NetSure™ SM-DU+
Supervision Module for Distribution Unit
Plus
Installation and User Manual
Specification Number: 10010507
Model Number: SM-DU+

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
The information contained in this document is subject to change without
notice and may not be suitable for all applications. While every precaution has
been taken to ensure the accuracy and completeness of this document, Vertiv
assumes no responsibility and disclaims all liability for damages resulting from
use of this information or for any errors or omissions. Refer to other local
practices or building codes as applicable for the correct methods, tools, and
materials to be used in performing procedures not specifically described in
this document.
The products covered by this instruction manual are manufactured and/or
sold by Vertiv. This document is the property of Vertiv and contains
confidential and proprietary information owned by Vertiv. Any copying, use or
disclosure of it without the written permission of Vertiv is strictly prohibited.
Names of companies and products are trademarks or registered trademarks of
the respective companies. Any questions regarding usage of trademark
names should be directed to the original manufacturer.
Technical Support Site
If you encounter any installation or operational issues with your product, check the pertinent section of this
manual to see if the issue can be resolved by following outlined procedures.
Visit https://www.vertiv.com/en-us/support/ for additional assistance.

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
iii
TABLE OF CONTENTS
Admonishments Used in this Document......................................................................................................................... iv
Important Safety Instructions ............................................................................................................................................. v
Static Warning ......................................................................................................................................................................... vi
1Introduction ......................................................................................................................................................................... 1
1.1 Overview.................................................................................................................................................................................................................................................................................1
1.2 Technical Specifications .........................................................................................................................................................................................................................................1
2Switch Settings.................................................................................................................................................................. 3
2.1 General ..................................................................................................................................................................................................................................................................................3
3Installation........................................................................................................................................................................... 6
3.1 Mounting...............................................................................................................................................................................................................................................................................6
4Electrical Connections..................................................................................................................................................... 6
4.1 Important Safety Instructions............................................................................................................................................................................................................................6
4.2 Wiring Considerations...............................................................................................................................................................................................................................................6
4.2.1 General.............................................................................................................................................................................................................................................................6
4.2.2 Input Fusing.................................................................................................................................................................................................................................................6
4.3 Frame Grounding Connection...........................................................................................................................................................................................................................7
4.4 Load Shunt Input Connections........................................................................................................................................................................................................................8
4.5 Fuse Alarm (FA) Input Connections ...........................................................................................................................................................................................................8
4.6 Input Power Connections...................................................................................................................................................................................................................................10
4.7 NCU CAN Bus Connections..............................................................................................................................................................................................................................11
5Operation............................................................................................................................................................................13
5.1 Indicators ............................................................................................................................................................................................................................................................................13
5.2 Configuring the NCU SM-DU+ Parameters.......................................................................................................................................................................................14

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
iv
Admonishments Used in this Document
DANGER!
Warns of a hazard the reader will be exposed to that will likely result
in death or serious injury if not avoided. (ANSI, OSHA)
WARNING!
Warns of a potential hazard the reader may be exposed to that could
result in
death or serious injury if not avoided. This admonition is not used for situations that pose a
risk o
nly to equipment, software, data, or service. (ANSI)
CAUTION!
Warns of a potential hazard the reader may be exposed to that could
result in minor or moderate injury if not avoided. (ANSI, OSHA) This admonition is not
used for situations that pose a risk only to equipment, data, or service, even if such use
appears to be permitted in some of the applicable standards. (OSHA)
ALERT!
Alerts the reader to an action that must be avoided in order to protect
equipment, software, data, or service. (ISO)
ALERT!
Alerts the reader to an action that must be performed in order to prevent
equipment damage, software corruption, data lo
ss, or service interruption. (ISO)
FIRE SAFETY!
Informs the reader of fire safety information, reminders, precautions,
or policies, or of the locations of fire
-fighting and fire-safety equipment. (ISO)
SAFETY!
Informs the reader of general safety information, reminders, precautions, or
policies not
related to a particular source of hazard or to fire safety. (ISO, ANSI, OSHA)

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
v
Important Safety Instructions
Safety Admonishments Definitions
Definitions of the safety admonishments used in this document are listed under “Admonishments Used in this Document” on page iv.
General Safety
DANGER! YOU MUST FOLLOW APPROVED SAFETY PROCEDURES.
Performing the following procedures may expose you to hazards. These procedures should be performed by qualified
technicians familiar with the hazards associated with this type of equipment. These hazards may include shock, energy,
and/or burns. To avoid these hazards:
a) The tasks should be performed in the order indicated.
b) Remove watches, rings, and other metal objects.
c) Prior to contacting any uninsulated surface or termination, use a voltmeter to verify that no voltage or the expected
voltage is present. Check for voltage with both AC and DC voltmeters prior to making contact.
d) Wear eye protection.
e) Use certified and well maintained insulated tools. Use double insulated tools appropriately rated for the work to be
performed.
Personal Protective Equipment (PPE)
DANGER! ARC FLASH AND SHOCK HAZARD.
Appropriate PPE and tools required when working on this equipment. An appropriate flash protection boundary analysis
should be done to determine the “hazard/risk” category, and to select proper PPE.
Only authorized and properly trained personnel should be allowed to install, inspect, operate, or maintain the equipment.
Do not work on LIVE parts. If required to work or operate live parts, obtain appropriate Energized Work Permits as required
by the local authority, per NFPA 70E “Standard for Electrical Safety in the Workplace”.
Handling Equipment Containing Static Sensitive Components
ALERT! Installation or removal of equipment containing static sensitive components requires careful handling. Before
handling any equipment containing static sensitive components, read and follow the instructions contained on the Static
Warning Page.

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
vi
Static Warning
This equipment contains static sensitive components. The warnings listed below must be observed to prevent damage to
these components. Disregarding any of these warnings may result in personal injury or damage to the equipment.
1. Strictly adhere to the procedures provided in this document.
2. Before touching any equipment containing static sensitive components, discharge all static electricity from yourself by
wearing a wrist strap grounded through a one megohm resistor. Some wrist straps have a built-in one megohm resistor;
no external resistor is necessary. Read and follow wrist strap manufacturer’s instructions outlining use of a specific wrist
strap.
3. Do not touch traces or components on equipment containing static sensitive components. Handle equipment
containing static sensitive components only by the edges that do not have connector pads.
4. After removing equipment containing static sensitive components, place the equipment only on static dissipative
surfaces such as conductive foam or ESD bag. Do not use ordinary Styrofoam or ordinary plastic.
5. Store and ship equipment containing static sensitive components only in static shielding containers.
6. If necessary to repair equipment containing static sensitive components, wear an appropriately grounded wrist strap,
work on a conductive surface, use a grounded soldering iron, and use grounded test equipment.

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
1
1Introduction
1.1 Overview
This assembly consists of a Vertiv™ NetSure™ SM-DU+ enclosed in a sheet metal housing. This assembly is used in applications
where the NetSure™ SM-DU+ is mounted external to a power system equipped with an NCU controller. The NetSure™ SM-DU+
assembly is used to connect load shunts and fuse alarm signals to the NCU controller. The NetSure™ SM-DU+ assembly provides
twenty-five (25) load shunt monitoring inputs and fourteen (14) fuse alarm monitoring inputs.
The NetSure™ SM-DU+ assembly connects into the NCU CAN bus. Up to eight (8) NetSure™ SM-DU+ assemblies can be connected
to an NCU. Refer to Figure 1.1 for an illustration of the NetSure™ SM-DU+ assembly.
Figure 1.1 NetSure™ SM-DU+ Assembly
1.2 Technical Specifications
See Table 1.1.
Table 1.1 Technical Specifications
Item Description
Operating Voltage Nominal: -48 VDC.
Input Voltage Range: -19 VDC to -60 VDC.
Input Current <2 Amps
Operating
Temperature Range
Normal Operation Temperature Range: -10°C to +65°C.
Non Destructive Range: -40°C to +75°C.
Communication CAN Bus
Input Signals
Fourteen (14) Fuse Alarm (Bus- base of 0 VDC, >10 VDC alarm, <10 VDC normal).
Twenty-Five (25) Load Shunts (25 mV DC to 75 mV DC Shunt)
Dimensions See Figure 1.2.
NetSure™ SM-DU+ Assembly

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
2
Figure 1.2 Dimensions
10.00
4.76
9.43
3.86
Diameter 0.14” (4-places)
2.57
Notes:
1. All dimensions are in inches,
unless otherwise specified.
Front
Bottom
Top
Left Side Right Side

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
3
2Switch Settings
2.1 General
The Vertiv™ NetSure™ SM-DU+ assembly uses two (2) 8-bit switches for parameter settings (SW1 and SW2). Refer to Figure 2.1 for
SW1 and SW2 locations. Refer to Table 2.1 for SW1 and SW2 settings.
Perform the following procedure to make switch setting adjustments.
Procedure
1. Remove the top cover to access the switches.
2. Set SW1 and SW2 per site requirements. Refer to Figure 2.1 for location. See Table 2.1 for setting descriptions. (Set the
addressing switches on each NetSure™ SM-DU+ assembly installed in the system to a unique address per Table 2.1.)

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
4
Figure 2.1 NetSure™ SM-DU+ Assembly Switch Locations
SW1
SW2
on
5678 1234
off
on
5678 1234
off
PowerCANRS485RS485
RS232
SW1SW2
J1
J7
ShuntShunt
J8J6
Fuse
J3
J4J4A
J5
ON
OFF
Green Indicator
8 7 6 5 4 3 2 1 8 7 6 5 4 3 2 1
SM-DU+ Circuit Board
Note that these ports are not used in this application,
refer to below image for customer connections
terminal blocks location. See also Figure 4.2.
Switch SW2
Switch SW1
Note that these terminal
blocks are for customer
connections. See also
Figure 4.2.

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
5
Table 2.1 Vertiv™ NetSure™ SM-DU+ Switch Settings
DIP Switch SW1
Reserved HW/S
W Shunt Voltage Shunt Current Description of Status
1 2 3 4 5 6 7 8
NA
OFF
NA
Shunt parameter is set through DIP switch.
ON Shunt parameter is set through software
(note 1)
.
NA
OFF OFF
NA
Shunt Voltage: 25mV
(note 1)
OFF ON Shunt Voltage: 50mV
ON OFF Shunt Voltage: 60mV
ON ON Shunt Voltage: 75mV
NA
OFF OFF OFF Shunt Current: 500 A
(note 1)
OFF OFF ON Shunt Current: 100 A
OFF ON OFF Shunt Current: 200 A
OFF ON ON Shunt Current: 300 A
ON OFF OFF Shunt Current: 400 A
ON OFF ON Shunt Current: 1000 A
ON ON OFF Shunt Current: 1500 A
ON ON ON Shunt Current: 2000 A
DIP Switch SW2
Reserved Communications Address
Baud
Rate Description of Status
1 2 3 4 5 6 7 8
NA
OFF OFF OFF
NA
Address 1#
(Setting for 1st SM-DU+ in System)
OFF OFF ON Address 2#
(Setting for 2nd SM-DU+ in System)
OFF ON OFF Address 3#
(Setting for 3rd SM-DU+ in System)
OFF ON ON Address 4#
(Setting for 4th SM-DU+ in System)
ON OFF OFF Address 5#
(Setting for 5th SM-DU+ in System)
ON OFF ON Address 6#
(Setting for 6th SM-DU+ in System)
ON ON OFF Address 7#
(Setting for 7th SM-DU+ in System)
ON ON ON Address 8#
(Setting for 8th SM-DU+ in System)
NA
OFF 19200
(note 1)
ON 9600
Note 1: Default Setting

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
6
3Installation
3.1 Mounting
The Vertiv™ NetSure™ SM-DU+ assembly provides mounting holes in each corner. Refer to Figure 1.2 for location and dimensions.
4Electrical Connections
4.1 Important Safety Instructions
DANGER! Adhere to the “Important Safety Instructions” starting on page v.
4.2 Wiring Considerations
4.2.1 General
All wiring should follow the current edition of the American National Standards Institute (ANSI) approved National Fire Protection
Association's (NFPA) National Electrical Code (NEC), and applicable local codes. For operation in countries where the NEC is not
recognized, follow applicable codes.
4.2.2 Input Fusing
The ungrounded input lead should be fused at 1-1/3 ampere.

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
7
4.3 Frame Grounding Connection
A frame ground stud (M3) is located on the outside of the Vertiv™ NetSure™ SM-DU+ assembly.
Procedure
1. Connect a frame ground lead to the frame ground stud located on the NetSure™ SM-DU+ assembly. Refer to Figure 4.1 for
location. Recommended torque is 6 in-lbs.
Figure 4.1 NetSure™ SM-DU+ Assembly Frame Grounding Connection
NetSure™ SM-DU+ Assembly Top View
Frame Ground
(Torque to 6 in-lbs.)

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
8
4.4 Load Shunt Input Connections
The Vertiv™ NetSure™ SM-DU+ assembly provides connections for up to twenty-five (25) load shunt inputs.
See also “Switch Settings” on page 3.
Procedure
1. Connect up to twenty-five (25) load shunt inputs to the NetSure™ SM-DU+ assembly. Observe proper polarity. Refer to
Figure 4.2 and the label on the NetSure™ SM-DU+ assembly for connection point identification.
NOTE! The shunt needs to be installed in the hot (-48V) bus. Connect the plus side of the shunt to the positive shunt input
on the NetSure™ SM-DU+ assembly. Connect the negative side of the shunt to the negative shunt input on the NetSure™
SM-DU+ assembly.
4.5 Fuse Alarm (FA) Input Connections
The NetSure™ SM-DU+ assembly provides connections for up to fourteen (14) fuse alarm (FA) inputs.
Procedure
1. Connect up to fourteen (14) fuse alarm (FA) inputs to the NetSure™ SM-DU+ assembly.Refer to Figure 4.2 and the label on
the NetSure™ SM-DU+ assembly for connection point identification.
-When a -48 VDC signal is applied to a fuse alarm input, the associated fuse alarm is inactive.
-When a -48 VDC signal is removed from a fuse alarm input, the associated fuse alarm is active.
It is suggested to use an external fuse alarm Form-C relay contact. Connect the common (COM) terminal of the external fuse
alarm Form-C relay to a -48 VDC source and connect the normally closed (NC) terminal of the external fuse alarm Form-C
relay to one of the NetSure™ SM-DU+ FA inputs, as shown below.
2. Any of the fourteen (14) fuse alarms not being used needs to have their severity set to NA to indicate that this fuse alarm
input is not being used. Refer to the NCU manual for details.
Connect to NetSure™ SM-DU+ FA InputConnect to -48 VDC
External Fuse Alarm
Form-C Relay Contact
NO
COM
NC
X

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
9
Figure 4.2 Vertiv™ NetSure™ SM-DU+ Assembly Shunt and Fuse Alarm (FA) Inputs Connections
Terminal Blocks
Wire Size Capacity: 16-26 AWG.
Recommended Torque: 2.2 in-lbs.
NetSure™ SM-DU+ Assembly Top View
FUSE ALARM
INPUTS
SHUNT
INPUTS
(+Shunt)
(-Shunt)

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
10
4.6 Input Power Connections
Input power must be supplied to each Vertiv™ NetSure™ SM-DU+ assembly installed in the system. A cable is factory provided for
this connection. The ungrounded input lead should be fused at 1-1/3 ampere. Refer to Figure 4.3 for input power connection location.
Procedure
1. Connect the spade lug end of cable P/N 557012 provided to the appropriate terminals located on the NetSure™ SM-DU+
assembly (see Figure 4.3.). Red to a -48V terminal, Black to a RTN terminal.
2. Route this cable to the input power source. Cut this cable to length and terminate it with the supplied spade lugs. Connect
Red to the -48V power source terminal. Connect Black to a RTN power source terminal.
Figure 4.3 NetSure™ SM-DU+ Assembly Input Power Connections
Screw: #6-32 Philslot
Recommended Lug: #6 Spade
Distance between Barriers: 0.30”
Torque: 9.0 in-lbs.
Use cable P/N 557012 to connect -48V and RTN
to the NetSure™ SM-DU+ Assembly.
-48V: Red Wire
RTN: Black Wire
-48V: Red Wire RTN: Black Wire
NetSure™ SM-DU+ Assembly Top View
P/N 557012 Cable Assembly (provided)

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
11
4.7 NCU CAN Bus Connections
Refer to Figure 4.4.
Procedure (Connecting First Vertiv™ NetSure™ SM-DU+ Assembly to NCU)
1. Connect the NetSure™ SM-DU+ assembly into the NCU CAN Bus. Connect CAN_H to CAN_H. Connect CAN_L to CAN_L.
Refer to the system documentation for NCU CAN port description and location. Cable P/N 562868 provided. Refer to Table
4.1 for cable information. Refer to Figure 4.4 for an interconnect diagram.
Table 4.1 CAN Bus Cable P/N 562868
Connector Pin No. Color Signal Symbol
RJ-45
1 W/O CAN_L
2 O CAN_H
4* BL CAN_H
5* W/BL CAN_L
* For use with NetSure 8200 and NetSure 802 retrofit kits.
Procedure (Connecting Multiple NetSure™ SM-DU+ Assemblies Together)
NOTE! The NCU can communicate with up to eight (8) NetSure™ SM-DU+ assemblies. Set each NetSure™ SM-DU+
assembly to a unique address number.
1. To connect multiple NetSure™ SM-DU+ assemblies together, for all assemblies connect the CAN_H terminals together and
connect the CAN_L terminals together (CAN_H to CAN_H, CAN_L to CAN_L). See Figure 4.4 for an interconnect diagram.
2. Connect a termination resistor such as P/N 561768 to the last NetSure™ SM-DU+ assembly in the NCU CAN bus. Connect to
CAN_H and CAN_L terminals along with the CAN_H and CAN_L leads factory connected to the terminal block. See
Figure 4.4.

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
12
Figure 4.4 Vertiv™ NetSure™ SM-DU+ Assembly CAN Bus Connections
To power system’s
CAN L Terminal.
To power system’s
CAN H Terminal.
Screw: #6-32 Philslot
Recommended Lug: #6 Spade
Distance between Barriers: 0.30”
Torque: 9.0 in-lbs.
NetSure™ SM-DU+ Assembly Top View
NetSure™ SM-DU+ Assembly Top View
NetSure™ SM-DU+ Assembly Top View
Remove the termination
resistor from power system
CAN bus terminal block and
place it here (or use P/N
561768 termination resistor).
Cable P/N 562868 provided.
Twisted Wire Pair
CAN_H to CAN_H
CAN_L to CAN_L
Twisted Wire Pair
CAN_H to CAN_H
CAN_L to CAN_L

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
13
5Operation
The Vertiv™ NetSure™ SM-DU+ assembly monitors load shunt inputs and fuse alarm inputs and reports this data to the NCU
controller.
5.1 Indicators
There is one (1) status and alarm indicator located on the NetSure™ SM-DU+ circuit card. The function of this indicator is as shown in
Table 5.1. Refer to Figure 5.1 for location.
Table 5.1 NetSure™ SM-DU+ Circuit Card Indicator
Indicator Normal State Fault State Fault Cause
Operation
(Green) On
Off SM-DU+ is non-operational.
Flashing
A 1/3Hz flashing indicates the SM-DU+ is being
identified by the Controller.
A 1Hz flashing indicates a communication failure.
Figure 5.1 NetSure™ SM-DU+ Circuit Card Indicator Location
Green Indicator

Vertiv™ NetSure™ Supervision Module for Distribution Unit Plus Installation and User Manual
14
5.2 Configuring the NCU SM-DU+ Parameters
Refer to the NCU controller manual (UM1M830BNA) for detailed instructions on how to program the monitored inputs to the SM-DU+
assembly.
