LM-HP-SERIES LOAD HOOK FORK ATTACHMENTS
INSTRUCTION MANUAL
Receiving instructions:
After delivery, IMMEDIATELY remove the packaging from the product in a manner that preserves the
packaging and maintains the orientation of the product in the packaging; then inspect the product closely to
determine whether it sustained damage during transport. If damage is discovered during the inspection,
immediately record a complete description of the damage on the bill of lading. If the product is
undamaged, discard the packaging.
Notes:
1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where the
product is used is exclusively the responsibility of the owner/end-user.
2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to apply either:
a) Instructions in this manual; or b) information provided on labels affixed to the product.
VESTIL MANUFACTURING CORP.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: [phone] -or- Toll Free [phone]
Fax: [phone]
www.vestilmfg.com
e
-
mail:
[email protected]
Table of Contents:
Signal Words….……………………………………………………………..………………………………………………………….2
Safe Use Recommendations…………………………………………………………….…………………………..…….………… 2
Labeling Diagram………………..……………………………………………………………………………………………..………2
FIG. 1: LM-HP parts diagram, dimensions, and bill of materials …………………………………………………..……………. 3
Installation Instructions…………………………………………………………………………………………………………..…….3
Use Instructions………………………………………………….……………………………………………….……………........... 3
Inspections…………………………………………………………………………………………………………………………..3 - 4
Maintenance……………………………………………………………………………………………………………………..…….. 4
Limited Warranty…...…………………………………………………………………………………………………………..……… 4

Rev. 2/4/2016 LM-HP, MANUAL.doc
Copyright 2014 Vestil Manufacturing Corp. Page 2 of 4
Signal Words:
This manual uses SIGNAL WORDS to indicate the likelihood of personal injuries, as well as the probable seriousness of
those injuries, if the product is misused in the ways described. Other signal words call attention to uses of the product likely
cause property damage.
The signal words used appear below along with the meaning of each word:
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or SERIOUS
INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
Identifies practices likely to result in product/property damage, such as operation that might
damage the product.
Each person who assembles, installs, uses, or maintains this product should read the entire manual in advance and
fully understand the directions. If after reading the manual you do not understand an instruction, ask your
supervisor or employer for clarification, because failure to adhere to the directions in this manual might result in
serious personal injury.
Safe Use Recommendations:
Vestil diligently strives to identify foreseeable hazards associated with the use of its products. However, material
handling is inherently dangerous and no manual can address every conceivable risk. The end-user ultimately is responsible
for exercising sound judgment at all times.
Improper use of this fork attachment could result in serious personal injuries. EVERY PERSON who might
install, use, or perform maintenance on the attachment must understand and apply all of the following recommendations:
 Failure to read and understand the entire manual before installing, using or servicing this fork attachment is a misuse of
the product. Read the manual to refresh your understanding of proper use and maintenance procedures when necessary.
 DO NOT attempt to resolve any problem with the attachment unless: 1) you are authorized to do so; AND 2) you are
certain that it will be safe to use afterwards.
Always inspect the attachment before using it. DO NOT use it unless it is in normal condition. If you observe any damage
to any part of the attachment including the nylon safety strap, tag the unit “Out of Service”. DO NOT use the attachment until
it is restored to normal condition.
This device is designed for material lifting only. DO NOT use the attachment to lift or move people or to drag material.
Any rigging used to lift a load must be properly attached to the hook before lifting the load off the ground. Be certain that
the load is properly balanced and positioned with the center of gravity directly below the hook.
DO NOT leave an elevated load unattended. Lower the forks until the load is fully supported by the ground and disengage
the load from the hook before leaving it unattended.
DO NOT use this attachment to lift and move a load that is unstable when elevated.
DO NOT attempt to lift a load that weighs more than the capacity of the attachment OR the lift truck, whichever is smaller.
The capacity of your attachment appears on tag 023, which is located on the product as shown in the diagram below.
DO NOT elevate any load more than a few inches above the ground. Only (momentarily) increase load elevation if it is
necessary to avoid contact with objects in the path of travel.
DO NOT raise a load over people or allow anyone to stand or reach beneath a suspended load.
DO NOT modify this product in any way. A “modification” is a change that alters the product from original condition, like
bending the hook plate or removing parts. Unauthorized modifications automatically void the limited warranty (see p.
4) and might make the product unsafe to use.
Store the LM-HP in a dry location.
Labeling Diagram:
The unit should always be labeled as shown in the diagram below. Replace a label as soon as it sustains damage or
becomes difficult to read.
Tag 023: Product specifications
[Tag attaches to handle of unit via zip-tie]
Label 218: Proper use
[Label adhered to back side of tag 023]

Rev. 2/4/2016 LM-HP, MANUAL.doc
Copyright 2014 Vestil Manufacturing Corp. Page 3 of 4
FIG. 1: LM-HP parts diagram, dimensions, and bill of materials
Model Hook
type A B C D E F G H J K L
LM-HP4-S Swivel 24in.
61cm
61/2in.
16.5cm
8in.
20.3cm
11/2in.
3.8cm
6 in.
15.2cm
13/4in.
4.4cm
21/4in.
5.7cm
5in.
12.7cm
5in.
12.7cm
3/4in.
1.9cm
131/2in.
34.3cm
LM-HP4-R Rigid 24in.
61cm
61/2in.
16.5cm
8in.
20.3cm
11/2in.
3.8cm
6 in.
15.2cm
13/4in.
4.4cm
21/4in.
5.7cm
5in.
12.7cm
5in.
12.7cm
3/4in.
1.9cm
131/2in.
34.3cm
LM-HP6-S Swivel 24in.
61cm
61/2in.
16.5cm
8in.
20.3cm
11/2in.
3.8cm
6 in.
15.2cm
13/4in.
4.4cm
21/4in.
5.7cm
5in.
12.7cm
5in.
12.7cm
3/4in.
1.9cm
143/4in.
37.5cm
Installation & Use Instructions: This product is a fork attachment. Therefore, the owner should request that the fork
truck manufacturer (or a professional engineer) determine how its use will affect the capacity, operation and maintenance of
the fork truck. Plates, tags, labels, etc. affixed to the truck should be changed accordingly. The truck should also be marked to
identify the attachment and to display the approximate weight of the truck and attachment combination at maximum elevation
with load laterally centered.
To install the LM-HP:
1) Adjust the positions of the forks to align with the fork receivers (see above); then slide the unit onto the forks. Keep the
forks level and position the LM-HP along the lengths of the forks as necessary.
2) Attach the safety strap to the fork carriage of your lift truck. Wrap the safety strap around the fork carriage. Attach the hook
at the free end of the safety strap to the safety strap. The strap must be wrapped around the carriage a sufficient number of
times so that there is no slack in the strap. When properly attached, the strap should prevent the unit from sliding forward
on the forks.
3) Connect the load to the hook via appropriate rigging. The weight of the load must not exceed the capacity of the hook.
[NOTE: The capacity is cast on the surface of the hook and it is displayed on tag 023 (see “Label placement diagram” on p.
2).] Connect the load to the hook in a manner that will minimize load swing when the load is lifted off of the ground.
Swinging loads might cause injuries and/or damage equipment.
Inspections: Inspect the LM-HP as described to ensure that the unit is and remains in normal, safe operating condition.
Before each use (including the first use) inspect:
1. Handle and pry plate: look for regions of significant wear, cracks, deformation and rot.
2. Wheels and mounting hardware: roll the pry bar to confirm that the wheels and bushings are in normal condition.
Examine the axle, machine bushings and cotter pins. The axle should be straight and undamaged. Bushings should
be undamaged and allow the wheels to turn smoothly without contacting the cotter pin. The cotter pin should be
undamaged and securely attached to the axle pin.
FIG. 2: Parts of Lifting hook
Item no. Part no. Description Quantity
1 08-028-034 Fork hook plate 1
2
08-145-001
08-145-002
Lifting hook:
LM-HP4 [2-ton capacity (4,000 lb.)]
LM-HP6 [3-ton capacity (6,000 lb.)]
1
1
3
08-145-003
08-145-004
Shackle:
LM-HP4 [2-ton capacity (4,000 lb.)]
LM-HP6 [3-ton capacity (6,000 lb.)]
1
1
4 08-145-028 Retaining/safety strap with hook 1
E F G
H
A
B C D
K
L
Model Capacity
LM-HP4-S 4,000 lb. (1,818.2kg)
LM-HP4-R 4,000 lb. (1,818.2kg)
LM-HP6-S 6,000 lb. (2,727.3kg)
Fork receiver
Lifting
hook
J
Swivel
Spring
latch
Shackle
pin

Rev. 2/4/2016 LM-HP, MANUAL.doc
Copyright 2014 Vestil Manufacturing Corp. Page 4 of 4
3. Product labels: all labels should be readable and located as shown in the “Label placement diagram” on p. 2. If a
label is unreadable or missing, contact Vestil to order a replacement.
(A) Before each use and AT LEAST once per month, inspect the following:
Hook spring latch: Confirm normal condition and proper operation of the spring latch.
Hook, swivel, & shackle: Check each component for significant wear, looseness, distortion & damage.
Hook plate: Inspect the main body for deformation, cracking, etc.
Safety strap: Closely examine the strap, snap hook, and the hook at the free end of the strap. Look for thinned, frayed,
torn, or significantly worn areas.
Labels: Frequently examine the labels. Confirm that each label is present (see “Label placement diagram” on p. 2),
readable, and in good condition.
(B) Load test: At least once per year, use the LM-HP to lift a full capacity load. Observe the unit from a safe distance. Pay
particular attention to the hook, shackle and swivel (-S models). Hold the load for ~1 minute; then lower it and disconnect it
from the hook. After the load is removed, closely inspect all parts and surfaces of the entire LM-HP for fatigue, cracks or
deformation. If any significant damage is observed, remove the unit from service.
Maintenance:Proper use, maintenance, and storage are essential for this product to function properly.
1: Clean all surfaces of the unit.
2: Inspect the unit. If deformity, cracks, or excessive wear is discovered DO NOT use the product.
3: Perform all necessary adjustments, replacements and/or repairs. ONLY install replacement parts supplied or approved by
the manufacturer.
LIMITED WARRANTY
Vestil Manufacturing Corporation (“Vestil”) warrants this product to be free of defects in material and workmanship during the warranty
period. Our warranty obligation is to provide a replacement for a defective original part if the part is covered by the warranty, after we
receive a proper request from the warrantee (you) for warranty service.
Who may request service? Only a warrantee may request service. You are a warrantee if you purchased the product from Vestil or
from an authorized distributor AND Vestil has been fully paid.
What is an “original part”? An original part is a part used to make the product as shipped to the warrantee.
What is a “proper request”? A request for warranty service is proper if Vestil receives: 1) a photocopy of the Customer Invoice that
displays the shipping date; AND 2) a written request for warranty service including your name and phone number. Send requests by
any of the following methods:
Mail Fax Email
Vestil Manufacturing Corporation [phone] [email protected]
2999 North Wayne Street, PO Box 507 Phone
Angola, IN 46703 [phone]
In the written request, list the parts believed to be defective and include the address where replacements should be delivered.
What is covered under the warranty? After Vestil receives your request for warranty service, an authorized representative will contact
you to determine whether your claim is covered by the warranty. Before providing warranty service, Vestil may require you to send the
entire product, or just the defective part or parts, to its facility in Angola, IN. The warranty covers defects in the following original
dynamic components: motors, hydraulic pumps, electronic controllers, switches and cylinders. It also covers defects in original parts
that wear under normal usage conditions (“wearing parts”): bearings, hoses, wheels, seals, brushes, batteries, and the battery charger.
How long is the warranty period? The warranty period for original dynamic components is 90 days. For wearing parts, the warranty
period is 90 days. The warranty periods begin on the date when Vestil ships the product to the warrantee. If the product was purchased
from an authorized distributor, the periods begin when the distributor ships the product. Vestil may, at its sole discretion, extend the
warranty periods for products shipped from authorized distributors by up to 30 days to account for shipping time.
If a defective part is covered by the warranty, what will Vestil do to correct the problem? Vestil will provide an appropriate
replacement for any covered part. An authorized representative of Vestil will contact you to discuss your claim.
What is not covered by the warranty?
1. Labor;
2. Freight;
3. Occurrence of any of the following, which automatically voids the warranty:
Product misuse;
Negligent operation or repair;
Corrosion or use in corrosive environments;
Inadequate or improper maintenance;
Damage sustained during shipping;
Collisions or incidental contacts causing damage to the product;
Unauthorized modifications: DO NOT modify the product IN
ANY WAY without first receiving written authorization from
Vestil. Modification(s) might make the product unsafe to use or
might cause excessive and/or abnormal wear.
Do any other warranties apply to the product?
Vestil Manufacturing Corp. makes no other express warranties. All implied warranties are disclaimed to the extent allowed by law. Any
implied warranty not disclaimed is limited in scope to the terms of this Limited Warranty.
