and essential performance
• IEC 60601-1-2, Medical electrical equipment - Part 1-2: General
requirements for basic safety and essential performance - Collateral
Standard: Electromagnetic disturbances
- Requirements and tests:
• IEC 62471, Photobiological safety of lamps and lamp systems

Page 7
1.4 Regulatory
The EzScan is manufactured and marketed in accordance with US FDA
Regulations and EU Medical Device Regulation 2017/745.
1.5 Intended Use
The EzScan is an optical impression system. It is used to record the
topographical characteristics of teeth, dental impressions, or stone models
for use in the computer-aided design (CAD) and computer-aided
manufacturing (CAM) of dental restorative prosthetic devices.
1.6 Classifications
The EzScan system has the following classifications
•Protection against electrical shock: Type B Applied Part
•Protection against harmful ingress of water: Ordinary equipment
(IPX0)
•Safety of application in the presence of a flammable anesthetic
material with air or with oxygen or nitrous oxide: Equipment not
suitable for use in the presence of a flammable anesthetic mixture
with air or with oxygen or nitrous oxide.
WARNING: Unintended use of the system can result in physical injury
to the patient and operator, and damage to the system.
CAUTION: Rx only - Federal law restricts this device to be sold by or on
the order of a Dentist.

Page 8
User Manual
2. Components Overview
The EzScan system is composed of hardware and software components:
2.1 Hardware Components
The EzScan system is composed of the
following hardware components*:
1. EzScan Scanner
2. EzScan base
3. Removable autoclavable tips
4. USB 3.0 cable
5. AC/DC power adapter
Hardware Component Part Number
EzScan System (Includes3 Tips) V2810110
USB 3.0 Cable IOS-CP-00-043
AC/DC Power Adapter IOS-CP-00-088
Save the Box: It is highly recommended that you store the box in a safe place and do
not dispose of it. The box is optimal for any necessary transportation or shipment of
the EzScan.
2.2 Software Components
The EzScan system comprises the following software components:
EzScan-i : 3D Scanning and Case Management software.
EzScanCloud : Dedicated cloud platform for ordering and communicating with
labs

Page 9
2.3 System Requirements and Specifications
Scanner Specifications
Scanner Type
Hand-held (chairside) scanner that creates
optical impressions for dental restorations.
Design Compact, lightweight, ergonomic – designed
to be operated with little physical effort.
Dimensions Base Size: L 306mm, W 98mm, H 72mm
Dimensions Scanner Weight: 150 grams
Size: L 256mm, W 43mm, H 43mm
Cable length (scanner to base): 2m
Power Requirement DC 5.0V / 4A (Power supply included)
Scanner Tip
Reusable up to 250 times, sterilize using steam
autoclave
Heating Element Ventilated. Prevents formation of fog on optics
Acquisition Method/Imaging
technology
Hybrid technology: active stereo imaging and
structured light
Sensor technology CMOS
Color Scanning 24-bit (8-bit per channel)
Scanning frequency 25-30 FPS
Imaging field-of-view 12mm x 14mm
Light sources High-power LEDs
Scanning Process
Tooth Preparation No powder or spray required
Scanning Principle Continuously scanning and
accumulating (stitching) depth
and color data
Distance Scanner - Tooth 0 – 16mm
Possible contact duration by operator <10 min. Note: May vary with
hardware configuration
Operator accessible part Handpiece

Page 10
User Manual
Possible contact duration by patient t ≤ 10 min
Patient accessible part (Type B Applied Part)
Tip (autoclavable)
Computer – Scanner Interface
USB 3.0
2.4 Software output and design software compatibility
Output File Format STL, PLY, OBJ
Compatibility with CAD/CAM
Systems
Open Architecture Output format STL, PLY, OBJ
Compatible with most Dental CAD systems
2.5 Computer Requirements
Minimum Software Requirements
Operating System
Windows 10 (Excluding Windows 10 S, now
defunct) Administrative rights required
Disk Space 100 GB or greater of free disk space
Ports At least 1 x USB 3.0 port (SuperSpeed)
Nvidia Driver Nvidia Studio driver version 471.68 is currently
required. Nvidia gamer-ready driver should not
be used with the EzScan-i software.
Screen resolution Screen resolution should be 1920 x 1080 pixels
minimum
Software Configuration Recommendations
Windows automatic updates We recommend deactivating all
Windows automatic updates (except
for security updates).
Nvidia driver automatic updates Nvidia driver automatic updates
should be disabled.

Page 11
Minimum Hardware Requirements
CPU Type Intel i7 - 4 Cores or greater (10, 11 and 12 generation give best
performances)
CPU Clock
2.8 GHz clock or greater
Memory
16 GB of RAM or greater (DDR4 or better)
GPU
Quadro RTX3000, RTX4000 and above for laptop and
desktop
RTX2060 for laptop and desktop
RTX2070 for laptop and desktop
RTX2080 for laptop and desktop
RTX2080TI for desktop
RTX3060 laptop and desktop
RTX3060TI for laptop and desktop
RTX3070 for laptop and desktop
RTX3080 for laptop and desktop
RTX3090 for desktop
2.6 Environment Conditions
Operating Temperature 10°C to 40°C
Operating Relative Humidity
10% to 80% (non-condensing)
Storage Temperature - 20°C to 60°C
Storage Relative Humidity 10% to 80% (non-
condensing) Indoor use
only
Installation Category 1
Pollution Degree
2
Ingress of Liquids IPXO
Protective Class
Class IIIb
Overvoltage category II per IEC 60664-1
Max. working condition Continuous cycles with image capture
and transmission from/to Notebook or
non-medical grade PC.

Page 12
User Manual
Other possible accessories (IEC60601-1
3rd, Cl. 16)
Notebook with AC/DC Adapter.
Equipment Maintenance No user maintenance is required, and no
user service is allowed. Please contact
technical support in case of problem.
Cleaning Do not try to clean the inside of the de-
vice Refer to section 9.1: Cleaning the
Handpiece for cleaning and sterilization.
2.7 Power Input
The power adapter input is 5V DC, 100-240V AC, 50-60Hz.
2.8 Reusable Tips
Scanner tip is autoclavable up to 250 times in a steam autoclave when used with
132°C/134°C 4 mins cycle or 121°C 45 min cycle.
See below: section 9.2 Cleaning and Sterilizing Tips.
2.9 Scanner Base and Handpiece
The scanner body consists of the Docking Base and Handpiece, which are
connected by a flexible, non-detachable cable.
2.10 Calibration
The EzScan™ intraoral scanner is factory calibrated. In the case of calibration issues
due to transport, please contact your reseller or Vatech support technician.

Page 13
3. Installing and connecting the EzScan
3.1 Wall Mount Installation Instructions (Optional)
When wall mounting the scanner’s base, be careful to respect measurements
indicated to drill holes for the wall mount.
•It is recommended to use wall anchors and threaded screws with an 8mm
(5/16th inch) head diameter.
•A 4-5mm (3/16th in) distance between wall and bottom screw head is
recommended.
Caution: If the docking base is not properly installed there is a
possibility of the base falling and damaging the scanner.
IMPORTANT: Vatech is not responsible for accidents or damage
caused in the event the scanner falls.

Page 14
User Manual
3.2 Connecting the EzScan
To install and connect the EzScan Scanner:
1. Place the docking base on a flat, stable surface and place the EzScan
handpiece securely on the base.
2. Connect the AC/DC power adapter cable to the docking base (the connector
socket is located underneath thebase of the scanner).
3. Connect the provided USB 3.0 cable to the docking base (the connector
socket is located underneath the base of the scanner).
4. Connect the other end of the USB 3.0 cable to the computer.
WARNING: Using a USB cable other than the one provided may
result in system malfunction or reduced performance.
WARNING: Make sure you use the 5.0V 4A power adapter
provided. Failure to do so may result in damage to the scanning
device.

Page 15
5. Connect the adapter block provided to a power outlet.
IMPORTANT: When using a desktop computer, it is strongly
recommended to plug the USB cable to a USB port located at the
back of the computer; not doing so may result in system
malfunction or reduced performance.
DO NOT plug the USB cable into an intermediate hub.
WARNING: Unsuitable installation sites:
•Locations with excessive humidity or dust
•Locations subject to high temperature
•Locations subject to shaking or vibration
•Locations exposed to considerable electrical or magnetic
noise, or other forms of electromagnetic energy
IMPORTANT: If using a laptop computer, make sure the power
supply is connected to a power outlet and not running on battery
power. Failure to do so will mean that the scanner will not have
sufficient power to produce images.
On laptop computers, battery settings in Windows should be
configured to high performance mode only, with no battery
saving option (Settings/System/Battery).
IMPORTANT: Make sure to use a USB port that is compatible
with USB 3.0 (SuperSpeed), usually indicated by this symbol:
not doing so may result system malfunction or reduced
performance.

Page 16
User Manual
4. Getting Started With EzScan-i
Once you have connected the EzScan, you are ready to launch the EzScan-i
software installed on your computer. The EzScan-i software is launched by
selecting the IO Scanner option in EzDent-i.
4.1 Device Registration
When you launch the EzScan-i software for the first time, you will be invited to
register your EzScan device:
1. Enter your personal contact details.
2. Copy/paste the scanner serial number from General settings
3. Tick the consentbox to agree to the storage and processing of your data.
4. Click to Submit device registration information.
When you submit the device registration form, the EzScan-i interface will open
directly in the Case Setup page.

Page 17
Case Setup
The Case Setup icon is highlighted in the left-hand menu.
The Case Setup page enables you to select restorations, and to enter
restoration and order form details.
For more information see below: section 6.3 Setting Up a Case in EzScan-i
4.2 Accessing the EzScan-i Homepage
To go to the EzScan-i homepage, click on the Home icon in the top left
corner of the Case Setup window.
Patients/Cases View
In the EzScan-i homepage, you can toggle
between Patients and Cases views, and Filter
or search desired Patients/Cases.

Page 18
User Manual
Filter/Search
You can search by term or Click on the Filter icon to open the Filters dialog
box.
Patients and cases can be filtered by Gender and/or Date.
An active filter is indicated as shown above.
Select A User Start Page Default View
To select a preferred Default View for the User Start Page:
1. Click Settings.
2. In the left-hand Settings menu select General.
3. Click Preferred Start Page, and in the drop-
down menu select Recent Patients or Recent Cases.
4.3 Customizing the EzScan-i Admin User Account
To customize the EzScan-I Admin User Account (E):
1. Click the EzScan-i Admin User Account icon (E) :
This will open the User Start Screen.
2. Click the System icon located in the top right-hand corner of the User Start
Screen, to access the Settings interface.
3. Select Users in the left-hand Settings menu, and click on Add and Edit
Users.
4. Select the default “EzScan-i”
User profile, and click on the
Edit icon to customize the
default Admin User account.

Page 19
Note: The default admin ID “EzScan” cannot be
modified.
5. In the User Image field,
you can click to open the
Picture dialog box, to add
or take a User Photo.
6. To apply changes, restart
the application.
4.4 Adding a New User Account
You can use the EzScan-i Admin User profile (E) to add new User Accounts.
To add a new User account:
1. In Add and Edit Users, click ADD NEW USER:
This opens the New User dialog box.
2. Enter User information: email address, first
name, last name, registration no. (optional) and
photo (optional).
Password Protecting a User Account
To password protect a User profile (recommended):
3. Select Yes in the Use Password field.
4. Enter and confirm the password to apply to this
user account.
5. To apply User changes, close and restart the
application.

Page 20
User Manual
4.5 Accessing Your EzScan-i User Account
User accounts are displayed in the left-hand menu of the
EzScan-i Home Page.
To access your User account Start Screen:
1. Click on your User profile in the left-hand menu of the
EzScan-i Home page.
The EzScan-i Login window will open automatically,
inviting you to Login or to Create a New Account.
2. Enter the password and click SIGN IN.
4.6 Linking a User Account to the EzScanCloud
You can link your EzScan-i User account(s) to the EzScan solution’s dedicated
EzScanCloud platform. The EzScanCloud enables users to easily and efficiently setup and
manage file transfers and connections with labs.
Note: The EzScanCloud platform is designed to
facilitate file sharing and manage connections with
laboratories. It is not a cloud storage service.
To link the EzScan-i User profile to an
EzScanCloud account:
1. Using the Admin account, In Add and
Edit Users, click ADD NEW USER to
create a User account.
2. Enter account details, and in the Use
EzScanCloud field, Select Yes.
3. Click Create, to add the new User
account.
4. Click OK.
The EzScanCloud Login window will open
automatically, inviting you to Login or to
Create a New EzScanCloud Account.
