Installation Guide
WARNING
• To reduce the risk of death, personal injury or property damage from fire, electric shock, falling parts, cuts/
abrasions, and other hazards, be sure to read all warnings and instructions included with and on the fixture
box and all fixture labels.
• WARNING - Risk of fire or electric shock. LED Retrofit Kit installation requires knowledge of luminaires
electrical systems. If not qualified, do not attempt installation. Product must be installed in accordance with
the National Electrical Code or your local electrical code. Contact a qualified electrician.
• WARNING - Risk of fire or electric shock. Install this kit only in the luminaires that have the construction
features and dimensions shown in the photographs and/or drawings and where the input rating of the retrofit
kit does not exceed the input rating of the luminaire.
• WARNING - To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other
sharp objects.
• WARNING – Risk of fire or electric shock. Luminaire wiring and electrical parts may be damaged when
installing retrofit kit hardware. Check for enclosed wiring and components.
• Only those open holes indicated in the photographs and/or drawings may be made or altered as a result of
kit installation. Do not leave any other open holes in an enclosure of wiring or electrical components.
• Do not make or alter any open holes in an enclosure of wiring or electrical components during kit installation.
• Turn off the electrical power at fuse or circuit breaker box before any installation work.
• Turn off the power when you perform any maintenance.
• Ensure that all electrical and grounded connections are in accordance with the National Electrical Code or
your local code requirements.
• SUITABLE FOR DAMP LOCATIONS.
• Lamps must be operated within an ambient fixture temperature of -4F (-20c) and 104F (40c) to comply with
all safety and warranty regulations.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this
device may not cause harmful interference, and 2) this device must accept any interference received, including
interference that may cause undesired operation.
Safety Information
Product Specifications
Part
Number
Housing
Designation
LED Model Number Rated Input
Voltage
(VAC)
Rated Input
Frequency
(Hz)
Rated Input
Current
(A)
Rated Input
Wattage
(W)
CCT
(K)
99931 2 x 2 TRK22-W22-L2800-C35
120-277 50/60
0.2 22 3500
99932 TRK22-W22-L2800-C40 4000
99933 2 x 4 TRK24-W36-L4600-C35 0.32 36 3500
99934 TRK24-W36-L4600-C40 4000

Installation Guide
Installation Instructions
Wiring Diagram
1. Make sure power to the existing troffer is switched off.
2. Remove existing door frame (if applicable), lamps, reflector and ballast cover. Depending on clearance space,
ballast may need to be removed.
3. Gently lift the original luminaire housing and slide in both side mounting brackets between the housing and
the T-grid. Lower the housing to rest on the brackets, securing them in place.
4. Secure the brackets to the original luminaire housing using the screws provided.
5. Hang the retrofit kit body onto the two mounting brackets by inserting the hinge screws on the kit housing
into the hole slots on each bracket and slide forward.
6. Attach the safety cables to the original luminaire housing using the screws provided.
7. Connect the retrofit kit power to the AC power and 0-10V dimmer (optional) according to wiring instructions.
If a ground wire is missing from the power supply, attach the retrofit kit’s ground wire directly to the luminaire
housing.
8. Apply “Modification Sticker” on a visible location inside the fixture.
9. Close the retrofit kit by pushing it up and securing both latches.
10. Switch on power to the luminaire.
Product Dimensions
Housing
Designation
Dimension (w/ bracket) Dimension (w/o bracket) Product weight
inch mm inch mm lbs. kg
2 x 2 23.7 x 23.7 x 2.99 602 x 602 x 76 22.56 x 21.73 x 2.99 573 x 552 x 76 6.17 2.8
2 x 4 47.87 x 23.7 x 2.9 1216 x 602 x 76 45.87 x 22.56 x 2.99 1165 x 573 x 76 11.57 5.25

Installation Guide
Warranty
Verbatim 5-year warranty www.verbatimlighting.com/warranty
For support, visit www.verbatimlighting.com/support
Step 2
Step 5
Steps 8 & 9
Step 3
Step 6
Steps 8 & 9
Step 4
Step 7
