Vecow ECS-9700 User manual

USER
Manual
USER
Manual
1.1.0 Edition 20161114
ECS-9700/9600
Quad Core Intel®Xeon®/ Core™i7/ i5/ i3 Fanless Embedded System
High Performance, Rugged, Expandable, Extended Temperature

ii
Version Date Page Description Remark
1.0 11/14/2016 All Ofcial Release
Record of Revision

iii
This manual is released by Vecow Co., Ltd. for reference purpose only. All
product offerings and specications are subject to change without prior notice.
It does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable
for direct, indirect, special, incidental, or consequential damages arising out of
the use of the product or documentation or any infringements upon the rights of
third parties, which may result from such use.
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy, and if it is not installed and used
in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC
The products described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by Vecow Co., Ltd. The rights of all the brand names, product names, and
trademarks belong to their respective owners.
Disclaimer
Declaration of Conformity
Copyright and Trademarks

iv
Part Number Description
ECS-9710-505M ECS-9700, Quad Core Intel® Xeon® E3-1505M v5, 6 GigE LAN
w/ 4 PoE+, 2 SSD Tray, 1 PCIe x16, 6 USB 3.0, 4 COM, 4 SIM,
32 Isolated DIO
ECS-9710-820Q ECS-9700, Quad Core Intel® Core™ i7-6820EQ, 6 GigE LAN w/
4 PoE+, 2 SSD Tray, 1 PCIe x16, 6 USB 3.0, 4 COM, 4 SIM, 32
Isolated DIO
ECS-9710-440Q ECS-9700, Quad Core Intel® Core™ i5-6440EQ, 6 GigE LAN w/
4 PoE+, 2 SSD Tray, 1 PCIe x16, 6 USB 3.0, 4 COM, 4 SIM, 32
Isolated DIO
ECS-9701-505M ECS-9700, Quad Core Intel® Xeon® E3-1505M v5, 6 GigE LAN
w/ 4 PoE+, 2 SSD Tray, 1 PCI, 6 USB 3.0, 4 COM, 4 SIM, 32
Isolated DIO
ECS-9701-820Q ECS-9700, Quad Core Intel® Core™ i7-6820EQ, 6 GigE LAN
w/ 4 PoE+, 2 SSD Tray, 1 PCI, 6 USB 3.0, 4 COM, 4 SIM, 32
Isolated DIO
ECS-9701-440Q ECS-9700, Quad Core Intel® Core™ i5-6440EQ, 6 GigE LAN
w/ 4 PoE+, 2 SSD Tray, 1 PCI, 6 USB 3.0, 4 COM, 4 SIM, 32
Isolated DIO
ECS-9610-505M ECS-9600, Quad Core Intel® Xeon® E3-1505M v5, 2 GigE LAN,
2 SSD Tray, 1 PCIe x16, 6 USB 3.0, 4 COM, 4 SIM, 16 Isolated
DIO
ECS-9610-820Q ECS-9600, Quad Core Intel® Core™ i7-6820EQ, 2 GigE LAN,
2 SSD Tray, 1 PCIe x16, 6 USB 3.0, 4 COM, 4 SIM, 16 Isolated
DIO
ECS-9610-440Q ECS-9600, Quad Core Intel® Core™ i5-6440EQ, 2 GigE LAN,
2 SSD Tray, 1 PCIe x16, 6 USB 3.0, 4 COM, 4 SIM, 16 Isolated
DIO
ECS-9601-505M ECS-9600, Quad Core Intel® Xeon® E3-1505M v5, 2 GigE LAN,
2 SSD Tray, 1 PCI, 6 USB 3.0, 4 COM, 4 SIM, 16 Isolated DIO
ECS-9601-820Q ECS-9600, Quad Core Intel® Core™ i7-6820EQ, 2 GigE LAN,
2 SSD Tray, 1 PCI, 6 USB 3.0, 4 COM, 4 SIM, 16 Isolated DIO
ECS-9601-440Q ECS-9600, Quad Core Intel® Core™ i5-6440EQ, 2 GigE LAN,
2 SSD Tray, 1 PCI, 6 USB 3.0, 4 COM, 4 SIM, 16 Isolated DIO
Order Information

v
Part Number Description
DDR4 16G Certied DDR4 16GB 2133MHz RAM
DDR4 8G Certied DDR4 8GB 2133MHz RAM
DDR4 4G Certied DDR4 4GB 2133MHz RAM
PWA-280WB-WT 280W, 24V, 85V AC to 264V AC Power Adaptor with 3-pin
Terminal Block (7.62mm pitch), Wide Temperature -30°C to
+70°C
PWA-160WB-WT 160W, 24V, 85V AC to 264V AC Power Adaptor with 3-pin
Terminal Block (7.62mm pitch), Wide Temperature -30°C to
+70°C
VESA Mount VESA Mounting Kit
DIN-RAIL DIN Rail Kit
Rack Mount 2U Rackmount Kit
TMK2-20P-100 Terminal Block 20-pin to Terminal Block 20-pin Cable, 100cm
TMK2-20P-500 Terminal Block 20-pin to Terminal Block 20-pin Cable, 500cm
TMB-TMBK-20P Terminal Board with One 20-pin Terminal Block Connector
and DIN-Rail Mounting
3G Module Mini PCIe 3G/GPS Module with Antenna
4G Module Mini PCIe 4G/GPS Module with Antenna
WiFi & Bluetooth
Module Intel® Mini PCIe WiFi & Bluetooth Module with Antenna
Order Accessories

vi
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 2
1.3.1 Specications of ECS-9710 2
1.3.2 Specications of ECS-9701 4
1.3.3 Specications of ECS-9610 7
1.3.4 Specications of ECS-9601 9
1.4 Supported CPU List 11
1.5 Mechanical Dimension 12
1.5.1 Dimensions of ECS-9710/9701 12
1.5.2 Dimensions of ECS-9610/9601 12
CHAPTER 2 GETTING TO KNOW YOUR ECS-9700/9600 13
2.1 Packing List 13
2.2 Front Panel I/O & Functions 14
2.3 Rear Panel I/O & Functions 22
2.4 Main Board Expansion Connectors 30
2.5 Main Board Jumper & Deep Switch Settings 44
2.6 Ignition Control 49
CHAPTER 3 SYSTEM SETUP 52
3.1 How to Open Your ECS-9700/9600 52
3.2 Installing DDR4 SO-DIMM Modules 55
3.3 Installing Mini PCIe Card 56
3.4 Installing CFast Card 57

vii
3.5 Installing SIM Card 58
3.6 Installing PCI/ PCIe Card 59
3.7 Installing SSD/ HDD 61
3.8 Mounting Your ECS-9700/9600 63
CHAPTER 4 BIOS SETUP 69
4.1 Entering BIOS SETUP 69
4.2 Main 70
4.3 Advanced 70
4.4 Chipset 80
4.5 Security 85
4.6 Boot 86
4.7 Save & Exit 87
APPENDIX A : Isolated DIO Guide 88
APPENDIX B : Software Functions 94
APPENDIX C : RAID Installation Guide 96
APPENDIX D : Power Consumption 100
APPENDIX E : Supported Memory & Storage List 104

1
GENERAL INTRODUCTION
1
GENERAL INTRODUCTION
Vecow ECS-9700/9600 Series is a high-performance, all-in-one integrated,
expandable fanless embedded system. Powered by 6th generation Quad
Core Intel® Xeon®/ Core™ processor (Skylake-H) running with advanced
Intel® CM236 chipset, dual channel DDR4 2133MHz up to 32GB memory,
ECS-9700/9600 delivers up to 26% CPU performance improved than former
generations with max 80% lower CPU power consumption; Cutting-edge Intel®
HD Graphics P530/ 530 graphics engine supports DirectX 12, OpenGL 4.2 and
OpenCL 2.0 API, onboard dual DisplayPort and DVI-I display interface support
up to Ultra HD 4K resolution, ECS-9700/9600 offers up to 22% improved
graphics performance than the former generation; Multiple SATA III (6Gbps),
USB 3.0 (5Gbps), PoE (1Gbps) LAN and wireless connections make high-speed
data conveying possible. Vecow ECS-9700/9600 Series Expandable Fanless
Embedded System brings you new generation system and power productivity to
conquer demanding workloads in mission critical real-time embedded computing
applications.
All-in-one and cable-less designs, fanless -25°C to 70°C operating temperature,
6 GigE LAN ports with 4 IEEE 802.3at (25.5W/ 48V) PoE+ without additional
power connections, 2 Front-access 2.5” SSD/ HDD trays, 4 SIM card sockets (3
front-access, 1 internal) for 3G/ 4G/ LTE/ WiFi/ GPRS/ UMTS, 1 Front-access
CFast socket, 4 SATA III supports software RAID 0, 1, 5, 10 function, 6 external
USB 3.0, 1 PCI/ PCIe x16 expansion slot, 4 COM RS-232/ 422/ 485, 4 Mini
PCIe sockets, 32 Isolated DIO, 6V to 36V wide range power input with 80V
surge protection, congurable ignition power control, smart remote management
features, remote power switch, EN50155 and EN50121-3-2 compliant, optional
supports full function SUMIT A, B expansion, Vecow ECS-9700/9600 Series
Expandable Fanless Embedded System enables excellent performance, leading
integration, user-friendly, smart manageability, mobile availability and rugged
reliability possible for performance driven embedded applications.
With excellent performance, leading integrated features, smart manageability,
superb mobile availability, secure power protection and rugged reliability,
Vecow ECS-9700/9600 Series Expandable Fanless Embedded System is your
ideal choices for Machine Vision, Factory Automation, Robot Control, Smart
Manufacturing, Mobile DVR/ NVR, Intelligent Surveillance, Industry 4.0 and
any Internet of Things (IoT) performance driven real-time embedded computing
applications.
1.1 Overview

2
GENERAL INTRODUCTION
©Vecow ECS-9700/ 9600 User Manual
1.2 Features
• Quad Core Intel® Xeon®/ Core™ i7/ i5/ i3 Processor (Skylake-H) with CM236
Chipset supports up to 4K display
• 2 DDR4 2133MHz Memory, up to 32GB
• Fanless, -25°C to 70°C Operating Temperature
• 6 GigE LAN with 4 IEEE 802.3at PoE+ compliant, iAMT 11.0 supported
• 1 Easy-swap PCI/ PCIe x16 Expansion Slot
• 4 Mini PCIe Slot, 4 COM, 6 USB 3.0
• 4 SIM Card Socket (3 External) support 3G/ 4G/ LTE/ WiFi/ GPRS/ UMTS
• 2 Front-access 2.5" HDD/ SSD Tray, 1 CFast Socket
• 32 Isolated DIO
• Configurable Ignition Power Control
• 6V to 36V DC Power Input with 80V Surge Protection
1.3 Product Specication
1.3.1 Specications of ECS-9710
System
Processor Quad Core Intel® Xeon® E3-1505M v5/ Core™ i7-6820EQ/
i5-6440EQ Processor (Skylake-H)
Chipset Intel® CM236
BIOS AMI
SIO IT8786E
Memory • DDR4 2133MHz
• Up to 32GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/ 422/ 485 w/ auto flow control
USB • 6 USB 3.0 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO (16 DI, 16 DO)
LED Power, HDD, Wireless, PoE
SIM Card 4 SIM Card Socket (3 External, 1 Internal)
Expansion
Mini PCIe 4 Mini PCIe Socket :
• 1 Mini PCIe Socket for PCIe/ USB/ Internal SIM Card/
Optional mSATA
• 3 Mini PCIe Socket for PCIe/ USB/ External SIM Card

3
GENERAL INTRODUCTION
PCI/ PCIe 1 PCIe x16 Slot
SUMIT A, B 2 SUMIT Slot (Optional)
Graphics
Graphics Processor Intel® HD Graphics P530/ 530
Interface • VGA : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort 1 : Up to 4096 x 2304 @ 60Hz
• DisplayPort 2 : Up to 4096 x 2304 @ 60Hz
Storage
SATA 4 SATA III support software RAID 0, 1, 5, 10 :
• 3 SATA III (6Gbps)
• 1 SATA III co-lay with Mini PCIe (6Gbps)
mSATA 4 mSATA connection :
• 3 SATA III (Mini PCIe Type, 6Gbps)
• 1 SATA III co-lay with SATA (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/ Push-out Ejector
• 2 Front-access 2.5" SSD/ HDD Tray
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219 GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
Power
Input Voltage 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
interface
Watchdog Timer Reset : 1 to 255 sec./min. per step

4
GENERAL INTRODUCTION
©Vecow ECS-9700/ 9600 User Manual
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux
Mechanical
Dimensions (WxDxH) 260mm x 215mm x 79mm (10.2" x 8.5" x 3.1")
Weight 3.5 kg (7.72 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature -25°C to 70°C (-13°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 70°C
Shock • IEC 60068-2-27
• SSD : 50G @ Wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2
1.3.2 Specications of ECS-9701
System
Processor Quad Core Intel® Xeon® E3-1505M v5/ Core™ i7-6820EQ/
i5-6440EQ Processor (Skylake-H)
Chipset Intel® CM236
BIOS AMI
SIO IT8786E
Memory • DDR4 2133MHz
• Up to 32GB
• 2 260-pin SO-DIMM Socket

5
GENERAL INTRODUCTION
I/O Interface
Serial 4 COM RS-232/ 422/ 485 w/ auto flow control
USB • 6 USB 3.0 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO (16 DI, 16 DO)
LED Power, HDD, Wireless, PoE
SIM Card 4 SIM Card Socket (3 External, 1 Internal)
Expansion
Mini PCIe 4 Mini PCIe Socket :
• 3 Full-size for PCIe/ USB/ External SIM Card/ mSATA
• 1 Full-size for PCIe/ Internal SIM Card/ mSATA
PCI/ PCIe 1 PCI Slot
SUMIT A, B 2 SUMIT Slot (Optional)
Graphics
Graphics Processor Intel® HD Graphics P530/ 530
Interface • VGA : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort 1 : Up to 4096 x 2304 @ 60Hz
• DisplayPort 2 : Up to 4096 x 2304 @ 60Hz
Storage
SATA 4 SATA III support software RAID 0, 1, 5, 10 :
• 3 SATA III (6Gbps)
• 1 SATA III co-lay with Mini PCIe (6Gbps)
mSATA 4 mSATA connection :
• 3 SATA III (Mini PCIe Type, 6Gbps)
• 1 SATA III co-lay with SATA (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/ Push-out Ejector
• 2 Front-access 2.5" SSD/ HDD Tray
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219 GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210

6
GENERAL INTRODUCTION
©Vecow ECS-9700/ 9600 User Manual
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
Power
Input Voltage 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power
UPS Supported (Optional)
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux
Mechanical
Dimensions (WxDxH) 260mm x 215mm x 79mm (10.2" x 8.5" x 3.1")
Weight 3.5 kg (7.72 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature -25°C to 70°C (-13°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 70°C
Shock • IEC 60068-2-27
• SSD : 50G @ Wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

7
GENERAL INTRODUCTION
1.3.3 Specications of ECS-9610
System
Processor Quad Core Intel® Xeon® E3-1505M v5/ Core™ i7-6820EQ/
i5-6440EQ Processor (Skylake-H)
Chipset Intel® CM236
BIOS AMI
SIO IT8786E
Memory • DDR4 2133MHz
• Up to 32GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/ 422/ 485 w/ auto flow control
USB • 6 USB 3.0 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 16 Isolated DIO (8 DI, 8 DO)
LED Power, HDD, Wireless
SIM Card 4 SIM Card Socket (3 External, 1 Internal)
Expansion
Mini PCIe 4 Mini PCIe Socket :
• 3 Full-size for PCIe/ USB/ External SIM Card/ mSATA
• 1 Full-size for PCIe/ Internal SIM Card/ mSATA
PCI/ PCIe 1 PCIe x16 Slot
SUMIT A, B 2 SUMIT Slot (Optional)
Graphics
Graphics Processor Intel® HD Graphics P530/ 530
Interface • VGA : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort 1 : Up to 4096 x 2304 @ 60Hz
• DisplayPort 2 : Up to 4096 x 2304 @ 60Hz
Storage
SATA 4 SATA III support software RAID 0, 1, 5, 10 :
• 3 SATA III (6Gbps)
• 1 SATA III co-lay with Mini PCIe (6Gbps)
mSATA 4 mSATA connection :
• 3 SATA III (Mini PCIe Type, 6Gbps)
• 1 SATA III co-lay with SATA (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/ Push-out Ejector
• 2 Front-access 2.5" SSD/ HDD Tray

8
GENERAL INTRODUCTION
©Vecow ECS-9700/ 9600 User Manual
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN
Power
Input Voltage 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux
Mechanical
Dimensions (WxDxH) 260mm x 215mm x 79mm (10.2" x 8.5" x 3.1")
Weight 3.5 kg (7.72 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature -25°C to 70°C (-13°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 70°C
Shock • IEC 60068-2-27
• SSD : 50G @ Wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

9
GENERAL INTRODUCTION
1.3.4 Specications of ECS-9601
System
Processor Quad Core Intel® Xeon® E3-1505M v5/ Core™ i7-6820EQ/
i5-6440EQ Processor (Skylake-H)
Chipset Intel® CM236
BIOS AMI
SIO IT8786E
Memory • DDR4 2133MHz
• Up to 32GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/ 422/ 485 w/ auto flow control
USB • 6 USB 3.0 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 16 Isolated DIO (8 DI, 8 DO)
LED Power, HDD, Wireless
SIM Card 4 SIM Card Socket (3 External, 1 Internal)
Expansion
Mini PCIe 4 Mini PCIe Socket :
• 3 Full-size for PCIe/ USB/ External SIM Card/ mSATA
• 1 Full-size for PCIe/ Internal SIM Card/ mSATA
PCI/ PCIe 1 PCI Slot
SUMIT A, B 2 SUMIT Slot (Optional)
Graphics
Graphics Processor Intel® HD Graphics P530/ 530
Interface • VGA : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort 1 : Up to 4096 x 2304 @ 60Hz
• DisplayPort 2 : Up to 4096 x 2304 @ 60Hz
Storage
SATA 4 SATA III support software RAID 0, 1, 5, 10 :
• 3 SATA III (6Gbps)
• 1 SATA III co-lay with Mini PCIe (6Gbps)
mSATA 4 mSATA connection :
• 3 SATA III (Mini PCIe Type, 6Gbps)
• 1 SATA III co-lay with SATA (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/ Push-out Ejector
• 2 Front-access 2.5" SSD/ HDD Tray

10
GENERAL INTRODUCTION
©Vecow ECS-9700/ 9600 User Manual
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN
Power
Input Voltage 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux
Mechanical
Dimensions (WxDxH) 260mm x 215mm x 79mm (10.2" x 8.5" x 3.1")
Weight 3.5 kg (7.72 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature -25°C to 70°C (-13°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 70°C
Shock • IEC 60068-2-27
• SSD : 50G @ Wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

11
GENERAL INTRODUCTION
1.4 Supported CPU List
Processor No. TDP Cache Max. Frequency Embedded
Xeon® E3-1575M v5 45W 8M Up to 3.00 GHz
Xeon® E3-1545M v5 45W 8M Up to 2.90 GHz
Xeon® E3-1535M v5 45W 8M Up to 2.80 GHz
Xeon® E3-1515M v5 45W 8M Up to 2.80 GHz
Xeon® E3-1505M v5 45W 8M Up to 2.80 GHz Yes
Xeon® E3-1505L v5 25W 8M Up to 2.00 GHz
Core i7-6970HQ 45W 8M Up to 3.70 GHz
Core i7-6920HQ 45W 8M Up to 3.80 GHz
Core i7-6870HQ 45W 8M Up to 3.60 GHz
Core i7-6820HQ 45W 8M Up to 3.60 GHz
Core i7-6770HQ 45W 6M Up to 3.50 GHz
Core i7-6700HQ 45W 6M Up to 3.50 GHz
Core i7-6820EQ 45W 8M Up to 3.50 GHz Yes
Core i7-6822EQ 25W 8M Up to 2.80 GHz
Core i5-6440HQ 45W 6M Up to 3.50 GHz
Core i5-6350HQ 45W 6M Up to 3.20 GHz
Core i5-6300HQ 45W 6M Up to 3.20 GHz
Core i5-6440EQ 45W 6M Up to 3.40 GHz Yes
Core i5-6442EQ 45W 6M Up to 2.70 GHz

12
GENERAL INTRODUCTION
©Vecow ECS-9700/ 9600 User Manual
1.5 Mechanical Dimension
1.5.1 Dimensions of ECS-9710/9701
260.0 (10.24”)
282.0 (11.10”)
297.0 (11.69”)
155.0 (6.10”)
215.0 (8.46”)
79.1 (3.11”)
Unit: mm (inch)
1.5.2 Dimensions of ECS-9610/9601
260.0 (10.24”)
282.0 (11.10”)
297.0 (11.69”)
155.0 (6.10”)
215.0 (8.46”)
79.1 (3.11”)
Unit: mm (inch)

13
GETTING TO KNOW YOUR ECS-9700/ 9600
2
GETTING TO KNOW YOUR ECS-9700/9600
2.1 Packing List
Item Description Qty
1ECS-9700/9600 Expandable Fanless Embedded System
(According to the conguration you order, the ECS-9700/9600
series may contain SSD/HDD and DDR4 SO-DIMM. Please
verify these items if necessary.)
1
2ECS-9700-Accessory box, which contains
● Vecow Drivers & Utilities DVD
● Wall-mounting bracket
● KHS#6-32x6 screw for wall-mounting bracket
● M2.5x6 screw for Mini PCIe Slot
● Din-Rail-PH-M4x16.5-S Ni
● 3-pin pluggable terminal block
● 20-pin pluggable terminal block
● Foot Pad
● F-M3x4 for SSD/HDD screws
1
2
4
4
4
2
2
4
4
3 ECS-9600-Accessory box, which contains
● Vecow Drivers & Utilities DVD
● Wall-mounting bracket
● KHS#6-32x6 screw for wall-mounting bracket
● M2.5x6 screw for Mini PCIe Slot
● Din-Rail-PH-M4x16.5-S Ni
● 3-pin pluggable terminal block
● 20-pin pluggable terminal block
● Foot Pad
● F-M3x4 for SSD/HDD screws
1
2
4
4
4
2
1
4
4
