VeGue VS-0650 User manual

Trouble shooting guide
Product features
Charging instructions
Common function description
Vol：Adjust volume
Treble：Adjust treble
Bass： Adjust bass
Mic Vol：Adjust microphone volume
Echo：Adjust Echo
Mic：Wired microphone input
VS-0650VS-0650VS-0650
Portable SpeakerPortable SpeakerPortable Speaker
Instruction Manual
Main technical specifications
Output power------------------------------------
Input sensitivity-----------------------------
SNR-----------------------------------------
Frequency response-----------------------
Power supply----------------------------------
50W
550±30mV
≥71dB
20Hz~20KHz
DC 15V
*Above specifications are the specifications of the sampling machine and
are for reference purpose only.
*Because of continuous product improvement.specifications will keep
changing at any time without prior notification.
This system can be used with PC, DVD, VCD, MP3, Electronic Piano and any
devices with audio output.
The amplifying circuit is designed with high performance and high fidelity, and
equipped with professional and high quality speaker, it can make the sound field
positioning clear and layered.
The system voice effect is outstanding, the bass is surging and shocking, the
middle tone is strong and bright, the treble is crisp and pleasant.
Professional electronic frequency division circuit, so that the division point of
the machine more accurate, better effect.
The use of professional design and manufacture of large capacity batteries, as
well as audio power supply capacitor makes the local power reserve margin more
larger,more stable,better dynamic,higher SNR.
When charging, connect the supplied power adapter to AC 100V-240V~ for
charging. The charging time should be 4 ~ 8 hours. After being fully charged,
unplug the power supply to avoid damage to the battery due to long-term charging.
Battery level indicator: There is a battery level indicator on the
display.When the battery power is low, the entire power indicator
icon will flash, so please charge in time. When charging, the battery
indicator icon will flash. After the flashing stops, the battery should
continue to charge for 1 ~ 2 hours, which can prolong the battery life.
Note: If the battery is used out, please recharge the battery within 48 hours.Do
not leave the empty battery for a long time, otherwise the battery will be damaged.
Common
problems Possible Cause Solution
There is
no sound
when
power is
on
Distortion
of sound
Mic
is silent
MP3
is silent
1. No input source.
2. The main volume is at the
minimum position.
1. Use better music signals.
2. Adjust the volume appropriately.
1.Turn down the main volume.
2. Check whether the speaker is
damaged or not.
If it so, it needes to be repaired.
1.Volume is adjusted to max.
2.Speaker may be damaged.
1.USB song format is wrong.
2. Improper operation leads to
procedural chaos.
3. The USB /TF card is not
inserted properly.
1. Convert the format to MP3.
2. Restart the machine.
3. Unplug and re-plug into
the USB/TF card.
1. The microphone switch is not
on.
2. Mic volume is at 0 position.
3. Low battery of wireless
microphone.
1. Turn on the microphone switch.
2. Adjust the microphone volume
appropriately.
3. Replace the wireless microp-
hone battery.

LED CONTROL
LED CONTROL
Remote control instructions Function declaration
Connection diagram
*Image diagram, for reference only
*Image diagram, for reference only
1.Mute
2.Music number
3.AUX
4.Input
5.USB Input
6.Next
7.EQ
8.VOL -
9.Replay
10.PREV
11.Record
12. VOL+
13. Repeat
1.MIC
2.LED Control
3.MIC VOL
4.Echo
5.Bass
6.Treble
7.DC 15V IN
8.Power
9.Input
10.Record
11.REC.Play
12.PREV
13.Play / Pause
14.Next
15.Audio Input
16.USB
17.TF
1.Under normal circumstances, the remote control
should be used within a range of about 20 feet and
30 degrees from the remote reception window.
2.When operating the remote control, point the
remote control at the receiver window of the
machine. There should be no obstacles between
the remote control and the machine.
3.If the receiving window is in the position of strong
light, the remote control may fail. In this case,
please remove the machine,to avoid direct
exposure to strong light.
4.Please don't make both new and old batteries
work together,and regularly check whether the
remote control batteries need to be replaced.
Play function
USB port: insert USB and play music.
TF port: insert TF card and play music.
Supports MP3, WMA, and WAV music formats, outstanding sound
performance, high fax stereo design.
INPUT: to switch external Audio / Bluetooth functions.
►||: press to pause the music, press again to continue.
|◄◄ /►►|: when playing, select the PREVIOUS/NEXT music.
Bluetooth operation
Bluetooth connection method:Turn on the speaker,press the‘INPUT’key
on the speaker panel,and the screen will display ‘bt’.Use your phone to
connect the Bluetooth of the speaker.The Bluetooth name is VS-0650.
If the connection fails,please restart the device or the phone and try again.
The use range of the Bluetooth is 32ft in the open area.
*Image diagram, for reference only
Recording instuctions
Please insert USB or TF card fisrt and then press RECORD into recording
mode. When recording music at the first time, an new file "Voice" will be created
in the card and all recordings will be saved into the file. These recording files
are automatically named as REC0001,REC0002,REC0003 in sequence.
When recording music, press RECORD to puase it and press again to
continue. Press INPUT or REC.Play to quit recording mode.
Please press REC.Play into recording-play mode(automatically play the
musics recording before). Usually the machine will play the last recording
music first. Press PREV( |◄◄) or NEXT( ►►|) to select the music. Press
Replay on the remote control to replay music. If you would like to replay single
music or all musics, please press Replay repeatedly.
1.Microphone on
2.Microphone off
3.Screen
1
2
3
USB/TF
Microphone controls and basic operation
Music files in USB and TF cards should be formatted as FAT32 on the
computer.
The order about music play is based on file name,if the music file names
are as "01,02,03"in sequence.This product will play the file "01"first.
Copy MP3 or WMA music files to USB/TF cards. It is recommended to
delete unnecessary files and folders to speed up card reading and reduce
card reading problems
Power adapter
Computer,Disk drive,MP3,
Audio source,etc.
20 feet
100-240V
