Vents Quietline User manual

AXIAL FANS
User’s manual
www.ventilation-system.com
Quietline
EN

2
EN
CONTENTS
Safety requirements.......................................................................................................................................................................................................................... 3
Delivery set.............................................................................................................................................................................................................................................7
Brief description .................................................................................................................................................................................................................................. 7
Operation guidelines .......................................................................................................................................................................................................................7
Designation key...................................................................................................................................................................................................................................8
Installation............................................................................................................................................................................................................................................... 9
Electronics operation algorithm ............................................................................................................................................................................................... 9
Fan setup .................................................................................................................................................................................................................................................11
Technical maintenance...................................................................................................................................................................................................................12
Troubleshooting.................................................................................................................................................................................................................................. 12
Storage and transportation regulations...............................................................................................................................................................................13
Manufacturer’s warranty................................................................................................................................................................................................................ 14
This user’s manual is a main operating document intended for technical, maintenance, and operating staff.
The manual contains information about purpose, technical details, operating principle, design, and installation of the
Quietline unit and all its modifications.
Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should
be able to work in accordance with workplace safety rules as well as construction norms and standards applicable in the
territory of the country.

3
EN
PLEASE READ THE USER’S MANUAL CAREFULLY PRIOR TO INSTALLING, CONNECTION TO POWER
MAINS AND OPERATING THE UNIT.
THE MANUFACTURING COMPANY SHALL NOT BE RESPONSIBLE FOR DAMAGE TO HEALTH AND
PROPERTY OF THE CUSTOMER CAUSED BY THE CUSTOMER’S VIOLATING THE USER’S MANUAL.
FOLLOW THE USER’S MANUAL REQUIREMENTS TO ENSURE DURABLE OPERATION OF THE UNIT, ITS
MECHANICAL AND ELECTRICAL RELIABILITY.
KEEP THIS USER’S MANUAL.
All user’s manual requirements as well as the provisions of all the
applicable local and national construction, electrical, and technical
norms and standards must be observed when installing and
operating the unit.
Disconnect the unit from the power supply prior to any connection,
servicing, maintenance, and repair operations.
Only qualied electricians with a work permit for electrical units
up to 1000 V are allowed for installation and maintenance. The
present user’s manual should be carefully read before beginning
works.
• Check the unit for any visible damage of the impeller, the casing,
and the grille before starting installation. The casing internals must
SAFETY REQUIREMENTS

4
EN
be free of any foreign objects that can damage the impeller blades.
• While mounting the unit, avoid compression of the casing!
Deformation of the casing may result in motor jam and excessive
noise.
• Misuse of the unit and any unauthorised modifications are not
allowed.
• Do not expose the device to adverse atmospheric agents (rain, sun,
etc.).
• Transported air must not contain any dust or other solid impurities,
sticky substances, or fibrous materials.
• Do not use the unit in a hazardous or explosive environment
containing spirits, gasoline, insecticides, etc.
• Do not close or block the intake or extract vents in order to ensure
the efficient air flow.
• Do not sit on the unit and do not put objects on it.
• The information in this user’s manual was correct at the time of the
document’s preparation.
• The Company reserves the right to modify the technical

5
EN
characteristics, design, or configuration of its products at any time
in order to incorporate the latest technological developments.
WARNING! Similar to the use of any other household electrical
appliances when operating this fan, the following basic rules
must be followed:
• Never touch the unit with wet or damp hands.
• Never touch the unit when barefoot.
Enheten är inte tillåten för användning av personer (inklusive barn)
med nedsatt fysisk, mental eller sensorisk förmåga utan lämplig
praktisk erfarenhet eller expertis, såvida de inte kontrolleras eller
instrueras om produktens funktion av den eller de personer som
ansvarar för deras säkerhet.
Övervaka barnen och låt dem inte leka med enheten.
Försiktighetsåtgärder bör vidtas för att undvika återflöde av gaser in i
rummet från öppna skorstenar eller apparater som bränner bränsle.
Anslutningen till elnätet måste göras genom ett urkopplingsmedel
som är inkorporerat i den fasta ledningen i enlighet med

6
EN
Se till att enheten är frånkopplad från elnätet innan du tar bort
skyddet.
WARNING: If there are any unusual oscillating movements,
immediately stop using the appliance and contact the manufacturer,
its service agent or suitably qualified persons.
The replacement of parts of the safety suspension system device
shall be performed by the manufacturer, its service agent or suitably
qualified persons.
Om nätsladden är skadad måste den bytas ut av tillverkaren, dess
serviceagent eller liknande kvalificerade personer för att undvika en
säkerhetsrisk.
THE PRODUCT MUST BE DISPOSED SEPARATELY AT THE END OF ITS SERVICE LIFE.
DO NOT DISPOSE THE UNIT AS UNSORTED DOMESTIC WASTE.
ledningsreglerna och har en kontaktseparation i alla poler som
möjliggör fullständig frånkoppling under överspänningskategori III.

7
EN
DELIVERY SET
Fan — 1 pc.
Screws and dowels — 4 pcs.
Self-tapping screws for fixing the bar* — 2 pcs.
Mounting bracket (for Quietline-k fans) — 1 pc.
Plastic screwdriver (only for the models with a timer) — 1 pc.
Wire fixing bar * — 1 pc.
User’s manual — 1 pc.
Packing box — 1 pc.
* — except for models with a power cable
BRIEF DESCRIPTION
The product is an axial fan for exhaust or supply ventilation of small and medium-sized premises.
The fan is designed for connection to ø 100, 125 and 150 mm air ducts.
OPERATION GUIDELINES
The fan is rated for connection to single-phase AC power mains.
Power supply parameters are stated on the unit packaging and/or the label on the unit casing.
Ingress protection rating against access to hazardous parts and water ingress is IPX4.
WARNING! IP is shown for the mounted product
The fan is rated for operation at ambient temperatures ranging from +1 °C to +40 °C.
WARNING! Do not operate the fan outside the specied temperature range.
The unit is rated as a Class II (220-240 V, 50 Hz) or Class III (12 V/50 Hz) electrical appliance and requires no grounding.

8
EN
DESIGNATION KEY
Quietline 100 T Q black
Colour
_ : white
black
grey
Motor modication
_ : single-speed motor
Duo: double-speed motor.
Extra: two-speed high-powered motor
Q: motor with reduced speed
12: low-powered motor with supply voltage of 12 V/50 Hz
Additional modication
T: turn-off delay timer
K: non-return valve
R: power cord with an electric plug
R1: power cord with a europlug
R2: power cord with a British plug
Spigot diameter [mm]
100/125/150
Fan series
Quietline: duct axial fan
Quietline-k: duct axial fan with a mounting bracket

9
EN
INSTALLATION
The fan is designed for vertical or horizontal installation into a round air duct of a matching diameter (Fig. 1-2).
Caution! In case of vertical mounting, the fan must be protected against ingress of rainfalls and condensate inside the fan.
Fan installation with direct air discharge upwards is not allowed (Fig. 3).
Use the mounting bracket to install the fan.
The mounting of the bracket to the fan is shown in Fig. 3.
The fan mounting sequence is shown in Fig. 4-11.
The fan wiring diagrams are shown in Fig. 12-15.
ELECTRONICS OPERATION ALGORITHM
The Quietline T fan starts to operate when an external switch, such as a light switch, trips, and when applying power to
the LT terminal. After the external switch is turned off the fan keeps operating for a set time period, adjustable from 2 to 30
minutes, and then turns off.
The Quietline T DUO/Quietline T Extra fan has 4 operation modes. The choice of operating mode is carried out by setting
the DIP switch to a certain position. Use the plastic screwdriver from the delivery set to set the DIP-switch to a required
position.
ON
12
Operation mode 1 (single-speed mode)
The fan is turned off by default.
When an external switch, such as a light switch, is triggered, the power supply voltage is applied to
the LT terminal and the fan starts to run at second speed.
After the external switch is turned off the fan keeps operating for a set time period, adjustable from
2 to 30 minutes, and then turns off.
DO NOT USE A METAL SCREWDRIVER, KNIFE, ETC. FOR ADJUSTMENT
OPERATIONS NOT TO DAMAGE THE CIRCUIT BOARD.

10
EN
ON
12
Operation mode 2 (single-speed mode)
The fan is turned off by default.
When an external switch, such as a light switch, is triggered, the power supply voltage is applied to
the LT terminal and the fan starts to run at the first speed.
After the external switch is turned off the fan keeps operating for a set time period, adjustable from
2 to 30 minutes, and then turns off.
ON
12
Operation mode 3 (two-speed mode)
When an external switch, such as a light switch, is triggered, the supply voltage is applied to the LT
terminal and the fan switches to the second speed.
After the external switch is turned off the fan keeps operating at the second speed for a set time
period, adjustable from 2 to 30 minutes, and then switches to the first speed.
ON
12
Operation mode 4 (two-speed interval mode)
The fan switches to the second speed after a set period of time (from 1 to 15 hours) and runs at the
second speed from 2 to 30 minutes, then returns to the first speed.
When an external switch, such as a light switch, is triggered, power is supplied to the LT terminal
and the fan switches to the second speed.
After the switch is turned off the fan keeps operating at the second speed for a set time period,
adjustable from 2 to 30 minutes, and then switches to the first speed.
WARNING! The operation mode 1 is set by default.
The operating mode may be changed during the fan mounting or operation.

11
EN
FAN SETUP
Quietline T fan (Fig. 16)
Toff
To adjust the fan turn-off delay time, turn the control knob Toff clockwise to increase and counter-
clockwise to decrease the turn-off delay time respectively, adjustable from 2 up to 30 minutes.
Quietline T DUO/Quietline 150 Extra T fan (Fig. 17)
Modes 1, 2 and 3.
Ton
To adjust the fan turn-on delay time or to switch the speed for the operation mode 3, turn the control knob
Ton clockwise to increase and counter-clockwise to decrease the turn-on delay time respectively, adjustable
from 0 up to 2 minutes.
Toff
To adjust the fan turn-off delay time or to switch the speed for the operation mode 3, turn the control knob
To clockwise to increase and counter-clockwise to decrease the turn-off delay time respectively, adjustable
from 2 up to 30 minutes.
Режим 4.
Tint
To adjust the fan interval operation time, turn the control knob Tint clockwise to increase and counter-
clockwise to decrease the speed switching time respectively, adjustable from 1 up to 15 hours.
T
off&HS time
To adjust the operating time at the second speed and the delay time for switching to the first speed (after
turning off the switch), turn the To&HS time potentiometer knob clockwise to increase and counterclockwise
to decrease, respectively (from 2 to 30 minutes).
Caution! The timer circuit is live! Disconnect the fan from power supply prior to any adjustment operations. The fan
delivery set includes a specially designed plastic screwdriver for fan settings adjustments. Use it if you need to change
the timer setting. Do not use a metal screwdriver, knife, etc. for adjustment operations not to damage the circuit board.

12
EN
TECHNICAL MAINTENANCE
Disconnect the fan from power mains prior to any maintenance operations and take measures to prevent unintentional power-
up until maintenance is complete. The fan maintenance periodicity is at least once per 6 months, depending on the operating
conditions. The technical maintenance includes cleaning the surfaces of the fan from dust, dirt, and also in checking the reliability
of electrical connections (Fig. 18-21).
Follow the national safety regulations when carrying out maintenance.
WARNING! Do not allow water or liquid come into contact with electric components!
TROUBLESHOOTING
Problem Possible reasons Troubleshooting
When the unit is connected to power
mains, the fan does not rotate and
does not respond to any controls.
No power supply.
Make sure the power supply line
is connected correctly, otherwise
troubleshoot the connection error.
Internal connection fault. Contact the Seller.
Low air flow. The ventilation system is clogged. Clean the ventilation system.
Increased noise, vibration.
The impeller is clogged. Clean the impeller.
The fan is not secured well or is not
mounted properly. Troubleshoot the installation error.
The ventilation system is clogged. Clean the ventilation system.

13
EN
STORAGE AND TRANSPORTATION REGULATIONS
• Store the unit in the manufacturer’s original packaging box in a dry closed ventilated premise with temperature range
from +5 °C to + 40 °C and relative humidity up to 70 %.
• Storage environment must not contain aggressive vapors and chemical mixtures provoking corrosion, insulation, and
sealing deformation.
• Use suitable hoist machinery for handling and storage operations to prevent possible damage to the unit.
• Follow the handling requirements applicable for the particular type of cargo.
• The unit can be carried in the original packaging by any mode of transport provided proper protection against precipitation
and mechanical damage. The unit must be transported only in the working position.
• Avoid sharp blows, scratches, or rough handling during loading and unloading.
• Prior to the initial power-up after transportation at low temperatures, allow the unit to warm up at operating temperature
for at least 3-4 hours.

14
EN
MANUFACTURER’S WARRANTY
The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility.
We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/
EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and
of the Council and CE-marking Council Directive 93/68/EEC. This certificate is issued following test carried out on samples
of the product referred to above.
The manufacturer hereby warrants normal operation of the unit for 60 months after the retail sale date provided the user's
observance of the transportation, storage, installation, and operation regulations. Should any malfunctions occur in the
course of the unit operation through the Manufacturer's fault during the guaranteed period of operation, the user is entitled
to get all the faults eliminated by the manufacturer by means of warranty repair at the factory free of charge. The warranty
repair includes work specific to elimination of faults in the unit operation to ensure its intended use by the user within the
guaranteed period of operation. The faults are eliminated by means of replacement or repair of the unit components or a
specific part of such unit component.
The warranty repair does not include:
• routine technical maintenance
• unit installation/dismantling
• unit setup
To benefit from warranty repair, the user must provide the unit, the user's manual with the purchase date stamp, and the
payment paperwork certifying the purchase. The unit model must comply with the one stated in the user’s manual. Contact
the Seller for warranty service.
The manufacturer’s warranty does not apply to the following cases:
• User’s failure to submit the unit with the entire delivery package as stated in the user’s manual including submission
with missing component parts previously dismounted by the user.
• Mismatch of the unit model and the brand name with the information stated on the unit packaging and in the user's
manual.
• User’s failure to ensure timely technical maintenance of the unit.
• External damage to the unit casing (excluding external modifications as required for installation) and internal
components caused by the user.
• Redesign or engineering changes to the unit.

15
EN
• Replacement and use of any assemblies, parts and components not approved by the manufacturer.
• Unit misuse.
• Violation of the unit installation regulations by the user.
• Violation of the unit control regulations by the user.
• Unit connection to power mains with a voltage different from the one stated in the user's manual.
• Unit breakdown due to voltage surges in power mains.
• Discretionary repair of the unit by the user.
• Unit repair by any persons without the manufacturer’s authorization.
• Expiration of the unit warranty period.
• Violation of the unit transportation regulations by the user.
• Violation of the unit storage regulations by the user.
• Wrongful actions against the unit committed by third parties.
• Unit breakdown due to circumstances of insuperable force (fire, flood, earthquake, war, hostilities of any kind,
blockades).
• Missing seals if provided by the user’s manual.
• Failure to submit the user’s manual with the unit purchase date stamp.
• Missing payment paperwork certifying the unit purchase.
FOLLOWING THE REGULATIONS STIPULATED HEREIN WILL ENSURE A LONG AND TROUBLE-FREE
OPERATION OF THE UNIT.
USER’S WARRANTY CLAIMS SHALL BE SUBJECT TO REVIEW ONLY UPON PRESENTATION OF THE
UNIT, THE PAYMENT DOCUMENT AND THE USER’S MANUAL WITH THE PURCHASE DATE STAMP.

16
EN
2
1
3
2
1
3
KN
ø D
KN
H
LD [mm] L [mm] H [mm] K [mm] N [mm]
Quietline 100 99 138 - - -
Quietline-k 100 99 138 109 160 54
Quietline 125 124 162 - - -
Quietline-k 125 124 162 138 160 54
Quietline 150 149 182 - - -
Quietline-k 150 149 182 160 190 54

17
EN
QF
L N
5
6 7
89
4

18
EN
10 11
13 14
15 16
2
1
S
QF
L
N
QF
N
N
L
L
LT
S
1
2
3
S
N
L
QF Sspeed
QF 1
N
3
L
2
SLT
N
L
12 13
14 15
Wiring diagrams
2: speed 2
3: speed 1
Quietline
Quietline Т
Quietline DUO/Quietline Extra
Quietline T DUO/Quietline T Extra

19
EN
17
16
+
-
2 min 30 min
Toff
+
-
2 min 30 min
Toff & HS time
+
-
0 min 2 min
Ton
OR
+
-
1 hour 15 hour
Tint
Quietline Т
Quietline T DUO/Quietline T Extra

20
EN
20
18
21
19
QF
L N
