Vaxcel F0105 User manual

Model No.: F0105
LIMITED LIFETIME WARRANTY
PAGE: 1 / 11
ORIGINAL VAXCEL CEILING FAN LIMITED LIFETIME WARRANTY
The limited lifetime warranty covers this fan, for residential use by the original purchaser, against defects in material or
workmanship as follows:
If your fan motor fails at any time during the lifetime of the original purchaser due to defects in material or workmanship,
we will provide a replacement part free of charge.
If your fan motor fails at any time within one year after the original date of sale to the original purchaser due to defects
in material or workmanship, we will provide labor to repair the defect, with the exception of take down/reinstallation,
free of charge. The original purchaser will be responsible for all labor costs after this one year period.
If no replacement parts are provided for any part of your fan motor that fails at any time during your lifetime due to
defects in material or workmanship, we will refund the original purchase price of your fan.
If your fan blades, or any accessory, except glass globes and light bulbs, fails at any time within one year after the
original date of purchase due to a defect in material and workmanship, we will repair or, if we choose, replace the
defective blades, switch, or accessory free of charge, with the exception of take down/reinstallation services.
If the original purchaser ceases to own the fan, this warranty and any implied warranty, including but not limited to any
implied warranty of merchantability or fitness for a particular purpose, become void. This warranty and any implied
warranty, including but not limited to any implied warranty of merchantability or fitness for a particular purpose, do not
cover glass globes, light bulbs, or finish on any metal portions of the fan.
This warranty is in lieu of express warranties. The duration of any implied warranty of merchantability or fitness for a
particular purpose, with respect to any fan motor, blades, switch, or accessories, is expressly limited to the period of the
express warranty set forth above for such motor, blades, switch, or accessories.
This warranty excludes defects, malfunctions, or failures of any fan that are caused by repairs by persons not authorized
by us, use of parts or accessories not authorized by us, mishandling, improper installation, modifications or damage to
the fan while in your possession, or unreasonable use, including failure to provide necessary maintenance.
In no event shall VAXCEL be liable for consequential or incidental damages.
Some states do not allow the exclusion or limitation of consequential or incidental damages, in which case the above
limitation or exclusion may not apply.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
220330

PAGE: 2 / 11
Unpack your fan and check the contents. You should have the following items.
1.) Hanger Bracket
2.) Canopy
3.) Canopy Cover (Comes in a Separate Bag)
4.) Downrod Stand Cover
6.) Decorative Plate (3 PCS)
7.) Blade Bracket (3 PCS)
8.) Fan Blade (3 PCS)
9.) Fan Motor Assembly
10.) 6W E26(M) Base ST19 Type LED Bulb (5 PCS)
) Blade Balancing Kit.11
12.) Assembly Kit
13.) Installation Instructions
14.) Remote Control Set ( Includes Receiver & Transmitter & Wire Connectors & Battery
& Screws & Remote Control Instructions)
5.) Downrod Set (Includes Hanger Ball, 6″ Downrod, Hanger Pin & Lock Pin)
Package Contents:
12345678
9 10 11 12 13 14
Installation
Instructions
X10
A. 16″ B. 25″ C. 2-1/2″ D. 6″
Remote
Control
Instructions
A
C
B
D
220330

PAGE: 3 / 11
Downrod Mount
Sloped Ceiling Mount (Up to 23 degrees)
Dual Mount Drawing
Exploded View Detail
Hanger Bracket
Canopy
Canopy Cover
Downrod Stand Cover
Downrod
Hanger Ball
Collar
Lock Pin
Fan Motor Assembly
Hanger Pin
Blade Bracket
Screw Set
Blade
Decorative Plate
LED Bulb
220330

Safety Instructions
READ ALL SAFETY INFORMATION AND INSTALLATION INSTRUCTIONS BEFORE YOU BEGIN TO
INSTALL THE FAN AND SAVE INSTRUCTIONS.
All set screws of the fan must be checked and retightened where necessary before installation.
To reduce the risk of personal injury, do not bend the blade brackets when installing the brackets,
balancing the blades or cleaning the fan. Do not insert foreign objects between rotating fan blades.
Before changing the fan direction, turn off the fan and wait for the fan blades to stop completely.
The safeguards provided by these safety instructions and by the separate installation
instructions are not meant to cover all possible conditions and situations that may occur. It must be
understood that common sense, caution and care are factors which can not be built into this product.
These factors must be supplied by the person(s) installing, caring for and operating the fan.
TO AVOID RISK OF ELECTRIC SHOCK, BE SURE TO SHUT OFF POWER AT THE MAIN
FUSE OR CIRCUIT BREAKER BOX BEFORE INSTALLING OR SERVICING THIS
FIXTURE. TURNING OFF THE ELECTRICAL POWER BY USING THE LIGHT SWITCH
IS NOT SUFFICIENT TO PREVENT ELECTRICAL SHOCK.
TO REDUCE THE RISK OF INJURY, INSTALL THE FAN SO THAT THE BLADES ARE
AT LEAST 7 FEET (2.1 METERS) ABOVE THE FLOOR AND AT LEAST 18 INCHES
(0.5 METERS) FROM THE TIP OF THE BLADES TO THE WALL.
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY, MOUNT
TO OUTLET BOX MARKED "ACCEPTABLE FOR FAN SUPPORT" AND USE MOUNTING
SCREWS PROVIDED WITH THE OUTLET BOX.
THE INSTALLATION HAS TO BE IN ACCORDANCE WITH THE NATIONAL ELECTRICAL
CODE, ANSI/NFPA 70-1999 AND LOCAL CODES. IF YOU ARE UNFAMILIAR WITH THE
METHODS OF INSTALLING ELECTRICAL WIRING, SEEK THE SERVICES OF A
QUALIFIED LICENSED ELECTRICIAN.
WARNING
PAGE: 4 / 11 220330

PAGE: 5 / 11
Installation Steps :
INSTALLATION INSTRUCTIONS
IMPORTANT:
BEFORE YOU BEGIN INSTALLING THE FAN, CAREFULLY READ ALL INFORMATION N THE SEPARATE
SHEET "SAFETY INSTRUCTIONS" AS WELL AS THE FOLLOWING "INSTALLATION INSTRUCTIONS". IF IN
DOUBT, CONSULT A QUALIFIED ELECTRICIAN.
SAVE ALL INSTRUCTIONS.
NOTE: The fan weight is 16.42 lbs (7.45 kg). Be sure the outlet box you are using is securely attached to the building
structure and can support the full weight of the fan. Failure to do so can result in serious injury.
Hanger Pin
Downrod
Lock Pin
Remove the lock pin from hanger
pin and remove the hanger pin
from the downrod.
Fig.3
Loosen the collar screws out part way.
Insert the downrod into the collar.
Slide hanger pin through holes of
collar and downrod.
Tighten the two collar screws.
Slide lock pin into hanger pin
until it is locked into position.
Slide canopy, canopy cover (Making
sure the smooth side of canopy cover
is facing downward.) and downrod
stand cover onto downrod, as shown;
then thread motor wires through
downrod.
Hang fan on hanger bracket, and rotate the downrod until the chip on
the hanger bracket snaps into the slot on the hanger ball.
Note: For sloped ceiling installation, make sure the slot of hanger
ball and the chip of hanger bracket are toward the floor.
Slot
Chip
Hanger Bracket
Fig.7
Fig.5
Hanger Pin
Motor Wires
Fig.1
Turn OFF the electric circuit at the
main fuse or circuit breaker box.
Fig.4
Motor Wires
Collar
Downrod
Canopy
Canopy Cover
Downrod Stand
Cover
Tighten the hanger bracket to the outlet box with two mounting screws.(Make sure
the outlet box is securely installed so that it will be able to support at least the
fan weight.) Attach the safety cable hook to the ceiling with the drywall screw and
washer, and make sure the safety cable hook is covered by the fan canopy.
WARNING: MOUNT ONLY TO AN OUTLET BOX MARKED "ACCEPTABLE FOR
FAN SUPPORT"!
Washer
Safety Cable Hook
Drywall Screw
Ceiling
Hanger Bracket
Ceiling Joist
Wood Member
(2" x 4" Approx.)
Junction Box
Fig.5.Fig.2.
Ceiling
Hanger Bracket
Ceiling Joist
Wood Member
(2" x 4" Approx.)
Junction Box
Collar
Screws
Fig.6
Lock Pin
220330

Fig.9
Move Ground Wires (a), Outlet Box wires (b), and
Motor Wires (c) away from the center of the Hanger
Bracket. Then slide Receiver through Hanger
Bracket as shown, Antenna end first, until it is
placed in the center. Finally, cut Motor Wires (c)
to length needed for connections.
PAGE: 6 / 11
Code example:
1-ON 2-OFF 3-ON 4-OFF on both
SUR Switches.
Note: If you have two ceiling fans
with 2 remote control units, set 2
different codes for each set of
transmitter / receivers.
Fig.8a
Hang the safety cable into the safety cable hook,
tighten the safety cable to the safety cable hook
by using the zip-tie.
Fig.10
Hanger
Bracket
Hanger
Ball
Receiver
1. 4. 5.
6.
.3 .2
Antenna:
DO NOT CUT
OR SPLICE
Make wire connections:
1) The Motor white wire to the white "To Motor N" wire from
Receiver with a wire connector.
2) The Motor black wire to the black "To Motor L" wire from
Receiver with a wire connector.
3) The Motor blue wire to the blue "For Light" wire from
Receiver with a wire connector.
4) The white wire from Outlet Box to the white "AC in N" wire
from Receiver with a wire connector.
5) The black (hot) wire from Outlet Box to the black "AC in L" wire
from Receiver with a wire connector.
6) The ground wire from Outlet Box to the green ground wire
from the Hanger Ball and the green ground wire from the
Hanger Bracket with a wire connector.
Make sure all of wire connectors are connected firmly.
*** Tuck all wire connectors and wires carefully up into the
Outlet Box.
Fig.8a
Hanger Bracket
Receiver
Antenna
Fig.8
Both the transmitter and receiver have a 4-key
unit code on each SUR Switch (Fig.8) and by
default, all keys are pre-set to the "off" position.
This means that the transmitter and receiver are
already paired together. However, if you have
multiple fans and remote controls and want to
avoid interference between them, you can "pair"
other transmitters and receivers together by
adjusting the SUR switches, so the same
numbered keys are in the "ON" position
on both (Fig.8a).
Note: The ceiling fan may work abnormally
if there is interference from other remote
controls.
Antenna
SUR Switch
Transmitter
Receiver
SUR
ON
ON SUR
Fig.11
Safety Cable Hook
Safety Cable Zip-tie
220330

PAGE: 7 / 11
Slide the canopy up to ceiling and over
the two canopy screws on hanger
bracket. Rotate canopy clockwise, next,
while holding the canopy with one hand,
slide the canopy cover over the screws
and rotate clockwise until tight.
Note: Adjust the canopy screws as
necessary until the canopy and
canopy cover are snug.
Fig.12
Canopy Screw
Hanger Bracket
Canopy
Canopy Cover
NOTE: Before installing blade
brackets to the motor, please
remove the plastic inserts
Remove the motor screws from fan motor
assembly.
Secure blade brackets to the motor with
motor screws.
Fig.13
Blade Screw
Blade Bracket
Blade
Decorative
Plate
Thread the blade screws through the
blade bracket and blade into the
decorative plate. Tighten all blade
screws securely. Repeat to other
blades.
Install LED bulbs (included). See relamping label
at socket area or packaging for maximum wattage
allowed.
NOTE: Extra light kit cannot be installed.
The slide switch on switch box sets direction
of fan rotation. Select the desired direction of
fan rotation.
Push the slide switch down for " Forward" and
up for "Reverse”.
Note: Wait for fan to stop before reversing the
direction of blade rotation.
Turn ON the electric circuit at the
main fuse or circuit breaker box.
Fig.17
Fig.14
Blade
Bracket
Plastic Insert
Decorative
Plate Motor Screw
Fig.15
6W E26 (M) ST19 LED
Bulb Included
Slide
Switch
Switch Box
Fig.16
Reverse
Forward
220330

PAGE: 8 / 11
Fig.18
Transmitter
Wall Bracket
Screw
Fig.19
Install the battery (9V, included) into the transmitter.
* Press "HI" button to turn on the fan at high speed.
* Press "MED" button to turn the fan in medium speed.
* Press "LOW" button to turn the fan in low speed.
* Press "FAN OFF" button to turn off the fan.
* Press "LIGHT ON/OFF" button to turn on or turn off the light.
* Press and hold the "DIMMER" button to dim or brighten lights to the desired level and
release, and the brightness level will be memorized. Turn on the light again, then fan light
will be restored to the brightness-level at which it was dimmed last time.
Note:
1. This remote controller has a memory function setting. The fan will operate at the same
speed and the fan light will stay at the same brightness-level as the last time the power
supply was turned off.
2. Compatible Wall Switch: Lutron SKU# S2-LFSQH-WH.
Install the transmitter wall bracket on the wall with two screws and place transmitter in it carefully.
20
21
Note: Remote controller can not be used along with a solid-state speed control at the same time.
Fig.20
Fig.21
220330

Fig.22
Connect the white (neutral)
wire from motor to the white
(neutral) wire from the
outlet box with a wire
connector.
Connect the black (hot) wire
(This is for fan control) and blue
wire (This is for light control) from
motor to the black (hot) wire from
outlet box with a wire connector.
Bla
Black
ck
Blue
Green
White
White
Grounding
Green
*** After making the wire connections, the wires should
be spread apart. The white (neutral) conductor and
green (grounding) conductor on one side and the
black (hot) conductor and blue (light) conductor on
the other side of the outlet box.
*** The wire connection points should be turned upward
and pushed carefully up into outlet box.
Connect three
ground wires (Green
or bare copper) coming
from outlet box,
downrod and hanging
bracket with a wire
connector.
For a single switch
Follow these steps:
Connect three
ground wires (Green
or bare copper) coming
from outlet box,
downrod and hanging
bracket with a wire
connector.
Connect the black (hot) wire
from motor (This is for fan
control) to the black (hot)
wire from outlet box with a
wire connector.
Green
Black
Blue
Green
White
Black
Blue
(light)
White
Grounding
Connect the white (neutral)
wire from motor to the white
(neutral) wire from outlet box
with a wire connector.
Connect the blue wire (This
is for light control) from motor
to the blue wire from outlet
box with a wire connector.
*** The wire connection points should be turned
upward and pushed carefully up into outlet box.
Fig.24
Turn ON the electric circuit at the main fuse or circuit breaker box.
For dual switches
Follow these steps:
*** After making the wire connections, the wires should
be spread apart. The white (neutral) conductor and
green (grounding) conductor on one side and the
black (hot) conductor and blue (light) conductor on
the other side of the outlet box.
PAGE: 9 / 11
Fig.23
220330

Troubleshooting Guide
If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation
or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any
faults, please check this Troubleshooting Guide. If a problem cannot be remedied or you are
experiencing difficulty in installation, please call our Customer Service Department (1-800-482-9235).
PROBLEM
1. If fan does not start:
2. If fan sounds noisy:
3. If fan wobbles:
4. If light does not work:
1. Check main and branch circuit fuses or circuit breakers.
2. Check line wire connections to fan and switch wire connections in switch
housing.
CAUTION: Make sure main power is turned off.
3. Make sure that the wall control is turned "ON".
4. Make sure forward/reverse switch is firmly in bottom or top position. Fan
will not operate when switch is in the middle.
1. Make sure all screws in motor housing are snug. (not too tight)
2. Make sure the screws which attach the fan blade bracket to the motor are tight.
3. Make sure wire connectors in switch housing are not rattling against each
other or against the interior wall of the switch housing.
CAUTION: Make sure main power is turned off before accessing switch
housing.
4. If using an optional ceiling fan light kit, check to be sure the screws securing
the glassware are finger tight. Check to be sure light bulb is tight in socket and
not touching glass shade(s). If vibration persists from glass, remove glass and
install a 1/4 in. wide rubber band on glass neck to act as an insulator. Replace
glass and tighten screws against rubber band.
5. Some fan motors are sensitive to signals from Solid State variable speed
controls. DO NOT USE a Solid State variable speed control.
6. Allow "break-in" period of 24 hours. Most noises associated with a new fan will
disappear after this period.
All blades are weighed and grouped by weight. Natural woods vary in density
which could cause the fan to wobble even though all blades are weight-matched.
The following procedures should eliminate most of the wobble. Check for wobble
after each step.
1. Check that all blades are screwed firmly into blade beackets.
2. Check that all blade brackets are tightened securely to motor.
3. Make sure that canopy and mounting bracket are tightened securely to ceiling
junction box and junction box is mounted firmly to ceiling joist.
4. Most fan wobble problems are caused when blades are not equally level. To
check the blade levels, select a point on the ceiling above the tip of any blade.
Measure the distance from the ceiling to the blade tip, to an accuracy of 1/8
inch. Rotate the blades until the next blade is in the measuring position. Repeat
measurement for each blade. If all blade levels are not equal, you can adjust
blade levels by the following procedure. To adjust a blade tip down, insert a
washer (not supplied) between the blade and blade bracket at the screw
closest to the motor. To adjust a blade tip up, insert washer (not supplied)
between the blade and blade bracket at the two screws farthest from the motor.
5. If blade wobble is still noticeable, interchanging two adjacent (side by side)
blades can redistribute the weight and possibly result in smoother operation.
1. Check blue wire from fan to make sure it is connected to hot wire from house.
2. Check for loose or disconnected wires in fan switch housing.
3. Check for loose or disconnected wires in light kit.
4. Check for faulty light bulbs.
CAUTION: Make sure main power is turned off before accessing switch housing.
SUGGESTED REMEDY
PAGE: 10 / 11 220330

PAGE: 11 / 11 220330
Table of contents
Other Vaxcel Fan manuals
Popular Fan manuals by other brands

HOFFLIGHTS
HOFFLIGHTS POLYNESIA installation manual

Minka Group
Minka Group minkaAire CONCEPT I Instruction manual warranty certificate

Vent-Axia
Vent-Axia Multihome Basic NL Installation and wiring instructions

Lindab
Lindab Versio-R installation instructions

NuAire
NuAire Genie/tops 230 volt Installation and Maintenance

Alpha Fan
Alpha Fan AX20-5B/56 instruction manual

TJERNLUND
TJERNLUND Duct Booster RB10 Owner's instructions

Vortice
Vortice CA 100 MD Instruction booklet

Sunshine Solar
Sunshine Solar SSS224G installation guide

Superior
Superior RT 23I user manual

Dantherm
Dantherm HCV 400 P1 Service manual

NuTone
NuTone ROOMSIDE AERN100SN Installation and Use & Care Instructions
