Vent-Axia Sentinel Kinetic User manual

V:\Technical\ARTWORK\Fitting & Wiring\Word Files COMPLETE\442073S.doc
442073SCopyright © 2009 Vent-Axia Limited. All rights reserved.
Sentinel
Kinetic MVHR
and
Kinetic Plus MVHR
Operation & Monitoring
Stock Ref. N°
438222 Kinetic B
438222A Kinetic BS
443319 Kinetic BH
443319A Kinetic S BH
438342 Kinetic V
438342A Kinetic VS
443028 Kinetic Plus B
447938 Kinetic Plus BS
443029 Kinetic Plus CVP
PLEASE RETAIN THESE INSTRUCTIONS WITH THE PRODUCT.

About this Document
Sentinel Kinetic MVHR Operation & Monitoring 2
IMPORTANT
PLEASE READ THESE INSTRUCTIONS
CAREFULLY BEFORE USING THE UNIT.
1. THIS APPLIANCE IS NOT INTENDED FOR USE BY YOUNG
CHILDREN OR INFIRM PERSONS WITHOUT SUPERVISION.
2. YOUNG CHILDREN SHOULD BE SUPERVISED TO ENSURE
THAT THEY DO NOT PLAY WITH THE APPLIANCE.
3. DO NOT ATTEMPT TO REMOVE THE COVERS OF THIS
UNIT. HIGH VOLTAGE IS PRESENT IN THIS UNIT.
Disposal
This product should not be disposed of with
household waste. Please recycle where
facilities exist. Check with your local authority
for recycling advice.
Software Ver 28
Contents
Product Description 3
Sentinel Kinetic & Sentinel Kinetic Plus.........................................3
Control Unit Display .......................................................................5
Powering Up the Unit .....................................................................7
Startup Screens .............................................................................7
Operation and Monitoring 8
Overview ........................................................................................8
User Menu Screens .......................................................................9
Boost & Purge Screens................................................................11
Status Message Screens.............................................................12
Maintenance 14
Caring for the Unit........................................................................14
Filter Maintenance........................................................................14
12 Monthly Maintenance..............................................................14
Heat Exchanger Removal Instruction for CVP Unit......................15
Troubleshooting 17
Diagnosing a Problem..................................................................17
Appendix One: Control Mode 02 Description 18
Overview ......................................................................................18
Airflow Mode Selection.................................................................18

Product Description
Sentinel Kinetic MVHR Operation & Monitoring 3
Product Description
Sentinel Kinetic & Sentinel Kinetic Plus
The Vent-Axia Sentinel Kinetic & Sentinel Kinetic Plus Mechanical Ventilation/Heat Recovery (MVHR) is a
heat recovery unit designed for the energy efficient ventilation of houses and similar dwellings, conforming to
the latest requirements of the Building Regulations document F 2010.
The unit is designed for continuous 24 hour exhaust ventilation of stale moist air from bathrooms, toilets and
kitchens. As the stale air is extracted, a heat exchanger within the unit transfers up to 90% of the heat into the
supply air entering the bedrooms and lounge.
In addition a Kinetic Plus unit is available that maintains a constant air flow independent of change in the system
pressure.
Figure 1: Sentinel Kinetic (Front of Unit as supplied) Figure 2: Sentinel Kinetic Plus (Front of Unit as supplied)
Sentinel Kinetic Summer By Pass Models.
The Sentinel Kinetic B, BH, Plus B , Plus BS, S BH, BS and Plus CVP are fitted with a Summer By Pass (SBP)
and will provide energy-free heating and energy-free cooling when the house temperature and ambient
temperature allows.
If the room is warmer than the set (shown as "indoor") temperature (i.e. you need the room to be cooler) and the
outdoor air is cooler than the actual room temperature (i.e. the outdoor air could cool your room) then the SBP will
open and the unit will supply cooler air to your room.
If the room is cooler than the set ("indoor") temperature (i.e. you need the room heating) and the outdoor air is
warmer than the actual room temperature (i.e the outdoor air could heat your room) then the SBP will open and
the unit will supply warmer air to your room.
Note that the above only applies whilst the outdoor air temperature is above 14 C (adjustable) in order to prevent
cold draughts.

Product Description
Sentinel Kinetic MVHR Operation & Monitoring 4
The set ("indoor") temperature should be set 2 or 3 degrees higher than the central heating thermostat and 2 or 3
degrees below any air conditioning thermostat if fitted. This will prevent any clash between the separate systems
Models
438222 - Sentinel Kinetic B with summer bypass.
438222A - Sentinel Kinetic BS with summer bypass.
443319 - Sentinel Kinetic BH with summer bypass and integral humidity sensor.
443319A - Sentinel Kinetic S BH with summer bypass and integral humidity sensor
438342 - Sentinel Kinetic V without summer bypass.
438342A - Sentinel Kinetic VS without summer bypass.
443028 - Sentinel Kinetic Plus B with Summer Bypass and integral humidity sensor.
447938 - Sentinel Kinetic Plus BS with Summer Bypass and integral humidity sensor.
443029 - Sentinel Kinetic Plus CVP (currently not available)
Accessories
441838 - Sentinel Kinetic Plug-in integral humidity sensor
441865 - Wireless enable kit (consists of wireless receiver and one wireless switch).
437827 - Additional wireless switch (up to four may be connected).
441780 - Vent-Wise accessory pack.
442367 - Monza System Cooker Hood 600mm wide.
442368 - Latina System Cooker Hood 900mm wide
443283 - Remote Wired Control.
447340 – Opto coupler
A range of sensors can be used to manage system demand and control the ventilation rate. These include an
internal humidity sensor, humidity sensors for independent mounting in rooms, wireless receiver and wireless
boost switches, CO2sensor, Ventwise sensors, manual switches and pull cords. For these alternative control
options, see www.vent-axia.com

Product Description
Sentinel Kinetic MVHR Operation & Monitoring 5
Control Unit Display
The Control Unit is located at the front of the Sentinel Kinetic unit. The Control Unit provides the user interface
for commissioning and monitoring purposes.
Figure 2: Control Unit
Display
The main display is an LCD with automatic backlight,
which is turned off to minimise power consumption
when the unit is operational (see Overview on page 8).
Normal Airflow
30%
Buttons
Four buttons on the Control Unit provide the controls for configuring and monitoring the unit.
Table 1: Control Unit Buttons
N.B Additional airflow modes are available from the button when Control Mode 02 is selected in the
start-up screens see Appendix One for further details.
Button Function
Press to adjust settings and press to save settings.
Press to go to the above screen or to increase a parameter value. Press
and hold for more than 2 seconds for fast scrolling.
Press to go to the next screen or to decrease a parameter value. Press and
hold for more than 2 seconds for fast scrolling.
Press to activate Boost mode.
No. of presses Boost action
(Control Mode 01)
1 Boosts for 30 minutes
2 Boosts for 60 minutes
3 Boosts continuously
4 Back to Normal flow rate
Press and hold for 5 seconds to activate Purge mode. (Press and hold for
5 seconds to cancel Purge).

Technical Specification
Sentinel Kinetic MVHR Operation & Monitoring 6
Performance Sentinel Kinetic Sentinel Kinetic Plus
Airflow Maximum, FID, 290 m3/h
Low default 20%
Normal default 30%
Boost default 50%
Purge 100%
Maximum, FID, 500 m3/h
Low default 20%
Normal default 30%
Boost default 50%
Purge 100%
Sound levels (@ 3 m) 20 dB(A) (normal), 36 dB(A) (boost) 24 dB(A) (normal), 34 dB(A) (boost)
Power
AC Voltage Input 220-240 V AC (single phase)
AC Frequency Input 50 Hz nominal
Supply Fuse 3 A (located in fused spur)
Product Fuse 2 A (located on main PCB)
Rated Power 150 W (max.) 190 W (max.)
Physical
Height (excluding
spigots) 550 mm 630 mm
Width (excluding
spigots) 550 mm 775 mm
Depth 285 mm 520 mm
Weight 15 kg 24 kg
Spigot diameter 125 mm 150 mm
Condensate pipe
diameter 22 mm
Environmental
IP Rating IP22
Operating Temperature -20C to +45C
Air Intake Temperature As above
Operating Humidity 0% to 95% RH
Storage Temperature -20C to +45C
Storage Humidity 0% to 95% RH
Software Version V27
For all other technical details, please see the Product Catalogue or our website at www.vent-axia.com.

Starting Up
Sentinel Kinetic MVHR Operation & Monitoring 7
Powering Up the Unit
Switching On (The unit is designed to run continuously)
To switch the unit on:
1. Switch on the power at the mains supply isolator feeding the unit.
2. Following switch-on, the fan motors will start and the Control Unit will display a series of startup screens,
described below.
Switching Off
To switch the unit off: at the unit’s local isolator, turn the power off.
Startup Screens
Sentinel Kinetic Version Screen
The Sentinel Kinetic Version screen displays the
firmware version number for 3 seconds.
No adjustments are possible on this screen.
V--
Language Screen
The Language screen displays the language used for
the screens. It is typically displayed for 5 seconds, or
longer if changing the setting.
Control Mode Screen
Language
English
Selects between Control Mode 01 operation described
herein and the alternative Control Mode 02 described
in Appendix One.
Control Mode
01
Airflow Units Screen
The Airflow Units is a percentage of the unit’s
maximum flow. Airflow Units
%
Wireless Control Screen
The Wireless Control screen automatically displays
whether the wireless boost control switch is fitted. It is
typically displayed for 3 seconds.
Wireless Control
Not Fitted
Humidity Sensor Screen
The Humidity Sensor screen displays whether the
humidity sensor is fitted. It is typically displayed for
3 seconds.
Humidity Sensor
Not Fitted

Operation and Monitoring
Sentinel Kinetic MVHR Operation & Monitoring 8
Outdoor Temp
14 C
Press for Boost
Dryout Mode
1
68 h
Defrost Active
Airflow Mode
Room Too Cold
F
an Off
BMS
F
an Off
CVP Control
Switched Off
V
-
-
Language
En
g
lish
Control Mode
01
Wireless Control
Not Fitte
d
Humidity Sensor
Not Fitte
d
Airflow Units
%
Timeout after 2 m
Normal Airflow
30%
Set Clock
Mon 12:30
Summer Mode
On
Indoor Temp
25 C
Press for > 5 s
Purge 120 m
100 %
Boost Airflow
50%
Cooker Hood
100 %
Low Airflow
20%
Operation and Monitoring
Overview
When the Sentinel Kinetic unit has been installed and commissioned it should require no further intervention in order to operate,
unless external switches are used to control on/off/boost, etc, or BMS control requires user action.
Low Speed – If timer selected
on installation.
Start-up Screens
Status
User Menu

Operation and Monitoring
Sentinel Kinetic MVHR Operation & Monitoring 9
User Menu Screens
From the Normal Airflow screen, press the button to access the rest of the User Menu screens.
Changing the value of a setting (if adjustable) is typically a 3-step procedure:
1. Press to select the setting (the setting will flash).
2. Use the or buttons to adjust the value. To scroll quickly, press and hold the or buttons for
more than 2 seconds.
3. Press again to enter the new settings and move to the next screen.
To return to the Normal Airflow screen, press the button repeatedly or press and hold the button for 5
seconds. Alternatively, the Normal Airflow screen will be restored if no buttons are pressed for two minutes
(timeout). Settings are stored in a the memory and will be retained in the event of mains power supply failure.
Low Airflow / Normal Airflow / Boost Airflow Screen
When the start-up screens are finished, the Low or
Normal screen is displayed showing operating status
(Low Airflow X % or Normal Airflow X % or Boost
Airflow X %).
The Normal screen displays the rate of normal airflow
(supply air) through the unit.
If the installation has proportional sensors or an internal
humidity sensor fitted, an αsymbol will be displayed
when they are boosting the airflow.
Normal Airflow
30 %
When the summer bypass is active, the normal screen
top line will alternate (for 3 seconds) with Summer
Bypass.
SUMMER BYPASS ON
30 %
An interval can be set, see page 38 of the Installation
and Commissioning manual, at which the unit reminds
the user to check the filters. This will be 6, 12 or 18
months. The normal screen top line will include Check
Filter as a reminder to check and, if necessary, clean or
replace the filters.
When this has been done, press and hold the and
buttons for 5 seconds to reset the automatic
message.
Filter Service
Suburban

Operation and Monitoring
Sentinel Kinetic MVHR Operation & Monitoring 10
Set Clock Screen
From the Normal Airflow screen, simply press the
button once to access the Set Clock screen.
The Set Clock Control screen enables you to change
the clock settings. The clock retains its settings for
approximately two weeks without mains power, after
which it will need resetting when power is reconnected
Values are DDD HH:MM.
Return to the normal display by pressing the button
or leave to timeout and return automatically after 2
minutes.
The unit will not automatically switch for Daylight
saving time.
Set Clock
Mon 12:30
Summer Mode Screen
From the Set Clock screen, simply press the button
twice to access the Summer Mode screen.
If the unit is a summer bypass model, the Summer
Mode screen enables you to switch the summer
bypass control on or off. This screen is only displayed
when the bypass is fitted.
Options available are On (default) and Off.
Return to the normal display by pressing the button
or leave to timeout and return automatically after 2
minutes.
Summer Mode
On
Indoor Temp Screen
From the Summer Mode screen, simply press the
button 3 times to access the Indoor Temp screen.
The Indoor Temp screen enables you to choose the
target room temperature in degrees Centigrade – only
displayed when the bypass is fitted.
Selectable range is 16-40 (25 default).
Return to the normal display by pressing the button
or leave to timeout and return automatically after 2
minutes.
Indoor Temp
25 C

Operation and Monitoring
Sentinel Kinetic MVHR Operation & Monitoring 11
Boost & Purge Screens
Boost Screen
Pressing the button activates boost airflow mode
when extra ventilation is required.
No. of presses Boost action
(Control Mode 01)
1 Boosts for 30 minutes
2 Boosts for 60 minutes
3 Boosts continuously
4 Back to Normal flow rate
N.B Additional airflow modes are available from the
button when Control Mode 02 is selected in the
start-up screens see Appendix One for further
details.
If the wireless boost option is fitted, this can be
triggered from the wireless transmitter/boost switch.
If the installation has switch sensors, is wired to the
lighting, has Vent-Wise sensors or if the internal time
switch is set for periodic operation, operation will
change from normal to boost automatically. Pressing
the button will reveal a code to show which device
has activated boost.
s1 = Switch S/W1
s2 = Switch S/W2
s3 = Switch S/W3
s4 = Switch SW4
s5 = Switch SW5
v1 = Vent-Wise Input S/W1
v2 = Vent-Wise Input S/W2
v3 = Vent-Wise Input S/W3
ls = Switched live (LS)
w1-4 = Wireless controller
c1-3 = Internal Time switch
If running on boost due to pressing the button, a
device will ‘take over’ the boost. Flow will return to low /
normal when that device switches off. If a number of
different devices are calling for boost flow, the unit will
run at boost until the last one has reverted to normal.
Boost Airflow
50 %

Operation and Monitoring
Sentinel Kinetic MVHR Operation & Monitoring 12
Purge Screen
Pressing and holding the button for 5 seconds
activates purge mode when you want to purge air from
the building. The unit will revert to normal flow by
pressing and holding the button again for 5
seconds. If the wireless boost option is fitted, this can
be triggered from the wireless transmitter/boost switch.
Purge mode runs the fans at full speed for 2 hours (120
minutes). The Purge screen displays a countdown of
the time remaining.
Purge 120m
100 %
Cooker Hood Boost Screen
There is a separate connection for a cooker hood
control which allows the boost level to be higher when
triggered by a Cooker Hood.
Cooker Hood
100 %
Low Airflow Screen
Low Airflow mode is activated when the Normal Airflow
is set to Off, (see page 31 in the Installation and
Commissioning manual for set up details).
The Normal Airflow mode can be set to run during the
daytime i.e. from 6am to 11pm, the Low Airflow mode
will then run during the night from 11pm to 6pm.
Low Airflow
20 %
Status Message Screens
The status message screens override the Normal Airflow and other user screens, and display status and key
operational conditions (temperatures or pressures, etc.) according to how the unit has been configured. If there
is more than one status item to be displayed, the highest priority message is shown.
These screens are displayed in a loop during normal operation of the unit, either after displaying the start-up
screens, or when commissioning has been completed. After a few seconds the display backlight is turned off in
order to minimise power consumption. The and buttons can be used to stop the loop sequence in order
to display individual screens for a longer period with the backlight turned on, if required.
Dryout Mode Screen
The Dryout Mode screen displays the time remaining
for the building to dry out. The unit runs at maximum
flow for 1 week.
Dryout Mode
168 h

Operation and Monitoring
Sentinel Kinetic MVHR Operation & Monitoring 13
Defrost Active Screen
The Antifrost screen is only displayed if a summer
bypass is fitted. In installations where a negative
pressure is not permitted during antifrost operation, set
this to bypass mode.
Available options: Airflow Mode (default) and Bypass
Mode.
Airflow Mode - When the supply air temperature is
between 0° and -20°C, antifrost will automatically
activate. This will reduce the supply airflow rate and
increase the extract airflow rate to prevent frost forming
on the heat exchanger. During antifrost operation the
supply motor can stop for 15 minutes and run for 45,
depending on the temperature below 0°C. If the supply
air temperature is -20°C or below the supply fan
switches off and the extract fan continues to run at
reduced rate to prevent frost forming on the heat
exchanger.
Bypass Mode - While the supply air temperature is
below 0°C, the antifrost mode will automatically
activate. This mode will open the bypass to prevent
frost forming on the heat exchanger.
Defrost Active
Airflow Mode
Room Too Cold Screen
The Room Too Cold screen displays the status of the
fan. If the heating system in the building fails or is
switched off and the internal temperature drops below
5°C, the unit will stop running so as to not bring cold air
into an already cold house. The unit will start up every
hour and will run for a short time to measure the
temperature of the property. When the temperature
rises, e.g. the heating system is switched back on, the
unit will restart and continue normal operation.
Bottom line of display may be ( Fan Off, Fan
Restarting).
Room Too Cold
Fan Off
BMS Screen
The BMS screen shows if a Fan Off command has
been received from a Building Management System
(BMS), if used.
A Fan Off command could be received from the BMS
in the event of a fire alarm.
BMS Mode
Fan Off
CV Failure
The Fault Code screen is displayed when the Constant
Volume stops working. CV Control
Switched Off

Maintenance
Sentinel Kinetic MVHR Operation & Monitoring 14
Maintenance
Caring for the Unit
Heat recovery units, by their very nature, require regular maintenance. The Sentinel Kinetic has been designed
to facilitate access to enable maintenance to be carried out easily.
Filter Maintenance
Item Action
Fan Filters When the unit displays “Check filters”. This is a reminder to ensure that the filters are not so
dirty that they are blocking the airflow or allowing dirt to pass through. The rate at which the
filters become dirty will vary hugely depending on the environment and the activity within the
property.
1. Open the filter flaps and remove the 2 filters.
2. Clean gently by tapping or carefully using a vacuum cleaner if necessary.
3. Replace the filters
4. Close the filter flaps.
5. Reset the automatic message, press and hold the and buttons for 5 seconds.
12 Monthly Maintenance
Item Action
Fan Filters
(Interval to suit
environment)
Change the Fan Filters depending on which environment the unit has been installed; urban,
suburban or rural.
1. Open the filter flaps and remove the 2 filters.
2. Insert the replacement filters.
3. Close the filter flaps.
4. Reset the automatic message, press and hold the and buttons for 5 seconds.
Unit & Heat Exchanger
Cell Inspect and clean the unit
1. Isolate the mains power supply.
2. Remove front cover from the unit.
3. Remove the 2 filters.
4. Slide out the heat exchanger. For Sentinel Kinetic Plus CVP refer to pages 15 and 16.
5. Wash the outer cover and heat exchanger in warm water using a mild detergent (such as
Milton Fluid) and dry thoroughly.
NOTE: Keep water away from all electrical components and wiring within the unit.
Motors Inspect the motors for build-up of dust and dirt on the impeller blades, which could cause
imbalance and increased noise levels. Vacuum or clean if necessary.
Condensate Drain Check the condensate drain tube is secure and clear of debris. Clean if necessary.
Fastenings Check that all unit and wall-mount fastenings are sufficiently tight and have not become
loose. Re-tighten if necessary.
CV Control Switched Off This can be caused either by a trapped pressure tube/s or by faulty sensors.

Maintenance
Sentinel Kinetic MVHR Operation & Monitoring 15
Heat Exchanger Removal Instruction for CVP Unit
1. Remove the 8 screws and detach the front cover
and then pull out both filters.
2. Remove both pressure tubes from their channels
and let them remain suspended in the air as shown
opposite.
3. Pull out the Heat Exchanger Cell to gain access to
the 2 screws on the cell as shown opposite.
Loosen up the both screws (no need to remove
them completely) to be able to remove the pressure
tube and its rubber grommet strip.

Maintenance
Sentinel Kinetic MVHR Operation & Monitoring 16
4. Pull out the cell and make sure that the rear bottom
of the cell is securely resting on the lower edge of
the foam so you can access the rear pressure tube.
Repeat step 3 to detach the rear pressure tube.
When the rear pressure tube is removed then the
cell is free to clean.
Once the cell is cleaned then attach the
pressure tubes in reverse order starting from
step 4 to 1. Do not over tighten the screws for
securing clips. The clips should just slightly
grip the rubber grommet strips as over
tightening of the clips can block the air
pressure.

Troubleshooting
Sentinel Kinetic MVHR Operation & Monitoring 17
Troubleshooting
Diagnosing a Problem
In the event of a problem, always troubleshoot the unit according to:
Fault code displayed on the Control Unit or Remote Wired Control.
Fault LED if connected.
If no indications are displayed, then troubleshoot problem according to the fault symptom as described in the
following tables.
Service/Fault Code Screens
The Service screen is displayed, alternating with the
Fault Code screen, when a fault has caused the unit to
switch off and you must phone the telephone number
displayed on the screen for assistance.
Service Phone
01293nnnnnn
The Fault Code screen is displayed, alternating with
the Service screen, when a fault has occurred. Take
note of the fault code when reporting a fault.
Fault Code
01
For assistance contact the service provider and quote the fault code number. The following fault codes numbers
may be displayed. Code numbers are added together if more than one is detected.
Table 2: Fault Codes
Code Problem
01 Supply Fan not running
02 Extract Fan not running
04 Control PCB 24 V fuse (FS1) failure
08 Temperature sensor T1 (supply) faulty
16 Temperature sensor T2 (extract) faulty
32 Wired Remote Control failure

Appendix One
Appendix One: Control Mode 02 Description
Overview
The functional differences described in this Appendix are available when Control Mode 02 is selected from the start-up
screens. Control Mode 02 assigns alternative functions to certain wiring Terminal Connections (described in Appendix
One of the Installation and Commissioning Manual) and allows additional airflow settings to be accessed via the
button on the front of the Kinetic unit or remote control as shown below:
Airflow Mode Selection
The following switching Functions are available via the button with Control Mode 02:
No. of presses Airflow Mode
(Control Mode 02)
1 Low
2 Normal
3 Boosts 30 minutes
4 Boosts 60 minutes
5 Boosts continuously
6 Cancel
Press 10 seconds after last press to cancel and return to normal operation.
If the wireless boost option is fitted, this can be triggered from the wireless transmitter/boost switch.
If the installation has switch sensors, is wired to the lighting, has Vent-Wise sensors, Vent-Wise momentary switch or if
the internal time switch is set for periodic operation, operation will change from normal to boost automatically. Pressing
the button will reveal a code to show which device has activated boost.
s4 = Switch SW4
v1 = Vent-Wise Input S/W1
v2 = Vent-Wise Input S/W2
v3 = Vent-Wise Input S/W3
ls = Switched live (LS)
w1-4 = Wireless controller
c1-3 = Internal Time switch
If running on boost due to pressing the button, another device may ‘take over’ the boost. Flow will return to normal
when that device switches off. If a number of different devices are calling for boost flow, the unit will run at boost until the
last one has reverted to normal.

Appendix One
Head Office: Fleming Way, Crawley, West Sussex, RH10 9YX.
UK NATIONAL CALL CENTRE, Newton Road, Crawley, West Sussex, RH10 9JA
SALES ENQUIRIES: Tel: [phone] Fax: [phone]
TECHNICAL SUPPORT Tel: [phone] Fax: [phone]
For details of the warranty and returns procedure please refer to www.vent-axia or write to Vent-Axia Ltd, Fleming Way, Crawley, RH10 9YX
442073S © 2013 Vent-Axia Limited. All rights reserved. 0213
The Guarantee
Applicable only to products installed and used in the United Kingdom. For details of guarantee outside the United Kingdom contact your local supplier.
Vent-Axia guarantees its products for two years from date of purchase against faulty material or workmanship. In the event of any part being found to be
defective, the product will be repaired, or at the Company’s option replaced, without charge, provided that the product:-
Has been installed and used in accordance with the instructions given with each unit.
Has not been connected to an unsuitable electricity supply. (The correct electricity supply voltage is shown on the product rating label
attached to the unit).
Has not been subjected to misuse, neglect or damage.
Has not been modified or repaired by any person not authorised by the company.
IF CLAIMING UNDER TERMS OF GUARANTEE
Please return the complete product, carriage paid to your original supplier or nearest Vent-Axia Centre, by post or personal visit. Please ensure that it is
adequately packed and accompanied by a letter clearly marked “Guarantee Claim” stating the nature of the fault and providing evidence of date and
source of purchase.
