Veeder-Root DIS-51 Manual instruction

Manual No: 577014-445 •Revision: C
DIS-51
Installation, Setup & Operation Guide

Notice
Veeder-Root makes no warranty of any kind with regard to this publication, including,
but not limited to, the implied warranties of merchantability and fitness for a particular
purpose.
Veeder-Root shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance, or use
of this publication.
The information contained in this publication may be subject to change without
notice.
This publication contains proprietary information which is protected by copyright. All
rights reserved. No part of this publication may be photocopied, reproduced, or
translated to another language without the prior written consent of Veeder-Root.
Example Illustrations
Illustrations used in this publication may contain components that are customer
supplied and not included with the Veeder-Root device. Please check with your
Veeder-Root Distributor for recommended installation accessories.
©Veeder-Root 2021. All rights reserved.

iii
Table of Contents
Introduction
Overview ...................................................................................................................................1
Safety Precautions ..................................................................................................................1
General ......................................................................................................................................2
Product Components .............................................................................................................3
Technical Data .........................................................................................................................3
Gauge Requirements .............................................................................................................4
Cable Installation .....................................................................................................................4
Location .................................................................................................................................4
Connections .............................................................................................................................5
Wiring Connections ................................................................................................................5
DIS-51 To TLS Console Wiring Connections
Connection Instructions - DIS-51 to TLS2P .....................................................................8
RS-485 Serial Port Configuration On TLS2P ..............................................................8
TLS2P Software Setup For DIS-51 ................................................................................9
Connection Instructions - DIS-51 To TLS-350R .............................................................9
OPTION 1 .............................................................................................................................9
Wiring Diagram For Option 1 ........................................................................................ 10
Software Setup For Serial Port RS-485 On TLS-350R - Option 1 ..................... 10
OPTION 2 .......................................................................................................................... 10
Wiring Diagram For Option 2 ........................................................................................ 10
Software Setup For Serial Port RS-232 On TLS-350R - Option 2 ..................... 10
Connection Instructions - DIS-51 to TLS4 ..................................................................... 11
RS-485 Serial Port Configuration On TLS4 .............................................................. 11
Wiring Diagram ................................................................................................................. 11
Software Setup For TLS4 Serial 2 Port ...................................................................... 11
Connection Instructions - DIS-51 to TLS-450 Series ................................................. 13
RS-485 Serial Port Configuration On TLS-450/TLS-450PLUS ........................... 13
Wiring Diagram ................................................................................................................. 13
Software Setup For TLS-450/TLS-450 PLUS Serial 2 Port .................................. 14
DIS-51 Configuration Screens
Main Menu ............................................................................................................................. 15
Sub-Menu Language Selection ........................................................................................ 16
Sub-Menu Tank Selection .................................................................................................. 17
Sub-Menu Operating Mode ............................................................................................... 18
Sub-Menu Display Duration ............................................................................................... 18

iv
Table of Contents
Sub-Menu Display Backlight ............................................................................................. 20
Sub-Menu Information ......................................................................................................... 21
Entering and Changing the Security Code in DIS-51 ................................................. 21
Operating Instructions
Display Icons ......................................................................................................................... 24
Error screens ......................................................................................................................... 25
Alarm screens ....................................................................................................................... 25
Figures
Figure 1. System Block Diagram .....................................................................................4
Figure 2. DIS-51 Junction Box Wiring Diagram ...........................................................6
Figure 3. Serial Comm Wiring Input Options ...............................................................7
Figure 4. Serial Port Configuration For TLS2P ............................................................8
Figure 5. Single Port RS-485 Module For TLS-350R - DCD Configuration ........9
Figure 6. Serial Port 2 J38 Jumpers Set To RS-485 Positions ............................. 11
Figure 7. RS-232/RS-485 Comm Module For TLS-450/TLS-450PLUS ........... 13
Tables
Table 1. DIS-51 Cable Signals ..........................................................................................5

1
Introduction
Overview
This manual describes the installation, setup, and operations for the DIS-51 unit
sold by Gilbarco Veeder-Root.
The DIS-51 displays ullage as determined by the TLS console up to the tank
capacity. Use the display for this purpose only.
Safety Precautions
The following safety symbols are used throughout this manual to alert you to
important safety hazards and precautions.
EXPLOSIVE
Fuels and their vapors are
extremely explosive if ignited.
FLAMMABLE
Fuels and their vapors are extremely
flammable.
ELECTRICITY
High voltage exists in, and is
supplied to, the device. A poten-
tial shock hazard exists.
TURN POWER OFF
Live power to a device creates a
potential shock hazard. Turn Off
power to the device and associated
accessories when servicing the unit.
WARNING indicates a
hazardous situation which,
if not avoided, could result
in death or serious injury.
NOTICE is used to address prac-
tices not related to physical injury.

2
Introduction General
Keep out of reach of children!
General
The DIS-51 unit allows a tanker driver to connect with the station’s ATG to view
continuous level measurements for up to 32 tanks, ullage for the tanks, as well as
any alarms and warnings.
The DIS-51 display is mounted to the inside window of the station. It is operated
by the tanker driver using a push-button switch mounted outside the station in view
of the display. Pressing the button activates the display. Pushing the button
repeatedly displays tank status for each tank. The display clears when the button
has not been pressed for a long period of time.
WARNING
The equipment is used in location where lethal voltages and
explosive vapors or flammable fuels may be present.
FAILURE TO COMPLY WITH THE FOLLOWING WARNINGS
AND SAFETY PRECAUTIONS COULD CAUSE DAMAGE TO
PROPERTY, ENVIRONMENT, RESULTING IN SERIOUS
INJURY OR DEATH.
For this system:
1. Installers and operators must comply with all
applicable safety regulations. This also applies to any
local safety any accident prevention regulations which
are not stated in this manual. In addition, take
necessary precautions during installation, service, and
repair to prevent personal injury, property loss and
equipment damage.
This device must be installed into an electrical system
complying with the plant engineering regulations in
force and equipped at least wih a 2-pole, 6A, C curve,
MCB differential for supply line.
2. The installation of the DIS-51 including wiring to the
TLS console may be only carried out by expert
personnel. Refer servicing to trained and qualified
personnel only.
3. Do not change or modify the display or all any
equipment without the prior consent of Veeder-Root.
4. Substitution of components may impair intrinsic safety.
5. Be sure AC power is “Off” before opening the TLS cover
to access communication jumpers. Do not short any
voltage across any barrier terminal.

3
Introduction Product Components
Product Components
The DIS-51 kit includes:
• 1 DIS-51 unit (cable and cable gland included)
• 1 Power supply
• 1 Junction box
• 1 Push button/switch
• 5 Cable glands PG 13.5 20/25 diameter - 1 for push-button switch, 4 for
junction box
• 1 DB9 male connector (used for TLS4 serial port)
• 6 Clamps 4mm2for din bar
• 1 Clamp p/fuse 4mm2for din bar
• 2 Terminals (connector end stop for multiple series)
• 1 DIN bar
This kit includes the items you may need to connect the DIS-51 and push-button
switch to the junction box. The kit does not include the wire/cable that goes from
the console to the junction box.
Technical Data
Supply voltage 230 V~+10% - 15%
Mains frequency 50±2 Hz
Maximum input current 0,2A
IP protection degree 65
Operating temperature 0 to +40°C
Display 2,8“ LCD graphic display with back light
Communication RS-485 interface, 3-pole connection, galvanically isolated
Connection cable
Communication Shielded and twisted cable 3 x 0,25 mm2(min.)
Power supply 3 x 1,0 mm2(min.)

4
Introduction Gauge Requirements
Gauge Requirements
The DIS-51 can be connected to a Veeder-Root TLS-2, TLS-350, TLS4 or TLS-
450/TLS-450PLUS tank monitoring console via a RS-485 serial communications
port.
Cable Installation
Cable must be installed to comply with all local and national regulations that may
be in force at the time of installation. It is the installer’s responsibility to ensure that
the installation complies with all relevant and pertinent legislation and codes of
practice. Figure 1 shows the wiring connections for DIS-51 system components.
Do not run DIS-51 cabling in the same ducts as intrinsi-
cally safe TLS probes or sensors.
Figure 1. System Block Diagram
Location
The DIS-51 display is designed to be mounted against the inside window of the
kiosk and visible to the tanker driver outside the window. After determining the
ideal location for mounding the display, ensure the window is clean and dry.

5
Introduction Connections
Remove the protective paper from the sticker on the front of the display (Figure 1),
press the display firmly against the inside of the window.
Enough space must be left underneath the unit to allow the power lead and the
RS-485 cable to be connected, approximately 70 mm.
In case of Automatic Mode installation, the push button can be removed but it is
important to complete the DIS-51 configuration before removing the button and
attaching the display to the glass of the window.
The DIS-51 and installation kit (including junction box
and push-button switch) are not intrinsically safe and
must not be located in areas what may contain explosive
or inflammable concentration of petroleum vapor.
Once installed avoid getting window cleaning agents, water, etc. onto the DIS-51
display.
Connections
The cable that comes with the DIS-51 is two meters long with 7 pole connections.
The signals on this wire are shown in the Table 1 below.
The wire connectors are used to connect the wires to the power supply, push-
button switch, and cable coming from the TLS console. These connections are
done inside the junction box (see Figure 2).
Wiring Connections
The junction box is equipped with a protection fuse. If necessary, only replace the
protection fuse with one having the same characteristics: 1A, glass 5x20mm T.
Table 1. DIS-51 Cable Signals
Wire Signal
White Voltage supply, GND
Brown Voltage supply, +5V
Green RS-485 interface, B (-)
Yellow RS-485 interface, A (+)
Grey RS-485 interface, GND
Pink Button, connection 2
Blue Button, connection 1

6
Introduction Wiring Connections
Figure 2. DIS-51 Junction Box Wiring Diagram

7
Introduction Wiring Connections
Figure 3. Serial Comm Wiring Input Options

8
DIS-51 To TLS Console Wiring Connections
This section includes instructions for configuring the jumpers and serial ports and
setting up the software for applicable TLS Consoles. Instructions are specific to
each console type.
Connection Instructions - DIS-51 to TLS2P
RS-485 Serial Port Configuration On TLS2P
Set jumper J3 onto pins 1 and 2 for 2-wire configuration (see Figure 4).
Figure 4. Serial Port Configuration For TLS2P
1. Attach the RS-485 cable from the DIS-51 to TLS2P Serial Port 2 connector
(J8) as shown in Figure 3.
2. Only one terminal connector (J8 or J9) can be in use at one time. J9 is for RS-
232 only.

9
DIS-51 To TLS Console Wiring Connections Connection Instructions - DIS-51 To TLS-350R
TLS2P Software Setup For DIS-51
Go to Menu>System Setup >Comm>Serial Port and select Serial Port 2. Then
select/enter the following parameters:
• Comm Type - SERIAL
• Handshaking - None
• Baud Rate - 9600
• Parity - NO PARITY
• Data Length - 8
• Stop Bits - 1
Connection Instructions - DIS-51 To TLS-350R
OPTION 1
This is the preferred option and requires a Single Port Kit P/N 461-100-4102
which includes:
• DIS-51 Interface Module for TLS-350R, provides single RS-485 Port, P/N
330799-001 (see Figure 5).
Figure 5. Single Port RS-485 Module For TLS-350R - DCD Configuration
• Flat Cable, P/N 222-007-0001

10
DIS-51 To TLS Console Wiring Connections Connection Instructions - DIS-51 To TLS-350R
Wiring Diagram For Option 1
Figure 3 shows the wiring connection between the DIS-51 junction box and a TLS-
350R RS-485 Interface Module.
Software Setup For Serial Port RS-485 On TLS-350R - Option 1
• Comm Type - 2 (RS-485)
• Baud Rate - 9600
• Parity - None
• Stop Bits - 1
• Data Length - 8
• RS-232 Security Code - Disabled
OPTION 2
This option uses a TLS-350R RS-232 Comm Module (P/N 329362-002) and an
external RS232/RS485 Converter (P/N 500194).
The external converter must be installed outside of the DIS-51
junction box to maintain its certifications.
Wiring Diagram For Option 2
Figure 3 shows the wiring connection between the DIS-51 junction box and the
TLS-350R RS-232 Interface Module.
Software Setup For Serial Port RS-232 On TLS-350R - Option 2
• Comm Type - 2 (RS-232)
• Baud Rate - 9600
• Parity - None
• Stop Bits - 1
• Data Length - 8
• RS-232 Security Code - Disabled

11
DIS-51 To TLS Console Wiring Connections Connection Instructions - DIS-51 to TLS4
Connection Instructions - DIS-51 to TLS4
RS-485 Serial Port Configuration On TLS4
1. Put all three jumpers for the Serial Port 2 (J38) into position P2-RS-485 as
shown in Figure 6.
Figure 6. Serial Port 2 J38 Jumpers Set To RS-485 Positions
a. Turn off power to the TLS4 Console.
b. To reach the jumpers, remove the housing lid. The jumpers are located near
the lower right side of the display.
c. Close to the jumpers there are the two LEDs D15 (Rx, green) and D16 (Tx,
red) that indicate the status of the Rx and Tx lines of port 2.
d. When the communication between the DIS-51 Display and the TLS-4 is
established, both LEDs should light up periodically.
Wiring Diagram
Figure 3 shows the wiring connections between the DIS-51 junction box and the
TLS4 Serial 2 Port.
Software Setup For TLS4 Serial 2 Port
Go to Menu>Setup > Communication > Serial Port and select Serial Port 2.
Enter the following parameters:
• Label - e.g. DIS-51 Display
• Usage - RS-485
• Baud Rate - 9600
• Data Bit - 8
• Parity - No Parity

12
DIS-51 To TLS Console Wiring Connections Connection Instructions - DIS-51 to TLS4
• Stop Bit - 1
• Use Handshaking - No Handshaking
• Security Code - Serial Command Security can be used but this requires that this
feature is also enabled in the DIS-51 Display and that the
Security Code is set to the same characters in both devices.
Use Configuration menu to enable and change the Security
Code settings in the DIS-51. See “Entering and Changing the
Security Code in DIS-51” on page 21.
• RS232 End of Message - Disabled
• EXT Character Display - 0x03
• ETX Character Computer - 0x03

13
DIS-51 To TLS Console Wiring Connections Connection Instructions - DIS-51 to TLS-450 Series
Connection Instructions - DIS-51 to TLS-450 Series
The RS-232/RS-485 Comm module (P/N 330020-618 for DIS-51 communication
is shown in Figure 7.
Figure 7. RS-232/RS-485 Comm Module For TLS-450/TLS-450PLUS
RS-485 Serial Port Configuration On TLS-450/TLS-450PLUS
1. The jumpers should be set as shown in Figure 7 above:
a. J7 (determines if serial interface is RS-232 or RS-485) should be set on
pins 1 and 2. Notice the 1 on the right side of the J7 box. That is pin 1.
b. J8 should connect both pins.
2. The other jumpers should be set as shown.
Wiring Diagram
Figure 3 shows the wiring connections between the DIS-51 junction box and the
TLS-450/TLS-450PLUS RS-485 Port.
J8
J7
J11
J5

14
DIS-51 To TLS Console Wiring Connections Connection Instructions - DIS-51 to TLS-450 Series
Software Setup For TLS-450/TLS-450 PLUS Serial 2 Port
Go to Menu>Setup > Communication > Serial Port and select Serial Port 2.
Enter the following parameters:
• Label - e.g. DIS-51 Display
• Usage - RS-485
• Baud Rate - 9600
• Data Bit - 8
• Parity - No Parity
• Stop Bit - 1
• Use Handshaking - No Handshaking
• Security Code - Serial Command Security can be used but this requires that this
feature is also enabled in the DIS-51 Display and that the
Security Code is set to the same characters in both devices.
Use Configuration menu to enable and change the Security
Code settings in the DIS-51. See “Entering and Changing the
Security Code in DIS-51” on page 21.
• RS232 End of Message - Disabled
• EXT Character Display - 0x03
• ETX Character Computer - 0x03

15
DIS-51 Configuration Screens
The user enters the Configuration Main Menu after pressing on the push-button
switch for more than10 seconds.
Once in the Configuration Main Menu, the following actions can be triggered by
pressing the push-button switch as discussed below:
Pressing the push-button switch for less than 2 seconds (short press):
• The cursor (<) moves to the next line item in the menu.
• If the cursor is on the bottom line of the display and another menu item exists,
that menu item will be displayed in the bottom line.
• If the cursor is on the last available menu item, it jumps back to the top item in
the menu.
Pressing the push-button switch for more than 2 seconds (long press):
• If the cursor IS on the top line item of a menu, it returns to the next higher menu
or leaves the Configuration Main Menu.
• If the cursor is NOT on the top line of a menu, the selected menu is opened, or
the configuration is selected/changed.
After exiting the Configuration Main Menu, all changes are automatically stored and
saved even after turning off the system.
Do not interrupt the power supply while in the Configuration Menu or
any changes will not be saved.
Main Menu
Configuration Main Menu:
Configuration Main Menu (scrolled down one line):

16
DIS-51 Configuration Screens Sub-Menu Language Selection
Configuration Main Menu (scrolled down two lines):
Configuration Main Menu (scrolled down three lines):
Configuration Main Menu (scrolled down four lines):
Sub-Menu Language Selection
Available languages: via console ,English, Deutsch, Français, Español, Português,
Italiano and русский.
Configuration, sub-menu Language, via console selected:
