Vents Simple 100 User manual

AXIAL FAN
USER’S MANUAL
www.ventilation-system.com
VENTS 100 Simple
EN

2
EN
CONTENTS
Delivery set............................................................................................................................................................................................................................................. 6
Brief description .................................................................................................................................................................................................................................. 6
Operation guidelines ....................................................................................................................................................................................................................... 6
Designation key................................................................................................................................................................................................................................... 7
Installation and setup ...................................................................................................................................................................................................................... 7
Fan setup ........................................................................................................................................................................................................................................... 8
Electronics operation algorithm .............................................................................................................................................................................................. 10
Technical maintenance................................................................................................................................................................................................................... 11
Storage and transportation regulations............................................................................................................................................................................... 11
Manufacturer’s warranty................................................................................................................................................................................................................ 12

3
EN
This user’s manual is a main operating document, intended for technical, maintenance, and operating staff.
The manual contains information about the purpose, technical details, operating principle, design, and installation of the
VENTS 100 Simple unit and all of its modifications.
Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should
be able to work in accordance with workplace safety rules as well as construction norms and standards applicable in the
territory of the country.
The information in this user’s manual was correct at the time of the document’s preparation.
The Company reserves the right to modify the technical characteristics, design, or configuration of its products at any time
in order to incorporate the latest technological developments.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means in any
information search system or translated into any language in any form without the prior written permission of the Company.
READ THE USER’S MANUAL CAREFULLY BEFORE PROCEEDING WITH INSTALLATION WORKS.
COMPLIANCE WITH THE MANUAL REQUIREMENTS ENSURES RELIABLE OPERATION AND LONG
SERVICE LIFE OF THE UNIT.
KEEP THE USER’S MANUAL AVAILABLE AS LONG AS YOU USE THE UNIT. YOU MAY NEED TO RE-READ
THE INFORMATION ON THE PRODUCT SERVICING.

4
EN
FOLLOW THE USER’S MANUAL REQUIREMENTS TO ENSURE DURABLE AND
TROUBLE-FREE OPERATION OF THE UNIT.
Disconnect the unit from power supply prior to any connection, servicing, maintenance, and repair operations.
Only qualied electricians with a work permit for electrical units up to 1000 V are allowed
for installation and maintenance. The present user’s manual should be carefully read
before beginning works.
• Single-phase power mains must comply with the acting local electrical norms and standards.
• Fixed electrical wiring must be equipped with an automatic circuit breaker.
• The unit must be connected to power mains through a QF automatic circuit breaker integrated into the fixed wiring
system. The gap between the circuit breaker contacts on all poles must be not less than 3 mm. Check the unit for any
visible damages of the impeller and the casing before starting installation. The casing internals must be free of any foreign
objects that can damage the impeller blades.
• While mounting the unit, avoid compression of the casing! Deformation of the casing may result in the motor jam and
noisy operation. Misuse of the unit and any unauthorised modifications are not allowed.
• Take steps to prevent ingress of smoke, carbon monoxide, and other combustion products into the room through open
chimney flues or other fire-protection devices. Sufficient air supply must be provided for proper combustion and exhaust
of gases through the chimney of fuel burning equipment to prevent back drafting. Transported air must not contain any
dust or other solid impurities, sticky substances, or fibrous materials.
• Do not use the unit in a hazardous or explosive environment containing spirits, gasoline, insecticides, etc.
• Do not close or block the intake or exhaust vents in order to ensure efficient air flow.
• Do not sit on the unit and do not put objects on it.
• The unit is allowed to be used by children aged from 8 years old and above and persons with reduced physical, sensory,
or mental capabilities or no experience and knowledge provided that they have been given supervision or instruction

5
EN
THE PRODUCT MUST BE DISPOSED SEPARATELY AT THE END OF ITS SERVICE LIFE.
DO NOT DISPOSE THE UNIT AS UNSORTED MUNICIPAL WASTE.
regarding safe use of the unit and understand the risks involved.
• Do not allow children to play with the unit.

6
EN
DELIVERY SET
Fan — 1 pc.
Screws and dowels — 4 pcs.
Plastic screwdriver (only for the models with a timer) — 1 pc.
User’s manual — 1 pc.
Packing box — 1 pc.
BRIEF DESCRIPTION
The unit described herein is an axial fan for exhaust ventilation of small to medium-sized premises heated during winter.
The fan is made of white plastic. The fan design can also include a backdraft damper to prevent back flow when the fan is
switched off. The fan fits 100 mm air ducts.
OPERATION GUIDELINES
The fan is rated for connection to single-phase AC 230 V/50 Hz or 230 V/60 Hz power mains. Air motion direction in the
system must match the pointer on the fan casing.
Ingress protection rating against access to hazardous parts and water ingress is IP45.
The fan is rated for operation at the ambient temperature ranging from +1 °C up to +45 °C.
The unit is rated as a Class II electrical appliance.

7
EN
DESIGNATION KEY
Vents 100 Simple X Х X
Motor and impeller modications:
L — motor on ball bearings
Turbo — high-powered motor
12 — motor with 12 V/50 Hz rated voltage
K — backdraft damper
Additional options:
V — built-in pull-cord switch
T — turn-off delay timer
T1 — turn-on and turn-off delay timer
TH — humidity sensor and turn-off delay timer
Fan series
Outlet duct diameter [mm]
INSTALLATION AND SETUP
The fan is designed for wall or ceiling mounting with direct air exhaust to the ventilation shaft or into the round air duct of
matching diameter (Fig. 2).
Fan installation sequence:
Step 1. Cut off power supply and make sure electricity has been turned off (Fig. 4).
Step 2. Run the power cable to the vent hole (Fig. 5).
Step 3. Remove the front panel from the fan. Then remove the terminal block cover (Fig. 6).
Step 4. Mark and drill holes for mounting the fan and then install the fan (Fig. 7-9).
Step 5. Connect the fan to power mains according to the wiring diagram (Fig. 13-16).
Step 6. Install the terminal block cover (Fig. 10) and the front panel on the fan casing (Fig. 11).
Step 7. Supply power voltage to the fan (Fig. 12).

8
EN
FAN SETUP
on — interval timer turning on and adjustment is performed with the potentiometer Ton. To turn the interval timer off
set the potentiometer Ton into the leftmost position. Rotation of the potentiometer for 1/3 clockwise sets the interval timer
operation for 6 hours, rotation of the potentiometer for 2/3 clockwise sets the interval timer operation for 12 hours, and
rotation of the potentiometer clockwise in the rightmost position sets the interval timer operation for 24 hours.
off — To adjust the fan turn-off delay time, turn the control knob To clockwise to increase and counter-clockwise to
decrease the turn-off delay time respectively, adjustable from 2 up to 30 minutes.
— To adjust the humidity set point turn the control knob H clockwise to increase and counter-clockwise to decrease the
humidity sensor set point, adjustable from 60 % up to 90 %.
WARNING! If the switch is turned o or the indoor humidity falls below the set point within 60 seconds after
activation of the switch or the humidity sensor, the fan continues operation at low speed.
Terminal designations on wiring diagrams:
L — phase
N — 0
S — external switch
QF — automatic circuit breaker
CAUTION! The fans rated for 12 V power voltage (stated on the packing box and on the fan casing) connect to
12 V power mains only!
DO NOT USE A METAL SCREWDRIVER, KNIFE, ETC. FOR ADJUSTMENT
OPERATIONS NOT TO DAMAGE THE CIRCUIT BOARD.

9
EN
H
60% 90%
Toff
2 min 30 min
Ton
Off 24 hour
The fan delivery set includes a specially designed plastic
screwdriver for fan settings adjustments. Use it to change
the turn-on and turn-off delay time and the humidity set
point.

10
EN
ELECTRONICS OPERATION ALGORITHM
The fan with the timerT — the fan is started after actuation of the external switch, e.g. the light switch. The control voltage
is supplied to the input terminal LT (ST). After the control voltage is off the fan continues to operate within the set time
period adjustable from 2 to 30 minutes by the timer.
The VT model is turned on and off by the pull-cord switch.
The fan with the timer T1 — after turning on the switch, for example, a light switch, the fan is switched on in a set turn-on
delay time period, adjustable from 0 to 2 minutes. After the switch is turned off the fan keeps operating for a set turn-off
delay time period, adjustable from 2 to 30 minutes.
The fan with the timer and the humidity sensor TH — the fan starts after the control voltage is supplied to the input
terminal S or if indoor humidity level Hexceeds the set point adjustable from ~60 % to ~90 %. After the control voltage is off
or the humidity level has decreased the fan will keep running within the time set by the timer ranging from 2 to 30 minutes.
To set the maximum humidity setpoint 90 % set the potentiometer to H max position.
To adjust the fan turn-on delay time, turn the control knob T clockwise to increase and counter-clockwise to decrease the
turn-on delay time respectively. To adjust the humidity set point turn the control knob Hclockwise to increase and counter-
clockwise to decrease the humidity sensor set point.
CAUTION!The timer circuit is live! Disconnect the fan from power mains prior to any adjustment operations. The
fan delivery set includes a specially designed plastic screwdriver for fan settings adjustments. Use it to change
the turn-on and turn-o delay time and the humidity set point.
DO NOT USE A METAL SCREWDRIVER, KNIFE, ETC. FOR ADJUSTMENT
OPERATIONS NOT TO DAMAGE THE CIRCUIT BOARD.

11
EN
TECHNICAL MAINTENANCE
The fan maintenance periodicity is at least once per 6 months.
Maintenance steps:
• Disconnect the fan from power supply and make sure electricity has been turned off (Fig. 17).
• Remove the front and the decorative panels, wipe the fan with a dry cloth or a brush (Fig. 18-19).
• Clean the front panel under running water (Fig. 20).
• Wipe the fan surfaces dry.
• Cover the fan with the front panel (Fig. 21).
• Connect power supply to the fan (Fig. 22).
CAUTION! Do not allow water or liquid come into contact with electric components!
• Store the unit in the manufacturer’s original packaging box in a dry closed ventilated premise with temperature range
from +5 °C to + 40 °C and relative humidity up to 70 %.
• Storage environment must not contain aggressive vapours and chemical mixtures provoking corrosion, insulation, and
sealing deformation.
• Use suitable hoist machinery for handling and storage operations to prevent possible damage to the unit.
• Follow the handling requirements applicable for the particular type of cargo.
• The unit can be carried in the original packaging by any mode of transport provided proper protection against precipitation
and mechanical damage. The unit must be transported only in the working position.
• Avoid sharp blows, scratches, or rough handling during loading and unloading.
• Prior to the initial power-up after transportation at low temperatures allow the unit to warm up at room temperature for
at least 3-4 hours.
STORAGE AND TRANSPORTATION REGULATIONS

12
EN
The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility.
We hereby declare that the product complies with the provisions of Electromagnetic Council Directive 2014/30/EU, Low
Voltage Directive 2014/35/EU and CE-marking Directive 93/68/EEC. This certificate is issued following test carried out on
samples of the product referred to above.
The manufacturer hereby warrants normal operation of the unit for 60 months after the retail sale date provided the user's
observance of the transportation, storage, installation, and operation regulations. Should any malfunctions occur in the
course of the unit operation through the Manufacturer's fault during the guaranteed period of operation, the user is entitled
to get all the faults eliminated by the manufacturer by means of warranty repair at the factory free of charge. The warranty
repair includes work specific to elimination of faults in the unit operation to ensure its intended use by the user within the
guaranteed period of operation. The faults are eliminated by means of replacement or repair of the unit components or a
specific part of such unit component.
The warranty repair does not include:
• routine technical maintenance
• unit installation/dismantling
• unit setup
To benefit from warranty repair, the user must provide the unit, the user's manual with the purchase date stamp, and the
payment paperwork certifying the purchase. The unit model must comply with the one stated in the user’s manual. Contact
the Seller for warranty service.
The manufacturer’s warranty does not apply to the following cases:
• User’s failure to submit the unit with the entire delivery package as stated in the user’s manual including submission with
missing component parts previously dismounted by the user.
• Mismatch of the unit model and the brand name with the information stated on the unit packaging and in the user's
manual.
• User’s failure to ensure timely technical maintenance of the unit.
• External damage to the unit casing (excluding external modifications as required for installation) and internal components
caused by the user.
MANUFACTURER’S WARRANTY

13
EN
• Redesign or engineering changes to the unit.
• Replacement and use of any assemblies, parts and components not approved by the manufacturer.
• Unit misuse.
• Violation of the unit installation regulations by the user.
• Violation of the unit control regulations by the user.
• Unit connection to power mains with a voltage different from the one stated in the user's manual.
• Unit breakdown due to voltage surges in power mains.
• Discretionary repair of the unit by the user.
• Unit repair by any persons without the manufacturer’s authorization.
• Expiration of the unit warranty period.
• Violation of the unit transportation regulations by the user.
• Violation of the unit storage regulations by the user.
• Wrongful actions against the unit committed by third parties.
• Unit breakdown due to circumstances of insuperable force (fire, flood, earthquake, war, hostilities of any kind, blockades).
• Missing seals if provided by the user’s manual.
• Failure to submit the user’s manual with the unit purchase date stamp.
• Missing payment paperwork certifying the unit purchase.
FOLLOWING THE REGULATIONS STIPULATED HEREIN WILL ENSURE A LONG AND TROUBLE-FREE
OPERATION OF THE UNIT.
USER’S WARRANTY CLAIMS SHALL BE SUBJECT TO REVIEW ONLY UPON PRESENTATION OF THE
UNIT, THE PAYMENT DOCUMENT AND THE USER’S MANUAL WITH THE PURCHASE DATE STAMP.

14
EN
ø 99.5
15015 83
1.
2.

15
EN
QF
L N
3. 4. 5.
6. 7. 8.
9. 10. 11.

16
EN
12.
13.
-/V
T/VT/TH/VTH
QF
2
L
N
3
S
-
60% 90%
H
++
-
2min
30min
T
1
QF
2
L
N
3

17
EN
14.
-
60% 90%
H
++
-
2min
30min
T
1
QF
2
L
N
3
S
15.
1
QF
2
L
N
3
S
+
-
2min
30min
T
Jumper
T/VT/TH/VTH
T1

18
EN
QF
L N
16. 17.
18. 19.
20. 21.

19
EN
Quality Inspector’s Stamp
Manufacture Date
Sold by
(name and stamp of the seller)
Purchase Date

V171EN-01
Certificate of acceptance
The fan is recognized as serviceable.
VENTS 100 Simple
V
K
T
T1
TH
L
Turbo
12
