Vent-Axia HR500D Assembly instructions

Copyright © 2009 Vent-Axia Limited. All rights reserved.
HR500D
Semi-Remote Wall Mounted Heat
Recovery Unit with Spigot
Connections & Integral Fans
Installation and Wiring Instructions
Stock Ref. N°
370450 - HR500D
PLEASE RETAIN THESE INSTRUCTIONS WITH THE PRODUCT.

Warnings & Safety Information
2
IMPORTANT SAFETY
INFORMATION
PLEASE READ THESE
INSTRUCTIONS
CAREFULLY BEFORE
COMMENCING
INSTALLATION.
1. Do not install this product in areas
where the following may be present or
occur:
• Excessive oil or a grease laden
atmosphere.
• Corrosive or flammable gases,
liquids or vapours.
• Subject to direct water spray from
hoses.
• Ambient temperatures higher than
40°C.
• Possible obstructions that may
hinder access to or removal of the unit.
2. All wiring must be in accordance
with the current IEE wiring regulations
BS7671, or appropriate standards of
your country. Installation should be
inspected and tested by a suitably
qualified person after completion.
3. Ensure the mains supply (voltage,
frequency and phase) complies with
the rating label.
4. The power feed to the unit should
be provided with a local double pole
fused spur fitted with a 3A fuse having
a contact separation of at least 3mm.
5. This unit must be earthed.
6. Precautions must be taken to avoid
the back-flow of gases into the building
from the open flue of gas or other fuel-
burning appliances.
7. This appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision or
instruction concerning use of the
appliance by a person responsible for
their safety.
8. Young children should be
supervised to ensure that they do not
play with the appliance.
INSTALLATION GUIDANCE
1. The installer is responsible for the installation and
electrical connection of the system on site. It is the
responsibility of the installer to ensure that the
equipment is safely and securely installed and left
only when mechanically and electrically safe.
2. All regulations and requirements must be strictly
followed to prevent hazards to life and property,
both during and after installation, and during any
subsequent servicing and maintenance.
Disposal
This product should not be disposed of with
household waste. Please recycle where facilities
exist. Check with your local authority for recycling
advice.

3

4

5

6

7

8

9

Product FICHE
10

Product FICHE
11
PRODUCT FICHE
For Residential Ventilation Units (Complying Commission Delegated Regulation (EU)
No 1254/2014)
Name: Vent‐Axia
ModelID(StockRef.):HR500D‐370450
SECClassC
SECValue('Average') ‐24.00
SECValue('Warm') ‐2.84
SECValue('Cold') ‐61.72
LabelRequired?(Yes/No=Outofscope)Yes
Declaredas:RVUorNRVU/UVUorBVURVU/BVU
SpeedDriveVariableSpeed
TypeHRS(Recuperative,Regenerative,None)VariableSpeed
ThermalEff:[(%),NA(ifnone)]Recuperative
Max.FlowRate(m3/h)626.40
Max.PowerInput(W):(@Max.FlowRate)210.00
LWA:SoundPowerLevel(dB)70.52
Ref.FlowRate(m3/s)0.12180
Ref.PressureDiff.(Pa)70.00
SPI[W/(m3/h)]0.48
ControlFactor&ControlTypology:(CTRL/Typology)
ControlFactor;CTRL1.00
ControlTypologyManualControl
Declared:‐MaxInternal&ExternalLeakageRates(%)forBVUsorcarryover(forregenerative
heatexchangersonly),‐
&Ext.LeakageRates(%)forDuctedUVUs;
<5%Internal,<5%External
MixingRateofNon‐DuctedBVUsnotintendedtobeequippedwithoneductconnectionon
eithersupplyorextractairside;N/A
PositionanddescriptionofvisualfilterwarningforRVUsintendedforusewithfilters,including
textpointingouttheimportanceofregularfilterchangesforperformanceandenergy
efficiencyoftheunit
N/A
ForUVUs(InstructionsInstallRegulatedSupply/ExtractGrillesFaçade)N/A
InternetAddress(forDisassemblyInstructions)www.vent‐axia.com
Sensitivityp.Variation@+20/‐20Pa:(forNon‐DuctedVUs)N/A
AirTightness‐ID/OD‐(m3/h)(forNon‐DuctedVUs)N/A
AnnualElectricityConsumption:AEC(kWh/a)6.45
AnnualHeatingSaved:AHS(kWh/a)
AHS:Average39.45
AHS:Warm17.84
AHS:Cold77.17

Guarantee and Contact information
12
Head Office: Fleming Way, Crawley, West Sussex, RH10 9YX.
UK NATIONAL CALL CENTRE, Newton Road, Crawley, West Sussex, RH10 9JA
SALES ENQUIRIES: Tel: [phone] Fax: [phone]
TECHNICAL SUPPORT Tel: [phone] Fax: [phone]
For details of the warranty and returns procedure please refer to www.vent-axia or write to Vent-Axia Ltd, Fleming Way, Crawley, RH10 9YX
370695C © 2016 Vent-Axia Limited. All rights reserved. 1116
