Ventrac Terra Rake KR502 User manual

Operator’s Manual
& Parts Drawings
Terra Rake
Serial Number KR502-AC1128 --
VENTRAC.COM
KR502
Revised 12/19/18
09.10065 Rev. 04
Original Operator’s Manual

2
To the Owner
Contact Information and Product Identication
If you need to contact an authorized Ventrac dealer for information on servicing your product,
always provide the product model and serial numbers.
Please ll in the following information for future reference. See the picture(s) below to nd the
location of the identication numbers. Record them in the spaces provided.
Date of Purchase: __________________________________________________________________
Dealer:___________________________________________________________________________
Dealer Address:____________________________________________________________________
____________________________________________________________________
Dealer Phone Number: ______________________________________________________________
Dealer Fax Number: ________________________________________________________________
Model # (A):__________________________
Serial # (B): __________________________
A󰀩x Part/Serial Number label here.
Venture Products Inc. reserves the right to make changes
in design or specications without obligation to make like
changes on previously manufactured products.
B
A
500 Venture Drive
Orrville Oh 44667
www.ventrac.com
View all manuals
Visit ventrac.com/manuals
for the latest version of this
operator’s manual.
A downloadable parts manual
is also available.

TABLE OF CONTENTS
3
INTRODUCTION PAGE 5
Product Description................................................................................................................................5
Why Do I Need an Operator’s Manual? .................................................................................................5
Using Your Manual .................................................................................................................................6
Manual Glossary ....................................................................................................................................6
SAFETY PAGE 7
Safety Decals .........................................................................................................................................7
General Safety Procedures....................................................................................................................9
Training Required...................................................................................................................................9
Personal Protective Equipment Requirements ......................................................................................9
Operating Safely ....................................................................................................................................9
Preventing Accidents............................................................................................................................10
Keep Riders O󰀨....................................................................................................................................10
Operating On Slopes............................................................................................................................ 11
Roadway Safety................................................................................................................................... 11
Truck Or Trailer Transport .................................................................................................................... 11
Maintenance.........................................................................................................................................12
Fuel Safety...........................................................................................................................................12
Hydraulic Safety ...................................................................................................................................13
OPERATIONAL CONTROLS PAGE 15
Height Adjustment Link ........................................................................................................................15
Terra Rake Angle..................................................................................................................................15
Hydraulic Height Adjustment Cylinder..................................................................................................15
Hydraulic Function Selector .................................................................................................................15
GENERAL OPERATION PAGE 16
Daily Inspection....................................................................................................................................16
Attaching ..............................................................................................................................................16
Detaching.............................................................................................................................................16
Operating Procedure............................................................................................................................16
Transport of Terra Rake .......................................................................................................................17
Setting Tine Depth................................................................................................................................17
Gauge Wheel Positions........................................................................................................................17
Rear Mount (3 Point Hitch) Procedures ...............................................................................................17
SERVICE PAGE 18
Cleaning and General Maintenance.....................................................................................................18
Rake Tine Replacement.......................................................................................................................18
Tire Pressure........................................................................................................................................18
Lubrication Locations ...........................................................................................................................18
Storage.................................................................................................................................................18
Maintenance Schedule.........................................................................................................................19
Maintenance Checklist.........................................................................................................................19

TABLE OF CONTENTS
4
SPECIFICATIONS PAGE 20
Dimensions ..........................................................................................................................................20
Features...............................................................................................................................................20
PARTS PAGE 22
Main Frame & Gauge Wheels..............................................................................................................22
Hitch Frame, Height Adjuster, & Hydraulics .........................................................................................24
Optional Rake Extension Kit & Optional Hydraulic Height Adjustment Kit ...........................................26
WARRANTY PAGE 28

INTRODUCTION
Introduction - 5
Product Description
The Ventrac KR502 terra rake is designed to level or spread soil, sand, gravel, and other similar loose
material. It can also be used to remove rocks or unwanted debris in preparation for seeding a new lawn.
The KR502 is a front mounted attachment, which allows the operator to keep material from being driven over
and compacted. It also allows the operator to view the operation of the terra rake while facing the direction of
travel. The terra rake can also be mounted to the rear 3-point hitch with a Ventrac 3-N-1 adapter.
The terra rake can be hydraulically angled up to 28 degrees right or left.
If a wider surface area is needed, optional 10 inch (25.4 cm) extensions are available, giving the operator
an additional 20 inches (50.8 cm) of surface area.
Why Do I Need an Operator’s Manual?
This manual has been created to help you gain the important knowledge of what is needed to safely
operate, maintain, and service your machine. It is divided into sections for convenient reference of the
appropriate section.
You must read and understand the operator’s manual for each piece of Ventrac equipment you own.
Reading the operator’s manual will help you become familiar with each specic piece of equipment. Under-
standing the operator’s manual will help you, as well as others, avoid personal injury and/or damage to the
equipment. Keep this manual with the machine at all times. The manual should remain with the machine
even if it is sold. If this manual becomes damaged or unreadable, it should be replaced immediately. Con-
tact your local Ventrac dealer for a replacement.
When using a Ventrac attachment, be sure to read and follow the safety and operating instructions of both
the power unit and the attachment being used to ensure the safest operation possible.
The information in this manual provides the operator with the safest procedures to operate the machine
while getting the maximum use out of the unit. Failure to follow the safety precautions listed in this manual
may result in personal injury and/or damage to the equipment.
INTRODUCTION
Accessories
Item Description Part Number
Terra Rake Extension Kit (20” overall) 70.8034
KR Hydraulic Height Adjustment Cylinder Kit* 70.8035
Flat Free Tire/Wheel Assembly (requires 2 per rake) 53.0148
*Power unit must be equipped with a front 12 volt switch & plug kit.
Venture Products Inc. is pleased to provide you with your new Ventrac terra rake! We hope that Ventrac equipment will
provide you with a ONE Tractor Solution.
Listed below are just some of the items that can provide you
versatility as you use your KR502. Please visit our web site,
or contact your authorized Ventrac dealer for a complete list of
items available for your new terra rake.

INTRODUCTION
Introduction - 6
Using Your Manual
Throughout this manual, you will encounter special messages and symbols that identify potential safety
concerns to help you as well as others avoid personal injury or damage to the equipment.
ATTENTION
This symbol identies potential health and
safety hazards. It marks safety precautions.
Your safety and the safety of others is involved.
SYMBOL DEFINITIONS
There are three signal words that describe the level of safety concern: Danger, Warning, and Caution.
Safety should always be the #1 priority when working on or operating equipment. Accidents are more likely
to occur when proper operating procedures are not followed or inexperienced operators are involved.
Note: Right-Hand and Left-Hand orientations may be referred to at di󰀨erent places throughout this manual.
Right-Hand and Left-Hand is determined as if sitting on the power unit seat facing forward.
SIGNAL WORD DEFINITIONS
Indicates a potentially hazardous situation
which, if not avoided, could result in death or
serious injury.
Indicates an imminently hazardous situation
which, if not avoided, will result in death or
serious injury. This signal word is limited to the
most extreme cases.
Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderate injury and/or property damage. It may
also be used to alert against unsafe practices.
Manual Glossary
Power Unit A Ventrac tractor or other Ventrac engine powered device that may be operated by itself or
with an attachment or accessory.
Attachment A piece of Ventrac equipment that requires a Power Unit for operation.
Accessory A device that attaches to a Power Unit or Attachment to extend its capabilities.
Machine Describes any “Attachment” or “Accessory” that is used in conjunction with a power unit.

SAFETY
Safety - 7
Safety Decals
The following safety decals must be maintained on your terra rake.
Keep all safety decals legible. Remove all grease, dirt, and debris from safety decals and instructional
labels. If any decals are faded, illegible, or missing, contact your dealer promptly for replacements.
When new components are installed, be sure that current safety decals are a󰀩xed to the replacement
components.
SAFETY
A
A
B

SAFETY
Safety - 8
Decal Description Part Number Quantity
ADanger, Pinching Hazard 00.0102 2
BWarning - Read Owner’s Manual 00.0217 1
AB

SAFETY
Safety - 9
General Safety Procedures
for Ventrac Power Units, Attachments, & Accessories
Training Required
• The owner of this machine is solely responsible for properly training the operators.
• The owner/operator is solely responsible for the operation of this
machine and prevention of accidents or injuries occurring to him/her-
self, other people, or property.
• Do not allow operation or service by children or untrained personnel.
Local regulations may restrict the age of the operator.
• Before operating this machine, read the operator’s manual and under-
stand its contents.
• If the operator of the machine cannot understand this manual, then it
is the responsibility of this machine’s owner to fully explain the material
within this manual to the operator.
• Learn and understand the use of all controls.
• Know how to stop the power unit and all attachments quickly in the event of an emergency.
Personal Protective Equipment Requirements
It is the responsibility of the owner to be sure that the operators use the proper personal protective equip-
ment while operating the machine. Required personal protective equipment includes, but is not limited to,
the following list.
• Wear a certied ear protection device to prevent loss of hearing.
• Prevent eye injury by wearing safety glasses while operating the machine.
• Closed toe shoes must be worn at all times.
• Long pants must be worn at all times.
• When operating in dusty conditions, it is recommended that a dust mask be worn.
Operation Safety
• Inspect machine before operation. Repair or replace any damaged, worn, or missing parts. Be sure
guards and shields are in proper working condition and are secured in place. Make all necessary
adjustments before operating machine.
• Some pictures in this manual may show shields or covers opened or removed in order to clearly illustrate
any instructions. Under no circumstance should the machine be operated without these devices in place.
• Alterations or modications to this machine can reduce safety and could cause damage to the machine.
Do not alter safety devices or operate with shields or covers removed.
• Before each use, verify that all controls function properly and inspect all safety devices. Do not operate
if controls or safety devices are not in proper working condition.
• Check parking brake function before operating. Repair or adjust parking brake if necessary.
• Observe and follow all safety decals.
• All controls are to be operated from the operator’s station only.
• Always wear a seat belt if the machine has a roll cage/bar installed and in upright position.
• Ensure the attachment or accessory is locked or fastened securely to the power unit before operating.
• Ensure that all bystanders are clear of the power unit and attachment before operating. Stop machine if
someone enters your work area.
• Always be alert to what is happening around you, but do not lose focus on the task you are performing.
Always look in the direction the machine is moving.
• Look behind and down before backing up to be sure of a clear path.
• If you hit an object, stop and inspect the machine. Make all necessary repairs before operating machine again.
• Stop operation immediately at any sign of equipment failure. An unusual noise can be a warning of equipment
failure or a sign that maintenance is required. Make all necessary repairs before operating machine again.

SAFETY
Safety - 10
General Safety Procedures
for Ventrac Power Units, Attachments, & Accessories
• If equipped with a high/low range feature, never shift between high and low range while on a slope.
Always move the machine to level ground and engage the parking brake before shifting range.
• Do not leave machine unattended while it is running.
• Always park the machine on level ground.
• Always shut o󰀨 engine when connecting attachment drive belt to the power unit.
• Never leave the operator’s station without lowering the attachment to the ground, setting the parking
brake, shutting o󰀨 the engine, and removing the ignition key. Make sure all moving parts have come to
a complete stop before dismounting.
• Never leave equipment unattended without lowering the attachment to the ground, setting the parking
brake, shutting o󰀨 the engine, and removing the ignition key.
• Only operate in well-lit conditions.
• Do not operate when there is a risk of lightning.
• Never direct the discharge of any attachment in the direction of people, buildings, animals, vehicles, or
other objects of value.
• Never discharge material against a wall or obstruction. Material may ricochet back towards the operator.
• Use extra caution when approaching blind corners, shrubs, trees, or other objects that may obscure vision.
• Do not run the engine in a building without adequate ventilation.
• Do not touch the engine or the mu󰀪er while the engine is running or immediately after stopping the engine.
These areas may be hot enough to cause a burn.
• Do not change the engine governor settings or over-speed the engine. Operating engine at excessive speed
may increase the hazard of personal injury.
• To reduce the hazard of re, keep the battery compartment, engine, and mu󰀪er areas free of grass, leaves,
excessive grease, and other ammable materials.
Preventing Accidents
• Clear working area of objects that might be hit or thrown from machine.
• Keep people and pets out of working area.
• Know the work area well before operation. Do not operate where traction or
stability is questionable.
• Reduce speed when you are operating over rough ground.
• Equipment can cause serious injury and/or death when improperly used.
Before operating, know and understand
the operation and safety of the power
unit and the attachment being used.
• Do not operate machine if you are not in good physical and
mental health, if you will be distracted by personal devices, or are
under the inuence of any substance which might impair deci-
sion, dexterity, or judgment.
• Children are attracted to machine activity. Be aware of children
and do not allow them in the working area. Turn o󰀨 the machine if
a child enters the work area.
Keep Riders O󰀨
• Only allow the operator on the power unit. Keep riders o󰀨.
• Never allow riders on any attachment or accessory.
Operation Safety (continued)

SAFETY
Safety - 11
General Safety Procedures
for Ventrac Power Units, Attachments, & Accessories
Operating On Slopes
• Slopes can cause loss-of-control and
tip-over accidents, which can result in
severe injury or death. Be familiar with the
emergency parking brake, along with the
power unit controls and their functions.
• If power unit is equipped with a fold down
roll bar, it must be locked in the upright
position when operating on any slope.
• Use low range (if equipped) when operating
on slopes greater than 15 degrees.
• Do not stop or start suddenly when operating on slopes.
• Never shift between high and low range while on a slope. Always move the power unit to level ground
and engage the parking brake before shifting range or placing the power unit in neutral.
• Variables such as wet surface and loose ground will reduce the degree of safety. Do not drive where
machine could lose traction or tip over.
• Keep alert for hidden hazards in the terrain.
• Stay away from drop-o󰀨s, ditches, and embankments.
• Sharp turns should be avoided when operating on slopes.
• Pulling loads on hills decreases safety. It is the responsibility of the owner/operator to determine loads
that can safely be controlled on slopes.
• Transport machine with attachment lowered or close to the ground to improve stability.
• While operating on slopes, drive in an up and down direction when possible. If turning is necessary
while driving across slopes, reduce speed and turn slowly in the downhill direction.
• Assure a su󰀩cient supply of fuel for continuous operation. A minimum of one-half tank of fuel is recommended.
Roadway Safety
• Operate with safety lights when operating on or near roadways.
• Obey all state and local laws concerning operation on roadways.
• Slow down and be careful of tra󰀩c when operating near or crossing roadways. Stop before crossing
roads or sidewalks. Use care when approaching areas or objects that may obscure vision.
• If there is doubt of safety conditions, discontinue machine operation until a time when
operation can be performed safely.
• When operating near or on roadways, have a Slow Moving Vehicle Emblem clearly
displayed.
Truck Or Trailer Transport
• Use care when loading or unloading machine into a truck or trailer.
• Use full width ramps for loading machine into a truck or trailer.
• The parking brake is not su󰀩cient to lock the machine during transport. Always secure the power unit
and/or attachment to the transporting vehicle securely using straps, chains, cable, or ropes. Both front
and rear straps should be directed down and outward from the machine.
• Shut o󰀨 fuel supply to power unit during transport on truck or trailer.
• If equipped, turn the battery disconnect switch to the O󰀨 position to shut o󰀨 electrical power.

SAFETY
Safety - 12
General Safety Procedures
for Ventrac Power Units, Attachments, & Accessories
Maintenance
• Keep all safety decals legible. Remove all grease dirt, and debris from safety decals and instructional labels.
• If any decals are faded, illegible, or missing, contact your dealer promptly for replacements.
• When new components are installed, be sure that current safety decals are a󰀩xed to the replacement
components.
• If any component requires replacement, use only original Ventrac replacement parts.
• Always turn the battery disconnect to the O󰀨 position or disconnect the battery before performing any
repairs. Disconnect the negative terminal rst and the positive terminal last. Reconnect the positive
terminal rst and the negative terminal last.
• Keep all bolts, nuts, screws, and other fasteners properly tightened.
• Always lower the attachment to the ground, engage parking brake, shut o󰀨 engine, and remove the
ignition key. Make sure all moving parts have come to a complete stop before cleaning, inspection,
adjusting or repairing.
• If the power unit, attachment, or accessory requires repairs or adjustments not instructed in the operator’s
manual, the power unit, attachment, or accessory must be taken to an authorized Ventrac dealer for service.
• Never perform maintenance on the power unit and/or attachment if someone is in the operator’s station.
• Always use protective glasses when handling the battery.
• Check all fuel lines for tightness and wear on a regular basis. Tighten or repair them as needed.
• To reduce the hazard of re, keep the battery compartment, engine, and mu󰀪er areas free of grass,
leaves, and excessive grease.
• Do not touch the engine, the mu󰀪er, or other exhaust components while the engine is running or imme-
diately after stopping the engine. These areas may be hot enough to cause a burn.
• Allow the engine to cool before storing and do not store near an open ame.
• Do not change the engine governor settings or over-speed the engine. Operating engine at excessive
speed may increase the hazard of personal injury.
• Springs may contain stored energy. Use caution when disengaging or removing springs and/or spring
loaded components.
• An obstruction or blockage in a drive system or moving/rotating parts may cause a buildup of stored
energy. When the obstruction or blockage is removed, the drive system or moving/rotating parts may
move suddenly. Do not attempt to remove an obstruction or blockage with your hands. Keep hands,
feet, and clothing away from all power-driven parts.
• Dispose of all uids in accordance with local laws.
Fuel Safety
• To avoid personal injury or property damage, use extreme care in handling gasoline. Gaso-
line is extremely ammable and the vapors are explosive.
• Do not refuel machine while smoking or at a location near ames or sparks.
• Always refuel the machine outdoors.
• Do not store machine or fuel container indoors where fumes or fuel can reach an open
ame, spark, or pilot light.
• Only store fuel in an approved container. Keep out of reach of children.
• Never ll containers inside a vehicle or on a truck or trailer bed with a plastic liner. Always place containers
on the ground away from your vehicle before lling.
• Remove machine from the truck or trailer and refuel it on the ground. If this is not possible, refuel the
machine using a portable container, rather than from a fuel dispenser nozzle.
• Never remove fuel cap or add fuel with the engine running. Allow engine to cool before refueling.
• Never remove fuel cap while on a slope. Only remove when parked on a level surface.
• Replace all fuel tank and container caps securely.

SAFETY
Safety - 13
General Safety Procedures
for Ventrac Power Units, Attachments, & Accessories
• Do not overll fuel tank. Only ll to bottom of fuel neck, do not ll fuel neck full. Overlling of fuel tank could
result in engine ooding, fuel leakage from the tank, and/or damage to the emissions control system.
• If fuel is spilled, do not attempt to start the engine. Move the power unit away from the fuel spill and
avoid creating any source of ignition until fuel vapors have dissipated.
• If the fuel tank must be drained, it should be drained outdoors into an approved container.
• Dispose of all uids in accordance with local laws.
• Check all fuel lines for tightness and wear on a regular basis. Tighten or repair them as needed.
• The fuel system is equipped with a shut-o󰀨 valve. Shut o󰀨 the fuel when transporting the machine to
and from the job, when parking the machine indoors, or when servicing the fuel system.
Hydraulic Safety
• Make sure all hydraulic connections are tight and all hydraulic hoses and tubes are in good condition.
Repair any leaks and replace any damaged or deteriorated hoses or tubes before starting the machine.
• Hydraulic leaks can occur under high pressure. Hydraulic leaks require special care and attention.
• Use a piece of cardboard and a magnifying glass to locate sus-
pected hydraulic leaks.
• Keep body and hands away from pinhole leaks
or nozzles that eject high pressure hydraulic uid.
Hydraulic uid escaping under high pressure can
penetrate the skin causing serious injury, leading to
severe complications and/or secondary infections
if left untreated. If hydraulic uid is injected into the
skin, seek immediate medical attention no matter
how minor the injury appears.
• Hydraulic system may contain stored energy. Before performing maintenance or repairs on the hydraulic
system, remove attachments, engage parking brake, disengage weight transfer system (if equipped),
shut o󰀨 engine, and remove ignition key. To relieve pressure on the auxiliary hydraulic system, shut o󰀨 the
power unit engine and move the hydraulic control lever left and right before disconnecting the auxiliary
hydraulic quick couplers.
• Dispose of all uids in accordance with local laws.
Fuel Safety (continued)

SAFETY
Safety - 14
• The rake tines should comb not dig. Severe contact with the ground, debris, rocks, etc. can cause the rake
tines to bend or break.
• Bending a tine may cause it to break. Do NOT attempt to straighten a bent rake tine.
• Attachment hydraulic system may contain stored energy. Before performing maintenance or repairs on
the hydraulic system, the attachment’s auxiliary hydraulic hoses must be disconnected from the power
unit. Lower the attachment to the ground, shut o󰀨 power unit engine, move the secondary S.D.L.A. lever
left and right to relieve auxiliary hydraulic pressure, and disconnect the auxiliary hydraulic quick couplers.
KR502 Safety Procedures

Operation - 15
Height Adjustment Link
A
Turning the height adjustment link (A) will raise or
lower the tines on the terra rake.
Terra Rake Angle
(Secondary S.D.L.A. Lever*)
The secondary S.D.L.A. lever* on the power unit con-
trols the angle of the terra rake. The terra rake can be
angled up to 28 degrees to the left or the right.
Hydraulic Height Adjustment Cylinder
B
The optional adjustment cylinder (B) replaces the
tine depth adjustment link on the terra rake. It
couples with a 12 volt switch* on the power unit to
allow the operator to control the tine depth using the
secondary S.D.L.A. lever* on the power unit.
NOTE: the power unit must be equipped with a front
12 volt switch and plug kit in order to operate the
adjustment cylinder. Refer to your power units oper-
ator’s manual for the correct kit for your power unit.
Hydraulic Function Selector
C
The 12 volt on/o󰀨 switch* on the power unit couples
with the directional valves (C) to select the function of
the secondary S.D.L.A. lever* A ip of the switch will
allow the secondary S.D.L.A. lever* to control either
the rake angle or the tine depth of the terra rake.
OPERATIONAL CONTROLS
* Refer to power unit operator’s manual for operation of
power unit controls.

GENERAL OPERATION
Operation - 16
GENERAL OPERATION
Daily Inspection
1.
Always set the parking brake, shut o󰀨 power unit
engine, remove the ignition key, and ensure all
moving parts have come to a complete stop before
inspecting components, or attempting any repair or
adjustment.
Park the power unit and terra rake on a level
surface, with the engine shut o󰀨 and all uids
cold.
2. Perform a visual inspection of the power unit
and terra rake. Look for loose or missing hard-
ware, damaged components, bent rake tines, or
signs of wear. Inspect hydraulic hoses, hydraulic
ttings, and fuel lines to ensure tight, leak free
connections.
3. Refer to the power unit operator’s manual.
Check the power unit’s engine oil, hydraulic oil,
cooling system, tire pressure, and fuel level. Add
uid or service system as required.
4. Refer to the power unit operator’s manual. Test
the power unit’s operator safety interlock system.
Attaching
1. Drive the power unit slowly forward into the hitch
arms of the terra rake. Align the lift arms of the
power unit with the terra rake hitch arms by rais-
ing or lowering the front hitch and complete the
engagement.
2. Once completely engaged, close the front hitch
locking lever.*
3. Engage the parking brake* and shut o󰀨 the
engine.
4. Wipe hose ends clean, and connect to the power
unit’s hydraulic quick couplers. If equipped, con-
nect the hoses and quick couplers so the red
indicators are paired together and the yellow
indicators are paired together.
5. Connect the electric plug (if equipped).
Detaching
1. Park the power unit on a level surface and set
the parking brake.*
2. Lower the terra rake to the ground.
3. Shut o󰀨 power unit engine.
4. Disconnect the hydraulic quick couplers from the
power unit and store with the hose ends on the tine
frame. Do not allow hose ends to lay in the dirt.
5. Disconnect the electric plug (if equipped).
6. Disengage the front hitch locking lever.*
7. Restart the power unit and slowly back away
from the terra rake. A side to side movement of
the steering wheel may aid disengagement.
Operating Procedure
Before operation, perform daily inspection, set the
rake tines to the desired depth, and turn o󰀨 the
power unit’s weight transfer.
Move the machine into position, angle the rake if
desired, and lower the terra rake to the ground.
Place the power unit’s primary S.D.L.A. lever in
the oat position by pushing it to the right until the
detent engages. The lever will stay in this position
until intentionally removed.
Work in the forward direction so the tines can collect
the debris and help separate it from the soil. Operat-
ing the rake at an angle will allow the tines to comb
through the loose soil while rolling the debris into a
windrow at the trailing edge of the terra rake. Move
the secondary S.D.L.A. lever to the left or right to
angle the terra rake.
When rake is angled to the left or right, pinch
points are created. Make sure there are no people
or objects present between the rake frame and the
power unit.
NOTE: the greater the angle of the rake, the more
loose material it will move into the windrow along
with the debris.
NOTE: If the tines are set too deep when leveling
and raking debris, the amount of soil being removed
will increase. Reducing the depth of the tines will
help to separate the debris from the soil so only the
debris is removed from the work area.
Multiple passes may be required to remove the
desired amount of debris.
If grass or other debris becomes lodged in the rake
tines, rake performance will be reduced. Clean the
rake tines as needed.
Raise the rake tines o󰀨 the ground when backing up.
* Refer to power unit operator’s manual for operation of
power unit controls.

GENERAL OPERATION
Operation - 17
Transport of Terra Rake
Transport the terra rake with the power unit front hitch
and terra rake raised to reduce wear of the machine
and to prevent the rake tines from catching on high
spots in the ground, rocks, or other obstacles. Travel
slowly when transporting over undulating or rough
surfaces to maintain control of power unit and to
reduce the shock to the machine.
Setting Tine Depth
The tine depth is adjusted by turning the adjustment
link. Lengthening the adjustment link will raise the
tines and shortening the adjustment link will lower
the tines. If equipped with a height adjustment cylin-
der, select the height adjustment function with the 12
volt switch and move the secondary S.D.L.A. lever
to the left or right until the desired depth is reached.
For leveling and separating debris, set the rake tines
to comb through the soil at 1/4” to 1” deep.
For spreading or leveling large amounts of loose
material, setting the rake tines deeper will allow the
rake to move more material with each pass.
Gauge Wheel Positions
The terra rake has gauge wheels that can be
adjusted for di󰀨erent applications or user preference.
Inside
mounting
position
Outside
mounting
position
Mounting the gauge wheels in the outside mounting
positions creates a wider footprint which will help
obtain a more level surface. When the rake is fully
angled in this position, the wheels are outside the
raking path of the tines and can hinder performance
when windrowing debris. In this case, the wheels
should be moved to the inside mounting positions.
Mounting the gauge wheels in the inside mounting
positions creates a narrower footprint which ensures
the wheels are not in the way when windrowing and
makes maneuverability much easier. In this position,
the ends of the rake may dig in excessively hard
when moving along a mound or ridge.
Rear Mount (3 Point Hitch) Procedures
The hitch frame on the terra rake can be reversed
for use on a power unit that is equipped with a 3
point hitch and a 3-N-1 adapter. Remove the bolt
(A) that fastens the height adjustment link to the
tine frame and the four bolts (B) that fasten the hitch
frame anchor to the tine frame.
A
B
B
B
B
Reassemble on the opposite side of the tine frame.
Operate with the 3 point hitch control lever in the
oat position.
The gauge wheels can be used either in front of or
behind the rake tines.
Set up for 3 point hitch
Wheels mounted in front of tines.
Outer mounting position only.
Wheels mounted behind tines.
Inside or outside mounting
positions.
If the wheels are mounted in front of the tines, they
must be in the outer mounting position to prevent
the wheels from hitting the 3 point hitch arms when
the rake is angled.
NOTE: the hydraulic height adjustment cylinder can
not be used when the terra rake is mounted on the
rear 3 point hitch.

Service - 18
Cleaning and General Maintenance
For best results, and to maintain the nish of the
KR502, clean or wash the terra rake to remove dirt,
gravel, grass, or other debris.
Rake Tine Replacement
The terra rake functions best when the rake tines
are aligned well with each other. Replace any bent
or broken tines.
1. Park the power unit and terra rake on a smooth,
level surface and lower the rake to the ground.
2. Set the parking brake, shut o󰀨 the engine, and
remove the ignition key.
3. Turn the height adjustment link to raise the rake
tines o󰀨 the ground.
4. Remove the bolt (A) that fastens the damaged
tine to the rake frame.
5.
A
Slide the tine out of the rake frame.
6. Insert the new rake tine into the frame and fas-
ten with the original hardware. Torque to 31 ft-lbs
(42 Nm).
Tire Pressure
Tire pressure should be maintained at 18-20 psi.
Lubrication Locations
Lubrication is required at the following locations
using a lithium complex NLGI #2 grease. Refer to
the maintenance schedule for service intervals.
Storage
Preparing the Terra Rake for Storage
1. Clean the terra rake.
2. Inspect for loose or missing hardware, damaged
components, or signs of wear. Repair or replace
and damaged or worn components.
3. Apply grease to all grease points.
4. Wipe o󰀨 all excess grease.
Removing the Terra Rake from Storage
1. Clean the terra rake to remove any accumulated
dust or debris.
2. Inspect the terra rake as instructed in the daily
inspection section of this manual.
3. Test the terra rake to ensure all components are
working properly.
SERVICE
Always set the parking brake, shut o󰀨 power
unit engine, remove the ignition key, and ensure
all moving parts have come to a complete stop
before inspecting components or attempting any
repair or adjustment.
Attention
If any component requires replacement, use only
original Ventrac replacement parts.

SERVICE
Service - 19
Maintenance Schedule
KR502
Maintenance Schedule
#ofLocations
#ofPumps
ASNEEDED
Daily
At50Hours
At100 Hours
At150 Hours
At200 Hours
At250 Hours
At300 Hours
At350 Hours
At400 Hours
At450 Hours
At500 Hours
At550 Hours
At600 Hours
At650 Hours
At700 Hours
At750 Hours
At800 Hours
At850 Hours
At900 Hours
At950 Hours
At1000 Hours
Yearly
Grease & Lubrication: See Lubrication Section
Caster Wheel Pivot
21 99999999999999999999
Wheel Axle Bearing
2^
** 99999999999999999999
Cylinder Ends
2^
** 99999999999999999999
Rake Pivot Tube
1^
** 99999999999999999999
9
9
9
9
^ Grease Until Fresh Grease is visible
Grease & Lubrication: See Lubrication Section
Inspection
** Operation in severe conditions may require more frequent service intervals.
Inspect for Loose, Missing, or Worn
Components.
Inspect for Bent Rake Tines
Check Tire Pressure
Check Safety Decals
Maintenance Checklist
KR502
Maintenance Checklist
#ofLocations
#ofPumps
ASNEEDED
Daily
At50Hours
At100 Hours
At150 Hours
At200 Hours
At250 Hours
At300 Hours
At350 Hours
At400 Hours
At450 Hours
At500 Hours
At550 Hours
At600 Hours
At650 Hours
At700 Hours
At750 Hours
At800 Hours
At850 Hours
At900 Hours
At950 Hours
At1000 Hours
Yearly
Grease & Lubrication: See Lubrication Section
Caster Wheel Pivot
21
Wheel Axle Bearing
2^
**
Cylinder Ends
2^
**
Rake Pivot Tube
1^
**
Grease & Lubrication: See Lubrication Section
Inspection
^ Grease Until Fresh Grease is visible
Inspect for Loose, Missing, or Worn
Components.
Inspect for Bent Rake Tines
Check Tire Pressure
Check Safety Decals
** Operation in severe conditions may require more frequent service intervals.

SPECIFICATIONS
Specications - 20
Dimensions
Overall Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 inches (81.3 cm)
Overall Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 inches (149.9 cm)
Overall Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 inches (124.5 cm)
Overall Width with Rake Extensions. . . . . . . . . . . . . . . . . . . . . 69 inches (175.3 cm)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250 pounds (113.4 kg)
Angle (Left & Right) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 degrees
Tine Adjustment Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 inches (15.2 cm)
Digging Depth . . . . . . . . . . . . . . 3 inches (7.6 cm) out of ground / 3 inches (7.6 cm) deep
Features
Hydraulic power angle left or right.
Adjustable front gauge wheels.
SPECIFICATIONS
