Vestil EDGE-O-DOCK FM User manual

1
Vestil Manufacturing Corporation
2999 North Wayne St., Angola, IN 46703
Ph 260-665-7586 Fax: [phone]
www.vestil.com E-mail: [email protected]
EDGE-O-DOCK • MODEL FM / PP / PE
OWNER'S
MANUAL
Revised 0118
A company dedicated to solving loading dock and
material handling problems since 1955 .
EDGE-O-DOCK
FM / PP / PE SERIES
Loading Dock Solutions
WARNINGS & SAFETY INSTRUCTIONS
Read owner's manual completely before operating unit!
• Read and understand the owner's manual before using
or servicing the leveler.
• The lip plate should be secured outward before any work
is preformed on the leveler.
• Ensure that the safety and warning labels stay in place
and are legible. See the labels page in this manual.
• The Edge-O-Dock leveler must be securely welded and
anchored to the dock face. See the installation
instructions.
• Do not use the leveler if any damage or unusual noise is
observed.
• Always watch the leveler carefully when it is in
operation.
• Be sure nothing is on the top of the leveler before
operating it.
• Do not perform any modifications to the leveler without
the manufacturer's approval. Failure to receive
authorization for changes to the equipment could void
the warranty.
• Maintenance and repairs are to be performed only by
personnel qualified to perform the required work.
• Do not use brake fluid or jack oils in the hydraulic
system. If oil is needed, use an antiwear hydraulic fluid
with an SUS viscosity of 150 - 200 at 100°F, (SAE
viscosity grade 32), or Dexron transmission fluid.
• Use only replacement parts either supplied or approved
by the manufacturer.
Contents
Warnings and Safety Instructions ..................... 1
Receiving Instructions ...................................... 1
Loading Instructions ......................................... 2
Unpacking and Handling Instructions............... 2
Operating Instructions ...................................... 2
Installation Instructions .................................. 3-5
Electrical Schematic ......................................... 6
Power Unit Exploded Parts Drawing ................ 8
Spring Adjusting Instructions (FM Series) ....... 6
PE Hydraulic & Troubleshooting Guide 7
Exploded Parts Drawing (FM Series) .............. 9
Parts List (FM Series) .................................... 10
Exploded Parts Drawing (PP & PE) .............. 11
Parts List ....................................................... 11
Warning Label Identification .......................... 12
Limited Warranty/Service Record .................. 13
RECEIVING INSTRUCTIONS
Every unit is thoroughly tested and inspected
prior to shipment. However, it is possible that the unit
may incur damage during transit. If you see damage
when unloading, make a note of it on the BILL OF
LADING.
Remove all packing and strapping material,
inspect for damage. IF DAMAGE IS EVIDENT, FILE A
CLAIM WITH THE CARRIER IMMEDIATELY! Also,
check the unit size, type of power unit, etc., to see that
the unit is correct for the intended application.
MODEL NUMBER AND CAPACITIES
The model number, serial number and capacities
are inscribed on the nameplate. Please remember to
include these numbers in any correspondence with your
dealer or the factory.

2
Mechanical Operation • Series FM
1.) Remove the lever from right side of bumper box and
insert it into the socket of the back plate (the socket is
on right hand side).
2.) Pull the handle back until the leveler plate is fully
extended and leaning back towards the ramp.
3.) Push the handle forward to allow the lip
plate to extend and fall on the bed of the trailer.
Do not operate without a truck in place as the operator
may lose balance.
4.) Remove the lever and place it in the bumper box.
5.) When loading and unloading is complete, remove
chocks and allow trailer to pull away. The Edge-O-
Dock will return to its original position.
Hand Pump Operation • Series PP
1.) Rotate the valve on the pump clockwise to close the
fluid return valve. Raise the dockleveler with the hand
pump. When the dockleveler clears the trailer bed and
fully extends, open the return valve to allow the lip
to settle on the trailer bed.
Be sure to leave the
fluid return valve open to allow the dockleveler to
float with the trailer.
2.) When loading/unloading is complete, remove the
chocks and allow the trailer to pull away. The
Edge-O-Dock will return to its original position.
Electric Operation • Series PE
1.) Push "RAISE"button on control box. The dockleveler
will begin to rise. When the dockleveler lip reaches
full extension, release the button. It will lower and
settle on the trailer bed.
2.) When loading/unloading is complete, remove the
chocks and allow the trailer to pull away. The
Edge-O-Dock will return to its original position.
Ordering Replacement or Extra Parts
Our company takes pride in using the finest available
parts for our equipment. We are not responsible for equipment
failure resulting from the use of unapproved replacement parts.
To order replacement or extra parts for your equipment contact
Customer Service at the factory. In any correspondence with
the factory please include the Serial Number which is inscribed
on the nameplate of the piece of equipment. Use only the part
numbers provided in this Owner's Manual. Please indicate the
motor phase and voltage that the equipment is operating on.
Fork Truck
Boom
Chain
Self-locking
Clamp
WARNING:
KEEP HANDS AND
FINGERS OUT OF
HINGE AREA!
LOADING INSTRUCTIONS
The load capacity rating as inscribed on the
nameplate of your unit designates its net capacity. This
capacity must never be exceeded, as permanent damage or
personel injury may result.
UNPACKING AND HANDLING INSTRUCTIONS
CAUTION
Read instructions completely before adjusting.
Follow instructions carefully.
Use end wrench, not crescent wrench, as crescent
may slip.
Recommended unpacking and handling is shown
below.
Recommended dock height is 50".
Service range is +5" to -5".
OPERATING INSTRUCTIONS
I.) Back trailer slowly against Edge-O-Dock bumpers.
Turn off the engine and set the emergency brake on
truck. Position wheel chocks (by others) per OSHA
requirements to prevent trailer movement.
II.) Follow the instructions below according to the model
of Edge-O-Dock you have.

3
Recommended dock edge for new construction
The recommended dock edge for new
construction is a well anchored 6 inch
channel (8.2 lb. minimum). Concrete "J"
anchors shall be 1½ inches wide with a
length of 6 inches plus 1½ inches bent at
90 degrees on the end. Minimum material
thickness shall be ¼ inch. One anchor
shall be installed every 12 inches.
48" High Dock
Ramp Plate
96"W x 12"L x 2"H
Ramp Plate
96"W x 24"L x 4"H
6" Channel
INSTALLATION INSTRUCTIONS
(READ ALL INSTRUCTIONS BEFORE PROCEEDING!)
Dock Edge Construction
The procedure for the installation of the Edge-O-Dock dockleveler varies with the dock edge construction and the height
differential. The recommended dock edge for installing an Edge-O-Dock unit is a well anchored six inch channel. With a six inch
channel embedded in to the dock edge, the installer can weld the ramp and bumper blocks securely into position. The ramp and
blocks cannot be welded into position if the dock edge steel is less than six inches. For installations with less than six inches
of steel edging a combination of anchor bolts and welding is required. If the dock has no steel edging, a steel plate must be
anchored to the floor to provide a surface to weld the ramp to in order to maintain the capacity of the leveler. Failure to follow
the proper installation procedure will decrease capacity of dockleveler.
Linkage Installation Instructions
FOR MECHANICAL EDGE-O-DOCK
1.) Remove the cotter pin from the clevis pin.
2.) Remove the clevis pin from the linkage arms.
3.) Move the lip plate down until the hole in the mounting bracket is
aligned with the holes in the link arms.
4.) Insert the clevis pin through the aligned holes and fasten with the
cotter pin.
Height Differential
The optimum dock height in most cases is 50". On dock heights significantly different than 50", ramps and ramp
support angles as shown below must be employed.
LINK
ARMS
CLEVIS
PIN
COTTER PIN
MOUNTING
BRACKET

4
Installation procedure for loading dock
with steel edge 6in. or greater
Installation procedure for loading dock
with steel edge less than 6in.
1. Remove all material and protrusions from the face
of the dock.
2. Center the ramp in the doorway and tack weld at
each end. Be certain the mounting plate does not
extend above the edge of dock.
3. Continuously weld the mounting plate to the steel
dock edge.
4. Weld bumper blocks on each side of ramp. Weld
continuously across tops and down both sides.
1. Remove all material and protrusions from the face of
dock.
2. In installations where cartons or pallets are slid
along the building floor into the truck, the approach
plate must be recessed into a groove in the floor.
3. To install the groove, locate and mark the center of
the dock where ramp is to be mounted. Make a
centered chalk line 1/2 inch longer than ramp plate,
12 inches back from the face of the dock.
4. Using a SKIL ROTO Hammer No. 736, or similar
tool, cut a groove 3/8" deep x 2" wide x ramp
length plus 1/2 inch on the outside of the line. (The
groove will start 10" from the dock face and end
12" from dock face.)
INSTALLATION OF EDGE-O-DOCK • FM SERIES
Continuousweld
1. Remove all material and protrusions from the face of
the dock.
2. Center the ramp in the doorway and tack weld at the
end. Be certain the mounting plate does not extend
above the edge of the dock.
3. Continuously weld the mounting plate to the steel
dock edge.
4. Weld bumper blocks on each side of ramp.
Weld continuously across top and down both sides.
5. Install one lag bolt 3/4" x 5" on the flanges of
each bumper block.
6. Install four 3/4" x 5" lag screws along the bottom
of the mounting plate.
5. Set the beveled, formed (turned down) edge of the
approach plate in the groove. The opposite edge
should be flush with the edge of the dock.
6. Anchor the plate to floor with eight (8) 3/4" x 5" lag
bolts.
7. Center the mounting plate of leveler against the
approach plate anchored to floor. Tack weld the
mounting plate in place.
8. Continuously weld across the top. Chip and grind
as required.
9. Drill holes into the dock the through the holes in the
mounting plate.
10. Install four 3/4" x 5" anchor bolts and tighten.
11. Install bumper blocks on each side of ramp
mounting plate. Weld the top of the bumper blocks
to the ramp plate, and the side of the bumper blocks
to the ramp mounting the plate. Install two anchors
on each side of bumper blocks through the lower
bolt holes in the flange.
12. Weld and round-off (with grinder) the lag bolts on the
ramp plate.
Installation procedure for docks without
steel edges
Continuousweld
Mountingplate
Approach
plate
Steel edge
less than 6in.
high
Steel edge
6in. or greater
Bumper
block
flange
Mountingplate
Mountingplate
Bumper
block
flange
Bumper
block
Bumper
block

5
INSTALLATION OF EDGE-O-DOCK
PE AND PP SERIES
Installation of PP Series
1. Install the PP leveler and bumpers per the preceding instructions.
2. Install the cylinder with the supplied parts (rod end up) at bottom only. Keep the cylinder closed (piston retracted).
3. Mount the hand pump adjacent to the leveler on a post or wall. Drill a hole thru the wall for hydraulic hose.
4. Attach the hydraulic line to the pump, run to the cylinder and loosely attach to the cylinder.
5. Fill the pump reservoir with the oil. Pump oil into line. Continue pumping slowly until air ceases to escape from cylinder.
6. Tighten fitting on cylinder and continue pumping until cylinder extends enough to attach to top bracket. Attach cylinder.
Installation of PE Series
1. Install the PE leveler and bumpers per preceding instructions.
2. Install the cylinder with the supplied parts (rod end up).
3. Remove the shipping plug in the reservoir and install the breather vent.
4. Mount the control box on the inside wall of the building at a convenient height. Drill a hole through the wall for 1/2"
conduit. Run the conduit from the hydraulic pump motor, below the bumper, and up through the hole previously drilled.
5. Follow standard electrical procedures and all applicable codes when installing the control box to the hydraulic unit
(See electrical the schematic on page 6).
6. Check the operation of the leveler. Push the RAISE button and hold it in until the cylinder is fully extended. Release the
button and the leveler should descend to a work position. If the leveler fails to operate, check the electrical connections
to verify proper connections, power source on, and fuses installed and functioning. Operate at least 6 full cycles.
7. Grease all hinge fittings at the time of installation and every 3 months thereafter.
PE Series
ControlBox
HydraulicCylinder
HydraulicHose
Hydraulic Power Unit
(Fill with AW-32 hydraulic oil) GreaseFittings

6
ELECTRICAL CIRCUIT DIAGRAM
BE SURE ALL POWER IS OFF BEFORE ATTEMPTING TO WORK ON THIS EQUIPMENT!
CAUTION: SERVICE WORK SHOULD BE PERFORMED ONLY BY TRAINED & QUALIFIED PERSONNEL
MECHANICAL EDGE-O-DOCK ADJUSTING INSTRUCTIONS
1.) Stand on the ground in front of the leveler. Raise the leveler to the vertical position. Place the forks of your
lift truck under lip to hold lip out at nearly level position. Never work directly under lift truck forks.
2.) To adjust the force that counterbalances the leveler, use the pipe lever
("handle" no,.16 on p. 9) supplied with the dockleveler and a 3/4" open end
wrench or socket. Place the open end of the pipe over the stem on the
spring winding tube. We recommend that one person rotate the winding
tube with the pipe to the desired strength and a second person tighten the
3/4" bolts onto the milled flats (of the interior bar).
3.) When the required lifting torsion is achieved, return to leveler to
normal operating position. Check the adjustments. If the leveler still does
not raise properly, repeat the previous steps to either increase or
decrease spring lifting torsion. If the leveler bounces or floats when the
lip is extended there is too much lifting torsion. Reverse the process
described in step 2 to reduce spring tension.
NOTE:
This is an excellent time to lubricate the grease zerks on the hinges.
A standard grease gun will service these. This must be done regularly (at
least once per month) for ease of operation and maintenance.
1
P
H
A
S
E
3
P
H
A
S
E
Torsion
spring
Locking
bolt
Decrease
Increase
Milled
flats
Interior bar
Mounting
plate
Spring
winding tube
4.) In order for the ramp plate to automatically remain under spring
tension in the vertical position (when the deck plate is raised), it might
be necesary to adjust the position of the cylinder bracket. Install a
3/4in. UNC x 2in. bolt through the opening at the base of the bracket
(see FIGS. 2A & 2B). Wind the bolt through the nut welded onto the
back side of the bracket. As the end of the bolt presses against the
loading dock wall, the bracket position changes. After installing the
bolt, raise the leveler. If the ramp plate still does not snap to a vertical
position, lower the leveler and turn the bolt farther.
FIG. 1
FIG. 2A FIG. 2B
Install bolt
through hole
in cylinder
bracket
Stem

7
MODULAR POWER UNIT OPERATION - PE
Troubleshooting Guide for "PE" Series
2QO\TXDOLILHGLQGLYLGXDOVWUDLQHGWRXQGHUVWDQGPHFKDQLFDOGHYLFHVDQGWKHLUDVVRFLDWHGHOHFWULFDODQGK\GUDXOLFFLUFXLWVVKRXOG
DWWHPSWWURXEOHVKRRWLQJDQGUHSDLURIWKLVHTXLSPHQW
&DUHVKRXOGEHWDNHQWRLGHQWLI\DOOSRWHQWLDOKD]DUGVDQGFRPSO\ZLWKDSSOLFDEOHVDIHW\SURFHGXUHVEHIRUHEHJLQQLQJZRUN
&RQVXOWWKHIDFWRU\IRUSUREOHPVDWWLPHRILQVWDOODWLRQRUIRUDQ\SUREOHPVQRWDGGUHVVHGEHORZ
%HIRUHZRUNLQJRQWKHSRZHUXQLWDOZD\VVHFXUHWKHOLSSODWHRXWZDUGDQGGLVFRQQHFWWKHSRZHUVXSSO\
PROBLEM
/HYHUGRHVQWF\FOHZKHQWKH
5$,6(EXWWRQLVSUHVVHG
POSSIBLE CAUSE
0RWRUGRHVQWUXQ
0RWRUUXQVSURSHUO\EXWWKHGHFNGRHVQW
PRYHRUWKHOLSGRHVQWH[WHQG0RWRUDQG
SXPSQRWQRLV\
/HYHOHUUDLVHVEXWZRQWORZHURUORZHUV
RQO\VORZO\
CORRECTIVE ACTION
8VHDPXOWLPHWHUWRFKHFNIRUSURSHUVXSSO\DOO legs) and
control voltage; for an "open anywhere in the control circuit.
9LVXDOO\FKHFNIRUORRVHZLULQJRUSXVKEXWWRQ components.
 9HULI\WKHPRWRUVKDIWURWDWHV&&:
(QVXUHWKDWWKHUHVHUYRLULVIXOODQGWKDWLWVILOO hole plug has
been replaced by a breather plug.
&KHFNIRULWHPVUHVWLQJRQWKHOHYHOHU
,QVWDOODSUHVVXUHJDXJHWRFKHFNK\GUDXOLF system pressure. If
it doesn't build to 1,500 psi, consult the factory for a
replacement pump.
5HPRYHFKHFNDQGFOHDQWKHSLORWRSHUDWHG check valve.
5HPRYHFKHFNDQGFOHDQWKHSLORWRSHUDWHG check valve and
the flow control valve.
&KHFNIRUDQ\ELQGLQJRIWKHPHFKDQLFDOSDUWV, hinge, etc.
7KHHOHFWULFK\GUDXOLFHGJHRGRFNOHYHOHUXWLOL]HVDQHOHFWULFPRWRUGLUHFWO\FRXSOHGWRDJHDUW\SHK\GUDXOLFSXPSWRSURGXFHWKH
QHHGHGIOXLGSUHVVXUHDQGIORZWRDOORZWKHF\OLQGHUVWRSHUIRUPWKHZRUNRIOLIWLQJWKHGRFNSODWH
$K\GUDXOLFPDQLIROGKRXVHVWKHK\GUDXOLFFRQWUROFRPSRQHQWVDQGLVEROWHGGLUHFWO\RQWRWKHJHDUSXPS
7KHSRZHUXQLWVK\GUDXOLFFRPSRQHQWVDUHDOOUDWHGIRUSVLZRUNLQJSUHVVXUH
,PSRUWDQWSDUWVRISRZHUXQLWLQFOXGHG
 7KHHOHFWULFPRWRU0RWRUVDUHDYDLODEOHIRURSHUDWRQRQVLQJOHRUWKUHHSKDVH$&VXSSOLHVDOODUHGXDOYROWDJHFDSDEOH
 7KHJHDUSXPS,WVVKDIWLVFRXSOHGGLUHFWO\WRWKHVKDIWRIWKHHOHFWULFPRWRU
 7KHFKHFNYDOYH,WVSXUSRVHLVWRSUHYHQWWKHEDFNIORZRIIOXLGWKURXJKWKHSXPS
 7KHSUHVVXUHUHOLHIYDOYH,WVMRELVWRRSHQDSDWKIRUIOXLGWRIORZEDFNWRWKHUHVHUYRLULQWKHHYHQWWKDWWKHIOXLGSUHVVXUHEXLOWXSE\
WKHSXPSH[FHHGVSVL7KXVWKHV\VWHPFDQQRWVHHPRUHWKDQSVL
 7KHSLORWRSHUDWHGFKHFNYDOYH7KLVLVDK\GUDXOLFDOO\RSHUDWHGFDUWULGJHYDOYH,WFORVHVWRDOORZRLOIORZWRWKHF\OLQGHUVZKHQWKH
V\VWHPLVXQGHUSUHVVXUHWKHQRSHQVWRDOORZWKHOHYHOHUVOLSWRIDOOZKHQWKHV\VWHPSUHVVXUHGURSVDIWHUWKHPRWRUWXUQVRII
 7KHSUHVVXUHFRPSHQVDWHGIORZFRQWURO7KLVUHJXODWHVWKHIOXLGIORZIURPWKHF\OLQGHUVEDFNWRWKHUHVHUYRLUZKHQWKH
SLORWRSHUDWHGYDOYHRSHQV,WDOORZVIRUWKHDGMXVWPHQWRIWKHOLSIDOOUDWH
 7KHK\GUDXOLFOLIWF\OLQGHUVV
 7KHK\GUDXOLFIOXLG7KHV\VWHPXVHV+2K\GUDXOLFIOXLG$Q\DQWLZHDUK\GUDXOLFIOXLGZLWKDQ686YLVFRVLW\RIDW
)6$(YLVFRVLW\JUDGHRIVXFKDV$:RU'H[WURQWUDQVPLVVLRQIOXLGDUHDFFHSWDEOH
:KHQWKHOHYHOHULVWREHH[WHQGHGWKHRSHUDWRUSUHVVHVWKH5$,6(SXVKEXWWRQ7KHPRWRUWXUQVDQGLQWXUQLQJLWVSLQVWKH
K\GUDXOLFJHDUSXPS2LOLVGUDZQIURPWKHUHVHUYRLUDQGLQWRWKHSXPS6\VWHPSUHVVXUHEXLOGVDQGFDXVHVWKHSLORWRSHUDWHGFKHFN
YDOYHWRFORVH
2QFHWKHOLSH[WHQGVRXWWKHRSHUDWRUUHOHDVHVWKHSXVKEXWWRQ7KHFKHFNYDOYHSUHYHQWVRLOIURPIURPUHWXUQLQJWRWKH
UHVHUYRLUWKURXJKWKHSXPS:KHQWKHSUHVVXUHLQWKHK\GUDXOLFV\VWHPGURSVVXIILFLHQWO\WKHSLORWRSHUDWHGFKHFNYDOYHRSHQV
WRDOORZWKHRLOLQWKHF\OLQGHUVWRUHWXUQEDFNWRWKHUHVHUYRLUWKURXJKWKHSUHVVXUHFRPSHQDWHGIORZFRQWUROYDOYHZKLFKZLOO
UHJXODWHWKHUDWHDWZKLFKWKHOLSORZHUV
,QWKHHYHQWWKDWWKHOLSZRQWUDLVHLWZLOOEHQHFHVVDU\WRUHPRYHWKHSLORWRSHUDWHGFKHFNYDOYHIRULQVSHFWLRQDQGFOHDQLQJDV
IROORZV
 6HFXUHWKHOLSSODWHLQWKHH[WHQGHGSRVLWLRQWRDOORZDFFHVVWRWKHSRZHUXQLW
 'LVFRQQHFWDQGORFNRXWWKHOHYHOHUVSRZHUVXSSO\
 5HPRYHWKHFDUWULGJHYDOYHIURPWKHFDYLW\PDUNHG32&9
 ,QVSHFWIRUFRQWDPLQDQWVLQWKHYDOYHRUWKHYDOYHFDYLW\
 :DVKWKHYDOYHLQPLQHUDOVSLULWVRUNHURVHQHLISRVVLEOH%ORZRIIWKHYDOYHZLWKDFRPSUHVVHGDLUJXQ
 5HSODFHWKHYDOYHDQGF\FOHWKHOHYHOHUVHYHUDOWLPHV

When I raise the leveler, the
ramp plate (above the hinge)
should be vertical but it isn't
Cylinder mounting bracket is improperly
adjusted
See instruction 4 on p. 6.


8
POWER UNIT ASSEMBLY, PE
ELECTRIC MOTOR, 01-135-032
MANIFOLD RETAINING BOLT, 5/16"-18 x 1-1/4" SHCS
PUMP RETAINING BOLT, 3/8"-16 x 1" SHCS
O-RING, PARKER O-RING ø15-8N7ø
O-RING, 34ø-B47ø
STRAINER, 01-031-005
O-RING ø11-BN7ø
BREATHER, 3/8" NPT
TUBE, 99-031-009
MANIFOLD ASSEMBLY, 99-627-015
PUMP, 01-143-005
FLOW CONTROL, 99-153-022
MANIFOLD, 99-127-015
PILOT TO CLOSE VALVE, 99-153-020
RELIEF, 99-153-006
CHECK VALVE, 99-153-011



































ExplodedPartsDiagramandBillofMaterials



Itemno.

Partno.

Description

Quantity

1

07‐513‐007

07‐513‐006

07‐513‐013

07‐513‐012

07‐513‐075

07‐513‐074
Weldment,assembly,deck
:

FM‐2066
FM‐2072
FM‐2566
FM‐2572
FM‐3066
FM‐3072

1
1
1
1
1
1
2

07
‐
525
‐
004

Assembly,handle

1

3

07
‐
516
‐
008

Assembly,link

arm

1

4

07
‐
612
‐
001

Assembly,pin,springretainer

1

5

07
‐
518
‐
009

Assembly,torsiontube,springtensioner

1

6

07
‐
514
‐
001

Weldment,13”bumperbox

2

7

21
‐
112
‐
003

Pin,
1
/
2
”x1
15
/
16
”retainingclevispin

4

8

07
‐
025
‐
005

Handle,blackrubber,6”

1

9

07
‐
040
‐
003

Lever,springlinkagebar

2

10

07
‐
146
‐
009

Spring

1

11

65078

Extendedprongcotterpin,zincfinish
1
/
8
”x1
1
/
2
”

4

12

2
9
‐
001
‐
001

Specialtymoldedrubberbumper

2

13

1
1
311

Bolt,HHCS,#5plain
5
/
8
”
–

11x2
”

4

14

33016

Flatwasher,lowcarbon,USSzincplated,
5
/
8
”

4


9


10
ITEM NO.
1
2
3
4
5
6
7
8
DESCRIPTION
Control box
Power unit
Handpump
Extension spring
Hydraulic cylinder, 1" dia. x 14"
PP Hose Kit
PE Hose Kit
Cylinder Retaining Bolt
QTY
1
1
1
1
1
1
1
2
PARTS IDENTIFICATION
EDGE-O-DOCK PP AND PE SERIES
PART NO.
PE-CONBOX
PE-MOPU
PP-HDPUMP
EOD-ES
EOD-HC
EOD-PP-HK
EOD-PE-HK
EOD-PP-PE-CYLP
EDGE-O-DOCK PP AND PE SERIES
PE SERIES ONLY
12
45
ENGINEERNO.
PE-CONBOX
PE-MOPU
99-640-003-003
15-146-001
06-021-001
06-623-007
06-623-006
n/a

11
WARNING LABEL IDENTIFICATION
MAKE SURE ALL WARNING LABELS ARE IN PLACE!
1
*Product safety signs or labels should be
periodically inspected and cleaned by the
product users as necessary to maintain good
legibility for safe viewing distance ...
ANSI 535.4 (10.21)
Contact manufacturer for replacement labels.
2
T & S EQUIPMENT CO. ANGOLA, IN
SECURE AND HOLD LIP IN VERTICAL POSITION.
HOLD SQUARE TUBING SECURELY BEFORE
LOOSENING LOCKING BOLTS WITH ANOTHER
WRENCH. ADJUST IN DESIRED DIRECTION,
THEN TIGHTEN LOCKING BOLTS ON FLATS OF
INTERIOR ROUND BAR. CHECK FOR LIFTING
EFFORT AND REPEAT OPERATION IF NEEDED.
LIP AND PLATE SHOULD NOT FLOAT WHEN LIP
IS EXTENDED. DECREASE COUNTERBALANCE
IF NEEDED. GREASE HINGES, OIL LINKAGE, AND
CHECK FOR WEAR MONTHLY.
CONSULT OWNERS MANUAL BEFORE
ADJUSTING
245
CAUTION
!
ASEGURE Y MANTENGA LA CEJA EN POSICION VERTICAL.
MANTENGA EL TUBO CUADRADO DE FORMA SEGURA AN-
TES DE SOLTAR LOS PERNOS CON OTRA LLAVE. AJUSTE
EN LA DIRECCION DESEADA. ENTONCES APRIETE LOS
PERNOS DE SEGURO EN LAS PARTES PLANAS DE LA
BARRA INTERIOR. COMPRUEBE EL ESFUERZO DE
LEVANTAMIENTO Y REPITA LA OPERACION SI ES
NECESARIO. LA CEJA Y LA PLATAFORMA NO DEBEN
FLOTAR CUANDO LA CEJA ESTA EXTENDIDA. REDUZCA EL
CONTRABALANCE SI ES NECESARIO. ENGRASE LAS
BISAGRAS, FUGAS DE ACEITE, Y REVISE POR DESGASTE
MENSUALMENTE.
CONSULTE EL MANUAL DEL PROPIETARIO ANTES
DE AJUSTAR
ASSURER ET MAINTENIR LE REBORD EN POSITION
VERTICALE. BIEN TENIR LE TUBE CARRÉ AVANT DE
DESSERRER LES BOULONS DE VERROUILLAGE AVEC
UNE AUTRE CLÉ. AJUSTER À LA POSITION DÉSIRÉE.
PUIS SERRER LES BOULONS SUR LES SURFACES
PLANES À L’INTÉRIEUR DE LA BARRE. VÉRIFIER
L’EFFORT D’ÉLEVATION ET RÉPÉTER L’OPÉRATION SI
NÉCESSAIRE. LE REBORD ET LA PLAQUE NE
DEVRAIENT PAS FLOTTER LORSQUE LE REBORD EST
ÉTENDU. RÉDUIRE LE CONTRE-POIDS SI NÉCESSAIRE.
GRAISSER LES CHARNIÈRES, HUILER LES JOINTURES
ET VÉRIFIER L’USURE MENSUELLEMENT.
CONSULTER LE MANUEL DU PROPIÉTAIRE
AVANT D’AJUSTER
PRECAUCION
!PRUDENCE !
T & S EQUIPMENT CO. ANGOLA, IN T & S EQUIPMENT CO. ANGOLA, IN
HYDRAULIC OIL OR EQUIVALENT
ACEITE HIDRÁULICO O EQUIVALENTE
HUILE OU ÉQUIVALENT
ISO AW-32
206
POWER SUPPLY: 115 Volt/1 Phase/60 HZ
CONTROL VOLTAGE: 24 VOLT AC
CORRIENTE: 115 Volt/1 Fase/60 HZ
VOLTAJE DE CONTROL: 24 VOLT CA
ALIMENTATION ÉLECTRIQUE: 115 Volt/1 Phase/ 60 HZ
VOLTAGE DE CONTRÔLE: 24 VOLT AC 248
NOTICE NOTA AVIS
3 4
PP & PE SERIES ONLY
LOCATED ON HAND PUMP OR POWER UNIT
PE SERIES ONLY
LOCATED ON POWER UNIT
FM SERIES ONLY
FM SERIES ONLY
FM MODEL SHOWN
1
2
DECREASE COUNTER BALANCE
REDUCIR EL CONTRA BALANCE
DIMINUER LE CONTRE-POIDS
INCREASE CONTER BALANCE
INCREMENTAR EL CONTRA BALANCE
AUGMENTER LE CONTRE-POIDS 244

LIMITEDWARRANTY

VestilManufacturingCorporation(“Vestil”)warrantsthisproducttobefreeofdefectsinmaterialandworkmanshipduringthe
warrantyperiod.Ourwarrantyobligationistoprovideareplacementforadefectiveoriginalpartifthepartiscoveredbythe
warranty,afterwereceiveaproperrequestfromthewarrantee(you)forwarrantyservice.
Whomayrequestservice?
Onlyawarranteemayrequestservice.YouareawarranteeifyoupurchasedtheproductfromVestilorfromanauthorized
distributorANDVestilhasbeenfullypaid.
Whatisan“originalpart”?
Anoriginalpartisapartusedtomaketheproductasshippedtothewarrantee.
Whatisa“properrequest”?
ArequestforwarrantyserviceisproperifVestilreceives:1)aphotocopyoftheCustomerInvoicethatdisplaystheshippingdate;
AND2)awrittenrequestforwarrantyserviceincludingyournameandphonenumber.Sendrequestsbyanyofthefollowing
methods:
Mail FaxEmail
VestilManufacturingCorporation (260)665‐1339 [email protected]
2999NorthWayneStreet,POBox507 Phone
Angola,IN46703  (260)665‐7586
Inthewrittenrequest,listthepartsbelievedtobedefectiveandincludetheaddresswherereplacementsshouldbedelivered.
Whatiscoveredunderthewarranty?
AfterVestilreceivesyourrequestforwarrantyservice,anauthorizedrepresentativewillcontactyoutodeterminewhetheryour
claimiscoveredbythewarranty.Beforeprovidingwarrantyservice,Vestilmayrequireyoutosendtheentireproduct,orjustthe
defectivepartorparts,toitsfacilityinAngola,IN.Thewarrantycoversdefectsinthefollowingoriginaldynamiccomponents:
motors,hydraulicpumps,electroniccontrollers,switchesandcylinders.Italsocoversdefectsinoriginalpartsthatwearunder
normalusageconditions(“wearingparts”),suchasbearings,hoses,wheels,seals,brushes,andbatteries.
Howlongisthewarrantyperiod?
Thewarrantyperiodfororiginaldynamiccomponentsis1year.Forwearingparts,thewarrantyperiodis90days.Thewarranty
periodsbeginonthedatewhenVestilshipstheproducttothewarrantee.Iftheproductwaspurchasedfromanauthorized
distributor,theperiodsbeginwhenthedistributorshipstheproduct.Vestilmay,atitssolediscretion,extendthewarranty
periodsforproductsshippedfromauthorizeddistributorsbyupto30daystoaccountforshippingtime.
Ifadefectivepartiscoveredbythewarranty,whatwillVestildotocorrecttheproblem?
Vestilwillprovideanappropriatereplacementforanycoveredpart.AnauthorizedrepresentativeofVestilwillcontactyouto
discussyourclaim.
Whatisnotcoveredbythewarranty?
1. Labor;
2. Freight;
3. Occurrenceofanyofthefollowing,whichautomaticallyvoidsthewarranty:
Productmisuse;
Negligentoperationorrepair;
Corrosionoruseincorrosiveenvironments;
Inadequateorimpropermaintenance;
Damagesustainedduringshipping;
Collisionsorotherincidentalcontactscausingdamagetotheproduct;
Unauthorizedmodifications:DONOTmodifytheproductINANYWAYwithoutfirstreceivingwrittenauthorizationfrom
Vestil.Modification(s)mightmaketheproductunsafetouseormightcauseexcessiveand/orabnormalwear.
Doanyotherwarrantiesapplytotheproduct?
VestilManufacturingCorp.makesnootherexpresswarranties.Allimpliedwarrantiesaredisclaimedtotheextentallowedbylaw.
AnyimpliedwarrantynotdisclaimedislimitedinscopetothetermsofthisLimitedWarranty.
12
