WHEELCHAIRS | USER GUIDE
ECL X2-16 ECLIPS
DETACHABLE
WHEELCHAIR
For illustration purposes only

Flip Up Arm Rest
Stationary
Hand Brake
Safety Belt
Solid PU
Wheels
Detachable
Foot Rest
PRODUCT OVERVIEW
ECL X2-16 ECLIPS DETACHABLE WHEELCHAIR
ECL X2-16 Eclips Detachable Wheelchair
•Multi-functionwheelchairwithdetachablefootrestsandarm
rests for easier patient transfer.
•Breathablewovennylonseat
•Lightweightaluminiumframe
Handle
Brake
Foldable
Back Rest
For illustration purposes only

PRODUCT FEATURES
Press on the lever to
release and fold back rest
downwards for both sides
FOLDABLE BACKREST
Pull the lever to release
lock and ip up arm rest
Press button to release lock
and ip up arm rest
DETACHABLE
FOOTREST
FLIP UP ARM REST
Push up to unlock and
down to lock
STATIONARY
HAND BRAKE
CARE INSTRUCTIONS
• When using the Wheelchair, please pay attention to people and/or items around
to avoid collision.
• Lock the wheels before getting in and out of the Wheelchair.
• When getting in and out of the Wheelchair, please do not stand on the footplates.
• The footplates should be folded up / detached beforehand.
• Pay attention to the shift of the Center of Gravity when on elevated grounds.
• When passing through doors or arches, make sure that there is enough room to
avoid causing injuries to the user, or the Wheelchair.
• Do not exceed the maximum safe working load.
DETACHABLE WHEELCHAIR
For illustration purposes only

PRODUCT SPECIFICATIONS
Check our our full range of detachable wheelchair. When making
comparisons, our best suggestion would be for you to think about your
environment and consider how certain task like transferring someone is
done before deciding.
Scan the QR code to nd out more about the product. To scan, use your
camera app or a QR code reader on your device.
Overall Height
Folded Length
Folded Width
Folded Height
Seat Height
Seat Depth
Seat Width
Arm Rest Height (Floor to Arm Rest)
Back Rest Height
Front Wheel Diameter
Back Wheel Diameter
Safe Working Load
Overall Weight
ECL X2-16 ECLIPS DETACHABLE WHEELCHAIR
Overall Length
53.3 cm or 21”
93 cm or 36.5”
80 cm or 31.4”
32 cm or 12.5”
48 cm or 18.8”
42 cm or 16.5”
46 cm or 18”
63 cm or 24.8”
40.6 cm or 16”
15.3 cm or 6”
40.6 cm or 16”
120 kg
14 kg
105 cm or 41.3”
Overall Width (Wheel to Wheel)
75 cm or 29.5”
