Vaxcel T0517 Instruction manual

ASSEMBLY AND INSTALLATION
INSTRUCTIONS
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF
POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.
190612
NOTE: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. READ AND SAVE THESE INSTRUCTIONS.
T0517 T0518 T0519 T0522 T0523 T0524
WARNING:
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF
POWER WHILE INSTALLING OR SERVICING THIS FIXTURE.
Turn off the power at fuse or circuit box
Installation Steps
Hardware Package (included):
Green Grounding Screw (E)
Headless screw (D)
Mounting Screw (B)
Lock Nut (F)
Mounting plate (A)
Rubber Pad (H)
Ball Nut (G)
Wire Connector (C)
1. Thread two headless screws (D) through the mounting plate (A), and then secure them with four lock nuts (F)
(two on each side of the mounting plate (A).) Adjust the length of the headless screws (D) if necessary.
Note: Make sure the headless screws are lined up horizontally to make the fixture will be level.
2. Attach the mounting plate (A) to the outlet box by using two mounting screws (B).
House Grounding Wire
Wire Connector (C)
Fixture Grounding Wire
Mounting Plate (A)
Outlet Box
Fixture Wire
Lock Nut (F)
Headless Screw (D)
Mounting Screw (B)
Green Grounding Screw (E)
Back Plate
Rubber Pad (H)
Ball Nut (G)
Bulb Type A MAX 60W
(not included)

190612
Green Grounding Screw (E)
Headless screw (D)
Mounting Screw (B)
Lock Nut (F)
Mounting plate (A)
Rubber Pad (H)Ball Nut (G)
Wire Connector (C)
Turn on the power at fuse or circuit box
3. Pull out the source wires and the house grounding wire from the outlet box. Make wire connections using the
wire connectors (C):
---Connect the black wire from the fixture to the black wire from the power source.
---Connect the white wire from the fixture to the white wire from the power source.
---Attach the fixture grounding wire to the mounting plate (A) with the green grounding screw (E). Then connect it to
the house grounding wire with a wire connector (C).
Carefully put the wires back into the outlet box.
4. Attach the fixture to the mounting plate (A) by inserting headless screws (D) into holes on back plate, and then secure
it with two rubber pads (H) and two ball nuts (G).
NOTE: With silicone caulking compound,caulk complete around the back plate meets with the wall surface to
prevent water from seeping into the outlet box.
5. Install a bulb (not included). See relamping label at socket area or packaging for maximum allowed wattage.
A: 5-1/2"
T0517
T0522
B: 9-1/2"
C: 7"
A: 6-1/4"
T0518
T0523
B: 11-3/4"
C: 8"
A: 8-1/2"
T0519
T0524
B: 14-3/4"
C: 10-1/2"
Spare Parts List:
The following parts are available for re-order if damaged or missing.
Mounting Hardware
6128MM (1 SET) foT0517 T0518 T0519
6129MM (1 SET) foT0522 T0523 T0524
A
B
C
Glass
10104CS for T0517 T0522
10105CS for T0518 T0523
10106CS for T0519 T0524
