TRACER
COVER Tracer_La out 1 21/01/10 08:42 Page 1

E
CONTENTS
Section Page
Contents.............................................................................................................................................1
Preface...............................................................................................................................................2
Technical details ................................................................................................................................2
General notes ....................................................................................................................................3
Applicability........................................................................................................................................3
Contents of the consignment .............................................................................................................3
Explanation of symbols......................................................................................................................3
Operating elements............................................................................................................................4
Adjusting the steering unit..................................................................................................................4
DX2 steering unit ...............................................................................................................................4
Seat and back....................................................................................................................................10
Mechanical adjustment of the back....................................................................................................10
Electric seat recline (option)...............................................................................................................10
Electric back adjustment (option).......................................................................................................11
Leg supports ......................................................................................................................................11
Armrests.............................................................................................................................................12
Battery charger ..................................................................................................................................12
Charging the batteries........................................................................................................................13
Batteries.............................................................................................................................................14
Removal and replacement of the batteries........................................................................................14
Connecting the batteries....................................................................................................................15
Battery storage...................................................................................................................................15
Thermal fuses ....................................................................................................................................15
Parking brakes...................................................................................................................................16
Tyres..................................................................................................................................................16
Changing the tyres.............................................................................................................................16
Pushing the wheelchair......................................................................................................................19
Transporting the wheelchair...............................................................................................................19
Transporting by car............................................................................................................................19
Using ramps.......................................................................................................................................20
Accessories........................................................................................................................................20
•Individual headrest (L55).............................................................................................................20
•Leg supports................................................................................................................................21
•Supporting system for persons (B58)..........................................................................................21
•Torso supports (L04)...................................................................................................................21
For your safety...................................................................................................................................22
Making regular checks.......................................................................................................................22
Care ...................................................................................................................................................23
•Covers.........................................................................................................................................23
•Plastic parts.................................................................................................................................23
•Outer coating...............................................................................................................................23
•Electronics casing........................................................................................................................23
Inspection...........................................................................................................................................24
Disinfection ........................................................................................................................................24
Storage ..............................................................................................................................................26
Guarantee..........................................................................................................................................27
Conformity..........................................................................................................................................27
Disposal .............................................................................................................................................27
Fault analysis.....................................................................................................................................28

E
TRACER
01/2010
2
PREFACE
First of all we want to thank you for putting your trust in us by selecting one of our wheelchairs.
The electric wheelchairs supplied by Vermeiren are the result of reseach and experience over many
years. During development simplicity of operation and servicing were especially emphasised.
But the expected working life of your vehicle depends essentially on your care and maintenance. This
instruction manual will help you to familiarise yourself with the operation of your wheelchair and advise
you about keeping your electric wheelchair in a good operating condition to ensure a long working life.
This instruction manual reflects the latest level of development of the product. However, our firm,
Vermeiren, reserves the right to introduce changes without any obligation to adapt or replace
previously delivered models.
Kindly keep in mind that your wheelchair will be in an excellent working condition and function
perfectly even after many years, if you follow our advice.
For any further questions, please consult your specialist dealer.
TECHNICAL DETAILS
Default (as delivered) settings specified. If different leg supports/head supports/seating systems/batteries or attachments are
used, the relevant specifications (cm / kg / °) will change too.
TRACER
TRACER 50+
Length (without leg supports)
87 cm
87 cm
Length (with leg supports)
119 cm
119 cm
Height (backrest included)
109 cm
109 cm
Width (total)
66 - 72 cm
74 - 82 cm
Seat depth
45 cm
50 cm
Height of seat
55 cm
58 cm
Height of backrest
60 cm
60 cm
Height of armrests (seat cushion)
20 - 24 cm
20 - 24 cm
Height of armrests (floor cushion)
71 - 74 cm
71 - 74 cm
Motors
2 x 200 W CD/Merrits
2 x 300 W (A.M.T)
Weight (batteries included)
+/- 119 kg
+/- 128 kg
Nominal load (max. load)
max. 125 kg
max. 150 kg
Max. speed
10 km/h (for Germany: max. 6 km/h)
Travel range*
Approx. 35 km
Max. climbing ability*
10° (17%) when sitting upright
Max. obstacle height
70 mm Class B (when sitting upright)
Batteries
2 x 12V/70Ah AGM
Battery charger
Impulse S (8 A) external
Control unit
DC (DX2) / electromagnetic brake system
Operating temperature of the electronics
between -20° Celsius and +40° Celsius
Thermal fuses
30 AMP
Use class
B
Operating pressure, steering wheels**
Max. 3.5 bar
Operating pressure, driving wheels**
Max. 2.5 bar
Turning circle
Approx. 140 cm
We reserve the right to introduce technical changes. Measurement tolerance +/- 1.5 cm / ° / kg
* When battery charge, tyre profile and ground are optimal
** Since different tyres may be used, please note the correct operating pressure of the tyres you use.

E
TRACER
01/2010
3
GENERAL NOTES
The TRACER electric wheelchair is designed for outdoor use, but it can also be used indoors because
of its manoeuvrability and compact construction.
No driving license or insurance policy are required to operate the TRACER electric wheelchair. We do,
however suggest that you take out a private insurance policy.
We wish to point out that electromagnetic sources (e.g. mobile phones, etc.) can cause interference
and that the wheelchair's electronics can also affect other electric appliances.
Even if you have been instructed by your specialist dealer about the operational elements of your
electric wheelchair and their use, we recommend that you read the following pages carefully before
you first use it.
APPLICABILITY
The many types of equipment and accessory and the modular construction allow full use by persons
disabled by
•Paralysis
•Loss of limbs (leg amputation)
•Limb defects / deformation
•Stiff or damaged joints
•Diseases like heart problems, poor circulation, disturbance of balance or "Kachexie" as well as for
aged persons.
When considering individual requirements
•body size and weight
•physical and psychological condition
•residential circumstances and
•the environment
should also be taken into consideration.
Guarantees can only be honoured when the product is used under the specified conditions and
for the intended purposes.
CONTENTS OF THE CONSIGNMENT
•The frame structure including the motors, the seat, and the back unit
•Footrests (standard: B06; removable, can be turned aside)
•2 x batteries including the battery boxes
•Battery charger
•Steering electronics
•Tools (Allen keys)
•Instruction manual
EXPLANATION OF THE SYMBOLS
Observe the safety instructions!
Read the instruction manual before use!
Position: Parking brakes activated (electronic driving possible)
Position: Parking brakes deactivated (free running and pushing possible, no electronic driving)
During free running, be careful with slopes and inclinations
Separate recovery and recycling of electric and electronic devices

E
TRACER
01/2010
4
THE OPERATING ELEMENTS
The electric wheelchair is delivered fully assembled. Only the footrests have to be fixed (see the
relevant description). Your dealer delivers the wheelchair fully assembled and explains the various
operating elements and their use. However, for your own safety we provide a further, detailed
explanation of the different parts.
The steering and control unit built into your electric wheelchair enables you to control all the driving,
steering and braking processes of the vehicle. The wheelchair's electrical unit and electronics are
constantly being monitored internally. Any fault in the electronics is indicated on the steering unit and,
if necessary, the wheelchair is switched off for reasons of safety (see the chapter on fault analysis).
Consult your specialist dealer if this happens.
The TRACER model can be fitted with equipment which can electrically adjust the inclination of the
seat and the backrest, as well as the height of the footrests.
ADJUSTING THE STEERING UNIT The steering unit's horizontal position can be changed
by loosening screw (1). The unit can then be adjusted
as desired, or removed. Screw (1) must then be
retightened properly. If screw (1) is pulled to the side,
the steering unit can be turned to the side.
LMake sure that the steering unit's connection cable stays clear of the pincer mechanism.
DX2 STEERING UNIT
The steering and control unit built into your electric wheelchair enables you to control all the vehicle's
driving, steering and braking processes and to control other adjusting motors (options: lifting column
and seat/back adjuster and leg supports). The wheelchair's electrical unit and electronics are
constantly being monitored internally. Any fault in the electronics is indicated on the operating display
(6) and the status display (1) and, if necessary, the wheelchair may be switched off for reasons of
safety (see the chapter on fault analysis).
1 = Display (colour)
2 = "ON / OFF" button
3 = "LEFT INDICATOR" + "LIGHT" button
4 = "RIGHT INDICATOR" + "WARNING INDICATOR" button
5 = "HORN" button
6 = Fault code/operating display
7 = Brightness sensor
8 = "DRIVE PROFILE" button
9 = "SELECT FIELD" button
10 = "SELECT MENU" button
1
2
3
4
5
6
7
8
9
10
1
1

E
TRACER
01/2010
5
The function buttons (8), (9) and (10)
enable functions to be selected that
are displayed in the assigned fields on
the screen.
The status display is constantly visible
in the upper part of the display and
always shows the batteries' charge
level and the current time.
The light, indicator and warning light
displays only appear when the
relevant function is selected. The
system status display appears when
there is a fault or an event, and
displays the relevant event or fault
code (1-12).
Display
Meaning
Battery fully charged
Battery fully charged
Battery half charged
Battery will soon be low, charge
it
Battery is low, charge it soon
Battery is dead, charge now
Start the steering / control unit
Press the ON/OFF button (2) and the operating display (6) will briefly flash on and the
screen will show the drive level (1-5) last used.
Switch off the steering / control unit
Press the ON/OFF button (2) and the system will switch off.
Lock the steering / control unit
If you keep the ON/OFF button (2) pressed for longer than 4 seconds, the steering unit
will be locked.
The lock symbol will briefly appear in the display.
Unlock the steering / control unit
When the ON/OFF button (2) is pressed...
... the lock symbol will appear in the display.
When you press the horn button (5) twice while the lock symbol is showing, the control
unit will be unlocked. The drive level (1-5) last used will appear in the display (1-5).
4 secs.

E
TRACER
01/2010
6
Switch the indicators on/off
To switch the drive direction display on and off, press buttons (3) or (4) for whichever
indicator you wish, left or right. When you activate a drive direction, it will flash in the
status display.
or
Select the light function using the field selection
button (9) and the display will show the light selection
menu.
To switch the flash function (left or right) on or off,
move the joystick in the appropriate direction left or
right.
To switch back to the driving program, select the
drive profile button (8) in drive mode.
Switch the light on/off
To switch the light on and off, keep the button for the left-hand indicator (3) pressed for
longer than 3 seconds. When the light function is switched on its symbol will light up in
the status display.
or
Select the light function using the field selection
button (9) and the display will show the light
selection menu.
Push the joystick upwards to switch the light on or
off.
To switch back to the driving program, select the
drive profile button (8) in drive mode.
Switch the warning light on/off
To switch the warning light on and off, keep the button for the right-hand indicator (4)
pressed for longer than 3 seconds. When the warning light function is switched on its
symbol will light up in the status display.
or
Select the light function using the field selection
button (9) and the display will show the light
selection menu.
Push the joystick downwards to switch the
warning light on or off.
To switch back to the driving program, select the
drive profile button (8) in drive mode.

E
TRACER
01/2010
7
Drive functions
In drive mode use the drive profile button (8) to select a higher or lower driving
program (drive profile 1-5). These drive programs are programmed in the factory
to rise from slow to fast. The drive program you select appears in red text in the
middle of the display.
slower faster
The top speed in any drive program can be changed using the menu selection
button (10) in the drive program selected.
To drive the wheelchair in the direction you wish, move the joystick to the position
you want.
If the loading socket is plugged in, the wheelchair will be locked for drive functions.
If the joystick is moved, the display will also briefly show a red warning bar.
LMake sure that the steering lever is in the neutral (central) position when pressing the on/off
button, otherwise the electronics will be blocked. This block can be lifted by switching the
control unit off and then on again.
LAlways adapt your speed to the prevailing environmental conditions.
Electric adjustments
Select the program function using the field
selection button (9) and the display will show the
menu for the adjust functions.
Select left/right with the joystick or the menu
selection button (10) until the adjust function you
want appears in the centre of the display.
Return
function
To adjust the selected function, move the joystick
in the direction you want up or down.
Start
function

E
TRACER
01/2010
8
To switch back to the driving program, select the
drive profile button (8) in drive mode.
Adjust function
In
Display
Display
Menu
Seat inclination
Angle of backrest
Leg support
left
Leg support
right
Leg supports
simultaneous
The only functions displayed in the menu selection and
the centre of the display are those which exist on your
wheelchair and have been enabled.
LMake sure that no objects and/or persons are
inside the swinging range of the adjust functions,
since this could cause damage and/or injury.
LFor your safety the adjust functions can only be
activated when all four wheels of the wheelchair
are standing still. The driver programs are
disabled while the adjust functions are active.
Set time
Select the program function using the field
selection button (9) and the display will show the
menu for the special functions.
Select left/right with the joystick or the menu
selection button (10) until the time function you
want appears in the centre of the display.
If you want to set the time, confirm by moving the
joystick upwards.
The time digit waiting to be set flashes. To change
other digits, you can select left/right with the
joystick or use the menu selection button (10).
To adjust the digits, select upwards with the
joystick.
To save the new time, confirm by moving the
joystick downwards.
To switch back to the driving program, select the
drive profile button (8) in drive mode.
By default, the factory sets the time to be visible in the status display. To change this option, proceed
as follows:
Select the program function using the field
selection button (9) and the display will show the
menu for the special functions.

E
TRACER
01/2010
9
Select left/right with the joystick or the menu
selection button (10) until the time function you
want appears in the centre of the display.
If you want to change the display option for the
time, confirm by moving the joystick upwards.
The option currently selected will appear in the
menu and the centre of the display. To change
this, select left/right with the joystick or the
left/right menu selection button (10).
To save the option you want, confirm by moving
the joystick upwards.
To switch back to the driving program, select the
drive profile button (8) in drive mode.
Adjust the screen brightness
Select the program function using the field
selection button (9) and the display will show the
menu for the special functions.
Select left/right with the joystick or the menu
selection button (10) until the brightness function
you want appears in the centre of the display.
If you want to change the brightness of the
display, confirm by moving the joystick upwards.
Adjust the brightness of the display by moving the
joystick left/right or selecting the left/right menu
selection button (10).
To save the brightness you have selected, confirm
by moving the joystick upwards or downwards.
To switch back to the driving program, select the
drive profile button (8) in drive mode.
By default, the factory sets the brightness of the display to be automatically adjusted to match the light
conditions. To change this function, proceed as follows:
Select the program function using the field
selection button (9) and the display will show the
menu for the special functions.
Select left/right with the joystick or the menu
selection button (10) until the brightness function
you want appears in the centre of the display.
If you want to change the brightness function,
confirm by moving the joystick upwards.

E
TRACER
01/2010
10
Select left/right with the joystick or the menu
selection button (10) until the brightness function
you want appears in the centre of the display.
If you want to change the brightness function,
confirm by moving the joystick upwards.
Adjust the display's brightness function by moving
the joystick left/right or selecting the left/right
menu selection button (10).
= inwards
= outwards
= automatically (via light sensor (7))
To save the brightness function you have
selected, confirm by moving the joystick upwards.
To switch back to the driving program, select the
drive profile button (8) in drive mode.
If you have special requirements, you can ask your
specialist dealer to enter an individual driving program.
SEAT AND BACK
In the standard version your TRACER has a fixed seat and a fixed backrest which can be adjusted
mechanically. As an optional extra the seat can be inclined electrically and the back can also be
adjusted electrically.
MECHANICAL ADJUSTMENT OF THE BACK
For easier stowing of the electric wheelchair in a vehicle, the back can be folded down forwards or
backwards. Open the lid of the battery box (see the chapter "Removal and replacement of the
batteries"). Above the battery box on the right-hand side are bolts which can be pulled out quickly by
loosening the clasps. You have now separated the connection between the back and the frame. The
backrest can be tilted to the front or to the rear, and removed, after loosening the screw handles on
the lower side of the back unit. (The back can be fixed again by reversing this process).
ELECTRIC SEAT INCLINE (option)
If you chose the electric seat tilting option, your wheelchair will have been fitted with the system before
delivery. To operate this, it is only necessary to switch the steering unit on. The driving program then
switches itself on. If you want to adjust the angle of your seat, you just need to use the function button
for adjusting the seat. The control indicator on the DX control unit shows that you have selected this
Lever screw
Fig. B
Fig. A
knob

E
TRACER
01/2010
11
function (on the G90 control unit, the selected symbol flashes). You can then adjust the slope of the
seat by pushing the joystick forwards or pulling it backwards.
LMake sure that no objects and/or persons are inside the swinging range of the wheelchair,
either in front or at the rear, since this could cause damage and/or injury.
LFor your safety this adjust function can only be activated when all four wheels of the
wheelchair are standing still. When this function is selected, the driving program is disabled.
ELECTRIC BACK ADJUSTMENT (option)
The back can be adjusted in a similar way to the seat angle. You only have to select button the
relevant button on the steering unit and you can then tilt the back as you wish.
LMake sure that no objects and/or persons are inside the swinging range of the wheelchair,
either in front or at the rear, since this could cause damage and/or injury.
LFor your safety this function can only be used when all four wheels of the wheelchair are
standing still. When this function is selected, the driving program is disabled.
LMake sure that you do not set the backrest too far over backwards, since this can displace the
centre of gravity too far to the back and cause tipping over.
LFor your own safety you should not drive the wheelchair in an inclined or tilted position, since it
would severely limit your visibility.
LEG SUPPORTS
The basic model of your electric wheelchair is equipped with leg supports which allow your legs to rest
comfortably. You can adjust the length of the foot supports continuously, turn them aside, or even
remove them completely. These adjustments should be carried out by a third person with the required
technical knowledge. Consult your specialist dealer if these adjustments become necessary. If you
want to carry out these adjustments yourself, you should read the following sections carefully.
When you want to fix the footrests, hang one leg support sideways on the outside and then turn it
inwards until it stops. The fixing lever (Figure B) must point backwards. If the leg supports do not
engage immediately, push them lightly inwards. Do the same on the other side. To remove the
footrests, reverse this process.
LWhen handling the leg supports, make sure that you hold on to the upper curve to prevent
your fingers from getting caught and hurt.
Turn the footplates out of the way for climbing in and out comfortably. The footplates are designed for
resting your feet securely on them; in addition, your feet are prevented from moving sideways
unnecessarily. Use the Allen keys provided to adjust the length of the leg supports. There is a
countersunk Allen screw (Figure A) on the rear side of the leg support for fixing the footplate. By
loosening this screw the footplate can be adjusted to the length of your leg. It must be tightened
properly afterwards.
Fig. A
Fig. B

E
TRACER
01/2010
12
1
2
Frame
LMake sure that the footplate is at least 6 cm above the ground to avoid scraping the ground
when moving. This could damage the wheelchair and endanger its operational safety. The
user might also get hurt.
LDo not stand on the footplates; they are only designed for letting your feet rest on
them.
LWhen the leg supports are adjusted, no persons or parts should be within their reach,
otherwise there is danger of injury and/or damage.
If there are patterns of illness and/or disabilities which mean there is no guarantee that your legs
would rest constantly on the leg supports, you may select from other available leg supports. Kindly ask
your specialist dealer if you have queries in this regard.
ARMRESTS The height of the armrests can be adjusted by
loosening screw (1) and pulling the armrest
upwards.
To adjust the width between the armrests, you only
have to loosen screw (2) and place the armrest in
the desired position. The screw must be tightened
properly afterwards.
LMake sure that all fixing screws are properly
tightened before using the wheelchair,
otherwise injury and/or damage can be
caused.
LNever pick the wheelchair up for transportation by grasping the armrests, but take hold of solid
frame parts only.
The armrest containing the steering electronics can only be detached if the electronics have been
removed previously.
LThe armrests may only be removed when there is no chance of the wheelchair user
falling out sideways.
If changes, damage, or wear of the suspension are noticeable, kindly consult your specialist dealer
who can remedy these defects.
LTo avoid endangering your safety, do not use the wheelchair if you see that the mountings have
changed, been damaged, or have worn out.
LIf you make any changes to the armrests and/or the armrest retainers, you do so entirely at
your own risk. Then your insurance claims lapse immediately.
BATTERY CHARGER
To charge the batteries, only use the battery charger supplied -IMPULSE S (8 A).
Primary voltage
230 Vac –50/60 Hz –single phase
Secondary nominal voltage
24 V
Secondary maximum voltage
35 V
Secondary power
max. 8 A
Battery type
Lead-sulphuric acid: gel
Battery capacity
60 Ah –85 Ah (80% capacity charged within 8 hours)
Safeguards
Protected against reverse polarisation, electrical
surges and extreme temperature
Nominal output
270 W
Efficiency
min. 80% (when fully loaded)

E
TRACER
01/2010
13
Ambient temperature
0° C to +40° C
Unit dimensions
H 70 x W 150 x D 200 mm
Protection range
IP 21, Protection Class II
Total weight
Approx. 1.3 kg
Mains cable length
1.9 m
Charge cable length
2.4 m
Ambient storage temperature
-15° C to +50° C
Relative storage humidity
max. 95% (non-condensing)
Conformity
EMC Directive 89/336/EEC
Low Voltage Directive 73/23/EEC
We reserve the right to introduce technical changes.
CHARGING THE BATTERIES
As the IMPULSE S (8 A) charger aligns the charge curve with the AGM batteries' charge level, you
can recharge your wheelchair after each use. This avoids any aggressive battery charging and the
"memory effect".
Recharge the wheelchair, at the latest, when the charge indicator on the steering unit goes into the red
zone. If, despite this, you continue driving, eventually only the last red diode lights up and flashes
continually, indicating that the batteries are nearly flat. If you disregard this warning signal, too, an
error message will shortly appear indicating that the batteries can no longer provide power for driving.
The batteries should therefore be charged before these error messages appear, using the supplied
battery charger IMPULSE S (8 A). Avoid the batteries becoming drained, in any case.
•SETTING UP THE CHARGER
When setting up the charger, ensure that it is well-ventilated on all sides. A minimum of 10 cm space
should be left free around the unit for this purpose. If the charger is insufficiently ventilated so that the
unit heats up, the charging rate will fall which will extend the charging time. If the charger overheats (>
+50° C), it will stop charging.
The charger should only be used from a wall socket with a voltage of 230V – 50/60Hz and in well-
ventilated, dry areas.
•FIRST USE
First put the plug into the wall socket. After an LED combination has lit up, the charger switches to
STANDBY. Both LEDs (green and yellow) are active.
Next, connect the charger cable with the three-pin plug to the loader socket on the electric
wheelchair's steering unit. Once connected to the batteries, the charger automatically begins charging.
Now only the yellow LED is active.
When charging is complete, the yellow LED goes out and the green LED comes on. Now remove the
charger cable from the steering unit. The charger switches back to STAND-BY mode (yellow and
green LEDs active).
If the charger cable is not removed, a tiny current will keep the batteries topped up (trickle charging).
LWhen charging is complete, always remove the plug from the steering unit first and only then
the mains plug from the wall socket.
•INDICATORS
Yellow LED
Green LED
Charger switched off (not plugged into the mains)
!
!
"
!
Charger has just been switched on and displays the
charging characteristic that has been set
!
"
Stand-by
#
#
Charging
#
!
Full
!
#
Fault
"
"
!= Off#= On "= Flashing

E
TRACER
01/2010
14
If you decide not to use your electric wheelchair for an appreciable period, you must nevertheless
recharge it regularly to keep it in a running condition ready for immediate use.
LIf the batteries are not used for an appreciable period, they discharge slowly by themselves
(drainage). Then it becomes impossible to recharge them with the battery charger supplied.
So charge the batteries at least once a month even if they are not being used.
LOnly use the battery charger supplied to charge the batteries.
LThe manufacturer accepts no liability for damage caused by improper charging.
LNever interrupt the charging cycle. The charger shows when the charging cycle is finished.
(green LED remains active).
For further information, please refer to the user instructions provided with the charger.
BATTERIES
The standard for your electric wheelchair is two closed, 12V/70Ah AGM batteries. The batteries used
with your electric wheelchair are drive batteries which only attain full capacity after a few charging and
use cycles.
If the batteries lose their power after long usage, or if they are damaged, get them both replaced by a
specialist dealer only.
LWe accept no liability for damage caused through using other types of battery.
LDo not use the batteries at temperatures below +5°C or above +50°C (the ideal is: +20°C).
LIf the batteries are opened, all manufacturer liability and all claims will become void.
REMOVAL AND REPLACEMENT OF THE BATTERIES
Kindly obey the following instructions when removing the batteries for servicing or for transportation:
Pull up the knobs (1) and pull the battery drawer
backwards. Now you can grasp the first battery by its
handle and pull it backwards on the rail. Then you can
lift the first battery out of the wheelchair by means of
the handgrip on the battery box. To remove the
second battery box, push your hand beneath the
battery box. There is a hollow which allows you to
take hold of the battery box from below and pull it
backwards with a slight upwards motion.
Now this battery box can also be lifted out of the wheelchair by grasping the handle. When replacing
the battery boxes, you reverse the process and only need to push the battery boxes backwards.
LTo avoid bruising, make sure that your hands are not caught between the handle and the
frame tube when battery boxes are pulled out.
LMake sure that the batteries are safely put down outside the wheelchair.
LWhen replacing the batteries, make sure that they are positioned correctly and that the plugs
on the battery boxes are on the left side.
LBoth connectors of the battery boxes, one at the front and the other at the rear, must be
plugged in first, otherwise there is no connection to the electronics.
LMake sure that the plugs are connected properly after replacing the battery boxes. If the rear
cover does not fit over the knobs (1), it means that the plugs have not connected properly.
When transporting the wheelchair, it is not necessary to remove the batteries from their boxes. When
removal of the batteries becomes necessary (e.g. replacing the batteries), note the following:
•Remove the battery box lid by loosening the screws on the handle.
•Lift the lid off.
1
1

E
TRACER
01/2010
15
•Put the handle back on the battery to allow it to be carried.
•On one side the battery box is connected to the battery by an Allen screw. Unscrew this and
remove it.
•The battery can be lifted out of the battery box by the handle after the pole clamps have been
removed.
•Reverse these processes when replacing the batteries.
LThese tasks should be undertaken by the specialist dealer.
LMake sure that no tools or other conducting objects make contact with both poles of the
batteries, or the resulting electric currents can cause injuries.
LNo work involving the batteries and the electronics should be undertaken in damp conditions.
LWhen connecting the batteries, you should consult the circuit diagram on the battery box lid.
LThe manufacturer is not liable for damage/injury caused by improper handling.
BATTERY CONNECTIONS
BATTERY STORAGE
If you do not use your wheelchair for a long while, you can leave it connected to the battery charger.
Charging is automatically controlled by the battery charger. If you remove and store the batteries,
kindly note the following:
•Remove the cable clamps from the poles of the battery.
•The positive pole must be covered by at least one pole cap.
•Only grasp the batteries by two opposite sides of the unit.
•Ensure no objects get in between the poles (a short-circuit could occur!).
•Batteries should only be stored in dry, well-ventilated spaces at a temperature between +5°C and
+45°C.
•Leave batteries in their battery boxes so they are protected from damp, etc.
•Protect the plugs and sockets of the battery boxes against corrosion.
•Protect the batteries against drainage (see "Charging the batteries" section).
LIf batteries are not used, they can completely drain.
Your dealer will be happy to advise you on storage and with inspecting your batteries.
THERMAL FUSES
To protect the motor against overload, on the right side of the seat frame there is a thermal fuse that
will automatically cut off the motor to prevent overheating and thus rapid wear and tear or
breakdowns. This can occur if you go up or down slopes that exceed the maximum gradient indicated.
Nominal loads exceeding the maximum could also trigger the safety mechanism. If you try to drive
with the brakes on, it could also result in overload. The values to comply with are indicated in the
“Technical Details” section. To be able to use the wheelchair again, remove the overload and wait till
the motor has cooled off, and then gently press in the thermal fuse again. The system is now ready for
use again.
Battery I
-+
24 V
- +
!
!
!
!
+ -
Black
Red
Brow
n
- +
Battery II
+ -
!
!
Brow
n
Red
OUTPUT

E
TRACER
01/2010
16
PARKING BRAKES
In addition to electromagnetic braking, your electric wheelchair can also be equipped with fixed
braking for each driving wheel. These must then be set for the wheels. When pneumatic tyres are
used, the parking brake can only function when the tyres are inflated hard enough (see the section
"Technical details").
LNote that the tyre pressure should always correspond to the values given in the section "Technical
details", otherwise the action of the parking brakes would be reduced or even be zero.
LNote that the parking brakes are not supposed to be used for braking while driving. The real
function of the parking brakes is to prevent the wheelchair from rolling away after it has
stopped. If it is used for reducing the speed while driving, injury and/or damage could result.
If the brakes lose their function through wear and tear and/or the covers and hoses have been
damaged, we advise you to consult your specialist dealer who has the tools and the knowledge for
repairing / replacing the defective parts.
LWhen unsuitable tools are used or through improper maintenance
damage and/or loss of function could result.
If you wish to adjust the parking brakes yourself, use a suitable Allen key to loosen the two screws
which hold the brake suspension on the rail. Then push the brake unit to the desired position and
retighten the two Allen screws and check whether the braking action is correct.
LBrake adjustments not complying with the manufacturer's instructions are done at your own
risk (only in the case of built-in parking brakes). No liability is applicable.
LRather let your dealer adjust the parking brakes; he is trained on our products and will comply
with all relevant prescribed safety measures.
LNote that the parking brakes are not supposed to be used for braking while driving. The real
function of the parking brakes is to prevent the wheelchair from rolling away after it has
stopped. If it is used for reducing the driving speed, injuries could follow.
If you are not satisfied with the braking behaviour of your wheelchair, consult your specialist dealer
immediately; he will then adjust the brakes properly.
LIf water, oil, or other kinds of dirt have soiled the wheels of the wheelchair, then the braking
action of the parking brakes would be impaired. Check the condition of the wheels every time
before using the wheelchair.
LIf the brakes lose their effectiveness because of wear and tear and/or damage to the
tyres/inner tubes, kindly consult your specialist dealer, since special machines are required for
changing the "PU" tyres. The end-user is not able to change the "PU" tyres.
TYRES
The TRACER electric wheelchair is fitted with 3.00-8 driving wheels (standard pneumatic) and 260x85
steering wheels (standard pneumatic). Consult your specialist dealer about other wheel combinations.
He will advise you as to which combinations are suitable for your individual requirements.
LMake sure that the wheels are always inflated correctly, otherwise the driving behaviour might
be affected. The correct pressures for the tyres are given in the chapter "Technical details". In
addition, you should always check the pressure values appearing on the tyres themselves.
LWe do not provide any guarantee for wheels not supplied by the manufacturer.
TYRE CHANGING
If you want to change the tyres or inner tubes, you should note the following:
Before you can remove a tyre, you must let all the air out of the tube, and insert a tyre lever between
the tyre and the rim. Then slowly and carefully push the lever downwards. This will pull the tyre over
the edge of the rim. If you then move the lever along the rim, the tyre will jump out. Now carefully
remove the tyre from the rim and then remove the tube.
LThere must be no air in the tube before it can be removed.

E
TRACER
01/2010
17
LIf handled improperly, the rim might be damaged. We recommend you get your dealer to do
this work.
Note the following before inserting the new inner tube:
Check the rim bed and the inside wall of the tyre for foreign matter and clean these properly if
necessary. Check the condition of the rim bed, especially around the position of the air valve. Please
use only genuine original replacement parts. No liability is accepted for damage caused by non-
genuine replacement parts. Kindly contact your specialist dealer.
WHEN PLASTIC RIMS ARE USED
Place the rim belt in position over the air valve before
inserting it into the rim. Then the rim belt can be pulled
over easily. Check whether all spoke heads are
covered (in the case of a plastic rim a rim belt is not
required).
Push the tyre over the edge of the rim, starting behind
the air valve. Inflate the tube slightly until it is round,
and place it inside the tyre.
If the inner tube fits snugly inside the tyre without any
folds (if there are folds, let some air out), then you can
push the upper side of the tyre gently onto the rim with
both hands, beginning behind the airvalve.
Check all around on both sides that the tube is not pinched between the rim and the edge of the tyre.
Lightly push the air valve inwards and pull it out again to make sure that the tyre is positioned properly
in the region of the air valve.
To ensure that the wheel is inflated correctly, admit only so much air initially that the tyre can still be
easily pushed inwards by using your thumbs. If the check-lines are equidistant from the edge of the
rim on both sides of the tyre, then the tyre is centered properly. If not - let out the air and position the
tyre afresh.
Now the tyre can be inflated to its full operating pressure (note the maximum) and the valve cap
should be replaced.

E
TRACER
01/2010
18
WHEN ALUMINIUM RIMS ARE USED
STEERING WHEELS A. Loosen the screw on the steering wheel axle and
remove it from the steering wheel fork.
B. Let the air out of the steering wheel by lightly pressing
the pressure pin on the valve.
C. Loosen the 5 screws that hold the split rim together.
Now separate the rim sides.
ASSEMBLY
Insert the partly-filled inner tube into the tyre.
C. Connect the two sides of the rim through the tyres and
use the 5 connecting screws to screw the rim
together.
B. Make sure that the valve juts out of the valve opening
in the rim.
A. Put the wheel back into the front wheel fork and inflate
the wheel.
LBefore taking the rim apart always let the air out of the tyres, or the sides of the rim could
come apart explosively and cause injury!
LMake sure that the inner tube does not get caught in the sides of the rim
LOnly inflate the wheels to the max. tyre pressure (see "Technical details")
LCheck to see that all the screws on the wheels are firmly tightened before using the
wheelchair.
DRIVE WHEELS A. Unscrew and remove the axle nut on the drive wheel
and the 4 screws that attach the wheel to the flange.
B. Let the air out of the wheel by lightly pressing the
pressure pin on the valve.
C. Unscrew the 5 screws on the inside of the rim.
Separate the rim sides.
ASSEMBLY
Insert the partly-filled inner tube into the tyre.
C. Connect the two sides of the rim through the tyres and
screw them back again.
B. Put the valve through the hole for it in the rim.
A. Put the wheel back on the flange and secure the
wheel by hand-tightening the axle nut. Inflate the
wheel to the recommended tyre pressure.
LBefore disassembling the rims, always let the air out of the tyres !
LWhen assembling, make sure that the inner tube does not get caught between the sides of the
rim.
LOnly inflate the wheels to the max. tyre pressure (see "Technical details")
LCheck to see that all the screws on the wheels are firmly tightened before using the
wheelchair.
LScrew adhesive (e.g. Loctite) should be applied to the screws on the flange. Screw adhesive
will only work if the thread is free of grease and particles.
LImproper assembly voids any warranty claim.
A
B
C
A
B
C
