USER MANUAL
1. Introduction
To all residents of the European Union
Important environmental information about thisproduct
T his symbol on the device or the package indicates that disposal of
the device after its lifecycle could harm the environment. Do not
dispose of the unit (or batteries) as unsorted municipalwaste; it
should be taken to a specialized company for recycling. T his device
should be returned to your distributor or to a local recycling
s ervice. Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
T hank you for choosing Velleman! Please read the manual thoroughly before
bringing this device into service. If the device was damaged in transit, do
not install or use it and contact your dealer.
2. Safety Instructions
Keep this device away from children and unauthorized users.
Indoor use only. Keep this device away from rain, moisture,
splashing anddripping liquids.
O nly use with compatible rechargeable batteries. Any attempt to recharge
other battery typesor non-rechargeable batteriesmay result in exploding
batteries, injury and a damaged device.
3. General Guidelines
Refer to the Velleman® Service and Quality Warranty on the last pages
of this manual.
4. Features
T wo independent charging c hannels charge two batteriesindependently,
with IC monitor, algorithm (TC, CC, CV) charging system.
3 c harging current options: 0 .25 A / 0 .5 A / 1 A
3 c harging voltage options: 3.2 V / 3 .6 V / 3 .8 V
charge for: 10440 / 14500 / 1 4650 / 16340 / 1 7670 / 1 8350/ 1 8500/
18 650 (ICR18650-26) / 1 8700/ 2 2650 / 2 5500 / 2 6650 3.0 V / 3.2 V,
3.6 V /3.7 V, 3 .8 V Li-ion batteries
low-voltage, overload and overheat protection, power indication
LED s tatus indications

VLEVP2
V. 01 –04/02/2015 4 ©Velleman nv
real-time status display
P WM technology to c ontrol the high-efficiency DC-DC circuit, lower the
voltage and reduce energy loss
three-stage charging and 0 V battery activation
IC temperature monitor prevents overheating
soft start charging
compact size, portable
reverse polarity and short c ircuit protection circuit
5. Overview
Refer to the illustrations on page 2 of this manual.
1
battery slot
3
voltage button
2
charging/USB LED
4
display
Display
5
c harge current s etting / voltage selection / U SB output button
6
c harging / U SB power indicator
7
pres ent charging current
8
pres ent charging voltage
9
pres ent battery power s tate
Charging Rate
0 .2 5 A: constant c harging current 500 mA
0 .5 A : c onstant charging c urrent 1000 mA
1 A : c onstant charging c urrent 2000 mA
Charging State and Battery Power Indication
charging
0 % - 20 %
20 % - 40 %
40 % - 60 %
60 % - 80 %
80 % - 99 %
100 %
When the battery voltage reaches the next stage, one more bare will be
added. No battery level icon will be displayed in the c orresponding
c hannel when the c hargeris in one of the following c onditions:

VLEVP2
V. 01 –04/02/2015 5 ©Velleman nv
ono battery is placed in the c hannel
os hort c ircuit
obattery voltage < 1 .0 V
obattery is reversed or poorly connected
Charging LED Indication
status
LED indic ation
charger s elf-check
red (2 s ec onds )
charger s tand-by
green
battery
ac tivated
1.0 V - 2.0 V
red
< 1.0 V
green
charging
red
fully c harged
green
U SB output
power
indic ation
> 50 %
green
25 % - 50 %
red
5 % - 25 %
red flas hing
< 5 %
off
Due to different battery types, deviationbetween the value on the
indicator and the battery’s actual capacity exist. I n addition, when the
battery is c harging, the LCD displays the battery’s charging voltage
(inc luding the voltage generated by the battery’s internal resistance).
When the battery is fully charged or not connected, the LCDdisplays
the no-load voltage of the battery.
6. Operation
Before charging your batteries, c heck that the battery types are c ompatible
with the VLEVP2. T hen, determine the suitable charge current and voltage
settings for them.
Remark
Damage c anoccur to the batteries and charger if incompatible batteries are
ins erted, or if impropercharge current and voltage settings are s elected.
Charging Batteries
1. C onnect the supplied power adapter to the VLEVP2. The VLEVP2
performs a s elf-check, turning on two LEDs (red s tatus indicator).
During the s elf-check, the LCD displays the battery powerindicator
and the selected voltage. After about two seconds, the two indicators
turn green. T he charger thenswitchesto standby mode, no battery
ic on will be displayed but the s elected voltage and default 0 .25 A
charge current.
2. Slide the voltage s etting switch to c hoose the suitable voltage for your
battery. T he LCDwill display the corresponding selected voltage. For
example, if your battery’s nominal voltage is 3 .6 V / 3 .7 V, thenyou
s hould choose the 3.6 V voltage.

VLEVP2
V. 01 –04/02/2015 6 ©Velleman nv
3. C hoose the charge current that best suits your rechargeable Li-ion
batteries:
0.25 A
s uitable for 10440-18700 Li-ionbatteries
0.5 A
s uitable for 18700-26650 Li-ionbatteries with
capacity ≥ 2 500mAh
1 A
s uitable for Li-ionbatteries withc apacity ≥
20 00 mAh, 1 A is the large charge c urrent for fast
charging
4. P ress the CC button one or more times to c hange to a different c harge
current. C urrent arrangement is 0 .25 A - 0.5 A - 1 A - 0.25A.
5. During charging, double-press the c urrent c hange button to check the
s elected voltage setting. The corresponding LCD displays the selected
voltage. Choose the voltage s etting suitable for your battery. After
about 3 s econds, the LCD reverts to show the c harge current, battery
real-time voltage and c harge status.
6. When the battery is fully charged, the VLEVP2 stops c harging, and the
s tatus indicator turns green. T he bars on the LCD will notbe added
again. Itis recommendedthat you remove the batteries from the
charger once charging has completed. I f batteries are left in the
charger after charging c ompletes, the c hargerwill automatically restart
the c harging cycle when the voltage drops below 3.9 V or 3.3 V, based
on the c hosenvoltage s etting.
7. D uring c harging, press and hold the c harge current s etting button
1.5 s econds to switch the LCD on or off. T he LCD is s witched on by
default.
USB Power Output Mode
1. E nsure that the VLEVP2 is not connected to any power source. I nsert a
battery (≥ 2 000 mAh) into the CH1 slot, being c areful to insert it with
the c orrect polarity. P ress and holdthe buttonfor 1.5 s econds to s tart
the U SB power output function. After the LEDindicator turns green,
you c anc onnect an external device to the USB port. I n USB output
mode, the LCD is invalid.
2. When finished using the USB power output, disconnect the external
device, press and hold the button for 1.5 seconds to switch off the USB
power output. After the status indicator extinguishes, remove the
battery.
3. When battery c apacity is above 50 % , the LED indicator is green;
when c apacity is 25 % to 50 % , the LED indicator is red; when
c apacity is 5 % to 25 %, the LED indicator flashes red.
4. When the battery c apacity is low than 5 %, the USB power output
switches off automatically.

VLEVP2
V. 01 –04/02/2015 7 ©Velleman nv
Remarks
T he VLEVP2 is only for use with 3.0 V / 3 .2 V, 3.6 V / 3 .7 V, 3.8 V
rec hargeable Li-ion or LiFePO batteries. Charging other battery types
may be hazardous, and can damage the batteriesand charger.
T he VLEVP2 has an integrated short-circuit protection to protect the
charger if a short c ircuit occurs in a battery. Note that this short-circuit
protection protects the charger and doesnot prevent batteries from
s hort-circuiting internally.
Keep the VLEVP2 away fromwater and excessive dust.
Do not disassemble the VLEVP2as damage may result.
D o not use a damaged VLEVP2.
Tips
T he USB power output is only available when no externalpower source
is c onnected and the battery is inserted into the CH1 s lot.
P ress and hold the c harge current s etting to check the selected voltage.
Suitable voltage is s trongly being recommended.
Because of different battery types, c apacities and over-charge depths,
the battery revive time may vary. Heavily over-dischargedbatteries
may not be able to be revived.
D o not judge the battery is being c harged or not when it is in the
process of activation.
T o lengthen the over-discharged battery’s lifespan, a 0 .25 A c harge
current and suitable voltage are strongly beingrecommended.
Specifications and features are subject to change. P lease findthe most
rec ent description and s pecifications of the VLEVP2 on the Velleman
webs ite.
7. Cleaning and Maintenance
T his device does not need any particular maintenance. However,
occasionally clean it with a dampc loth to keep it like new.
8. Technical Specifications
input power
12 VDC, 1 A
c harge current options
0 .2 5 A constant c urrent
25 0 ± 3 0 mA
0.5 A c onstant current
50 0 ± 5 0 mA
1 A c onstant current
10 00 ± 80 mA
c orresponding terminationvoltage for three voltage options
3.2 V
3.6 ± 0 .05 V
3.6 V
4.2 ± 0 .05 V
3.8 V
4.35 ± 0 .05 V
T C of 0 .25 A / 0 .5 A
≤ 5 0 mA

VLEVP2
V. 01 –04/02/2015 8 ©Velleman nv
T C of 1 A
≤ 8 0 mA
res tart c harge automatically
3.2 V voltage gear
3.3 ± 0 .15 V
3.6 V / 3 .8 V voltage gear
3.9 ± 0 .15 V
voltage display precision
± 0 .03 V
operating temperature
0-40° C
U SB output parameter
U SB output voltage
5.0 ±0.3 V
max. U SB out c urrent
10 00 mA
battery overcharge discharge
protection voltage
3.0 ± 0.2 V
dimensions
13 5 x 68 x 35 mm
weight
12 5 g
Use this device with original accessories only. Velleman nv cannot
be held responsible in the event of damage or injury resulting f rom
(incorrect) use of this device. For more info concerning this product
and the latest version of this manual, please visit our website
www.velleman.eu. The information in this manual is subject to
change without prior notice.
© COPYRIGHT NOTICE
The copyright to this manual is owned by Velleman nv. All
worldwide rights reserved. N o part of this manual may be copied,
reproduced, translated or reduced to any electronic medium or otherwise
without the prior written consent of the copyright holder.

VLEVP2
V. 01 –04/02/2015 9 ©Velleman nv
GEBRUIKERSHANDLEIDING
1. Inleiding
Aan alle burgers van de Europese Unie
Belangrijke milieu-informatie betreffende dit product
Dit symbool op het toestelof de verpakking geeft aan dat, als het
na zijn levenscyclus wordt weggeworpen, dit toestel schade kan
toebrengen aan het milieu. Gooi dit toestel(en eventuele
batterijen) niet bij het gewone huishoudelijke afval; het moet bij
een gespecialiseerd bedrijf terechtkomen voorrecyclage. U moet
dit toestel naaruw dealer of naar een lokaal recyclagepunt
brengen. Respecteerde plaatselijke milieuwetgeving.
Hebt u vragen, contacteer dan de plaatselijke autoriteiten
betreffende de verwijdering.
Dank u vooruw aankoop! Leesdeze handleiding grondig vooru het toestel
in gebruik neemt. Werd het toestel beschadigd ti jdens het transport,
ins talleer het danniet en raadpleeguw dealer.
2. Veiligheidsinstructies
Houd dit toestel buiten het bereik van kinderen en onbevoegden.
Gebruik het toestel enkel binnenshuis. Bescherm het toestel
tegen regen, vochtigheid en opspattendevloeistoffen.
E nkel gebruiken met compatibele herlaadbare batterijen. H et opladen van
andere of niet-herlaadbare batterijtypeskanleidentot ontploffende
batterijen, verwondingen en een beschadigd toestel.
3. Algemene richtlijnen
Raadpleeg de Velleman® service- en kwaliteitsgarantie achteraandeze
handleiding.
4. Eigenschappen
T wee onafhankelijke oplaadkanalenladen twee batterijenonafhankelijk op,
met I C monitor, algoritme (TC, CC, CV) oplaadsysteem.
3 laadstromen:0,25 A / 0,5 A / 1 A
3 l3 .2 V / 3.6 V / 3.8 V
geschikt voor het opladen van:10440/ 1 4500 / 1 4650 / 1 6340 / 1 7670
/ 1 8350 / 1 8500/ 18650 (ICR18650-26) / 18700 / 2 2650 / 25500 /
26 650 3.0 V / 3.2 V, 3.6 V /3 .7 V, 3 .8 V Li-ion batterijen

VLEVP2
V. 01 –04/02/2015 10 ©Velleman nv
laagspanning-, overlaad- en oververhittingsbescherming, aanduiding
batterijniveau
LED-statusindicatie
real-time status display
P WM-technologie voorcontrole van het high-efficiency DC-DC circuit,
spanningsverlaging en vermindering van energieverlies.
opladenin 3 fasenen 0 V-batterij-activatie
IC-temperatuurmonitor voorkomt oververhitting
softstart laden
compact, draagbaar
omgekeerde polariteit en beveiligd tegen kortsluiting
5. Omschrijving
Raadpleeg de afbeeldingen op pagina 2 van deze handleiding.
1
batterijvak
3
spanningknop
2
oplaad/USB-LED
4
display
Display
5
laadstroomregeling / s panningselectie / U SB-uitgangsknop
6
oplaad-/USB-vermogen-indicator
7
huidige laadstroom
8
huidige laadspanning
9
huidige batterijsterkte
Oplaadsnelheid
0,25 A: constante laadstroom 500 mA
0,5 A: constante laadstroom 1000 mA
1 A : c onstante laadstroom 2000 mA
Laadstatus- en batterijvermogen-indicatie
opladen
0 % - 20 %
20 % - 40 %
40 % - 60 %
60 % - 80 %
80 % - 99 %
100 %
