Veeder-Root EMR3 XStream-PKG User manual

Sp ri ng I ns t a ll at i on I nst r uc t i o n s
NOTE: Veeder-Root recommends that the EM R3 Meter Register is driven in the counter-clockwise
(CCW) rotation. When looking down at the end of the flow meter vertical drive shaft it should be
turning CCW (see below).
1. Remove the four cover bolts of the EMR³ Display Head and lift off the cover. Put the cover and bolts aside.
2. With the encoder spring in your left hand and the input shaft in your right, orient the input shaft as shown in
Figure 1, then rotate the input shaft in a counter-clockwise direction as you ‘screw’ it into the spring until the
flange on the input shaft is about 1/8” from the end of the spring.
Figure 1. Screwing Input Shaft CCW Into Encoder Spring
3. With the Encoder Spring/Input Shaft assembly in one hand, push the open spring end onto the pulse encoder’s
shaft. Work the spring onto the shaft until it is about 1/8” from the pulse encoder (Figure 2).
T
o
p
o
f
f
l
o
w
m
e
t
e
r
’
s
vertical drive shaft
P
r
e
f
e
r
r
e
d
R
o
t
a
t
i
o
n
Input Shaf
t
Spring
1/8”
0
4
K
P
4
05 KP
5
06 KP
6
07 KP
7
08 KP
8
09 AS-
10 AS
+
11 + 5
V
1
2
G
N
D
0
4
K
P
4
05 KP5
06 KP6
07 KP7
08 KP8
09 AS-
10 AS+
11 + 5V
1
2
G
N
D
Manual No. 5 7 70 13 -9 91 Rev B
NOTE: The flow meter’s
drive shaft end view may
vary depending on the flow
meter type.
NOTE: The Input Shaft’s
appearance may vary
depending on the flow
meter type.

4. Place the thin washer from the kit onto the input shaft against the underside of the flange on the input shaft
and then CAREFULLY bend the spring to insert the end of the input shaft into the center hole on the bottom
of the EMR³ display head (Figure 3. Install the meter coupling as instructed in the EMR³ Installation Guide,
Manual No. 577013-758.
Figure 3. Inserting Input Shaft Into Base Of Display Head
If additional information is required, contact Mechanical / EM R Customer Service at:
800-873-3313 Option 6
Notice
Veeder-Root makes no warranty of any kind with regard to this publication, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose.
Veeder-Root shall not be liable for errors contained herein or for incidental or consequential damages in
connection with the furnishing, performance, or use of this publication.
Veeder-Root reserves the right to change system options or features, or the information contained in this
publication.
This publication contains proprietary information which is protected by copyright. All rights reserved. No part of
this publication may be photocopied, reproduced, or translated to another language without the prior written
consent of Veeder-Root.
DAM AGE CLAIM S
1. Thoroughly examine all components and units as soon as they are received. If damaged, write a complete and
detailed description of the damage on the face of the freight bill. The carrier's agent must verify the inspection
and sign the description.
2. Immediately notify the delivering carrier of damage or loss. This notification may be given either in person or by
telephone. Written confirmation must be mailed within 48 hours. Railroads and motor carriers are reluctant to
make adjustments for damaged merchandise unless inspected and reported promptly.
3. Risk of loss, or damage to merchandise remains with the buyer. It is the buyer's responsibility to file a claim with
the carrier involved.
RETURN SHIPPING
For the parts return procedure, please follow the appropriate instructions in the "General Returned Goods Policy"
and "Parts Return" section of the Veeder-Root EMR³ price list.
