Velleman CTC1000PIR User manual

CTC1000PIR
PIR MOTION SENSOR FOR CTC1000
PIR-BEWEGINGSDETECTOR VOOR CTC1000
DÉTECTEUR DE MOUVEMENTS PIR POUR CTC1000
DETECTOR DE MOVIMIENTOS PIR PARA CTC1000
PIR-BEWEGUNGSMELDER FÜR CTC1000
SENSOR DE MOVIMENTO PIR PARA O CTC1000
USER MANUAL 3
GEBRUIKERSHANDLEIDING 11
MODE D'EMPLOI 19
MANUAL DEL USUARIO 28
BEDIENUNGSANLEITUNG 36
MANUAL DO UTILIZADOR 44

CTC1000PIR
V. 01 –12/06/2013 2 ©Velleman nv

CTC1000PIR
V. 01 –12/06/2013 3 ©Velleman nv
USER MANUAL
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that
disposal of the device after its lifecycle could harm the
environment. Do not dispose of the unit (or batteries) as
unsorted municipal waste; it should be taken to a
specialized company for recycling. This device should be
returned to your distributor or to a local recycling
service. Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for choosing Velleman! Please read the manual thoroughly
before bringing this device into service. If the device was damaged in
transit, don't install or use it and contact your dealer.
2. Safety Instructions
Keep the device away from children and
unauthorised users.
Indoor use only.
Keep this device away from rain, moisture, splashing
and dripping liquids.
Damage caused by disregard of certain guidelines in this manual
is not covered by the warranty and the dealer will not accept
responsibility for any ensuing defects or problems.
Keep the device away from splashing and dripping liquids.
Note that damage caused by user modifications to the device is
not covered by the warranty.
This system can provide valuable protection for your home and
property if used properly. However, it cannot guarantee complete
protection against burglary or robbery. Therefore, VELLEMAN nv
will not be responsible for any losses or damages which occur
during the use of this product.

CTC1000PIR
V. 01 –12/06/2013 4 ©Velleman nv
3. General Guidelines
Refer to the Velleman® Service and Quality Warranty on the last
pages of this manual.
Have the system installed by a qualified installer.
Respect the legislation in your region when installing an alarm
system. If necessary, refer to local authorities.
Protect this device from shocks and abuse. Avoid brute force when
operating the device.
Protected the device against extreme heat, dust and moisture.
Familiarise yourself with the functions of the device before actually
using it.
All modifications of the device are forbidden for safety reasons.
The device does not contain any user-serviceable parts except for
the battery.
Only use the device for its intended purpose. Using the device in
an unauthorised way will void the warranty.
4. Features
eliminates false alarms caused by pets
lithium battery pre-installed for easy installation
microprocessor with advanced Digitized Adaptive Signal Processor
algorithm
wall or corner mounting
tamper-proof: housing cannot be opened or removed from the
mounting surface
randomized supervision signals for trouble-free system integrity
checking
low battery detection
superior white-light interference rejection
detection range: 12 m at 110° angle
superior radio frequency interference rejection of up to 20 V/m at
frequencies of 100 kHz to 1 GHz
automatic energy saving mechanism
insect and dirt proof
compact and unobtrusive design
LED: error and test mode indicator
LED also doubles as the "walk test" activation button
works with the control panel CTC1000 (not included)

CTC1000PIR
V. 01 –12/06/2013 5 ©Velleman nv
5. Overview
Refer to the illustrations on page 2 of this manual.
1
test button / LED indicator
2
battery protection strip
3
tamper switch
4
corner mounting bracket
5
sensitivity switch
6. Battery
The detector comes with the battery already installed.
Low battery detection
The detector has a low battery detection system. Low battery
detection operates where the PIR has enough reserve energy to
typically operate for 1 month before complete exhaustion. A low
battery signal will be sent to the control panel along with regular
signal transmissions for the control panel to display the status
accordingly.
Replacing the battery
1. Put the control panel in configuration mode to avoid triggering
the tamper alarm (tamper alarm is not active in this mode).
2. Remove the screw at the bottom of the detector and separate
both parts.
3. Remove the battery.
4. Press the tamper switch twice to fully discharge before inserting
new batteries.
5. Insert a new battery (always use the correct battery type: see
Technical specifications). Make sure the polarity is correct.
6. Close the detector using the screw.
7. On the control panel, exit configuration mode.
WARNING
Do not puncture or throw batteries in fire as they might
explode.
Keep batteries away from children.
