GAS GRILLS,
SMOKERS &
ACCESSORIES
GB002_1000-9723_2007_BBQ_Grill v3.qx :114621 CFM-Brochure 3/15/07 1:36 PM Page 1

BRING OUT THE BEST
IN FOODS with the
VERMONT CASTINGS SIGNATURE
FLAVOR PROCESS.
From the special porcelain-coated heavy cast iron grates for even heat distribution and
extraordinarily easy clean up, to the cast iron hood-ends that retain heat for moist,
perfect cooking every time, your Vermont Castings Signature Series Gas Grill is
FOR SUPERIOR TASTE, VERMONT CASTINGS CAST IRON MAKES ALL THE DIFFERENCE.
an efficient miracle of outdoor cooking. And best yet, the Vermont Castings
Signature Flavor Process makes your grilling perfect every time. By retaining the
heat inside our extra-deep fire box, our unique Sear Plates and our heavy Cast Iron
The EXTRA DEEP FIRE BOX
contributes to heat retention and
creates a convection-style cooking
so food stays amazingly moist.
Our double-walled lid panels and CAST
IRON HOOD END CAPS help retain
the heat for more efficient cooking and
superior flavor retention.
Stainless Steel SIGNATURE SEAR
PLATES are bigger, and optimally
designed for heat distribution across
the entire cooking surface.
HEAVY CAST IRON PORCELAIN-
COATED COOKING GRATES retain
heat for even cooking, and won’t
allow foods to stick.
Unique POP-UP LIGHT@NIGHT
helps you see what you’re cooking
in low or no-light situations. Convenient WARMING DRAWER
keeps breads and buns
warm and toasty!
“SOFTTOUCH” BACK-LIT DIALS
makes cooking at night easier than
ever with a bright orange glow to tell
you what temperature has been set.
NEVERFAIL ELECTRONIC
IGNITION works every time, with
a single push of the button!
.
cooking surfaces, you can actually lower the temperature of the grill, cook much
more efficiently, and maintain the moisture in all your foods. The result is perfect
grilling every time, from meats and chicken to vegetables, fish and much more
GB002_1000-9723_2007_BBQ_Grill v3.qx :114621 CFM-Brochure 3/15/07 1:37 PM Page 2

SIGNATURE SERIES |5-BUR NER GRI LLS
Signature Series | 5-Burner Grills Signature Series | 4-Burner Grills
SIGNATURE SE RIES |4-BUR NER GRI LLS
A beautiful, polished stainless steel lid marks this
5 burner grill as one of the most distinguished around.
Delivering superior flavor, outstanding heat retention,
and remarkable efficiency, no other grill can match
our cooking system. 600 square inches of primary
cooking area and 230 square inches of secondary
cooking space can accommodate a full three-course
meal and more. Double condiment trays, a 20,000
BTU Infra-Red Rotisserie Cooking System, “SoftTouch”
back-lit dials and more, it’s all here and ready to grill.
Add our heavy duty Signature Series Grill Cover, our
“Sizzling Barbeque” Cook Book, and you’ll bring out
the best in any meal.
Available with a Stainless Steel Lid, or Limited Edition
Porcelain Enameled lids in Mica Black, Mica Green or
Deep Bronze.
Cast Iron and Stainless Steel, this 4 burner grill is a
monument to modern grilling. The perfect size for
many different outdoor applications, this grill has 450
square inches of primary cooking area and 170 square
inches of secondary cooking space. 15,000 BTU
Infra-Red Rotisserie Cooking System and our super-
thick cast iron cook grids with rear lip make this the
grill to envy. Includes “SoftTouch” back-lit dials, a
15,000 BTU Side Burner for sauces, potatoes, baked
beans and more…it all adds up to a great grill and a
great value.
Available with a Stainless Steel Lid, or Limited Edition
Porcelain Enameled lids in Mica Black, Mica Green
or Deep Bronze.
BRING
THE B
YOUR
AND
OUT
EST IN
FOOD
YOU.
Model VCS4007 4-Burner
50,000 BTU Stainless Steel Grill
Our ROTISSERIE KIT AND BURNER
allows for slow and even cooking for
roasts and whole chickens, every time.
Convenient WARMING DRAWER
keeps breads and buns
warm and toasty!
Our double-walled lid panels and CAST
IRON HOOD END CAPS help retain
the heat for more efficient cooking and
superior flavor retention.
HEAVY CAST IRON PORCELAIN-
COATED COOKING GRATES retain
heat for even cooking, and won’t
allow foods to stick.
Model VCS5007 5-Burner
62,500 BTU Stainless Steel Grill
GB002_1000-9723_2007_BBQ_Grill v3.qx :114621 CFM-Brochure 3/15/07 1:37 PM Page 4

SIGNATURE SERIES |3-BUR NER GRI LLS
Signature Series | 3-Burner Grills Signature Series | Limited Edition Lids
SIGNATURE SE RIES |LIMIT ED EDIT ION LIDS
When you fit the amazing Signature Flavor Process
Cooking System into a 3-burner grill, you know you have
the best value in grilling around. 400 square inch primary
cooking area and 150 square inches of secondary cooking
space, NeverFail Electronic Ignition, Porcelain-Coated
Cast Iron cooking surface and stylish stainless steel lid
with Signature Cast Iron Hood End Caps, means you get
quality, dependability, and outstanding grilling results in
a grill that fits modest areas.
Comes with flush mounted side shelves, an option to add
a 15,000 BTU side burner, enclosed Stainless Steel Cart
Design, commercial grade castors and much more!
Available with a Stainless Steel lid, or with a Limited Edition
Porcelain Enameled Mica Black lid.
LET THE
BEST TIMES
ROLL.
Model VCS3507 3-Burner
37,500 BTU Stainless Steel Grill
TOP WARMING RACK allows you to
keep food warm and toasty.
Our double-walled lid panels and CAST
IRON HOOD END CAPS help retain the
heat for more efficient cooking and
superior flavor retention.
We proudly present
our Limited Edition
Porcelain Enameled Lids.
Mica Green Porcelain Enamel
Available on 4-Burner Model VCS4027
Available on 5-Burner Model VCS5027
Deep Bronze Porcelain Enamel
Available on 4-Burner Model VCS4037
Available on 5-Burner Model VCS5037
Mica Black Porcelain Enamel
Available on 3-Burner Model VCS3517
Available on 4-Burner Model VCS4017
Available on 5-Burner Model VCS5017
GB002_1000-9723_2007_BBQ_Grill v3.qx :114621 CFM-Brochure 3/15/07 1:37 PM Page 6

SIGNATURE SERIES |5-BUR NER BUI LT-IN G RILLS
Signature Series | 5-Burner Built-In Grills Signature Series | 3-Burner Built-In Grills
SIGNATURE SE RIES |3-BUR NER B UILT-IN GRIL LS
600 square inches of primary cooking area and
230 square inches of secondary cooking space
on this 5 burner model. It also includes a 20,000
BTU Infra-Red Rotisserie Cooking System, our
NeverFail Electronic Ignition, Porcelain-Coated
Cast Iron cooking surface and stainless steel lid
with Signature Cast Iron Hood End Caps.
More compact, but still a giant in built-in efficiency
and beauty. 400 square inch primary and 150 square
inches of secondary cooking area, a convenient
warming rack, a 15,000 BTU Infra-Red Rotisserie
Cooking System, NeverFail Electronic Ignition and
more! A great way to enjoy the luxuries of outdoor
living anytime you want!
Our ROTISSERIE KIT AND BURNER
allows for slow and even infra-red
cooking for delicious roasts and whole
chickens, every time.
Raised GRILL LIP at back of cooking
surface makes flipping easy.
Model VCS5007BI 5-Burner
62,500 BTU Stainless Steel Grill
(island not included)
“SOFTTOUCH” BACK-LIT DIALS
makes cooking at night easier than
ever with a bright orange glow to tell
you what temperature has been set.
Our CROSS FLOW IGNITION
system allows you to ignite once, and
then each burner fires in sequence.
WE’VE B
THE BEST
BUILT
UILT IN
FOR OUR
-INS.
The perfect way to complement your outdoor living,
Vermont Castings Built-in gas grills are every inch
a Vermont Castings Signature Series masterpiece.
Each can be installed into a complete outdoor cooking
center, with options that include built-in side burner
and front door assembly.
Model VCS3507BI 3-Burner
37,500 BTU Stainless Steel Grill
(island not included)
GB002_1000-9723_2007_BBQ_Grill v3.qx :114621 CFM-Brochure 3/15/07 1:38 PM Page 8

SIGNATURE SERIES |SMOKE R
Signature Series | Smoker
CAST IRON wood chip box has a
convenient sliding shelf for easy chip
removal.
FULLY-ADJUSTABLE DAMPERS
allow for precise smoking. ELECTRONIC IGNITION starts quickly every time, whenever you’re
ready.
Signature Series Grill Knife
Long wood handle, with sharp
stainless steel blade and serrated tip.
(VCK6A)
Signature Series Basting Brush
Long wood handle, with angled stainless
steel end. Removable basting heads
(silicone or boar bristle).
(VCBB6A)
Signature Series Grill Tongs
Long wood handle, with specially designed
stainless steel ends for use as a turner
or a tong. 3 settings to adjust to your
hand size.
(VCT6A)
Signature Series Grill Fork
Long wood handle, with 3 prong
stainless steel tines.
(VCF6A)
Signature Series Grill Turner
Long wood handle, with stainless steel
serrated end and convenient
built-in bottle opener.
(VCS6A)
Signature Series Grill Cleaning Brush
Long wood handle, with stainless steel
scraper and brass bristles.
(VCGB6A)
Cast iron griddle plate
Replace one cooking grate with this
griddle and you've got the perfect outdoor
stir-fry surface. Great for pizza, bacon
& eggs in hardly any time at all.
(VCGP1A)
Signature Series 2-Pack Replacement
Basting Brush Heads
Replace the heads on our basting brush
with a new set of boar bristles.
(VCBB6AR)
Signature Series 4-Pack Skewer Set
Elegant wood handle grilling skewers with
flat stainless steel skewer ends so your food
does not spin as you turn.
(VCSK6A)
Signature Series Grill Mitt
Durable Vermont Castings canvas mitt
with comfortable soft cloth lining.
(VCBM6A)
Deluxe Barbeque Cover
Keep your grill protected and clean with
a Deluxe Barbecue Cover to
ward off the exterior elements.
Signature Series Stainless Steel Wipes
A quick and easy way to clean, protect &
restore the luster to your stainless steel grill.
Contains 25 wipes Size 7 x 8 in
(VCSSW6A)
Just imagine what you can create with 1033 square
inches of cooking area and four adjustable oven-style
cooking grids. With 17,500 BTU’s and three
adjustable dampers at your command, you’re really
smoking. Our double-walled door design provides
excellent heat retention, and the cast nameplate
features a full-range heat indicator. You’ll love the
cast-iron wood chip box on its convenient sliding
shelf for easy chip removal. The cast brass burner
with adjustable control and quick-starting electronic
ignition make it easy to use. And the cool-grip locking
front-door handle and wide-stance legs make it sturdy
and practical for every area.
SIGNATURE SE RIES |ACCES SORIE S
Signature Series | Accessories
Model VC3624GS
17,500 BTU Stainless Steel Smoker
Complete your grilling experience with quality
Vermont Castings Signature Series accessories.
GET A FEEL
FOR THE BEST.
Signature Series
Grill Apron
Durable Vermont Castings
canvas apron with two
large pockets. One size
fits all. (VCBA6A)
Signature Series 4 Piece
Tool Set with Case
Includes Signature Series
tongs, turner, fork,
basting brush (boar bristle)
and extra basting head
(silicone). (VCTK6A)
GB002_1000-9723_2007_BBQ_Grill v3.qx :114621 CFM-Brochure 3/15/07 1:38 PM Page 10

© 2006 CFM Corporation - All rights reserved. Vermont Castings™ is a registered
trademark of CFM Corporation.
In the interest of constant product improvements,
we reserve the right to change specifications without notice. Before installation,
please read installation instructions and check all local building codes and gas
regulators.
Your Dealer
Stainless Steel Main Burners 54353
GB002 1000-9723 v3 02/07
Main Burners BTU’s 62,500 50,000 37,500 62,500 37,500
Primary Cooking Area (sq. in.) 600 450 400 600 400
Porcelain Coated Wire Warming Rack (sq. in.) 230 170 150 230 150
Total Cooking Area 830 620 550 830 550
Porcelain Coated Cast Iron Cooking Grates •••••
Signature Sear Plates (Stainless Steel) •••••
NeverFail Electronic Ignition System •••••
Stainless Steel Hood Construction •••••
Mica Black Porcelain Enamel • (VCS5017) • (VCS4017) • (VCS3517)
Mica Green Porcelain Enamel • (VCS5027) • (VCS4027)
Deep Bronze Porcelain Enamel • (VCS5037) • (VCS4037)
Black Iron End Caps •••••
Porcelain Coated Black Base Oven with 4” wide Stainless Steel Lip •••••
Enclosed Cart Design - Powder Coated Side Panels •
Cart - Complete Curved Profile Stainless Steel Front, Sides Double Doors Single Door (optional Double Door Kit) (optional Double Door Kit)
Bent, Stainless Steel Lid Handle with Center Grip •••••
Heavy Duty Commercial Casters •••
Infrared Rear Rotisserie Burner BTU’s 20,000 15,000 20,000 15,000
Rotisserie Kit •• (optional) ••
Stainless Steel Control Panel •••••
“SoftTouch” Back-lit Dials on Console •• •
Light
@
Night Cooking Light ••
Integrated Tool Holders built into Side Shelves •••
Stainless Steel Condiment Trays ••
Stainless Steel Shelving •••
Warming Drawer •
Grease Management- Rear Pull Out •••
Grease Management- Tray ••
15,000 BTU Side Burner with Stainless Steel Cover ••(optional) (optional) (optional)
Towel Bar •
Tank Pull Out Tray •
Propane or Natural Gas •••••
5-BURNER 4-BURNER 3-BURNER 5-BURNER BUILT-IN 3-BURNER BUILT-IN
Note For exact information on dimensions on all 2007 grills, please refer to www.myownbbq.com or www.vermontcastings.com
Limited Edition Porcelain Enameled Grill Lids
& Curved Profile Doors (black back)
Barbeque Cover •• ••
GB002_1000-9723_2007_BBQ_Grill v3.qx :114621 CFM-Brochure 3/15/07 1:38 PM Page 12
