Vega VEGABAR 81 User manual

Operating Instructions
Pressure transmitter with chemical seal
VEGABAR 81
4 … 20 mA/HART
Document ID: 45018

2
Contents
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
Contents
1 About this document ............................................................................................................... 4
1.1 Function ........................................................................................................................... 4
1.2 Target group ..................................................................................................................... 4
1.3 Symbols used................................................................................................................... 4
2 For your safety ......................................................................................................................... 5
2.1 Authorised personnel ....................................................................................................... 5
2.2 Appropriate use................................................................................................................ 5
2.3 Warning about incorrect use............................................................................................. 5
2.4 General safety instructions............................................................................................... 5
2.5 EU conformity................................................................................................................... 6
2.6 Permissible process conditions........................................................................................ 6
2.7 NAMUR recommendations .............................................................................................. 6
2.8 Installation and operation in the USA and Canada ........................................................... 6
2.9 Environmental instructions ............................................................................................... 7
3 Product description ................................................................................................................. 8
3.1 Conguration.................................................................................................................... 8
3.2 Principle of operation........................................................................................................ 9
3.3 Supplementary cleaning procedures.............................................................................. 12
3.4 Packaging, transport and storage................................................................................... 12
3.5 Accessories and replacement parts ............................................................................... 13
4 Mounting................................................................................................................................. 14
4.1 General instructions ....................................................................................................... 14
4.2 Ventilation and pressure compensation.......................................................................... 15
4.3 Isolating system.............................................................................................................. 17
4.4 Process pressure measurement..................................................................................... 18
4.5 Level measurement........................................................................................................ 20
4.6 External housing ............................................................................................................ 21
5 Connecting to power supply................................................................................................. 22
5.1 Preparing the connection ............................................................................................... 22
5.2 Connecting..................................................................................................................... 23
5.3 Single chamber housing................................................................................................. 24
5.4 Double chamber housing ............................................................................................... 25
5.5 Ex-d-ia double chamber housing.................................................................................... 27
5.6 Double chamber housing with VEGADIS-Adapter.......................................................... 28
5.7 Housing IP 66/IP 68 (1 bar) ............................................................................................ 29
5.8 External housing with version IP 68 (25 bar)................................................................... 29
5.9 Connection example ...................................................................................................... 31
5.10 Switch-on phase............................................................................................................. 32
6 Set up with the display and adjustment module ................................................................ 33
6.1 Insert display and adjustment module............................................................................ 33
6.2 Adjustment system......................................................................................................... 34
6.3 Measured value indication.............................................................................................. 35
6.4 Parameter adjustment - Quick setup .............................................................................. 36
6.5 Parameter adjustment - Extended adjustment................................................................ 36
6.6 Saving the parameterisation data................................................................................... 50
7 Setup with PACTware............................................................................................................. 51

3
Contents
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
7.1 Connect the PC.............................................................................................................. 51
7.2 Parameter adjustment with PACTware............................................................................ 51
7.3 Saving the parameterisation data................................................................................... 53
8 Set up with other systems .................................................................................................... 54
8.1 DD adjustment programs ............................................................................................... 54
8.2 Field Communicator 375, 475 ........................................................................................ 54
9 Diagnosis, asset management and service ........................................................................ 55
9.1 Maintenance .................................................................................................................. 55
9.2 Diagnosis memory ......................................................................................................... 55
9.3 Asset Management function........................................................................................... 56
9.4 Rectify faults................................................................................................................... 59
9.5 Exchanging the electronics module................................................................................ 60
9.6 Exchange process module on version IP 68 (25 bar) ..................................................... 60
9.7 Software update ............................................................................................................. 61
9.8 How to proceed if a repair is necessary.......................................................................... 62
10 Dismount................................................................................................................................. 63
10.1 Dismounting steps.......................................................................................................... 63
10.2 Disposal ......................................................................................................................... 63
11 Supplement ............................................................................................................................ 64
11.1 Technical data ................................................................................................................ 64
11.2 Chemical seal with vacuum applications........................................................................ 75
11.3 Dimensions .................................................................................................................... 79
11.4 Industrial property rights................................................................................................. 88
11.5 Trademark ...................................................................................................................... 88
Safety instructions for Ex areas
TakenoteoftheExspecicsafetyinstructionsforExapplications.
These instructions are attached as documents to each instrument
with Ex approval and are part of the operating instructions.
Editing status: 2019-03-11

4
1 About this document
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
1 About this document
1.1 Function
This operating instructions provides all the information you need for
mounting, connection and setup as well as important instructions for
maintenance,faultrectication,theexchangeofpartsandthesafety
of the user. Please read this information before putting the instrument
into operation and keep this manual accessible in the immediate
vicinity of the device.
1.2 Target group
This operating instructions manual is directed to trained personnel.
Thecontentsofthismanualmustbemadeavailabletothequalied
personnel and implemented.
1.3 Symbols used
Document ID
This symbol on the front page of this instruction refers to the Docu-
ment ID. By entering the Document ID on www.vega.com you will
reach the document download.
Information, tip, note
This symbol indicates helpful additional information.
Caution: If this warning is ignored, faults or malfunctions can result.
Warning: If this warning is ignored, injury to persons and/or serious
damage to the instrument can result.
Danger: If this warning is ignored, serious injury to persons and/or
destruction of the instrument can result.
Ex applications
This symbol indicates special instructions for Ex applications.
• List
The dot set in front indicates a list with no implied sequence.
→ Action
This arrow indicates a single action.
1 Sequence of actions
Numbers set in front indicate successive steps in a procedure.
Battery disposal
This symbol indicates special information about the disposal of bat-
teries and accumulators.

5
2 For your safety
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
2 For your safety
2.1 Authorised personnel
All operations described in this documentation must be carried out
onlybytrained,qualiedpersonnelauthorisedbytheplantoperator.
During work on and with the device, the required personal protective
equipment must always be worn.
2.2 Appropriate use
The VEGABAR 81 is a pressure transmitter for process pressure and
hydrostatic level measurement.
Youcannddetailedinformationabouttheareaofapplicationin
chapter "Product description".
Operational reliability is ensured only if the instrument is properly
usedaccordingtothespecicationsintheoperatinginstructions
manual as well as possible supplementary instructions.
2.3 Warning about incorrect use
Inappropriate or incorrect use of this product can give rise to applica-
tion-specichazards,e.g.vesseloverllthroughincorrectmounting
or adjustment. Damage to property and persons or environmental
contamination can result. Also, the protective characteristics of the
instrument can be impaired.
2.4 General safety instructions
This is a state-of-the-art instrument complying with all prevailing
regulations and directives.The instrument must only be operated in a
technicallyawlessandreliablecondition.Theoperatorisresponsi-
ble for the trouble-free operation of the instrument. When measuring
aggressive or corrosive media that can cause a dangerous situation
if the instrument malfunctions, the operator has to implement suitable
measures to make sure the instrument is functioning properly.
During the entire duration of use, the user is obliged to determine the
compliance of the necessary occupational safety measures with the
current valid rules and regulations and also take note of new regula-
tions.
The safety instructions in this operating instructions manual, the na-
tional installation standards as well as the valid safety regulations and
accident prevention rules must be observed by the user.
For safety and warranty reasons, any invasive work on the device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by the manufacturer. Arbi-
traryconversionsormodicationsareexplicitlyforbidden.Forsafety
reasons,onlytheaccessoryspeciedbythemanufacturermustbe
used.
To avoid any danger, the safety approval markings and safety tips on
the device must also be observed and their meaning read in this oper-
ating instructions manual.

6
2 For your safety
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
2.5 EU conformity
ThedevicefullsthelegalrequirementsoftheapplicableEUdirec-
tives.ByaxingtheCEmarking,weconrmtheconformityofthe
instrument with these directives.
YoucanndtheEUconformitydeclarationonourwebsiteunder
www.vega.com/downloads.
2.6 Permissible process conditions
For safety reasons, the instrument must only be operated within the
permissibleprocessconditions.Youcannddetailedinformationon
the process conditions in chapter "Technical data" as well as on the
type label.
Thepermissibleprocesspressurerangeisspeciedby"MWP"
(Maximum Working Pressure) on the type label, see chapter "Struc-
ture".The MWP takes the element of the measuring cell and process-
ingttingcombinationwiththeweakestpressureintoconsideration
andmayappliedpermanently.Thespecicationreferstoareference
temperature of +20 °C (+68 °F). It also applies when a measuring cell
with a higher measuring range than the permissible pressure range of
theprocessttingisinstalledorder-related.
In order to prevent damage to the device, the test pressure may only
exceedthespeciedMWPbrieyby1.5timesatreferencetempera-
ture.Thepressurestageoftheprocessttingaswellastheoverload
resistance of the measuring cell are taken into consideration here
(see chapter "Technical Data").
Inaddition,atemperaturederatingoftheprocesstting,e.g.with
anges,canlimitthepermissibleprocesspressurerangeaccording
to the respective standard.
2.7 NAMUR recommendations
NAMUR is the automation technology user association in the process
industry in Germany. The published NAMUR recommendations are
acceptedasthestandardineldinstrumentation.
ThedevicefullstherequirementsofthefollowingNAMURrecom-
mendations:
• NE 21 – Electromagnetic compatibility of equipment
• NE 43 – Signal level for fault information from measuring transduc-
ers
• NE53–Compatibilityofelddevicesanddisplay/adjustment
components
• NE107–Self-monitoringanddiagnosisofelddevices
For further information see www.namur.de.
2.8 Installation and operation in the USA and
Canada
This information is only valid for USA and Canada. Hence the follow-
ing text is only available in the English language.

7
2 For your safety
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
Installations in the US shall comply with the relevant requirements of
the National Electrical Code (ANSI/NFPA 70).
Installations in Canada shall comply with the relevant requirements of
the Canadian Electrical Code
A Class 2 power supply unit has to be used for the installation in the
USA and Canada.
2.9 Environmental instructions
Protection of the environment is one of our most important duties.
That is why we have introduced an environment management system
with the goal of continuously improving company environmental pro-
tection.Theenvironmentmanagementsystemiscertiedaccording
to DIN EN ISO 14001.
Pleasehelpusfullthisobligationbyobservingtheenvironmental
instructions in this manual:
• Chapter "Packaging, transport and storage"
• Chapter "Disposal"

8
3 Product description
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
3 Product description
3.1 Conguration
The scope of delivery encompasses:
• Pressure transmitter
• Documentation
– Quick setup guide VEGABAR 81
– Characteristicstestcerticate
– Instructions for optional instrument features
– Ex-specic"Safety instructions" (with Ex versions)
– Ifnecessary,furthercerticates
Note:
Optional instrument features are also described in this operating
instructions manual.The respective scope of delivery results from the
orderspecication.
This operating instructions manual applies to the following instrument
versions:
• Hardware from 1.0.0
• Software from 1.3.4
Note:
Youcanndthehardwareandsoftwareversionoftheinstrumentas
follows:
• On the type plate of the electronics module
• In the adjustment menu under "Info"
Thetypelabelcontainsthemostimportantdataforidenticationand
use of the instrument:
9
10
8
6
7
2
4
3
1
5
Fig. 1: Layout of the type label (example)
1 Instrument type and product code
2 Field for approvals
3 Power supply and signal output, electronics
4 Technical data
5 Order number
6 Serial number of the instrument
7 QR code
8 Symbol of the device protection class
9 ID numbers, instrument documentation
10 Reminder to observe the instrument documentation
Scope of delivery
Scope of this operating
instructions
Type label

9
3 Product description
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
The type label contains the serial number of the instrument. With it
youcanndthefollowinginstrumentdataonourhomepage:
• Product code (HTML)
• Delivery date (HTML)
• Order-specicinstrumentfeatures(HTML)
• Operating instructions and quick setup guide at the time of ship-
ment (PDF)
• Order-specicsensordataforanelectronicsexchange(XML)
• Testcerticate(PDF)-optional
Move to "www.vega.com"andenterinthesearcheldtheserial
number of your instrument.
Alternatively, you can access the data via your smartphone:
• Download the VEGA Tools app from the "Apple App Store" or the
"Google Play Store"
• Scan the Data Matrix code on the type label of the instrument or
• Enter the serial number manually in the app
3.2 Principle of operation
VEGABAR 81 is suitable for applications in virtually all industries. It is
used for the measurement of the following pressure types.
• Gauge pressure
• Absolute pressure
• Vacuum
Measured products are gases, vapours and liquids.
The chemical seal systems of VEGABAR 81, which are optimally
adapted to the process, also allow measurement of highly corrosive
and hot products.
The VEGABAR 81 is suitable for the measurement of the following
process variables:
• Process pressure
• Level
Fig. 2: Process pressure measurement VEGABAR 81
Serial number - Instru-
ment search
Application area
Measured products
Measured variables

10
3 Product description
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
Depending on the version, the VEGABAR 81 is also suitable for
electronicdierentialpressuremeasurement.Forthis,theinstrument
is combined with a slave sensor.
Fig. 3: Electronic dierential pressure measurement through Master/Slave
combination
Youcannddetailedinformationintheoperatinginstructionsofthe
respective slave sensor.
The VEGABAR 81 is equipped with a chemical seal. It consists of a
stainless steel diaphragm and a transmission liquid.
A chemical seal has two tasks:
• Separation of the sensor element from the medium
• Transmission of the process pressure to the sensor element
1
2
3
4
Fig. 4: Conguration of a chemical seal
1 Sensor element
2 Sealed screw
3 Transmission liquid
4 Stainless steel diaphragm
Electronicdierential
pressure
Chemical seal

11
3 Product description
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
Thechemicalsealisavailableindierentversions,seechapter
"Dimensions".
The process pressure acts on the sensor element via the isolat-
ing diaphragm.The process pressure causes a resistance change
which is converted into a corresponding output signal and output as
measured value.
Measuringrangesupto40bar:piezoresistivesensorelementwith
a transmission liquid, measuring ranges from 100 bar: a dry strain
gauge (DMS) sensor element.
1
3 4
2
Fig. 5: Conguration of a measuring system with piezoresistive sensor element
1 Sensor element
2 Base element
3 Transmission liquid
4 Diaphragm
1
2
3
Fig. 6: Conguration of a measuring system with strain gauge (DMS) sensor
element
1 Sensor element
2 Process diaphragm
3 Pressure cylinder
Relative pressure: the measuring cell is open to the atmosphere.
The ambient pressure is detected in the measuring cell and compen-
sated.Itthushasnoinuenceonthemeasuredvalue.
Absolute pressure: the measuring cell is evacuated and encapsu-
lated.The ambient pressure is not compensated and does hence
inuencethemeasuredvalue.
The measuring system is completely welded and thus sealed against
the process.
Measuring system
Pressure types
Seal concept

12
3 Product description
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
Theprocessttingissealedagainsttheprocessbyasuitableseal.It
mustbeprovidedbythecustomer,dependingontheprocesstting
also included in the scope of delivery, see chapter "Technical data",
"Materials and weights".
3.3 Supplementary cleaning procedures
The VEGABAR 81 is also available in the version "Oil, grease and
silicone-free".These instruments have passed through a special
cleaning procedure to remove oil, grease and paint-wetting impair-
ment substances (PWIS).
The cleaning is carried out on all wetted parts as well as on surfaces
accessible from outside.To keep the purity level, the instruments are
immediately packed in plastic foil after the cleaning process.The
purity level remains as long as the instrument is kept in the closed
original packaging.
Caution:
The VEGABAR 81 in this version may not be used in oxygen ap-
plications. For this purpose, instruments are available in the special
version "Oil and grease-free for oxygen applications".
3.4 Packaging, transport and storage
Your instrument was protected by packaging during transport. Its
capacity to handle normal loads during transport is assured by a test
based on ISO 4180.
The packaging of standard instruments consists of environment-
friendly, recyclable cardboard. For special versions, PE foam or PE
foil is also used. Dispose of the packaging material via specialised
recycling companies.
Transport must be carried out in due consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or con-
cealed defects must be appropriately dealt with.
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated, the packages must be stored only under
the following conditions:
• Not in the open
• Dry and dust free
• Not exposed to corrosive media
• Protected against solar radiation
• Avoiding mechanical shock and vibration
• Storage and transport temperature see chapter "Supplement -
Technical data - Ambient conditions"
Packaging
Transport
Transport inspection
Storage
Storage and transport
temperature

13
3 Product description
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
• Relative humidity 20 … 85 %
With instrument weights of more than 18 kg (39.68 lbs) suitable and
approved equipment must be used for lifting and carrying.
3.5 Accessories and replacement parts
The display and adjustment module PLICSCOM is used for measured
value indication, adjustment and diagnosis.
The integrated Bluetooth module (optional) enables wireless adjust-
ment via standard adjustment devices.
The interface adapter VEGACONNECT enables the connection of
communication-capable instruments to the USB interface of a PC.
Slave sensors of VEGABAR series 80 enable in conjunction with
VEGABAR81anelectronicdierentialpressuremeasurement.
The VEGADIS 81 is an external display and adjustment unit for VEGA
plics®sensors.
The VEGADIS adapter is an accessory part for sensors with double
chamber housings. It enables the connection of VEGADIS 81 to the
sensor housing via an M12 x 1 plug.
VEGADIS 82 is suitable for measured value indication and adjustment
of sensors with HART protocol. It is looped into the 4 … 20 mA/HART
signal cable.
The PLICSMOBILE T81 is an external GSM/GPRS/UMTS radio unit
for transmission of measured values and for remote parameter adjust-
ment of HART sensors.
PLICSMOBILE 81 is an internal GSM/GPRS/UMTS radio unit for
HART sensors for transmitting measured values and for remote
parameterization.
The overvoltage arrester B81-35 is used instead of the terminals in
the single or double chamber housing.
The protective cover protects the sensor housing against soiling and
intense heat from solar radiation.
Screwedangesareavailableindierentversionsaccordingtothe
following standards: DIN 2501, EN 1092-1, BS 10, ASME B 16.5,
JIS B 2210-1984, GOST 12821-80.
Welded sockets are used to connect the sensors to the process,
threadedadaptersforadaptationofthesensorwiththreadedtting
G¾ or G1½ to existing welded sockets.
Lifting and carrying
PLICSCOM
VEGACONNECT
Slave sensors
VEGADIS 81
VEGADIS adapter
VEGADIS 82
PLICSMOBILE T81
PLICSMOBILE 81
Overvoltage protection
Protective cover
Flanges
Welded sockets and
adapters

14
4 Mounting
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
4 Mounting
4.1 General instructions
Make sure before mounting that all parts of the instrument exposed to
the process are suitable for the existing process conditions.
These are mainly:
• Active measuring component
• Processtting
• Process seal
Process conditions in particular are:
• Process pressure
• Process temperature
• Chemical properties of the medium
• Abrasionandmechanicalinuences
Youcannddetailedinformationontheprocessconditionsinchapter
"Technical data" as well as on the type label.
Protect your instrument against moisture ingress through the following
measures:
• Use a suitable connection cable (see chapter "Connecting to
power supply")
• Tighten the cable gland or plug connector
• Whenmountinghorizontally,turnthehousingsothatthecable
gland or plug connector point downward
• Lead the connection cable downward in front of the cable entry or
plug connector
This applies mainly to outdoor installations, in areas where high
humidity is expected (e.g. through cleaning processes) and on cooled
or heated vessels.
To maintain the housing protection, make sure that the housing lid is
closed during operation and locked, if necessary.
Makesurethatthedegreeofcontaminationspeciedinchapter
"Technical data" meets the existing ambient conditions.
Ondeviceswithathreadedtting,thehexagonontheprocesstting
must be tightened with a suitable wrench.
See chapter "Dimensions"forwrenchsize.
Warning:
The housing or the electrical connection may not be used for screw-
ing in! Tightening can cause damage, e. g. to the rotation mechanism
of the housing.
If there is strong vibration at the mounting location, the instrument
version with external housing should be used. See chapter "External
housing".
Process conditions
Protection against mois-
ture
Screwing in
Vibrations

15
4 Mounting
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
The permissible process pressure range is stated on the type label.
The instrument should only be operated with these pressures if the
mountingaccessoryusedalsofullsthesevalues.Thisshouldbeen-
suredbysuitableanges,weldedsockets,tensionringswithClamp
connections, sealings, etc.
Higher process temperatures often mean also higher ambient
temperatures. Make sure that the upper temperature limits stated in
chapter "Technical data" for the environment of the electronics hous-
ing and connection cable are not exceeded.
1
2
Fig. 7: Temperature ranges
1 Process temperature
2 Ambient temperature
4.2 Ventilation and pressure compensation
Thelterelementintheelectronicshousinghasthefollowingfunc-
tions:
• Ventilation of the electronics housing
• Atmospheric pressure compensation (with relative pressure meas-
uring ranges)
Caution:
Thelterelementcausesatime-delayedpressurecompensation.
When quickly opening/closing the housing cover, the measured value
can change for approx. 5 s by up to 15 mbar.
Foraneectiveventilation,thelterelementmustbealwaysfreefrom
buildup.Incaseofhorizontalmounting,turnthehousingsothatthe
lterelementpointsdownwardaftertheinstrumentisinstalled.This
provides better protection against buildup.
Caution:
Donotuseahigh-pressurecleaner.Thelterelementcouldbedam-
aged, which would allow moisture into the housing.
Thefollowingparagraphsdescribehowthelterelementisarranged
inthedierentinstrumentversions.
Process pressure range -
Mounting accessory
Temperature limits
Filter element - Function

16
4 Mounting
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
1 2 3
6
6
6 6
6
5
4
Fig. 8: Position of the lter element
1 Plastic, stainless steel single chamber (precision casting)
2 Aluminium - single chamber
3 Stainless steel single chamber (electropolished)
4 Plastic double chamber
5 Aluminium, stainless steel double chamber housing (precision casting)
6 Filter element
With the following instruments a blind plug is installed instead of the
lterelement:
• Instruments in protection IP 66/IP 68 (1 bar) - ventilation via capil-
laries in non-detachable cable
• Instruments with absolute pressure
→ Turnthemetalringinsuchawaythatthelterelementpoints
downward after installation of the instrument.This provides better
protection against buildup.
1
2
Fig. 9: Position of the lter element - Ex-d version
1 Rotatable metal ring
2 Filter element
Instruments with absolute pressure have a blind plug mounted
insteadofthelterelement.
Filter element - Position
Filter element - Position
Ex-d version

17
4 Mounting
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
The Second Line of Defense (SLOD) is a second level of the process
separation in form of a gas-tight leadthrough in the housing neck,
preventing products from penetrating into the housing.
With these instruments, the process assembly is completely en-
capsulated. An absolute pressure measuring cell is used so that no
ventilation is required.
With relative pressure measuring ranges, the ambient pressure is
detected and compensated by a reference sensor in the electronics.
1
2
1
2
Fig. 10: Position of the lter element - gastight leadthrough
1 Filter element
2 Gas-tight leadthrough
1
Fig. 11: Position of the lter element - IP 69K version
1 Filter element
Instruments with absolute pressure have a blind plug mounted
insteadofthelterelement.
4.3 Isolating system
An isolating system consists of the components:
• Chemical seal
• Pressure transmitter
Depending on the construction, there is also a transmission cable
(e.g. capillary line). The components must not be separated.
Apart from the capillary line, particularly the chemical seal diaphragm
with a material thickness of only ~0.1 mm is the most sensitive com-
ponent. Even mininal leakages in the transmitting system will lead to
• Loss of transmission liquid
• Measuring inaccuracies
Filter element - Position
Second Line of Defense
Filter element - Position
IP 69K version
Conguration

18
4 Mounting
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
• Probable failure of the measuring system
To avoid this, please note the following general handling and mount-
ing instructions.
• Leave the measuring system in the packaging until mounting to
protect it against mechanical damages
• When removing the packaging and when mounting, take special
care to avoid mechanical damage and deformation of the dia-
phragm
• Do not carry the pressure transmitter by holding the capillary line
• Do not bent the capillary lines. Kinks can cause leakage and lead
to an increase in response time
• Do not damage the isolating diaphragm: scratches on the isolating
diaphragm(e.g.fromsharpsubjects)caninuencethemeasuring
performance and are the main areas where corrosion can occur
• Select suitable seals for sealing
• Forangemounting,useasealwithasucientlylargeinner
diameter and place it centrically; contact with the diaphragm will
cause measurement deviations
• When using soft material or PTFE seals, take note of the regula-
tionsofthesealmanuacturer,particularlywithrespecttotorque
and settling cycles
• Layinvibration-freeareastoavoidadditionalpressureuctuations
• Do not lay close to heating or cooling lines
• Insulate in case of colder or warmer ambient temperatures
• Bendingradiusofthecapillaries≥150mm
With decreasing pressure, the boiling temperature of the pressure
transmission liquid decreases. With pressure values < 1 barabs, gas
molecules dissolved in the isolating liquid may be released depend-
ing on the temperature. This causes measurement deviations.
For that reason, chemical seal systems can only be used to a limited
extent in a vacuum, depending on the pressure transmission liquid,
process temperature and pressure.
The permissible combinations of vacuum and process temperature
aredierentwithindividualisolatingliquids.Chemicalsealsystems
with "Vacuum service" can be used with higher process temperatures
andhighervacuum.Youcanndthecorrespondingdiagramsinchap-
ter "Chemical seals in vacuum applications".
4.4 Process pressure measurement
Keep the following in mind when setting up the measuring system:
• Mount the instrument above the measuring point
Possiblecondensationcanthendrainointotheprocessline.
Handling
Sealing
Laying the capillaries
Use in vacuum
Measurement setup in
gases

19
4 Mounting
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
1
2
3
Fig. 12: Measurement setup for process pressure measurement of gases in
pipelines
1 VEGABAR 81
2 Blocking valve
3 Pipeline
Keep the following in mind when setting up the measuring system:
• Connect via a siphon
• Do not insulate the siphon
• Fill the siphon with water before setup
1
4
3
2
1
2
3
4
Fig. 13: Measurement setup with process pressure measurement of gases in
pipelines
1 VEGABAR 81
2 Blocking valve
3 Siphon in U or circular form
4 Pipeline
A protective accumulation of water is formed through condensation
in the pipe bends. Even in applications with hot steam, a medium
temperature < 100 °C on the transmitter is ensured.
Measurement setup in
vapours

20
4 Mounting
VEGABAR 81 • 4 … 20 mA/HART
45018-EN-190320
Keep the following in mind when setting up the measuring system:
• Mount the instrument below the measuring point
Theeectivepressurelineisalwayslledwithliquidandgasbubbles
can bubble up to the process line.
3
1
2
Fig. 14: Measurement setup for process pressure measurement of liquids in
pipelines
1 VEGABAR 81
2 Blocking valve
3 Pipeline
4.5 Level measurement
Keep the following in mind when setting up the measuring system:
• Mount the instrument below the min. level
• Donotmounttheinstrumentclosetothellingstreamoremptying
area
• Mount the instrument so that it is protected against pressure
shocks from the stirrer
Fig. 15: Measurement setup for level measurement
Measurement setup in
liquids
Measurement setup
