Viavi SmartPocket OLP-35V2 User manual

OLP-35V2
OLP-35SC
OLP-38V2
SmartPocket™
Optical Power Meters
Operating manual
BN 2333/98.11
2021.01
English

Please direct all enquiries to your local Viavi sales company.
The addresses can be found at:
www.viavisolutions.com/en-us/contact-sales-expert
The description of additional features of the device can be found at:
www.viavisolutions.com/en-us/products/network-test-and-certification
Copyrights
This product or parts of this product are based on recommendations
and/or standards from the standardization section of the International
Telecommunication Union – ITU-T and/or the European
Telecommunications Standards Institute – ETSI. These recommendations
and standards are subject to the proprietary rights of these
organizations. It is not permitted to copy ITU-T recommendations or
ETSI standards fully or in part and/or to pass them on to third parties
without prior written permission from ITU-T and/or ETSI.
Copyright
© Copyright 2021 Viavi Solutions Inc. All rights reserved.
Viavi and the Viavi logo are trademarks of Viavi Solutions Inc.
All other trademarks and registered trademarks are the property of their
respective owners.
Viavi Solutions Deutschland GmbH
Arbachtalstraße 5, D-72800 Eningen u. A.
Order number: BN 2333/98.11
Issue: 2021.01
Previous issue: -.-
Notes:
Changes may be made to specifications, designations and delivery infor-
mation.

OLP-35V2/-35SC/-38V2 3
CONTENTS
CONTENTS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
OLP-35V2/-35SC/-38V2
Optical Power Meters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operating manual update. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Symbols used in this operating manual . . . . . . . . . . . . . . . . 7
SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Warning symbols on the device. . . . . . . . . . . . . . . . . . . . . . . 9
Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Laser safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Battery operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Unpacking the device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Device overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Switching the device on/off . . . . . . . . . . . . . . . . . . . . . . . . . 17
Display elements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Settings menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Selecting a wavelength . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Selecting an operating mode . . . . . . . . . . . . . . . . . . . . . . . . 21
Selecting a display mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Absolute power level mode . . . . . . . . . . . . . . . . . . . . . . . . . 22
Loss mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Pass/Fail mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Displaying modulated signals. . . . . . . . . . . . . . . . . . . . . . . . 24
Enabling Auto-Lambda mode . . . . . . . . . . . . . . . . . . . . . . . 24
Multi-Lambda mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
MEMORY MANAGEMENT . . . . . . . . . . . . . . . . . . . . . . . . 26
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Storing measurements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Recalling measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Deleting measurements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4 OLP-35V2/-35SC/-38V2
CONTENTS
DATA EXPORT AND FIRMWARE UPDATE . . . . . . . . . . . . . . 28
USB and SmartReporter . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Bluetooth® and MobileTech app /
StrataSync cloud (OLP-3x only) . . . . . . . . . . . . . . . . . . . . . . 28
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Cleaning the test port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Cleaning the instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
OLP-35V2/-35SC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
OLP-38V2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
General specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
ORDERING INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . 33
Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

OLP-35V2/-35SC/-38V2 5
OLP-35V2/-35SC/-38V2 OPTICAL POWER METERS
1 INTRODUCTION
1INTRODUCTION
OLP-35V2/-35SC/-38V2
Optical Power Meters
The handheld Optical Power Meters
• OLP-35V2 (BN 2333/12)
• OLP-35SC (BN 2333/13)
• OLP-38V2 (BN 2333/14)
measure power levels on fiber optical systems.
The Test Sets are specially designed for high performance
testing of all optical signals and systems, i.e. broadband, PONs,
and Gigabit Ethernet.
Battery operation from two AA batteries and the robust, shock-
proof design provide long operating time in the field even under
tough conditions. AC line operation via a separate AC adapter
and the USB interface ensure ease of use in the laboratory or
production environment.
Common features
All OLP-3xV2 power meters can connect to single-mode and
multi-mode fibers with a max. core diameter of 50 µm.
Tests on systems from different manufacturers with different
connector types are easy to handle due to the UPP adapter for
1.25 and 2.5 mm ferrules (OLP-35V2/-38V2 only).
A suitable optical source is required for measuring attenuation.
The Viavi OLS-3x and OLS-3xV2 Optical Light Sources are ideal
for this application.
Both modulated and unmodulated light signals can be
measured. The average power of modulated light signals is
displayed.
Modulated signal mode, which uses different fixed frequencies,
can be used to identify fibers in a fiber bundle, for example.
The “Auto-“ function provided by the OLP-3xV2 Optical Power
Meters allows automatic wavelength detection. This application
requires a wavelength encoding light source, e.g. one of the
Viavi OLS-3x or OLS-3xV2 Optical Light Sources.

6 OLP-35V2/-35SC/-38V2
1 INTRODUCTION
OPERATING MANUAL UPDATE
Differences between the models
All the power meters are calibrated at 850 nm, 980 nm, 1310 nm,
1490 nm, 1550 nm, 1577 nm, 1625 nm and 1650 nm. The
differences between the devices are the diode types and the
maximum permitted power levels:
Operating manual update
If the operating instructions about features provided by your
device are missing, please visit the Viavi web site to check if
additional information is available.
To download the latest operating instructions:
1. Visit the Viavi web site at
www.viavisolutions.com .
2. Search for SmartPocket V2.
3. Open the download area and download the operating
instructions if available.
Model BN... Diode type Adapter Display
range
OLP-35V2 2333/12 InGaAs UPP +10 dBm
OLP-35SC 2333/13 InGaAs fixed SC +10 dBm
OLP-38V2 2333/14 filtered
InGaAs
UPP +26 dBm

OLP-35V2/-35SC/-38V2 7
SYMBOLS USED IN THIS OPERATING MANUAL
1 INTRODUCTION
Symbols used in this operating manual
Various elements are used in this operating manual to draw
attention to special meanings or important points in the text.
Symbols and terms used in warnings
The following warnings, symbols and terms are used in this
document in compliance with the American National Standard
ANSI Z535.6-2011:
NOTICE
Follow the instructions carefully to avoid damage to or
destruction of the instrument.
CAUTION
Follow the instructions carefully to avoid a low or medium risk
of injury to persons.
WARNING
Follow the instructions carefully to avoid potential death or
severe injury to persons.
DANGER
Follow the instructions carefully to avoid death or severe
injury to persons.
High Voltage
Follow the instructions carefully to avoid damage to the
instrument or severe injury to persons.
This safety instruction is given if the danger is due to high
voltage.
Laser
Follow the instructions carefully to avoid damage to the
instrument or severe injury to persons.
This safety instruction is given if the danger is due to laser
radiation. Information specifying the laser class is also given.

8 OLP-35V2/-35SC/-38V2
1 INTRODUCTION
SYMBOLS USED IN THIS OPERATING MANUAL
Warning format
All warnings have the following format:
The following character formats are used in this operating
manual:
WARNING
Type and source of danger
Consequences of ignoring the warning
JAction needed to avoid danger.
IRequirement
This requirement must be met first; e.g.
IThe device is switched on.
J
1.
2.
Instruction
Follow the instructions given (the numbers indicate the order
in which the instructions should be followed); e.g.
JSelect mode.
Italics
Result
Indicates the result of following an instruction; e.g.
The page opens.
Bold
type face
Pages, controls, and display elements
Screen pages, controls, and display elements are indicated in
bold type.
Text in
blue
Cross references
Cross references are indicated in blue type. When using the
PDF version, just click on the blue text to skip to the cross
reference.
[MODE] Device keys
Device keys are indicated within square brackets.

OLP-35V2/-35SC/-38V2 9
WARNING SYMBOLS ON THE DEVICE
2 SAFETY INFORMATION
2SAFETY INFORMATION
Warning symbols on the device
Proper use
This instrument is intended for measurements on optical fiber
devices and systems.
JPlease make sure the instrument is not operated outside the
permitted ambient conditions.
JObserve the specified measurement range.
JAlways make sure that the instrument is in proper working
order before switching it on.
Warning symbols indicating a potential hazard
JA warning symbol on the device indicates a potential hazard.
In all cases where the a warning symbol is shown on the
display or labeled on the device, the operating manual must
be consulted to learn more about the nature of the potential
hazard and any actions that have to be taken.

10 OLP-35V2/-35SC/-38V2
2 SAFETY INFORMATION
LASER SAFETY
Laser safety
Battery operation
WARNING
Dangerous laser radiation
Laser radiation can cause irreparable damage to the eyes
and skin.
The maximum permitted power for the OLP-3xV2 means that
the optical input signals can reach Hazard Level 4, depending
on the device type.
Bear this in mind when using the OLP-3xV2.
JAlways be aware of the hazard level of the device to be
connected.
JConnect all optical fibers before switching on the radiation
source.
JSwitch off the laser source before disconnecting the optical
fibers.
JNever look directly into the output of a laser source or into
an optical fiber connected to it.
JAlways cover unused ports.
JHeed the normal precautions for working with laser radiation
and consider local regulations.
WARNING
Explosion danger
Short-circuiting the batteries can result in overheating,
explosion or ignition of the batteries and their surround-
ings.
JNever short-circuit the battery contacts by touching both
contacts simultaneously with an electrically conductive
object.
JOnly use AA size dry batteries or rechargeable batteries.
JTake care to insert the batteries correctly.
JNever use batteries based on lithium.
